Door Closers

Us Lock Supply Stocks Door Closers In All Options & Finishes.

Arrow Door Closers Corbin Russwin Door Closers Dorma Door Closers  Falcon Door Closers Hager Door Closers
LCN Door Closers Norton Door Closers Sargent Door Closers Taco Door Closers Yale Door Closers



Commercial door closers control how quickly or slowly a door closes, and the type of door closer you choose depends on several factors -- such as your needs, your budget, your building’s architecture, whether you need the door closer for an interior or exterior door, and whether you need a heavy-duty door closer for doors that get a high volume of usage. Us lock supply offers a wide variety of door closers to meet any need.

We have the most basic types of door closers for light duty applications, to power operated door closers, to electromechanical door closers for applications in which the door will be used frequently by those who are older, are ill, use a wheelchair or have other disabilities. We also offer low-power pneumatic door closers and openers that are helpful in applications where door usage is usually manual, but sometimes automatic operation is needed.

Whether you need a door closer for a school, hospital, retail store, apartment building, nursing home or any other facility, commercial door closers from US lock supply make sure the door closes securely but at a safe speed. Browse our selection of door closers for commercial or health care facilities and place your order today.

Norton 1601 Door Closer - Barzellock.com

Norton 1601 Door Closer

by Norton
$ 70.00

"Excellent service, excellent price, excellent timing! Huge help in crazy construction business environment! Five stars! Would suggest us lock supply to anybody, no doubt about it." Regency Glass.

                          Compare The Norton 1601
Brand/Model #
US Lock Supply Comment
Dorma 7400
Great Closer
Falcon SC60
Highly Recommended
Norton 1601
Best In Class Closer
S. Parker 900
Good Imported Closer
Sargent 1130

Solid Closer

Yale 51

Solid Closer

Best Used In Medium To High Traffic Doors


US Lock Supply Stocks The Norton 1601 Closer In All Options & Finishes Ready To Ship Free On Orders Over $189.  Ideal for use with aluminum storefront doors and frames, these closers have a history of proven quality and tradition.

1601 Arm Options:

RW/PA Regular Arm
HW/PA Hold Open With Regular Arm

1601 Finishes:

689-Aluminum
690-Dark Bronze
691-Light Bronze
696-Satin Brass

Features

    • 1600BC: Sized springs 3 or 4
    • 1601: Adjustable spring sizes 3-6
    • 1601BF: Adjustable spring sizes 1-4
    • Exceeds 12 million cycles (witnessed and verified by UL)
    • Non-handed
    • Rack and pinion design
    • Cast aluminum body
    • 2-7/8" (73mm) projection
    • 1-3/8" (35mm) diameter piston
    • 5/8" (16mm) diameter pinion journals
    • Standard, separate and independent, latch, sweep and backcheck intensity valves
    • Tri-Style® packaging (regular arm, top jamb and parallel arm mounting)
    • All standard arm applications allow doors to swing 180°, conditions permitting
    • Staked valves

    Optional Features

    • Delayed action (in lieu of backcheck). Specify 1601DA or 1601BFDA
    • Corrosion-resistant model (non-hold open only). Specify 1601SS or 1601BFSS. (Not tri-packed)
    • Molded plastic cover. Specify suffix P
    • Heavy-duty arms: Parallel Rigid, CloserPlus®, CloserPlus Spring™, and Unitrol®
    LCN 4040XP RW/PA Regular Arm Door Closer - Barzellock.com
     The 4040XP Is The Most Common Closer Used In
     Schools Malls Office Buildings Hospitals Storefronts

     "Excellent service, excellent price, excellent timing! Huge help in crazy construction business environment! Five stars! Would suggest US Lock Supply to anybody, no doubt about it!"

