Securitron

The DK-12 standalone keypad is ideal for lower security applications.

All-in-one keypad system for single door traffic control

The DK-12 standalone keypad is ideal for lower security applications such as traffic control. Easy to install and to program, the one-piece DK-12 supports 99 user codes, including Passage mode and Lockout mode. While primarily intended for indoor operation, an optional rain cover (WCC) and gasketed backbox (WBB) allow reliable use for exterior areas not directly exposed to rain or snow.

Product Features

• Stainless steel backplate with 12 illuminated keys (10 digits + "*" and "#" keys)
• One piece digital keypad specifically designed for control of electric locks
• Easy to install with simple hand tools
• Operates on low voltage AC or DC current
• Audible keystroke echo
• Single gang, stainless steel plate with plastic backbox
• 99 user code capability which is programmable from the keypad
• Passage mode and Lockout mode
• 5 Amp SPDT timed, control relay output
• Red and Green LEDs are visible indicators
• Yellow LED provides programming prompt
• True 10 digit operation
• Optional weather cover available
• Request to Exit (REX) input

Environmental

• Maximum Operating Temperature: 140
• Minimum Operating Temperature: -10
• Outdoor Rated: No

Weights & Dimensions

• _Shipping Weight: 1
• _Unit Box Depth [in]: 5.75
• _Unit Box Height [in]: 3.4
• _Unit Box Width [in]: 3.25

Electrical

• Current 12v AC: 325
• Current 12v DC: 100
• Current 24v AC: 325
• Current 24v DC: 100
• Voltage: 12/24

General

• Device Options: Stand Alone Keypad

Documents

Securitron DK-12 Keypads Operating Manual

Securitron DK-12 Keypads Quick Reference Guide

Securitron DK-12 Keypads Sell Sheet

Securitron DK-12 Keypads Catalog Page

Certifications

Securitron Magnalock CE Certificate of Conformity

The DK-26 digital keypad system provides medium/high security control of electric locks in one or two-door applications where doors have the same control needs. The fully weather resistant, rugged stainless steel keypad can be mounted in most outdoor environments. Encased in a separate enclosure for secure installation, the full-featured, easy to program, DK-26 is ideal for narrow stile applications.

Digital control system for narrow stile outdoor applications

The DK-26 digital keypad system provides medium/high security control of electric locks in one or two-door applications where doors have the same control needs. The fully weather resistant, rugged stainless steel keypad can be mounted in most outdoor environments. Encased in a separate enclosure for secure installation, the full-featured, easy to program, DK-26 is ideal for narrow stile applications.

Product Features

• Cast stainless steel with 11 EPDM rubber keys
• Weather resistant and vandal resistant
• 12V or 24V/ AC or DC current
• Mounts on a narrow mullion
• Audible keystroke echo
• True 10 digit operation (keys are not paired)
• 59 users with multiple entry codes
• User code and hard code disable feature
• Passage Mode and Lockout Mode
• 5A DPDT relay
• Request to exit (REX) input
• 16 ft [4.8m], 12 conductor, 22 gauge keypad cable
• 3 LEDs and a bell button

Environmental

• Maximum Operating Temperature: 158
• Minimum Operating Temperature: -22
• Outdoor Rated: Yes

Weights & Dimensions

• _Shipping Weight: 5
• _Unit Box Depth [in]: 8.8
• _Unit Box Height [in]: 12
• _Unit Box Width [in]: 3.3

Electrical

• Current 12v AC: 160
• Current 12v DC: 160
• Current 24v AC: 190
• Current 24v DC: 190
• Voltage: 12/24

General

• Device Options: Keypad System

Documents

Securitron DK-26 Keypads Operating Manual

Securitron DK-16, DK-26 Keypads Quick Reference Guide

Securitron DK-26 Keypads Catalog Page

Certifications

Securitron DK-26 Declaration of Conformity

The DK-37 digital keypad offers Wiegand output for universal compatibility with access control systems.

Digital keypad for narrow stile applications

The DK-37 digital keypad offers Wiegand output for universal compatibility with access control systems. The fully weatherproof stainless steel keypad is designed for narrow stile applications.

