Schlage Electronics CO100-CY-70-KP

CO-100 models are designed for use as easy to manage, low maintenance locks that use 3-6 digit PIN codes as credentials. Administrator level users can program it right at the door to add or delete user PIN codes or change preferences or functions at any time.



CO-100 Standalone Electronic Lock, Cylindrical, Classroom Function, Keypad Reader



How to order chart

They are ideal for:

  • Visitor pass through/common areas
  • Vestibules or reception area doors controlled by remote release
  • Pool gates, breezeways and other outdoor applications
  • Maintenance areas
  • Supply closets/equipment rooms
  • Workout rooms
  • Restrooms/bathrooms
  • Dressing/fitting rooms
  • Maternity/nursing rooms
  • Other private rooms needing occupancy indication

Security

  • Helps to minimize key distribution to ensure the integrity of the key system over time
  • Classroom/storeroom function can be used to secure doors and gates indoors and out
  • Office and privacy function options for application on interior or perimeter doors
  • Available with Schlage’s full complement of key cylinder options including levers designed for compatibility with many other OEM cylinders
  • Compatible with most major brands of exit devices

Efficiency

  • Manages up to 500 unique 3-6 digit PIN codes with user rights stored on the lock
  • Utilize existing master key system
  • Low lifetime cost of ownership

Convenience

  • PIN codes can be issued and revoked quickly, right at the keypad
  • Normal, toggle, pass through, and freeze programming options
  • Occupancy indication programmable option available on privacy function locks
  • Up to 2 years battery life with status indicator for easy maintenance

Certifications

  • ANSI/BHMA A156.25 full outdoor (70 function)
  • ANSI/BHMA, Grade 1
  • UL 294
  • UL 10C
  • UL Canada
  • FCC Part 15
  • ADA

Meets or exceeds

  • Cylindrical - ANSI/BHMA A156.2, Series 4000, Grade 1
  • Mortise - ANSI/BHMA A156.13, Series 1000, Grade 1
  • Exit trim - ANSI/BHMA A156.3

For full electronic specifications please reference the CO-100 data sheet.

Reader options

  • Keypad only

User verification

  • Capable of credential verification <1 second
  • Up to 500 users
  • Remote release available on Office function locks

Programming options

Basic users can:

  • Enter assigned PIN code to unlock door momentarily from normally locked state

Managers can:

  • Be assigned toggle code priveges to change the lock to an unlocked state and back when desired
  • Assign or delete basic user PIN codes

Administrators can:

  • Assign or delete basic user PIN codes
  • Change programming codes
  • Adjust desired relock delay from 1-120 seconds
  • Put lock into freeze state that cannot be toggled
  • Use a pass-through code to momentarily unlock regardless of current state
  • Disable or enable remote features like release or occupancy indication where available

Additional

  • Programmable privacy function option provides lighted occupancy indication when in use
  • Battery life - up to 2 years with 4 AA batteries
  • Exterior Temp: -31° to 151°F (-35° to 66°C)
  • Interior Temp: 32° to 120°F (0° to 49°C) (battery)
  • Humidity: 0 - 100% non-condensing



For full mechanical specifications please reference the CO-100 data sheet.

Chassis

  • Cylindrical
  • Mortise
  • Exit trim
  • Each offered with LED status indicator

Cylinder and keys

  • Standard keyway: Schlage 6-pin Everest 29 S123 with two patented keys
  • Classic and restricted keyways, master keying and grand master keying options
  • Key-in-lever, FSIC, and SFIC cylinder options
  • Less cylinder options to fit common Sargent®, Corbin Russwin®, Medeco®, Yale® and Falcon® cylinders

Functions

  • 70 Classroom/Storeroom



Category information

Product information

Schlage BE467F Smart Deadbolt

Schlage BE467F Smart Deadbolt

by Schlage
$ 333.00

MANY COLORS IN STOCK IN ADD OR GRW.

PLEASE CALL US AT 718-957-0007 TO CHECK AVAILABILITY.