     Used By The Following Professionals
     Glass Companies Locksmiths Management / Maintenence Companies Contractors
     Need a different arm?  Hold Open Extra Duty Arm All Arm Options







    Here are installation instructions for the 4040xp rw/pa closer

    LCN Closer Catalog

    Some of the features the 4040 Door Closer includes:

    • Non-handed
    •  Mounts pull side or top jamb with shallow reveal P4041 closer includes PA SHOE, 4040XP-62PA required for parallel arm mounting
    • 44% increased bearing load capacity
    • Strongest pinion ever- at 3/4” journal diameter
    • Widest bearing ever- at 5/8”
    • Stronger pinion teeth
    • New V-shield™ seal with 20% longer life
    • XP = eXtra Protection in real world applications
    • Cast Iron
    • Forged Steel Arm
    • Double Heat Treated Steel Pinion
    • All Weather Fluid
    • Non-Handed
    • LCN® Fast™ Power Adjust
    • Fast & Accurate Installation
    • UL & cUL Listed
    • Tested and certified under ANSI Standard A156.4, grade one

    Specifications

    • Non-sized cylinder is adjustable for interior doors to 5’0” and exterior doors to 4’0”
    • Closer can mount hinge side, top jamb, or parallel arm (with PA bracket) on either right or left swinging doors
    • Closers to meet ADA requirements
    • Standard or optional custom powder coat finish
    • Optional plated finish on metal cover, arm and fasteners
    • Optional SRI primer for installations in corrosive conditions is available with powder coat only
    • UL and cUL listed for self-closing doors without hold-open
    • 4040XP can be used with all 4040 accessories
    Falcon SC61 RW, HD, HW Door Closer SC60 Series - Barzellock.com
    US Lock Supply Stocks The Falcon SC61 Closer In All Finishes & Options Ready To Ship For Free On Orders Over $189.
    The Falcon SC60 Series is a dependable closer for light to medium-duty application. Designed for interior use with an aluminum storefront, the SC60 Series offers ANSI Grade 1 durability backed by a ten-year warranty. Most common hole pattern in the industry for versatile use and easy retrofit.
     Surface mounted light duty closer that is easily installed and adjusted for your light to medium duty doors.
    Finishes:
    689-Aluminum
    695-Dark Bronze
    Arms:
    RW/PA Regular Arm
    HW/PA Hold Open With Regular Arm
    HD/PA Heavy Duty With Parallel Arm
    Specifications
    • Meets ANSI A117.1
    • ANSI/BHMA A156.4, Grade 1
    • UL Listed
    • 1 3/8" diameter piston
    • Closer mounts hinge side, top jamb or parallel arm when either the Rw/PA or Hw/PA arm is specified
    • Adjustable sizes 1-5 (SC61)
    • Single piece cast aluminum body
    • Staked valves
    • Non-handed for left or right swinging doors
    • Separate adjustable general speed, latch speed and backcheck
    • Heat-treated steel piston
    • Heat-treated pinion
    • UL 10C approved fluid
    • Universal screw pack
    • 10-year warranty

    Certifications
    The Falcon SC60 Series is UL approved and compliant with the UL 10C and UBC 7-2 (1997) fire test. Additionally, the SC61 is designed to meet the American Disabilities Act (ADA) and ANSI A117.1. The SC60 Series is ANSI/BHMA A156.4, Grade 1 certified.

    S Parker 950 Door Closer - Barzellock.com

    S Parker 950 Door Closer

    by S. Parker
    $ 46.00

    US Lock Supply Stocks S Parker Door Closers Ready To Ship For Free On Orders Over $189. The 950 closer features 2 speed controls for closing and latching. Non-handed and using the same template as many other national brands, including the Parker 500, the Yale 50 and the Norton 1600, the S. Parker 950 is a rack and pinion action door closer with all temperature hydraulics in an aluminum housing. Separate controls adjust, at any time, both closing and latching speeds. A fully adjustable model with back check is available.

    953 #3 To Be Used With A  Medium/Heavy Duty
    36" Wide Interior or

    30" Wide Exterior Door

    954 #4 To Be Used With A Heavy Duty
    48" Wide Interior or
    36" Wide Exterior Door

    Finishes:

    Aluminum

    Duranodic

    S. Parker guarantees trouble free operation of each closer for 10 years. Each unit is UL tested, and listed for use on hollow metal fire rated doors. The exterior housing is made of high tensile strength aluminum. Available in aluminum and duranodic, the S. Parker 950 series fits even extra heavy doors.