Product Features

• 12-key cast stainless steel 2x6 keypad with silicone rubber keys
• Weather resistant and vandal resistant
• Dual voltage 12 or 24 VDC
• Mounts on narrow mullion
• Compatible with access control systems using standard Wiegand or Character output
• Field selectable Wiegand or Character mode output
• Red, green and yellow status LEDs
• Audible keystroke echo
• 16 foot (4.88m) cable included

Environmental

• Maximum Operating Temperature: 158
• Minimum Operating Temperature: -22
• Outdoor Rated: Indoor or Outdoor use

Weights & Dimensions

• Shipping Weight (lbs): 1.75
• Package Depth (in): 5.1
• Package Height (in): 9.7
• Package Width (in): 3.3
• Height (in): 7
• Width (in): 1.5
• Depth (in): 1

Electrical

• Current 12v DC: 35
• Current 24v DC: 75
• Voltage: 12/24

General

• Device Options: Weigand Keypad

Documents

Securitron DKC Digital Keypad Controller Operating Manual

Securitron DK-37 Keypads Operating Manual

Securitron DK-37 Keypads Sell Sheet

Securitron DK-37 Keypads Catalog Page

For double doors without a center mullion, the DM62 supplies two model 62 Magnalocks in a single, brushed stainless steel housing.

Product Features

• Patented instant release circuit - no residual magnetism
• Both locks can be controlled as one or individually
• Surface mounts easily with minimal tools
• Fully sealed electronics - tamper and weather resistant
• Mounted using steel machine screws into blind finishing nuts
• Architectural brushed stainless steel finish (US32D/630)
• All ferrous metal surfaces plated to MIL specification
• 36" of jacketed, stranded conductor cable for each lock
• Automatic dual voltage - no field adjustment required
• Lock options include BondSTAT magnetic bond sensor and integrated door position switch

Environmental

• Maximum Operating Temperature (°F): 140
• Minimum Operating Temperature (°F): -40

Electrical

• Current 12v DC (mA): 250
• Current 24v DC (mA): 150
• Voltage: 12/24

Strength & Durability

• Holding Force (lbs): 1200
• Grade: Grade 2

Weights & Dimensions

• Magnet Depth (in): 2.75
• Magnet Height (in): 3
• Magnet Length (in): 22
• Shipping Weight (lbs): 16

Ratings

• Outdoor Rated: No
• Fire Rated: Yes
• Preload Capable: No





Documents

Securitron DM62 Electromagnetic Locks Catalog Page

Securitron Maglock Mounting Accessories Brochure

Securitron BondSTAT Electromagnetic Locks Brochure

Securitron Integrated DPS Sheet Brochure



"Push to Exit" Pushbutton, for use with XMS Motion Sensor, Narrow Stile, Stainless Steel

Product Features

• Emergency Exit Buttons offer additional safety, as required by code, for possible malfunction of motion exit sensor
• Mounted next to door
• Momentarily pressing the button releases door for 30 seconds
• Retriggerable
• Single Gang or Narrow Stile
• SPDT 3 Amp wet N/C contacts
• Operates on 12 or 24 VDC (must be same voltage as the installed lock)
• For indoor use only
• EEB2 includes switchable green, red and blue ADA lenses
• EEB3N includes switchable green and red lenses
• UL Listed

Models

Note: The red and white wires from the EEB2/3N must receive voltage from the same power supply.

Weather Option: WCC and WBB available for all Single Gang Push Buttons, Keyswitches and Keypads.

Safety Notice: Securitron's UL294 certification indicates that when the EEB is used with the XMS Motion Sensor, it meets the NFPA Life Safety Code 101 requirements for exit of access controlled egress doors.

"Push to Exit" Pushbutton, for use with XMS Motion Sensor, Narrow Stile, Stainless Steel

Product Features

• Emergency Exit Buttons offer additional safety, as required by code, for possible malfunction of motion exit sensor
• Mounted next to door
• Momentarily pressing the button releases door for 30 seconds
• Retriggerable
• Single Gang or Narrow Stile
• SPDT 3 Amp wet N/C contacts
• Operates on 12 or 24 VDC (must be same voltage as the installed lock)
• For indoor use only
• EEB2 includes switchable green, red and blue ADA lenses
• EEB3N includes switchable green and red lenses
• UL Listed

Models

Note: The red and white wires from the EEB2/3N must receive voltage from the same power supply.

Weather Option: WCC and WBB available for all Single Gang Push Buttons, Keyswitches and Keypads.

Safety Notice: Securitron's UL294 certification indicates that when the EEB is used with the XMS Motion Sensor, it meets the NFPA Life Safety Code 101 requirements for exit of access controlled egress doors.

The Flex Mount Bracket System is a set of mounting brackets designed for use with the M62FG-SASM Gate Magnalock® and the GL1 Gate Lock.