Designed for multi-family properties

Eliminates the cost and hassle of managing keys

Two styles with a broad selection of finishes and suited decorative lever designs

Modern credentials - use a smart credential or smartphone as key

Upgrades property visual appeal

Increases intelligence and efficiency for property managers

Lock programming via mobile application on phone or tablet (Bluetooth connection)

Improves security and safety, reduces liability

ADA compliant

Supports networked (Gateway required), No-Tour and standalone applications

Up to 500 users per lock*

Audit trail reports up to 1,000 events**

Easy installation no wires to run and fits standard door prep

Up to 1 years (offline mode), up to 1 year (BLE credential enabled)

Also available as interconnected lock

*Maximum database storage capacity of lock. Can vary by access control software database capacity

** Maximum audit storage capacity of lock. Can vary by access control software audit storage capacity



Schlage Control Smart Lock Catalog

ADA Compliant: Yes



Applications: Residential single- and multi-family doors



Backset: Adjustable backset, fits 2-3/8 to 2-3/4 backsets



Battery: 4-AA batteries (included), 9V Battery Backup (If loss of battery power occurs, a 9V battery can be used to jump start the lock and provide access with an assigned credential.)



Door thickness range: 1-3/8 to 1-3/4 (thick door kit available up to 2-1/4)



Latch: 1" x 2-1/4" square and round corner faceplate (round corner standard, square corner included in package), 1" edge bore required



Material: All-metal chassis and escutcheons



Strike: 1-1/8 x 2-3/4, round corner, no box, latch strike



Warranty: Lifetime limited mechanical and finish; 1-year limited electronics

Schlage S210PD Interconnected Lock

Schlage S200 interconnected locks are designed to offer easy egress and dependable security with four single- or double-keyed functions each made for single motion egress. Focusing on safety, security and long-lasting performance, this lock is tested to exceed 400,000 ANSI cycles. The S200 is easy to install, service, and maintain to keep people and property secure.

Ideal for use on multifamily entrances, military-housing entrances, and small hotel/motel buildings.

Security

  • UL listed for 3-hour fire door
  • Heat-treated steel locking components for extra strength
  • Solid zinc bolt with hardened steel anti-saw pin
  • Metal wood frame reinforcer uses 3" screws to anchor deep into wood door frame to protect against kick-in attacks
  • Free spinning, cylinder collar resists wrenching and prying
  • Removeable security shield protects bolt from ice-pick attack through the door
  • Patented Everest 29™ S123 keyway is provided standard which prohibits unauthorized key duplication
  • Restricted geographically exclusive Primus upgraded security options offer advanced key control and exceptional physical security
  • UL 437 listed option resists drilling and physical attack on the cylinder



Aesthetics

  • Four lever options in solid cast zinc for strength and quality
  • Two escutcheon designs
  • Seven available finish options



Functional features

  • Five functions include single and double locking options plus a non-keyed dummy function
  • Adjustable backset has a lock-in-place helix design



Built to Last

  • Independent heavy-duty lever torsion springs for durability and long life
  • Every Schlage lock undergoes intensive testing to determine its ANSI grade level including: cycle, resistance, door impact, warped door and bolt strength tests



Non-keyed dummy functions

  • S290 Single dummy trim (ANSI F75)



Keyed functions

Single cylinder

  • S210 Entrance, single locking (ANSI F95)
  • S251 Entrance, double locking (ANSI F97)
  • S270 Classroom lock
  • S280 Storeroom lock (ANSI F98)

Material

  • Deadbolt: Zinc with hardened steel anti-saw pin insert
  • Deadbolt trim ring: 7/16" and 1/8" solid brass
  • Cylinder: Solid brass in a solid zinc housing
  • Deadbolt wood frame reinforcer: Metal with 3" screws standard
  • Latchbolt dust box: Polypropylene
  • Chassis: Zinc and steel components zinc dichromate plated for corrosion resistance



Door Thickness

  • Door thickness: 1-3/8" to 2" (35 mm to 51 mm) standard
  • Non-handed except Flair design



Trim Options

  • Four lever designs made of pressure cast zinc, plated to match product finish specification
  • Escutcheons: wrought brass, plated to match product finish specification



Deadbolt

  • 1" housing diameter; 0.81" x 0.62" x 1" throw
  • Backset: adjustable for 2-3/8" (60 mm) or 2-3/4" (70 mm) standard for standard non-fire-rated and optional fire-rated versions; fire-rated deadbolt with 5" fixed backset optional
  • Faceplate: square corner 1-1⁄8" x 2-1/4" (29 mm x 57 mm) standard; round corner options available
  • Strike: 1-1/8" x 2-3/4" with square corners standard; ANSI, round cornered, and thimble options available



Latch

  • Backset: Adjustable 2-3/8" or 2-3/4" backset (60 mm or 70 mm) standard; 5" optional
  • Latchbolt: 1/2" (13 mm) throw brass, chrome plated standard
  • Faceplate: square corner 1" x 2-1/4" (25 mm x 57 mm) standard; round corner option available
  • Strike: 1-1⁄8" x 2-3/4" (29 mm x 70 mm) T-strike standard; ANSI and radius corner strike options available
  • Strike lip length: 1-1⁄8" (29 mm) standard; extended lip strikes - 1-1/4" to 2" optional

Related Product Information

Product Information



Technical resources

Expert Tips on Schlage Lever Handle Removal

Training on Demand Library of Virtual Event Trainings

Allegion 101 Sercure the Door: Intro to Schlage Cylinders, Keys and Key Systems

Schlage FE410F Smart Interconnected Lock

LARGE QUANTITY IN STOCK!