    LCN 1261 Standard RW/PA Arm Door Closer 1260 Series - Barzellock.com
    The LCN 1260 Series combines the best features from the previous 1070 and 1370 into a single versatile and economical cast iron closer, with dual mounting capability. The 1260 is adjustable spring sizes 1-5 and mounts to the most common commercial footprint. The 1260 also features a complete line of regular and extra duty arms and LCN's peel-n-stick installation templates.

    UL and cUL listed for self-closing doors without hold-open. Tested and certified under ANSI Standard A156.4, grade one.

    Features Common to 1000 Series
    • 1000 series closers mount three ways. Closers with regular or hold-open arm mount hinge side or top jamb. Parallel arm, designated with a "P", closers include - 62PA SHOE required for parallel arm mount. 1460T mounts hinge side, top jamb (pull side) and stop face.
    • Non-handed for right and left swinging doors
    • Closers to meet ADA reduced opening for requirements
    • Adjustable hydraulic backcheck cushions opeing swing prior to 90 degrees
    • Separate regulation of general closing speed and latching speed
    • Joints in arm and shoe adapt to uneven trim
    • Reversible shoe to boost latching power on double lever arms
    Specifications
    • Standard 1260 series closer shipped with regular arm, a shaft cover, and self reaming and tapping screws. See 1260 Series catalog pages 8-9 for options
    • Non-sized (1-5) cylinder is adjustable for interior doors to 4’6” and exterior doors to 3’6”
    • Closer mounts hinge side, top jamb and parallel arm on either right or left swinging doors
    • Mounts to most common commercial footprint (3/4” x 9 1/16”)
    • Closer meets ADA requirements. See 1260 Series catalog page 10
    • Optional Quick Fix™ bracket kit
    • Standard or optional custom powder coat finish
    • Optional SRI primer for installations in corrosive conditions
    • Optional Slim Line cover
    Norton 7500 Door Closer - Barzellock.com

    Norton 7500 Door Closer

    by Norton
    $ 190.00

    US Lock Supply Stocks The Norton 7500 Series Door Closer Ready To Ship Free On Orders Over $189. Order Today!

    • Adjustable spring sizes 1 through 6 (ADA Compliant)
    • Tri-Style® packaging for regular, top jamb or parallel arm mounting
    • Exceeds 25 million cycles (witnessed and verified by UL)
    • Non-handed
    • Rack-and-pinion design
    • Cast aluminum body
    • 2-3/16" (56mm) projection
    • 1-1/2" (38mm) diameter piston
    • 5/8" (16mm) diameter pinion journals
    • Staked valves
    • Standard, separate and independent, latch, sweep and backcheck intensity valves
    • Backcheck positioning valve
    • NorGlide® fluid
    • Molded plastic cover
    • All standard arm applications allow doors to swing 180°, conditions permitting
    • Self-drilling screws
    • Slide Tracks: push or pull side mounting

    Optional Features

    • Heavy-duty arms: Regular Rigid, Parallel Rigid, CloserPlus®, CloserPlus Spring™ and Unitrol®
    • Corrosion resistant model (non-hold open only). Specify 7500SS
    • Metal cover. Specify M suffix



    • Lead lined metal cover. Specify MLL suffix
    • Enhanced backcheck. Specify EBC suffix
    • Delayed action with pressure relief valve
    • Retrofit plates

    Typical Applications

    Recommended for interior or exterior doors including:



    • Classrooms
    • Offices
    • Main entrance doors
    • Hospitals
    • High use, high abuse doors

    Certifications

    • ANSI/BHMA A156.4, Grade 1 certified
    • ANSI/BHMA standard A117.1 certified
    • UL listed



