Exit devices go by many other names, including crash bar, panic bar, push bar or panic device. Whatever you call it, commercial exit devices or panic bars are used on the inside of outward-opening doors to allow people to leave the building quickly in case of an emergency, and they may also trigger an alarm when opened. We offer many different wholesale commercial exit devices to fit different applications and door sizes.

We carry wholesale panic bars from major manufacturers such as Adams Rite, Arrow, Corbin Russwin, Falcon, Detex, Sargent, Von Duprin and Yale. Our website makes it easy to order the right wholesale commercial exit devices for specific types of exit doors because we offer your choice of finish (such as aluminum or dark bronze anodized finish), bar size and type, and right or left handing to fit the way the door opens.

If you have any questions about our commercial panic bars and exit devices, simply email us at sales@uslocksupply.com or give us a call.

V40 EB Cylinder Dogging Alarmed Rim Exit Device

Detex V40 EB Cylinder Dogging Alarmed Rim Exit Device

The V40 EB is designed for primary and secondary exits that require an alarmed panic device. The 100dB alarm will sound when someone attempts to exit, alerting management to the unauthorized exit. US Lock Supply Stocks The V40 EB CD In All Options.

Instructions For Detex V40 EB CD

Benefits:

Priced to be the best value for durable and attractive loss prevention panic hardware

• Reduces employee and customer theft
• Fast and easy installation
• Secure installation prevents mistakes, enhances security and reduces maintenance
• Durable design provides years of trouble-free protection, saving on replacement costs
• Fits almost any door in any décor
• Controls foot traffic, deters unauthorized exits, prevents loss and meets building code requirements
Features:
• V40xEB - Alarmed Exit Device powered by standard 9-volt battery
• Stainless steel, 3/4" deadlocking Pullman-type latch bolt
• 100 decibel alarm
• 1/8 turn cylinder dogging
 • Heavy-duty angled end cap
• Heavy-duty ribbed aluminum rail extrusion
• Accommodates all types of mortise cylinders with a standard Yale cam (collar required for 7-pin IC cylinders)
• Patented back plate and plastic strike locator provide paperless template for perfect alignment with door and frame
• Single mortise cylinder (sold separate) provides arming and dogging
• State-of-art electronics offer reliable security and instantaneous alarm
• Field selectable key rearm or 2 min. auto rearm
• Visual and audible arming indicators • Armed and disarmed field selectable status indicator
Mechanical Options:
• CD - Cylinder Dogging (Std.)
 • 36 - Fits 36" Door Width (Std.)
• 48 - Fits 48" Door Width
• 99 - Surface Strike (Std.)
• 98 - Semi Mortise Strike
Von Duprin 98EO/99EO Rim Panic Exit Device - Barzellock.com

100+ IN STOCK READY TO SHIP TODAY.
    "I've been doing business with US Lock Supply for over 25 years and have enjoyed a great relationship with them. Friendly staff, knowledgeable team, and quick delivery! US Lock Supply is a five star hardware distributor."
Here Is An Installation Video For The 98 & 99 Device.

All Von Duprin 98/99 Series exit devices are UL listed for Accident Hazard and Fire Exit Hardware and are tested in accordance to ANSI Grade 1 requirements.
Exit devices are a critical part of the Fire and Life Safety egress system and will provide safe and reliable service when properly applied and maintained. Von Duprin designs and manufactures exit devices in accordance to ISO 9001 Quality Management System and meets or exceeds accepted U.S. domestic and International standards. All 98 and 99 series exit devices are UL listed for Panic Hardware or Fire Hardware, and are certified to ANSI A156.3, 2001, Grade 1. Many models are also certified for Hurricane Resistant Applications. Consult your local Allegion sales consultant or the Von Duprin factory for current listings.
It is intended that the information included in this publication, when properly used, will provide clear and reliable guidelines to the proper general selection and application. However, the scope of the information is necessarily limited.

99/98 Specification

99- grooved mechanism case
98- smooth mechanism case
Unusual operating conditions and environments and other external influences can affect the proper application of the products represented. Modifications of these products will also affect UL listings. It is recommended that whenever an unusual application condition exists, or when any modification of a product is considered, that our engineers review the application.

Application engineering services are available to help ensure proper selection or to review any areas where users of Von Duprin products may have questions.

Von Duprin push pad exit devices are available in two external surface styles, designated 98 Series and 99 Series. The two styles are mechanically and dimensionally identical and provide a wide selection of appearance options.

Latch Bolt
Deadlocking latchbolt provides security and improved performance at standard device cost.

The Quiet One®
A fluid dampener decelerates the pushpad on its return stroke and eliminates most noise associated with exit device operations. Furnished on all 98/99™ series exit devices.

US Lock Supply Stocks The Adams Rite 8410, 8420 Narrow Stile Mortise Exit Devices In Stock Ready To Ship.

Finish:

Clear Aluminum 628

Dark Bronze 313

Features:
  • Heavy duty deadlatching mechanism
  • Strong, durable construction for a high level of security
  • Easy to install
  • Clean, unobtrusive design
  • Pushbar clad or anodized, not plated, in a variety of finishes
  • Fits standard cutout used for the Adams Rite MS® Deadlock on aluminum stile glass doors

Specifications:
8400 Series Certifications:
• UL 305 Panic Hardware
• ANSI/BHMA A156.3 Grade 1
• California State Fire Marshall
• New York City MEA*

*Consult Factory for specific number

Materials: Pushbar made of extruded aluminum, clad or anodized in a variety of finishes.

Handing: Specify handing and bevel if applicable. Lever Entry Trim is field reversible.

Pushbar Length: Standard sizes: dimensioned for 30”, 36”, 42”, and 48” openings. Standard width bars can be field cut to the next smallest opening width.