PLEASE CALL US AT 718-957-0007 TO CHECK AVAILABILITY.

Designed specifically for multifamily properties

Eliminated the cost and hassle of managing keys

Two styles with a broad selection of finishes and decorative lever designs

Modern credentials - use a smart credential or smartphone as key

Interconnected design provides single motion egress

Upgrades property visual appeal

Increases intelligence and efficiency for property managers

Lock programming via mobile application on phone or tablet (Bluetooth connection)

Improves security and safety, reduces liability

ADA compliant

Supports networked (Gateway required), No-Tour and standalone applications

Up to 500 users per lock*

Audit trail reports up to 1,000 events**

Easy installation no wires to run and fits standard door prep

Up to 1 1/2-years (offline mode), up to 1 year (BLE credential enabled)

Also available as a deadbolt

*Maximum database storage capacity of lock. Can vary by access control software database capacity

**Maximum audit storage capacity of lock. Can vary by access control software audit storage capacity

ADA Compliant: Yes

Backset: Adjustable backset, fits 2-3/8 to 2-3/4 backsets

Battery: 4-AA batteries (included), 9V Battery Backup (If loss of battery power occurs, a 9V battery can be used to jump start the lock and provide access with an assigned credential.)

Certifications:

Commercial Standard Certification:ANSI/BHMA A156.12 Grade 2, UL 90 minute, Canada UL 20 minute wood door rated, FCC Part 15, FBC

Door thickness range: 1-3/8" to 1-3/4" (thick door kit available up to 2")

Latch: 1" x 2-1/4" square and round corner faceplate (round corner standard, square corner included in package), 1" edge bore required

Material: All-metal chassis and escutcheons

Bore: 2-1/8"

Strike: 1-1/8 x 2-3/4, round corner, no box, latch strike

Warranty: Lifetime limited mechanical and finish; 1-year limited electronics

Schlage B560 Single Cylinder Deadbolt - Barzellock.com

Schlage B560 Single Cylinder Deadbolt. The B500 Series deadbolt is a revolutionary new deadbolt that delivers higher security, tougher performance and the ultimate in installation versatility. Designed by locksmiths for locksmiths, the B500 Series deadbolt can be fitted with any Schlage cylinder, fits virtually every door you service, enhances lock strength on the jamb side of the door and will change forever the way you look at deadbolts.

Schlage B560 - Single cylinder deadbolt

• Deadbolt thrown or retracted by key outside or thumbturn inside.



Finishes: 605-Bright Brass, 606-Satin Brass, 609-Antique Brass, 612-Satin Bronze, 613-Oil Rubbed Bronze, 619-Satin Nickel, 625-Bright Chrome, 606-Satin Chrome, 643e-Aged Bronze

 • Adjustable backset with lock-in-place helix design • Integrated anti-pry shield protects latch • Thicker metal security strike back-up on jamb side • Security strike on jamb has third screw for stronger, deeper anchoring • Added space inside strike box for true deadlatch • Seamless steel construction from beginning of latch to back of bolt • 10% larger diameter deadbolt • Zinc bolt with spinning hardened steel pin inside • Tapered front housing that can’t be unscrewed • Integrated trim piece for fewer pieces out of the box • Large, easy-to-use, ADA compliant thumbturn

Features and Benefits
• 1” (25 mm) throw, high-strength steel alloy deadbolt with hardened steel roller resists sawing and kick-in attacks
• Precision-built solid brass 6-pin cylinders with phosphor bronze springs and nickel silver pins ensure long life and smooth operation
• Tough nickel silver keys for smooth, long-lasting operation
• Exclusive concealed wood frame reinforcer protects wood jamb against kick-in attacks
• Large inside thumbturn makes it easy to throw and retract deadbolt
• Security shield protects bolt from ice-pick attack through the door
• Hardened steel ball-bearings protect mounting bolts from drill attack