    • UL10c compliant for positive pressure
    • Listed by the New York City Materials and Equipment Acceptance Division
    • 25-year limited warrant
    Norton 5700 Power Operated Door Closer 5710, 5730, 5730 - Barzellock.com

    Norton 5700 Series is the latest generation of power door operators. Low energy door operators were once considered a necessity only for those with physical challenges. Today, due to the population?s busy lifestyles, the convenience of ?hands-free? door opening is more popular than ever. The patented design of LEO? is based on ease and simplicity. LEO installs in minutes rather than hours and consists of three basic components: inverter, motor and Norton

    Features

    Non-Handed

    Ease of installation and setup - Simple instructions

    Application versatility & ease of adjustment - Push or pull side mounting units available

    Operates as mechanical surface closer during close cycles or when door is opened manually or if power is turned off - Quiet operation, acceptable for fire-rated doors, spring force provides the feel of a normal manual door closer, door can be opened manually if desired

    Power Size: Multi-Sized Door Closer Adjustable through the power range of sizes 3 through 6.

    Separate and independent, latch, sweep and backcheck intensity valves

    Sweep Speed: Allows adjustment of door speed from the door's full open position down to approximately 10from the closed position.

    Latch Speed: Allows adjustment of door speed from approximately 10down to the door?s fully closed position.

    Backcheck: Provides control of the door in the opening cycle, beginning at approximately 75of door opening. It slows/cushions the door opening, when the door is forcibly opened beyond its pre-adjusted opening speed limits.

    Unit Activation Options - Wall switches, Motion sensor, Radio frequency device

    End-User On/Off Switch

    Hold Open options - 0-30 seconds (5 seconds minimum required for ADA and ANSI A156.19)

    Obstruction Detection - Motor stops if door is obstructed during an opening, door closes under manual spring force.

    "Push and Close" Allows the operator to skip the hold open time when it is not necessary or required Adjustable door sensitivity

    Overload Safety Shut-Off After two minutes of receiving a door activation signal, the inverter will time out and close the door Prevents motor/inverter damage

    Motor Start Delay for Locking Hardware 0-5 second delay to allow locking hardware to release first

    2-year warranty (refer to current Nortonprice book for terms & conditions)

    Model: Norton, 5710, 5730, 5740

    9560 Series Door Closer by LCN

    Independent Pair, Surface Mount (Push/Pull) Double Egress

    9560 Series Door Closer by LCN

    LCN automatic operators are the proven standard in schools and health care facilities for over 20 years. They are easily retrofitted into existing doors and frames, as well as new construction. LCN low energy electrohydraulic and pneumatic automatic operators feature a heavy duty closer with a slow opening function. LCN's electromechanical automatic operators utilize a motor gearbox and control box to perform the opening and closing function. LCN's electromechanical products are designed primarily for automatic opening applications that occasionally require manual opening. A control box provides all electrical functions. These self-contained units are suitable for use on single leaf doors or pairs of doors. These products combine all the control and power elements into a single operator package, only some actuators are required to complete the system.

    The 9560 SENIOR SWING by LCN is an ADA door operator that is a two-in-one swing door operator. SENIOR SWING operators when activated, opens doors automatically for wheelchair access, yet allows for manual operation for regular pedestrian traffic.

    Features and Benefits:

    - Push 'N Go permits non-switch activation.
    - Power Boost provides additional latching force.
    - Electromechanical unit with microprocessor control.
    - Digital keypad for easy setup.
    - Meets International Building Code requirements and ANSI A156.19.
    - UL approved for fire doors.
    - Available in Aluminum (ANCLR) finish.

    9560 Series is fully compliant with UL325 & UL1998 and meets the provisions of ANSI A156.19. The 9560 Series is UL listed for fire-rated applications. The 9560 Series also meets the provisions of the Americans with Disabilities Act.

    Specifications:

    - 9560 Series operator is shipped with motor gearbox, control boxes, arms, header, and mounting hardware.
    - Independent pair, surface mounted.
    - Meets ADA requirements (power mode only).
    - Handed for right (RH or LHR) or left (LH or RHR) swinging doors.
    - Pull, Push or Double Egress applications available.
    - 72" header length is standard. Specify other length 60" to 98".
    - Adjustable hold open period of 1 to 32 seconds in automatic or manual mode.