Backset: Backsets available in 31/32”, 1-1/8”, and 1-1/2”

Door Thickness: Suits 1-3/4” standard. Can be modified for thicker doors.

Stile Width: Minimum 2” Stile. Fits narrow, medium, and wide stile aluminum doors.

Projection: 2-5/8” when fully projected, 1-5/8”when dogged.

Dogging: Standard dogging with hex key or cylinder dogging option. Electric dogging also available.

Fasteners: Standard self-tapping screws.

Cylinders (available separately)

Cylinder x Fixed Pull: (Function 03): Accepts any standard mortise cylinder with MS® cam.

3080 Entry Trim (Functions 08, 09): Accepts any standard diameter mortise cylinder with MS® cam. Accommodates cylinder lengths from 1” to 1-1/4”. (Available separately).

Warranty: Five year limited.

Strikes: A variety of strikes are available for different applications and conditions. Standard strike (included), Extended Lip 8460-17 (available separately), Longface 8455-01 (available separately).

Thick and Cladded Door Kits:
  • 91-0995-02* - 2” Thick Door Kit
  • 91-0995-03* - 2-1/4” Thick Door Kit
  • 91-0995-04* - 2-1/2” Thick Door Kit
  • 91-0995-05* - 2-3/4” Thick Door Kit
  • 91-0995-06* - 3” Thick Door Kit
  • 91-0325-01 – Thermal Door Kit – ¼” Cladding
  • 91-0325-02 – Thermal Door Kit – ½” Cladding
*Order 8460-XX Long Lip Strike as required.

Please Call If You Cant Find The Option On Our Site.

Options and Accessories:
Silent Electrification Motorized Latch Retraction: The SE Motorized Latch Retraction option provides near-silent operation for quiet environments such as hospitals, offices, hotels, and libraries where solenoid-driven devices would be disruptive.



Cylinder Dogging: For management control of dogging exit devices for life-safety exit devices only.

Electric Dogging: A holding magnet keeps the pushbar depressed (set manually) and the latch retracted for lower profile exit devices, resulting in less damage and quieter operation.

Matching End Caps: Matching end caps are available for applications where it is preferable that the end caps match the finish of the exit device. Available for US finishes only.

Available Finishes: 313 Dark Bronze Anodized, 335 Black Anodized, 628 Clear Anodized, US3 Bright Brass, US4 Satin Brass, US32 Bright Stainless, US32D Satin Stainless.

Falcon 24-R EO Narrow Stile Rim Exit Device - Barzellock.com
 Falcon 24-R EO Narrow Stile Rim Exit Device. Offices, banks, assisted living facilities, retail stores and other commercial buildings have constant traffic, so door hardware must be able to take continual use and abuse. The Falcon 24 Series exit devices fit the bill with some of the toughest, most reliable performance in the business. A host of features makes this a smart solution, like a choice of an A or B label fire rating, electrified and panic options, and a full complement of trims. Sleek, streamlined styling and narrow stile device applications means a smart solution for your building design, as well as its use. And since they’re backed by one of the best names in the business, you can be sure you’re getting the utmost value, reliability and durability.
Hand: Non-handed
Finishes: US26D (626); US32D (630); US28 (628), 313AN
Strikes: 299F strike standard
Latchbolt: Stainless steel, 3⁄4" throw
Dogging feature: Half turn hex dogging standard. No threaded parts to wear out.
Doors: 1 3⁄4" thick, wood or metal. Specify thickness if other than 1 3⁄4".
Projections: 2 3⁄4" maximum, 2" dogged.
Mounting height: 40" from CL to finished floor
Electric functions: Can be interfaced with building security systems. Latch retraction, security monitoring, delayed egress and exit alarm available (EL fail- secure only)Please Call 212-677-7530 Fot Electric Function.
Fasteners: All mounting screws are concealed.
Sex bolts: Recommended when device is used with hollow core wood, composite or light gauge hollow metal doors
ANSI: Certified ANSI A156.3-2001 grade 1 standards.
Features and Benefits
  • Streamlined design includes flush-end cap for clean lines and a more attractive installation
  • Stainless steel pushpad cover for a scratch-resistant surface
  • Clean design with no exposed screws or rivets on the back of the device
  • Patent-pending deadlocking technology ensures reliable security
  • One trim input design for maximum versatility
  • Extruded aluminum construction delivers greater strength and impact resistance
Marks M9900 36" Aluminum Exit Device - Barzellock.com

Marks M9900 36" Aluminum Exit Device

by Marks USA
$ 240.00
US Lock Supply Stocks The Marks M9900 & M9900F Ready To Ship For Free. The M9900 series exit device provides extreme durability for high impact applications such as schools, universities and other institutional or commercial buildings. The heavy-duty cast chassis provides superior durability, while the smooth reduced projection touchbar assembly minimizes catch hazards. The partial length touchpad permits options such as dogging.
Von Duprin 98EO-F/99EO-F Rim Fire Touch Bar Exit Device 98/99 Series for all types of single doors up to 4´ x 10´ (1219mm x 3048mm) or 8´ x 10´ (2438mm x 3048mm) double doors with 9954 or 9854 mullion, UL listed for Fire Exit Hardware. Devices are ANSI A156.3 – 2001 Grade 1. The 98-F device has a smooth mechanism case and the 99-F device has a grooved case. The rim device is non-handed except when the following device options are used: -2 (Double Cylinder) or SS (Signal Switch).

The 98-F/99-F devices are available in the following finishes: US3, US4, US10, US26, US26D, US28 and 313AN. US32D available with 98 Series only.