Specifications
Handing: B250-Series deadlatches are reversible. All other B-Series locksets are non-handed.
Door Thickness:
B250-Series, 5-pin: 13/8” to 13/4” (35mm to 44mm) standard. Available to 21/4” (57mm), assembled to order.
B500-Series, 5-pin: 13/8” to 13/4” thick (35mm to 44 mm) standard. Available to 21/4” (57mm), assembled to order.
B600/700/800-Series: 13/4” to 2” (44mm to 51mm) standard. Available for 13/8” (35mm) and doors up to 21/2” (63mm), assembled to order. Door ranges may vary by function.
Backset:
B250-Series: 23/8” (60mm) standard. 23/4” (70mm) optional.
B500-Series: Adjustable for 23/8” (60mm) or 23/4” (70mm) standard.
B600/700/800-Series: 23/4” (70mm) standard, 23/8” (60mm), 33/4” (95mm), 5” (127mm) optional.
Front: Brass, bronze or stainless steel. 11/8” x 21/4” (29mm x 57mm) square corner, beveled.
Dead Bolt: 1” (25 mm) throw with saw-resistant hardened steel insert.
Latch Bolt: Brass, 9/16” (14mm) throw, deadlocking on keyed and exterior functions.
Exposed Trim: Wrought brass, bronze or stainless steel.
Thumbturn: Pressure cast zinc, plated to match finish symbols.
Strike:
B500 Series: 11/8” x 23/4”, metal dust box reinforcer and three 3” screws. Optional strikes, lip lengths and ANSI strike box available.
B600 and B250-Series: 11/8” x 23/4” (32mm x 70mm) with steel reinforcer and two 3” screws standard.
Certifications
ANSI
:
B500 and B250-Series meet or exceed A156.5 Grade 2 strength and operational requirements.
B600/700/800-Series meets or exceeds A156.5 Grade 1 strength and operational requirements.
UL / cUL:
B600/700/800-Series locks are UL10B Listed auxiliary locks for A label single doors, 4 ’ x 8 ’.
UL10B Listing optional for B500-Series as auxiliary locks. Letter F and UL symbol on latch front indicate listing.
UL437 Listed locking cylinder optional:
Specify Primus 20-500 Series cylinder for B500 and B250-Series Grade 2 products, or specify B800-Series Grade 1 products.
ADA Compliant: Schlage Lock Company offers a wide selection of locks designed to meet the Americans With Disabilities Act.
Cylinder & Keys: 6-pin patented Everest C123 keyway standard with two nickel silver keys per lock. Items specified in C keyway will be furnished 5-pin.
Keying Options: Interchangeable core and Primus XP high security cylinders. Master keying, grand master keying and construction keying.
Warranty:
Commercial: Three-year limited.
Residential: Full lifetime mechanical.
Schlage B571 Door Bolt Occupancy Indicator - Barzellock.com

Schlage B571 Door Bolt Occupancy Indicator . The B500 Series deadbolt is a revolutionary new deadbolt that delivers higher security, tougher performance and the ultimate in installation versatility. Designed by locksmiths for locksmiths, the B500 Series deadbolt can be fitted with any Schlage cylinder, fits virtually every door you service, enhances lock strength on the jamb side of the door and will change forever the way you look at deadbolts.

Schlage B571 - Door Bolt Occupancy Indicator ANSI -

• Deadbolt thrown or retracted by thumbturn inside

• Outside indicator displays “In use” or “Vacant”

• Requires 1 1 ⁄2" cross bore prep

• Not UL rated

    Finishes: 605-Bright Brass, 606-Satin Brass, 609-Antique Brass, 612-Satin Bronze, 613-Oil Rubbed Bronze, 619-Satin Nickel, 625-Bright Chrome, 606-Satin Chrome, 643e-Aged Bronze

     • Adjustable backset with lock-in-place helix design • Integrated anti-pry shield protects latch • Thicker metal security strike back-up on jamb side • Security strike on jamb has third screw for stronger, deeper anchoring • Added space inside strike box for true deadlatch • Seamless steel construction from beginning of latch to back of bolt • 10% larger diameter deadbolt • Zinc bolt with spinning hardened steel pin inside • Tapered front housing that can’t be unscrewed • Integrated trim piece for fewer pieces out of the box • Large, easy-to-use, ADA compliant thumbturn