    Arm Function Option:

    REG2 (Regular Arm 9560-3077): Handed arm. Includes 77 main arm assembly and 79 linkage assembly.

    9540 Series Door Closer by LCN

    Simultaneous Pair, Surface Mount (Push/Pull) Double Egress

    9550 Series Door Closer by LCN

    LCN automatic operators are the proven standard in schools and health care facilities for over 20 years. They are easily retrofitted into existing doors and frames, as well as new construction. LCN low energy electrohydraulic and pneumatic automatic operators feature a heavy duty closer with a slow opening function. LCN's electromechanical automatic operators utilize a motor gearbox and control box to perform the opening and closing function. LCN's electromechanical products are designed primarily for automatic opening applications that occasionally require manual opening. A control box provides all electrical functions. These self-contained units are suitable for use on single leaf doors or pairs of doors. These products combine all the control and power elements into a single operator package, only some actuators are required to complete the system.

    The 9550 SENIOR SWING by LCN is an ADA door operator that is a two-in-one swing door operator. SENIOR SWING operators when activated, opens doors automatically for wheelchair access, yet allows for manual operation for regular pedestrian traffic.

    Features and Benefits:

    - Push 'N Go permits non-switch activation.
    - Power Boost provides additional latching force.
    - Electromechanical unit with microprocessor control.
    - Digital keypad for easy setup.
    - Meets International Building Code requirements and ANSI A156.19.
    - UL approved for fire doors.
    - Available in Aluminum (ANCLR) finish.

    9550 Series is fully compliant with UL325 & UL1998 and meets the provisions of ANSI A156.19. The 9550 Series is UL listed for fire-rated applications. The 9550 Series also meets the provisions of the Americans with Disabilities Act.

    Specifications:

    - 9550 Series operator is shipped with motor gearbox, control box, arms, header, and mounting hardware.
    - Simultaneous pair, surface mounted.
    - Meets ADA requirements (power mode only).
    - Handed for right (RH or LHR) or left (LH or RHR) swinging doors.
    - Pull, Push or Double Egress applications available.
    - 72" header length is standard. Specify other length 60" to 98".
    - Adjustable hold open period of 1 to 32 seconds in automatic or manual mode.

    Arm Function Option:

    REG2 (Regular Arm 9550-3077): Handed arm. Includes 77 main arm assembly and 79 linkage assembly.

    9540 Series Door Closer by LCN

    LCN automatic operators are the proven standard in schools and health care facilities for over 20 years. They are easily retrofitted into existing doors and frames, as well as new construction. LCN low energy electrohydraulic and pneumatic automatic operators feature a heavy duty closer with a slow opening function. LCN's electromechanical automatic operators utilize a motor gearbox and control box to perform the opening and closing function. LCN's electromechanical products are designed primarily for automatic opening applications that occasionally require manual opening. A control box provides all electrical functions. These self-contained units are suitable for use on single leaf doors or pairs of doors. These products combine all the control and power elements into a single operator package, only some actuators are required to complete the system.

    The 9540 SENIOR SWING by LCN is an ADA door operator that is a two-in-one swing door operator. SENIOR SWING operators when activated, opens doors automatically for wheelchair access, yet allows for manual operation for regular pedestrian traffic.

    Features and Benefits:

    - Push 'N Go permits non-switch activation.
    - Power Boost provides additional latching force.
    - Electromechanical unit with microprocessor control.
    - Digital keypad for easy setup.
    - Meets International Building Code requirements and ANSI A156.19.
    - UL approved for fire doors.
    - Available in Aluminum (ANCLR) finish.

    9540 Series is fully compliant with UL325 & UL1998 and meets the provisions of ANSI A156.19. The 9540 Series is UL listed for fire-rated applications. The 9540 Series also meets the provisions of the Americans with Disabilities Act.