Specifications
  • Device Functions: Device ships EO/DT/NL. Field selectable. For TP,K,or L remove NL drive screw from device
  • Device Lengths: 3’     2’4" to 3’ (711mm to 914 mm) Door Size; 4’     2’10" to 4’ (864 mm to 1219 mm) Door Size
  • Strikes: 299F – Dull Black, 499F with Mullions. Optional Strikes also available
  • Dogging Feature: No Mechanical Dogging, EL and QEL option available
  • Electric Options: LX Latchbolt Monitor Switch; RX Pushpad Monitor Switch; RX2 Double Pushpad Monitor Switch; E Electric Locking & Unlocking; EL Electric Latch Retraction; SS Signal Switch; CX Chexit Delayed Exit; ALK Alarm Exit Kit; QEL Quiet Electric Latch Retraction
  • Mechanical Options: PN Pneumatic Latch Retraction; -2 Double Cylinder; GBK Glass Bead Kit; XP Extra Protection
  • Fasteners & Sex Bolts (SNB): Includes screw pack for 1-3/4" (19mm) – 2-1/4" (57mm) Wood & Metal Doors Optional 425 SNB available for metal doors. 425 and 825 SNB required on wood doors without SLM blocking.
  • Latch Bolt: Deadlocking, 3/4" (19mm) throw
  • Device Centerline from Finished Floor: 39-13/16" (1011 mm); 39-11/16" (1008 mm) with Mullion
  • Center Case Dimensions: 8" x 2-3/4" x 2-3/8" (203mm x 70mm x 60mm)
  • Mechanism Case Dimensions: 2-1/4" x 2-1/4" (57mm x 57mm)
  • Projection: Pushbar Neutral – 3-13/16" (97 mm); Pushbar Depressed – 3-1/16" (78 mm)
Sargent 2828 Rim Exit Device With 12-Fire Option - Barzellock.com

Sargent 2828 Rim Exit Device With 12-Fire Option. The 2828 Non Configured Rim Exit Device is the perfect stocking device.

US Lock Supply Stocks The Sargent 2828 & 12-2828 Exit Devices.

Bar Sizes:

E-32" Bar

Standard F-36" Bar

G-48" Bar

Finishes:

EN-Sprayed Aluminum

EAB-Sprayed Brass(Call For Availability)

ED-Sprayed Black(Call For Availability)

Features

  • Chassis mounted unit construction assures easy installation and maintenance
  • Tapered push rail and angled covers
  • Steel end caps and covers
  • All devices meet ANSI/BHMA Standard 156.3 Grade 1
  • UL Listed
  • UL Listed to Canadian safety standards
  • Available as Fire Exit Hardware (12-)

Specifications

  • For Doors - 1-3/4" (44mm) thick standard. 4-1/2" (114mm) minimum stile width required for single or double door application using standard 649 strike
  • Mounting - Furnished standard with wood and machine screws. Available with through-bolts and mortise nuts
  • Cover - steel
  • Chassis - Nonferrous alloy
  • Rail Assembly - Roll formed steel
  • End Cap - steel
  • Hand - Non handed
  • Latchbolt - Stainless Steel 3/4" (19mm) throw
  • Strike - 649 packed standard
  • Dogging Feature - Allen-type key furnished standard(non fire rated devices only)
Detex V40 Cylinder Dogging Rim Exit Device - Barzellock.com

Detex V40 Cylinder Dogging Rim Panic Exit Device. The V40 Series rim exit device is secure and durable panic and fire exit hardware at an economical price. It is designed for use on all types of single and double doors with mullions. The patented mounting plate and strike locator system ensures the easiest and most accurate installation of panic hardware available. US Lock Supply Stocks The V40 In All Options.

Installation Video

Benefits:

• Priced to be the best value for durable and attractive loss prevention panic hardware

• Fast and easy installation

• Minimal door prep saves time and money

• Fits almost any door in any décor

• Outside trims are easily changed or rekeyed without removing device from door

Features:

• Patented mounting plate and strike locator

• Covers a 161 door prep

• Stainless steel, 3/4" deadlocking Pullman-type latch bolt

• Non-handed

• Field sizeable

• Heavy-duty angled end cap

• Heavy-duty ribbed aluminum rail extrusion

• High impact ABS and anodized surfaces

• Withstands over 1400 pounds of static pull force for greater security

• Modular design accepts a variety of outside trims and functions

• Standard and narrow stile pull trims available

Mechanical Options:

• CD - Cylinder Dogging

• 36 - Fits 36" Door Width (Std.)

• 48 - Fits 48" Door Width

• 99 - Surface Strike (Std.)

Instructions Catalog

Von Duprin 33A/35A-EO Rim Device - Barzellock.com

Von Duprin 33A/35A-EO Rim Device

by Von Duprin
$ 1,005.68
Von Duprin 33A/35A-EO Rim Device. 33A and 35A for all types of single and double doors with mullion, UL listed for Panic Exit Hardware. Devices are ANSI A156.3 – 2001 Grade 1. The 35A has a smooth mechanism case and the 33A has grooved case. The rim device is non-handed except when the SS (Signal Switch) option is used. See opposite page for available outside trim and device functions.

33A/35A fits door stiles as narrow as 1 3/4" (44mm). Newly designed device has a one piece center case cover.

The 33A/35A devices are available in the following finishes; US3, US4, US10, US26, US26D, US28, 313 and 315.