Bracket kits extend access control to gates and fences

Post Shim Brackets are used to adapt both small and large Post Brackets to pole/post sizes smaller than 2" or 3" respectively in 1/8" increments - 1-7/8", 1-3/4", 1-5/8" 2-7/8", 2-3/4", 2-5/8", etc. When more than two shims are used together on a single post, welding the bracket to the pole/post is recommended. All necessary mounting hardware including four Post Shims is included with each Flex-Mount Kit.

Product Features

• Permits electronics to be mounted on fence posts or gate posts
• Brackets are reversible
• Bracket kits include brackets, mounting hardware and post shims
• Post brackets are pre-drilled
• Zinc-plated steel provides durability and long life
• Bolt on or weld for installation
• Compatible with maximum 3" [76.2mm] round post with minimum pole separation of 1" [25.4mm]
• Use with post shim brackets for smaller post sizes
• MagnaCare® lifetime replacement, no-fault, no questions asked warranty

Weight & Dimensions

• Shipping Weight (lbs): 13.4
• Max Box Height (in): 10.1
• Max Box Width (in): 3.7
• Max Box Depth (in): 7.2

Application

• Mounting: permits Direct Mount
• Gate Type: Sliding|Swinging
• Works With: M62FG and GL1

Documents

Securitron FMK-SW, FMK-SL Electromechanical Lock Accessories Installation Instructions

Securitron FMK Mounting Bracket Catalog Page

The heavy duty GL1 Electromechanical Gate Lock provides weather-resistant access control for a wide range of gate applications.

Product Features

• 2,000 lbs holding force
• Operates under preload up to 100 lbs
• Automatic dual voltage - no field adjustment required
• Accepts a standard mortise cylinder with Adams Rite MS cam for manual key override (not included, see spacer guide below)
• Self-aligning receiver (+/- 1/2" horizontally) helps compensate for gate misalignment and sag
• Tamper resistant cast housing
• Optional latch status monitor
• Surface mount

Strength & Durability

• Holding Force (lbs): 2000

Weights & Dimensions

• Height (in): 2.75
• Width (in): 7.25
• Depth (in): 3.25
• Shipping Weight (lbs): 6

Environmental

• Maximum Operating Temperature (F): 167
• Minimum Operating Temperature (F): -58
• Weather Resistance: Indoor/Outdoor

Electrical

• Voltage: 12/24 VDC
• Current 12v DC (mA): 870
• Current 24v DC (mA): 720

Documents

Securitron GL1 Gate Locks Operating Manual

Securitron GL1 Gate Locks Quick Start Installation Instructions

Securitron GL1 Gate Lock Sell Sheet

Securitron GL1 Gate Locks Catalog Page

Securitron GL1 Gate Locks Gate & Fence Brochure

Certifications

Securitron GL1 Gate Lock Certificate of Compliance

Integrated Movement Exit Delay with Advanced Technology.

Configurable, 1,200 lbs. holding force, delayed egress Magnetic Lock

iMXDa helps prevent peril to persons/patients and property loss/theft for businesses. Applications include dementia wards, hospitals, dormitories, airports, child care facilities and retail or warehouse environments. Installation requires no alteration or replacement of existing fire-rated or non-fire-rated latching hardware. False triggering is eliminated by up to 1" of authorized door movement.

Product Features

• 1200 lbs. holding force Magnalock
• New shorter 12.5" overall length will fit most any door with a closer installed
• Now with automatic dual voltage - no field adjustment required
• New bracket-mounted design improves strength and installation time
• Microprocessor monitored BondSTAT magnetic bond sensor (MBS) and integrated door position switch (DPS) standard
• Reverse action plunger allows for adjustable alarm initiate gap from 1/8" [3.2mm] to 1" [25mm]
• Bright LEDs indicate unit status from the secure side of the door
• DIP switch selectable options: - Nuisance alarm times - 0 to 3 seconds - Irrevocable delay times - 15 or 30 seconds - user selectable - External bypass delay times - 0, 5, 10 or 15 seconds - Post alarm reminder - user selectable - Bypass expiration alarm - user selectable - Manual relock or delayed automatic relock (BOCA) - user selectable
• External alarm relay isolated dry contact (1 A at 24 VDC)
• External reset
• iEXD version allows alarm initiation via an external panic device
• Indoor use only
• UL Listed

Environmental

• Maximum Operating Temperature (° F): 104
• Minimum Operating Temperature (° F): 32