    Specifications:

    - 9540 Series operator is shipped with motor gearbox, control box, regular arm, header, and mounting hardware.
    - Single door, surface mounted.
    - Meets ADA requirements (power mode only).
    - Handed for right (RH or LHR) or left (LH or RHR) swinging doors.
    - 36" header length is standard. Specify length 33" to 48" max.
    - Adjustable hold open period of 2 to 32 seconds in automatic or manual mode.

    Arm Function Option:

    REG (Regular Arm 9540-3077): Handed arm.

    9530 Series Door Closer by LCN

    LCN automatic operators are the proven standard in schools and health care facilities for over 20 years. They are easily retrofitted into existing doors and frames, as well as new construction. LCN low energy electrohydraulic and pneumatic automatic operators feature a heavy duty closer with a slow opening function. LCN's electromechanical automatic operators utilize a motor gearbox and control box to perform the opening and closing function. LCN's electromechanical products are designed primarily for automatic opening applications that occasionally require manual opening. A control box provides all electrical functions. These self-contained units are suitable for use on single leaf doors or pairs of doors. These products combine all the control and power elements into a single operator package, only some actuators are required to complete the system.

    The 9530 SENIOR SWING by LCN is an ADA door operator that is a two-in-one swing door operator. SENIOR SWING operators when activated, opens doors automatically for wheelchair access, yet allows for manual operation for regular pedestrian traffic.

    Features and Benefits:

    - Push 'N Go permits non-switch activation.
    - Power Boost provides additional latching force.
    - Electromechanical unit with microprocessor control.
    - Digital keypad for easy setup.
    - Meets International Building Code requirements and ANSI A156.19.
    - UL approved for fire doors.
    - Available in Aluminum (ANCLR) finish.

    9530 Series is fully compliant with UL325 & UL1998 and meets the provisions of ANSI A156.19. The 9530 Series is UL listed for fire-rated applications. The 9530 Series also meets the provisions of the Americans with Disabilities Act.

    Specifications:

    - 9530 Series operator is shipped with motor gearbox, control box, standard arm, header, and mounting hardware.
    - Single door, surface mounted.
    - Meets ADA requirements (power mode only).
    - Handed for right (RH or LHR) or left (LH or RHR) swinging doors. Click here for Handing Diagram.
    - 36" header length is standard. Specify length 33" to 48" max.
    - Adjustable hold open period of 2 to 32 seconds in automatic or manual mode.

    Arm Function Option:

    STD (Standard Arm 9530-3077T): Handed arm. Track roller not included.

    9150 Series Door Closer by LCN

    The LCN 9150 BENCHMARK is an automatic electromechanical swinging door operator for use on hinged, center pivoted and offset pivoted doors. When activated, the Benchmark drives the door to full open position, then electrical power is turned off and the door is closed by spring force. The activating circuit opens the door from any position in the closing swing. During a power failure, the Benchmark acts as a manual door closer. Door opening and closing cycles, including opening speed, back check speed, hold open time delay, closing speed, and latch position, are adjustable.

    The 9150 BENCHMARK by LCN is an electrically powered low-energy operator. It provides easy access for people with disabilities, the elderly or the frail. Designed primarily for automatic opening applications that occasionally require manual opening. The BENCHMARK is a cost-effective solution for retrofitting an activated or manual door.

    Features and Benefits:

    - Push 'N Go permits non-switch activation.
    - Microprocessor control box ensures reliability and maintains customer settings.
    - Power Boost allows for increased closing force near latch.
    - Available in Aluminum (ANCLR) finish.

    9150 Series is fully compliant with UL325 and meets the provisions of ANSI A156.19. The 9150 Series is UL listed for fire-rated applications. The 9150 Series also meets the provisions of the Americans with Disabilities Act.

    Specifications:

    - 9150 Series operator is shipped with motor gearboxes, control boxes, mounting plate, regular arms, metal cover, wood and machine screw packs.
    - Pair of interior doors, surface mounted.
    - ADA compliant.
    - On/Off switch included as standard.
    - Non-handed for either right or left swinging door.
    - 72" cover is standard.
    - All potentiometers clearly labeled with their functions.
    - LED lights indicate power to control box and motor gearbox.