Features and Benefits
  • 33A Series features grooved mechanism case
  • 35A Series features smooth mechanism case
  • Deadlocking latchbolt prevents forced latchbolt retraction providing higher security for your openings
  • A fluid dampener decelerates the pushpad on its return stroke and eliminates most noise associated with exit device operations. Furnished on all 33A/35A series exit devices

Specifications

  • Device Lengths: 3’ 2’4" to 3’ (711mm to 914 mm) door size; 4’ 2’10" to 4’ (864 mm to 1219 mm) door size
  • Strikes: 1439 – Dull Black
  • Dogging Feature: Hex key dogging standard
  • Dogging Options: CD Cylinder Dogging; LD Less Dogging
  • Electric Options: LX Latchbolt Monitor Switch; RX Pushpad Monitor Switch; RX2 Double Pushpad Monitor Switch; SS Signal Switch; EL Electric Latch Retraction; ALK Alarm Exit Kit
  • Miscellaneous Options: PN Pneumatic Latch Retraction; GBK Glass Bead Kit
  • Fasteners & Includes Sex Bolts (SNB): 1 3/4" (44mm) – 2 ¹|4" (57mm) Wood & Metal Doors; #425 SNB furnished standard for end case; #325 SNB furnished standard for EO (exit only device)
  • Latch Bolt: Deadlocking, 3/4" (19mm) throw
  • Device Centerline from Finished Floor: 39 13/16" (1011 mm); 39 11/16" (1008 mm) with Mullion
  • Center Case Dimensions: 8 3/16" x 2 13/32" x 1 9|16" (208mm x 62mm x 40mm)
  • Mechanism Case Dimensions: 2 1/4" x 2 1/4" (57mm x 57mm)
  • Projection: Pushbar Neutral – 3 13/16" (97 mm); Pushbar Depressed – 3 1/16" (78 mm)
Corbin Russwin ED 8200 Rim Exit Device - Barzellock.com

Corbin Russwin ED 8200 Rim Exit Device

by Corbin Russwin
$ 380.00

Corbin Russwin ED 8200 Rim Exit Device

Handing- Non-handed.

Finishes:

689-Aluminum Painted

691-Light Bronze Painted

Bar Length: Easily field cut to size.

Standard: 36" bar fits 31" - 36" (787mm-914mm) door.

Optional: 30" bar fits 28" - 30" (711mm-762mm) door; .

Optional: 42" bar fits 37" - 42" (940mm-1067mm) door; .

Optional: 48" bar fits 43" - 48" (1092mm-1219mm) door; .

Door Thickness: 1-3/4" (44mm) standard.

Backset: 2-3/4" (70mm). Device and trim cover standard

Latchbolt: 3/4" (19mm) stainless steel pullman-type with stainless steel deadlocking latch

Materials: Heavy-duty wrought steel chassis and pushpad; aluminum front and rear bar covers; stainless steel springs; nylon bearings.

Dogging: Standard on ED8200 devices: single point 1/4 turn dogging.

Optional: less dogging; specify M51(Call To See If Its Avail.).

Fasteners: Standard on ED8200 devices: machine screws and wood door fasteners.

Certification/Compliance ANSI Meets A156.3, Type 1, Grade 1. Meets A117.1 Accessibility Code. C-UL US All devices listed for safety as panic hardware; devices comply with UL 305 standards for panic hardware. UL symbol on rear cover label indicates listing. Three-hour fire-rated devices listed as fire exit hardware for A label and lesser class 4' x 8' single or 8' x 8' double doors; UL symbol on rear cover label indicates listing. Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Corbin Russwin, Inc. makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings. Warnock Hersey International Inc. ED8200B listed as fire exit hardware for installation on up to 1-1/2 hour fire doors, up to 8' x 8'. California State Reference Code This product has been approved by the California State Fire Marshal (CSFM) pursuant to Section 13144.1 of the California Health and Safety Code. NFPA All exit devices comply with NFPA 101 Life Safety Code. All fire-rated devices comply with NFPA 80 Fire Doors and Windows. ADA Exit devices, lever trims and pulls comply with Americans with Disabilities Act.

Corbin Russwin ED 8200A Fire Rated Rim Exit Device

Handing- Non-handed.

Finishes:

689-Aluminum Painted

Bar Length: Easily field cut to size.

Standard: 36" bar fits 31" - 36" (787mm-914mm) door..

Door Thickness: 1-3/4" (44mm) standard.

Backset: 2-3/4" (70mm). Device and trim cover standard

Latchbolt: 3/4" (19mm) stainless steel pullman-type with stainless steel deadlocking latch

Materials: Heavy-duty wrought steel chassis and pushpad; aluminum front and rear bar covers; stainless steel springs; nylon bearings.

Dogging: Standard on ED8200 devices: single point 1/4 turn dogging.

Optional: less dogging; specify M51(Call To See If Its Avail.).

Fasteners: Standard on ED8200 devices: machine screws and wood door fasteners.

Certification/Compliance ANSI Meets A156.3, Type 1, Grade 1. Meets A117.1 Accessibility Code. C-UL US All devices listed for safety as panic hardware; devices comply with UL 305 standards for panic hardware. UL symbol on rear cover label indicates listing. Three-hour fire-rated devices listed as fire exit hardware for A label and lesser class 4' x 8' single or 8' x 8' double doors; UL symbol on rear cover label indicates listing. Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Corbin Russwin, Inc. makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings. Warnock Hersey International Inc. ED8200B listed as fire exit hardware for installation on up to 1-1/2 hour fire doors, up to 8' x 8'. California State Reference Code This product has been approved by the California State Fire Marshal (CSFM) pursuant to Section 13144.1 of the California Health and Safety Code. NFPA All exit devices comply with NFPA 101 Life Safety Code. All fire-rated devices comply with NFPA 80 Fire Doors and Windows. ADA Exit devices, lever trims and pulls comply with Americans with Disabilities Act.

Corbin Russwin ED4200 Narrow Stile Rim Exit Device - Barzellock.com

Corbin Russwin ED4200 Narrow Stile Rim Exit Device

Handing: Device non-handed.

Instructions

Bar Length: Easily field cut to size.

Standard: 36" (914mm) bar fits 30"- 36"

Optional: 48" (1219mm) bar fits 36"- 48" (914mm-1219mm) door; specify W048.