Electrical

• Current 12v DC (amps): 370
• Current 24v DC (amps): 270
• Voltage: 12/25

Strength & Durability

• Holding Force (lbs): 1200
• Grade: Grade 2

Weights & Dimensions

• Magnet Depth (in): 2
• Magnet Height (in): 3.625
• Magnet Length (in): 8.9375
• Shipping Weight (lbs): 15

Ratings

• Outdoor Rated: No
• Fire Rated: No
• Preload Capable: No

Documents

Securitron iMXDa Electromagnetic Locks Operating Manual

Securitron IMXDa, iEXDa City of Chicago Operating Manual Addendum

Securitron iMXDa Electromagnetic Locks Catalog Page

Certifications

Securitron SA6635-20090613 Certificate of Compliance

Securitron SA6635-20020103 Certificate of Compliance

Model 32 Magnalock, 600lb Holding Force, 12/24VDC, Satin Stainless Steel

300 lbs. holding force per strike (600 lbs. total). Typical applications include: retail display cases, chemical and pharmaceutical storage cabinets, inventory cages and other cabinets that utilize out-swinging doors with a common center latching point. Indoor or outdoor operation. For 5/8" to 7/8" thick cabinet doors.

Magnetic Cabinet Lock

Now you can add asset control to your existing access control system with the durable, power efficient M32-SS. Each strike plate of the M32-SS delivers 300 lbs. of holding force (600 lbs. total). Ideal for securing large two-door cabinets, retail cases or double-door, indoor/outdoor storage applications with out-swinging doors that share a center latching point.

Product Features

• Patented instant release circuit - no residual magnetism
• Surface mounts easily with a minimum of tools
• Fully sealed electronics - tamper and weather resistant
• Mounted using steel machine screws into blind finishing nuts
• Architectural brushed stainless steel finish (US32D/630)
• All ferrous metal surfaces plated to MIL specification
• Hardware accessories available to configure any opening
• Ten feet [3.05m] of jacketed, stranded conductor cable
• Optional BondSTAT magnetic bond sensor
• UL Listed

Environmental

• Maximum Operating Temperature (° F): 140
• Minimum Operating Temperature (° F): -40

Electrical

• Current 24v DC (amps): 150
• Voltage: 12/24

Strength & Durability

• Holding Force (lbs): 600

Weights & Dimensions

• Magnet Depth (in): 1.625
• Magnet Height (in): 1.875
• Magnet Length (in): 8
• Shipping Weight (lbs): 6

Ratings

• Outdoor Rated: Yes
• Fire Rated: Yes
• Preload Capable: Yes

Documents

Securitron M32-SS Cabinet Locks Template

HES Cabinet Locks Overview Brochure

Recessed Magnetic lock for traffic control on a sliding door.

The M62FG-SASM is the only heavy duty Magnalock specifically designed to secure and protect gates.

The shock absorbing 1,200 lbs. Magnetic lock solution for outdoor gates

This weatherproof unit delivers 1,200 lbs. of holding force and comes equipped with conduit fittings and a special shock absorbing strike mount (SASM). This unique design dramatically prolongs the life of the lock, the gate and other hardware by controlling excessive impact between the strike plate and the magnet. The SASM is also available as a separate retrofit kit and is compatible with M32, M62 or M82 Magnalock strike plates for areas prone to excessive force closures or slamming.

Product Features

• Patented instant release circuit - no residual magnetism
• Fully sealed electronics - tamper and weather resistant
• Ten feet [3.05m] of jacketed, stranded conductor cable
• Automatic dual voltage - no field adjustment required
• Universal threaded conduit fitting is 1/2" female - 3/4" male
• SASM is a simple-to-install Stainless Steel parts kit
• SASM main spring provides 5/8" impact compression and 110 lbs. resistance
• SASM anti-kickback spring provides 3/8" of rebound travel to return the gate to the normal "home" position

Environmental

• Maximum Operating Temperature (° F): 140
• Minimum Operating Temperature (° F): -40

Electrical

• Current 12v DC (amps): 250
• Current 24v DC (amps): 150
• Voltage: 12/24

Strength & Durability

• Holding Force (lbs): 1200
• Grade: Grade 2

Weights & Dimensions

• Magnet Depth (in): 1.75
• Magnet Height (in): 3
• Magnet Length (in): 8
• Shipping Weight (lbs): 12

Ratings

• Outdoor Rated: Yes
• Fire Rated: Yes
• Preload Capable: Yes

Documents

Securitron M62FG-SASM Electromagnetic Locks Catalog Page

Securitron Gate and Fence Brochure

Securitron SASM Brochure