    Arm Function Option:

    REG (Regular Arm 9150-3077): Non-handed arm.

    9140 Series Door Closer by LCN

    The LCN 9140 BENCHMARK is an automatic electromechanical swinging door operator for use on hinged, center pivoted and offset pivoted doors. When activated, the Benchmark drives the door to full open position, then electrical power is turned off and the door is closed by spring force. The activating circuit opens the door from any position in the closing swing. During a power failure, the Benchmark acts as a manual door closer (Size 3). Door opening and closing cycles, including opening speed, back check speed, hold open time delay, closing speed, and latching position, are adjustable.

    The 9140 BENCHMARK by LCN is an electrically powered low-energy operator. It provides easy access for people with disabilities, the elderly or the frail. Designed primarily for automatic opening applications that occasionally require manual opening. The BENCHMARK is a cost-effective solution for retrofitting an activated or manual door.

    Features and Benefits:

    - Push 'N Go permits non-switch activation.
    - Microprocessor control box ensures reliability and maintains customer settings.
    - Power Boost allows for increased closing force near latch.
    - Available in Aluminum (ANCLR) finish.

    9140 Series is fully compliant with UL325 and meets the provisions of ANSI A156.19. The 9140 Series is UL listed for fire-rated applications. The 9140 Series also meets the provisions of the Americans with Disabilities Act.

    Specifications:

    - 9140 Series operator is shipped with motor gearbox, control box, mounting plate, regular arm, metal cover, standard track, wood and machine screw pack.
    - Single interior door, surface mounted.
    - ADA compliant.
    - On/Off switch included as standard.
    - Non-handed for either right or left swinging door.
    - 27" cover is standard. Full length covers available up to 36" for single doors.
    - All potentiometers clearly labeled with their functions.
    - LED lights indicate power to control box and motor gearbox.

    Arm Function Option:

    REG (Regular Arm 9140-3077): Non-handed arm.

    9130 Series Door Closer by LCN

    The LCN 9130 BENCHMARK is an automatic electromechanical swinging door operator for use on hinged, center pivoted and offset pivoted doors. When activated, the Benchmark drives the door to full open position, then electrical power is turned off and the door is closed by spring force. The activating cirucit opens the door from any position in the closing swing. During a power failure, the Benchmark acts as a manual door closer (Size 3). Door opening and closing cycles, including opening speed, back check speed, hold open time delay, closing speed, and latch positon, are adjustable.

    The 9130 BENCHMARK by LCN is an electrically powered low-energy operator. It provides easy access for people with disabilities, the elderly or the frail. Designed primarily for automatic opening applications that occasionally require manual opening. The BENCHMARK is a cost-effective solution for retrofitting an activated or manual door.

    Features and Benefits:

    - Push 'N Go permits non-switch activation.
    - Microprocessor control box ensures reliability and maintains customer settings.
    - Tested internally to over 3,000,000 cycles.
    - Power Boost allows for increased closing force near latch.
    - Available in Aluminum (ANCLR) finish.

    9130 Series is fully compliant with UL325 and meets the provisions of ANSI A156.19. The 9130 Series is UL listed for fire-rated applications. The 9130 Series also meets the provisions of the Americans with Disabilities Act.

    Specifications:

    - 9130 Series operator is shipped with motor gearbox, control box, mounting plate, standard arm, metal cover, standard track, wood and machine screws.
    - Single interior door, surface mounted.
    - ADA compliant.
    - On/Off switch included as standard.
    - Non-handed for either right or left swinging door.
    - 27" cover is standard. Full length covers available up to 36" for single doors.
    - All potentiometers clearly labeled with their functions.
    - LED lights indicate power to control box and motor gearbox.

    Arm Function Option:

    STD (Standard Arm 9130-3077T): Non-handed arm. Track roller not included.