Finishes:

630-Satin Stainless Steel

613-Oil Rubbed Bronze

606-Satin Brass

Door Thickness: 1-3/4" (44mm) standard

Latchbolt: 3/4" (19mm) throw, pullman type with stainless steel deadlocking latch.

Dogging Standard: single point 1/4 turn hex key dogging.

Contact Us To See If We Have These Options In Stock

Optional: less dogging; specify M51.

Optional: cylinder dogging; specify M52.

Optional: electric dogging; specify M97.

Strike: Surface mounted 3/8" (10mm) diameter roller strike, complete with positive locking plate and shims.

Warranty: Five-year limited.

Certification/Compliance ANSI Meets A156.3, Type 4, Grade 1. Meets A117.1 Accessibility Code. UL/cUL All devices listed for safety as panic hardware; devices comply with UL 305 standards for panic hardware. UL symbol on active case cover indicates listing. California State Reference Code This product has been approved by the California State Fire Marshal pursuant to section 13144.1 of the California Health and Safety Code. NFPA All exit devices comply with NFPA 101 Life Safety Code. ADA Exit devices, lever trims and pulls comply with Americans with Disabilities Act.

Corbin Russwin ED4400 Narrow Stile Surface Vertical Rod Exit Device

Handing: Device is handed but easily field reversible.

Finish:

630-Satin Stainless Steel

613-Oil Rubbed Bronze

Bar Length: Easily field cut to size. Standard: 36" (914mm) bar fits 30"- 36" (762mm-914mm) door

Door Thickness: 1-3/4" (44mm) standard.

Stile: Minimum width 2" (51mm).

Door Height: Standard: Top rod for 7' door. All top rods easily field cut to size.

Latchbolt: Top: 3/4" (19mm) throw, pullman type with automatic deadlatching. Bottom: 5/8" (16mm) throw deadbolt, held retracted during door swing

Vertical Rods: 1/2" O.D. tubular brass, bronze or stainless steel with rod guides

Materials: Heavy-duty cold-forged steel chassis; heavy-gauge steel mechanisms, electroplated for corrosion resistance; finished parts are brass, bronze or stainless steel; stainless steel springs; nylon bearings.

Projection: 3-1/4" (83mm) active, 2-3/4" (70mm) dogged.

Dogging: Standard: single point 1/4 turn hex key dogging.

Fasteners: Standard: machine screws.

Strike: Top: Adjustable roller strike with positive locking plate and shims. Bottom: flush mounted.

Warranty: Five-year limited.

Certification/Compliance ANSI Meets A156.3, Type 5, Grade 1. UL/cUL All devices listed for safety as panic hardware; devices comply with UL 305 standards for panic hardware. UL symbol on active case cover indicates listing. California State Reference Code This product has been approved by the California State Fire Marshal pursuant to section 13144.1 of the California Health and Safety Code. NFPA All exit devices comply with NFPA 101 Life Safety Code. ADA Lever trims and pulls comply with Americans with Disabilities Act.

Corbin Russwin ED5200 Rim Exit Device - Barzellock.com

Corbin Russwin ED5200 Rim Exit Device

by Corbin Russwin
$ 1,250.00

Corbin Russwin ED5200  Rim Exit Device

Handing: Standard Device is non-handed.

ED5200 Installation Instructions

ED5200 Product Templates

Bar Length: Easily field cut to size.

Standard: 36" (914mm) bar fits 30"- 36"

Optional: 48" (1219mm) bar fits 36"- 48" (914mm-1219mm) door; specify.

Finishes:

630-Satin Stainless Steel

613-Oil Rubbed Bronze

606-Satin Brass

Door Thickness: 1-3/4" (44mm) standard

Latchbolt: 3/4" (19mm) throw,Stainless Steel pullman type with stainless steel deadlocking latch.

Dogging Standard: single point 1/4 turn hex key dogging.

Contact Us To See If We Have These Options In Stock

Optional: less dogging; specify M51.

Optional: cylinder dogging; specify M52.

Optional: electric dogging; specify M97.

Strike: Surface mounted 3/8" (10mm) diameter roller strike, complete with positive locking plate and shims, assuring low friction relocking for a long, trouble-free life.

Warranty: Five-year limited.

Certification/Compliance ANSI Meets A156.3, Type 1, Grade 1. Meets A117.1 Accessibility Code. UL /cUL All devices listed for safety as panic hardware; devices comply with UL 305 standards for panic hardware. Three-hour fire-rated devices listed as fire exit hardware for A label and lesser class 4' x 8' single or 8' x 8' double doors; UL symbol on active case cover indicates listing. Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Corbin Russwin, Inc. makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings. California State Reference Code This product has been approved by the California State Fire Marshal pursuant to section 13144.1 of the California Health and Safety Code. NFPA All exit devices comply with NFPA 101 Life Safety Code. All fire-rated devices comply with NFPA 80 Fire Doors and Windows. ADA Exit devices, lever trims and pulls comply with Americans with Disabilities Act.

Corbin Russwin ED5200A Fire Rated Rim Exit Device - Barzellock.com

Corbin Russwin ED5200A Fire Rated Rim Exit Device

Handing: Standard Device is non-handed.

Instructions

Bar Length: Easily field cut to size.

Standard: 36" (914mm) bar fits 30"- 36"

Optional: 48" (1219mm) bar fits 36"- 48" (914mm-1219mm) door; specify.

Finishes:

630-Satin Stainless Steel



Door Thickness: 1-3/4" (44mm) standard

Latchbolt: 3/4" (19mm) throw,Stainless Steel pullman type with stainless steel deadlocking latch.

Dogging Standard: single point 1/4 turn hex key dogging.

Contact Us To See If We Have These Options In Stock

Optional: less dogging; specify M51.

Optional: cylinder dogging; specify M52.

Optional: electric dogging; specify M97.

Strike: Surface mounted 3/8" (10mm) diameter roller strike, complete with positive locking plate and shims, assuring low friction relocking for a long, trouble-free life.

Warranty: Five-year limited.

Certification/Compliance ANSI Meets A156.3, Type 1, Grade 1. Meets A117.1 Accessibility Code. UL /cUL All devices listed for safety as panic hardware; devices comply with UL 305 standards for panic hardware. Three-hour fire-rated devices listed as fire exit hardware for A label and lesser class 4' x 8' single or 8' x 8' double doors; UL symbol on active case cover indicates listing. Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Corbin Russwin, Inc. makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings. California State Reference Code This product has been approved by the California State Fire Marshal pursuant to section 13144.1 of the California Health and Safety Code. NFPA All exit devices comply with NFPA 101 Life Safety Code. All fire-rated devices comply with NFPA 80 Fire Doors and Windows. ADA Exit devices, lever trims and pulls comply with Americans with Disabilities Act.

Features:
  • Patented top latching mechanism interlocks door to frame
  • Strong, durable construction for a high level of security
  • Adjustable steel rods protected in contoured covers
  • Easy to install
  • Clean, unobtrusive design
  • Pushbar clad or anodized, not plated, in a variety of finishes

Specifications:
• UL 305 Panic Hardware
• Warnock/Hersey Life-Safety Listing
• ANSI/BHMA A156.3 Grade 1
• California State Fire Marshall
• New York City MEA*

*Consult Factory for specific number

Materials: Pushbar made of extruded aluminum, clad or anodized in a variety of finishes.

Handing: Device is non-handed. Lever Entry Trim is field reversible.

Pushbar Length: Standard sizes: dimensioned for 30”, 36”, 42”, and 48” openings. Standard width bars can be field cut to the next smallest opening width.

Bar Height: Standard model adjusts from 30” to 44”.

Door Height: Standard model fits up to 8 ft door, with bar height at 40”- 44”. For doors up to 10 ft, use Tall Door Kit 8055.

Door Thickness: Suits 1-3/4” standard, up to 2-1/4”.

Stile Width: Minimum 2” stile. Fits narrow, medium, and wide stile aluminum doors.

Projection: 2-15/16” when fully projected, 1-15/16”when dogged.

Dogging: Standard dogging with hex key

Corbin Russwin ED5400 Surface Vertical Rod Exit Device - Barzellock.com

Corbin Russwin ED5400 Surface Vertical Rod Exit Device

Handing: Device is handed but easily field reversible. Lever trim is handed.

ED5000 Catalog

Finish:

630-Satin Stainless Steel

626-Satin Chrome

613-Oil Rubbed Bronze

612-Satin Bronze

Bar Length: Easily field cut to size. Standard: 36" (914mm) bar fits 30"- 36" (762mm-914mm) door Optional: 48" (1219mm) bar fits 36"-48" (914mm-1219mm) door; specify W048.

Door Thickness: 1-3/4" (44mm) standard.

Stile: Minimum width 4-1/2" (114mm).

Door Height: Standard top rod for 7' door. All rods easily field cut to size.

Latchbolt: Top: 3/4" (19mm) throw, stainless steel pullman-type with automatic deadlatching. Bottom: 5/8" (16mm) throw deadbolt, held retracted during door swing.

Vertical Rods: 1/2" O.D. tubular brass, bronze or stainless steel with rod guides.

Materials: Heavy-duty cold-forged steel chassis; heavygauge steel mechanisms, electroplated for corrosion resistance; finished parts are brass, bronze or stainless steel; stainless steel springs; nylon bearings.

Projection: 3-1/4" (83mm) active, 2-3/4" (70mm) dogged

Dogging: Standard on panic devices; single-point 1/4 turn hex key dogging.

Optional: Cylinder dogging less Cylinder,

Fasteners: Standard on panic devices: machine screws and wood door fasteners. Standard on fire-rated devices: sex nuts and bolts

Strike Top: adjustable roller strike with positive locking plate and shims. Bottom: flush mounted.

Warranty: Five-year limited.

Certification/Compliance ANSI Meets A156.3, Type 2, Grade 1. UL /cUL All devices listed for safety as panic hardware; devices comply with UL 305 standards for panic hardware. Three-hour fire-rated devices listed as fire exit hardware for A label and lesser class 8’ x 8’ double doors; ­UL symbol on active case cover indicates listing. Any retrofit or other field modification to a fire- rated opening can potentially impact the fire rating of the opening, and Corbin Russwin, Inc. makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings. California State Reference Code This product has been approved by the California State Fire Marshal pursuant to section 13144.1 of the California Health and Safety Code. NFPA All exit devices comply with NFPA 101 Life Safety Code. All fire-rated devices comply with NFPA 80 Fire Doors and Windows. ADA Lever trims and pulls comply with Americans with Disabilities Act.

Corbin Russwin ED5400A Fire Rated Surface Vertical Rod Exit Device

Handing: Device is handed but easily field reversible. Lever trim is handed.

ED5000 Catalog

Finish:

630-Satin Stainless Steel

626-Satin Chrome

613-Oil Rubbed Bronze

612-Satin Bronze

Bar Length: Easily field cut to size. Standard: 36" (914mm) bar fits 30"- 36" (762mm-914mm) door Optional: 48" (1219mm) bar fits 36"-48" (914mm-1219mm) door; specify W048.

Door Thickness: 1-3/4" (44mm) standard.

Stile: Minimum width 4-1/2" (114mm).

Door Height: Standard top rod for 7' door. All rods easily field cut to size.

Latchbolt: Top: 3/4" (19mm) throw, stainless steel pullman-type with automatic deadlatching. Bottom: 5/8" (16mm) throw deadbolt, held retracted during door swing.

Vertical Rods: 1/2" O.D. tubular brass, bronze or stainless steel with rod guides.

Materials: Heavy-duty cold-forged steel chassis; heavygauge steel mechanisms, electroplated for corrosion resistance; finished parts are brass, bronze or stainless steel; stainless steel springs; nylon bearings.

Projection: 3-1/4" (83mm) active, 2-3/4" (70mm) dogged

Dogging: Standard on panic devices; single-point 1/4 turn hex key dogging.

Optional: Cylinder dogging less Cylinder,

Fasteners: Standard on panic devices: machine screws and wood door fasteners. Standard on fire-rated devices: sex nuts and bolts

Strike Top: adjustable roller strike with positive locking plate and shims. Bottom: flush mounted.

Warranty: Five-year limited.

Certification/Compliance ANSI Meets A156.3, Type 2, Grade 1. UL /cUL All devices listed for safety as panic hardware; devices comply with UL 305 standards for panic hardware. Three-hour fire-rated devices listed as fire exit hardware for A label and lesser class 8’ x 8’ double doors; ­UL symbol on active case cover indicates listing. Any retrofit or other field modification to a fire- rated opening can potentially impact the fire rating of the opening, and Corbin Russwin, Inc. makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings. California State Reference Code This product has been approved by the California State Fire Marshal pursuant to section 13144.1 of the California Health and Safety Code. NFPA All exit devices comply with NFPA 101 Life Safety Code. All fire-rated devices comply with NFPA 80 Fire Doors and Windows. ADA Lever trims and pulls comply with Americans with Disabilities Act.

Corbin Russwin ED5800 & ED5800A Fire Concealed Vertical Rod Exit Device 630 finish

Handing: Device is handed but easily field reversible. Lever trim is handed.

Bar length: Easily field cut to size. Standard: 36" (914mm) bar fits 30"- 36" (762mm-914mm) door.

Finish: 630-Satin Stainless Steel

ED5800 & ED5800A Catalog

Door Thickness: 1-3/4" (44mm) standard

Stile: Minimum width 4-1/2" (114mm).

Door Height: Standard: top rod for 8' door.

Latchbolt: Top: 3/4" (19mm) throw, stainless steel pullman-type with automatic deadlatching. Bottom: 5/8" (16mm) throw deadbolt, held retracted during door swing.

Vertical Rods: 1/2" O.D. tubing, electroplated for corrosion resistance.

Materials: Heavy-duty cold-forged steel chassis; heavygauge steel mechanisms, electroplated for corrosion resistance; finished parts are brass, bronze or stainless steel; stainless steel springs; nylon bearings.

Projection: 3-1/4" (83mm) active

Dogging: Standard on panic devices; single-point 1/4 turn hex key dogging.

Fasteners: Standard on panic devices: machine screws. Standard on fire-rated devices: sex nuts and bolts.

Strike: Top: roller type. Bottom: flush mounted.

Applications and Listings: For use on metal doors only

Warranty: Five-year limited.

Certification/Compliance ANSI Meets A156.3, Type 8, Grade 1. Meets A117.1 Accessibility Code. UL/cUL All devices listed for safety as panic hardware; devices comply with UL 305 standards for panic hardware. Three-hour fire-rated devices listed as fire exit hardware for A label and lesser class 8' x 8' double doors; UL symbol on active case cover indicates listing. Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Corbin Russwin, Inc. makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings. California State Reference Code This product has been approved by the California State Fire Marshal pursuant to section 13144.1 of the California Health and Safety Code. NFPA All exit devices comply with NFPA 101 Life Safety Code. All fire-rated devices comply with NFPA 80 Fire Doors and Windows. ADA Exit devices, lever trims and pulls comply with Americans with Disabilities Act.

Corbin Russwin ED8400 Surface Verticle Rod Exit Device - Barzellock.com

Corbin Russwin ED8400 Surface Verticle Rod Exit Device

Handing: Handed; specify hand.

Finish:

689-Aluminum Painted

691-Light Bronze Painted

Instructions

ED 8400 Catalog

Bar Length: Easily field cut to size.

Standard: 36" bar fits 31"- 36" (787mm-914mm) door.

Optional: 30" bar fits 28" - 30" (711mm-762mm) door; .

Optional: 42" bar fits 37" - 42" (940mm-1067mm) door; .

Optional: 48" bar fits 43" - 48" (1092mm-1219mm) door;

Door Thickness: 1-3/4" (44mm) standard.

Backset: 2-3/4" (70mm). Device and trim cover standard

Door Height: All top rods easily field cut to size. Standard on ED8400 devices: top rod for 7'6" door.

Latchbolts ED8400 devices: Top: 1/2" interlocking drop latch. Bottom: 5/8" pivoted.

Materials: Heavy-duty wrought steel chassis and pushpad; steel vertical rods; aluminum bar and latch covers; stainless steel springs; nylon bearings.

Dogging: Standard on ED8400 devices: single point 1/4 turn dogging.

Fasteners: Standard on ED8400 devices: machine screws and wood door fasteners.

Warranty: One-year limited.

Certification/Compliance ANSI Meets A156.3, Type 2, Grade 1. C-UL US All devices listed for safety as panic hardware; devices comply with UL 305 standards for panic hardware. UL symbol on rear cover label indicates listing. Threehour fire-rated devices listed as fire exit hardware for A label and lesser class 8' x 8' double doors; UL symbol on rear cover label indicates listing. Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Corbin Russwin, Inc. makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings. California State Reference Code This product has been approved by the California State Fire Marshal (CSFM) pursuant to Section 13144.1 of the California Health and Safety Code. NFPA All exit devices comply with NFPA 101 Life Safety Code. All fire-rated devices comply with NFPA 80 Fire Doors and Windows. ADA Lever trims and pulls comply with Americans with Disabilities Act.

Corbin Russwin ED8400A Fire Rated Surface Verticle Rod Exit Device

Handing: Handed; specify hand.

Finish:

689-Aluminum Painted

691-Light Bronze Painted

Instructions

ED 8400 Catalog

Bar Length: Easily field cut to size.

Standard: 36" bar fits 31"- 36" (787mm-914mm) door.

Door Thickness: 1-3/4" (44mm) standard.

Backset: 2-3/4" (70mm). Device and trim cover standard

Door Height: All top rods easily field cut to size. Standard on ED8400 devices: top rod for 7'6" door.

Latchbolts ED8400 devices: Top: 1/2" interlocking drop latch. Bottom: 5/8" pivoted.

Materials: Heavy-duty wrought steel chassis and pushpad; steel vertical rods; aluminum bar and latch covers; stainless steel springs; nylon bearings.

Dogging: Standard on ED8400 devices: single point 1/4 turn dogging.

Fasteners: Standard on ED8400 devices: machine screws and wood door fasteners.

Warranty: One-year limited.

Certification/Compliance ANSI Meets A156.3, Type 2, Grade 1. C-UL US All devices listed for safety as panic hardware; devices comply with UL 305 standards for panic hardware. UL symbol on rear cover label indicates listing. Threehour fire-rated devices listed as fire exit hardware for A label and lesser class 8' x 8' double doors; UL symbol on rear cover label indicates listing. Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Corbin Russwin, Inc. makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings. California State Reference Code This product has been approved by the California State Fire Marshal (CSFM) pursuant to Section 13144.1 of the California Health and Safety Code. NFPA All exit devices comply with NFPA 101 Life Safety Code. All fire-rated devices comply with NFPA 80 Fire Doors and Windows. ADA Lever trims and pulls comply with Americans with Disabilities Act.

The 10 Series rim exit device is super-heavy-duty panic and fire exit hardware for use on all types of single and double doors with mullions. The patented mounting plate and strike locator system ensures the easiest and most accurate installation of panic hardware available.    Barzel Lock Stocks The Detex 10 Advantex Rim Exit Device In All Options.

Installation Video

Benefits:

• Tough and durable design for years of trouble-free service in high-use, high-abuse environments

• Fast and accurate installation

• Minimal door prep saves time and money

• Outside trims are easily changed or re-keyed without removing device from door

Features:

• Patented mounting plate and strike locator system replaces paper templates

• Stainless steel deadlocking, Pullman-type latch bolt

• Tested beyond 1,000,000 cycles - Twice the cycling required for Grade 1 UL testing

• All exposed surfaces are finished over stainless steel with PVD, an environmentally-friendly finishing process

• Heavy-duty angled end-cap deflects damage away from device

• Non-handed

• Field sizeable

• 1/8 turn hex or cylinder dogging

Mechanical Options:

• HD - Hex Dogging (Std.)

• 99 - Surface Strike (Std.)

• 36 - Fits 36" Door Width (Std.)


Catalog For Detex 10 Series Advantex Rim Exit Device





Detex ECL-230D Alarmed Deadbolt Panic Device - Barzellock.com

Detex ECL-230D Battery Alarmed Deadbolt Panic Device ECL-230D-PH. The ECL-230 is a code compliant, battery alarmed, rugged dead bolt, panic device with steel plate and photo-luminescent sign providing managed security and a 100 decibel alarm for secondary exits.


Detex ECL-230D Installation Instructions



• Attack resistant design withstands over 2200 lbs. of outside pull force

• Proven durability and reliability at a reasonable price

• Reduces employee and customer theft

• Single point, 1" throw dead bolt

• Saw resistant dead bolt

• Corrosion resistant alloy lock body

• 100 decibel alarm, powered by 9-volt battery (included)

• Easy to install

• Door Types - Wood, Hollow Metal or Aluminum

• Door Thickness - Fits standard 1-3/4" - 2-1/4"

• Minimum standard door width for ECL-230D is 20"

• Minimum standard door width for ECL-230D-PH is 34"

• Time tested construction resists attack from the inside

• Durable steel plate with photo luminescent sign absorbs light to then “glow in the dark” when lights are dimmed

• Easy to see if the lights go out

• Straightforward operation that everyone understands

• Accepts 5-pin through 7-pin standard and interchangeable core rim cylinders

• Resetting the alarm can only be accomplished with a control key

• Non-handed

• Locking and unlocking the dead bolt always arms and disarms the alarm

Detex ECL-230X Deadbolt Panic Device Alarm Grey - Barzellock.com

The ECL-230X is a code compliant, battery alarmed, rugged dead bolt, panic device with photoluminescent sign providing maximum security and a 100 decibel alarm for secondary exits.

Attack resistant design for maximum holding force

• Proven durability and reliability at a reasonable price

• Easy to install

• Dead bolt lock -1” throw with just over 3/4” engagement with the frame

• Saw resistant dead bolt

• Corrosion resistant alloy lock body

• 100 decibel alarm, powered by 9-volt battery (included)

• Surface/flush reversible strike

• Reduces employee and customer theft

• Time tested construction resists attack from the inside

• One size fits 36”-48” doors for code compliant acceptance

• For additional security with 4 locking points, specify ECL-230X-DX3

• Easy to see if the lights go out

• Straightforward operation that everyone understands

• Accepts 5-pin through 7-pin standard and interchangeable core rim cylinders without using cylinder collar

• Durable photo-luminescent sign absorbs light to then "glow in the dark" when lights are dimmed

• Locking and unlocking (dead bolt) always arms and disarms the alarm

• Non-handed

• Low profile meets International Building Code requirement allowing for 4” maximum projection off face of door

• Resetting the alarm can only be accomplished with a control key

• For 9VDC hardwiring add BE-961-1 or BE-961-2