    Features and Benefits
    • 1” (25 mm) throw, high-strength steel alloy deadbolt with hardened steel roller resists sawing and kick-in attacks
    • Precision-built solid brass 6-pin cylinders with phosphor bronze springs and nickel silver pins ensure long life and smooth operation
    • Tough nickel silver keys for smooth, long-lasting operation
    • Exclusive concealed wood frame reinforcer protects wood jamb against kick-in attacks
    • Large inside thumbturn makes it easy to throw and retract deadbolt
    • Security shield protects bolt from ice-pick attack through the door
    • Hardened steel ball-bearings protect mounting bolts from drill attack

    Specifications
    Handing: B250-Series deadlatches are reversible. All other B-Series locksets are non-handed.
    Door Thickness:
    B250-Series, 5-pin: 13/8” to 13/4” (35mm to 44mm) standard. Available to 21/4” (57mm), assembled to order.
    B500-Series, 5-pin: 13/8” to 13/4” thick (35mm to 44 mm) standard. Available to 21/4” (57mm), assembled to order.
    B600/700/800-Series: 13/4” to 2” (44mm to 51mm) standard. Available for 13/8” (35mm) and doors up to 21/2” (63mm), assembled to order. Door ranges may vary by function.
    Backset:
    B250-Series: 23/8” (60mm) standard. 23/4” (70mm) optional.
    B500-Series: Adjustable for 23/8” (60mm) or 23/4” (70mm) standard.
    B600/700/800-Series: 23/4” (70mm) standard, 23/8” (60mm), 33/4” (95mm), 5” (127mm) optional.
    Front: Brass, bronze or stainless steel. 11/8” x 21/4” (29mm x 57mm) square corner, beveled.
    Dead Bolt: 1” (25 mm) throw with saw-resistant hardened steel insert.
    Latch Bolt: Brass, 9/16” (14mm) throw, deadlocking on keyed and exterior functions.
    Exposed Trim: Wrought brass, bronze or stainless steel.
    Thumbturn: Pressure cast zinc, plated to match finish symbols.
    Strike:
    B500 Series: 11/8” x 23/4”, metal dust box reinforcer and three 3” screws. Optional strikes, lip lengths and ANSI strike box available.
    B600 and B250-Series: 11/8” x 23/4” (32mm x 70mm) with steel reinforcer and two 3” screws standard.
    Certifications
    ANSI
    :
    B500 and B250-Series meet or exceed A156.5 Grade 2 strength and operational requirements.
    B600/700/800-Series meets or exceeds A156.5 Grade 1 strength and operational requirements.
    UL / cUL:
    B600/700/800-Series locks are UL10B Listed auxiliary locks for A label single doors, 4 ’ x 8 ’.
    UL10B Listing optional for B500-Series as auxiliary locks. Letter F and UL symbol on latch front indicate listing.
    UL437 Listed locking cylinder optional:
    Specify Primus 20-500 Series cylinder for B500 and B250-Series Grade 2 products, or specify B800-Series Grade 1 products.
    ADA Compliant: Schlage Lock Company offers a wide selection of locks designed to meet the Americans With Disabilities Act.
    Cylinder & Keys: 6-pin patented Everest C123 keyway standard with two nickel silver keys per lock. Items specified in C keyway will be furnished 5-pin.
    Keying Options: Interchangeable core and Primus XP high security cylinders. Master keying, grand master keying and construction keying.
    Warranty:
    Commercial: Three-year limited.
    Residential: Full lifetime mechanical.
    Schlage AL80PD Storeroom Lever Lock - Barzellock.com
    ALX80P Storeroom Lever Lock. Dependable performance for high traffic commercial applications.
    At Schlage we know that every product you specify has to stand up to constant use, while meeting your needs for security at every level. Our ALX-Series locks are designed to deliver ADA compliant accessibility and constant, reliable performance. The ALX-Series is best for buildings with medium to high traffic flow, such as interior office doors, banks, retailspaces and hotel guest areas. With a Grade 2 ANSI rating, and styles and finishes to suit your building’s design, the AL-Series fits right where you need it.
    ALX80P-Storeroom lock
    • Outside lever is fixed.
    • Entrance by key only.
    • Inside lever is always unlocked.
    • Inside lever always free for immediate egress.
    The lever that looks as good as it performs.
    •Cold-rolled steel, machined and threaded hubs, and locking nuts prevent loosening of the lockset by securely bolting chassis to the door
    •Large diameter of mounting plate and rose covers new ANSI hollow metal door cutout
    •Patented door range adjuster allows quick and easy adjustment for doors ranging from 1 3/8” to 1 7/8” (35 mm to 48 mm) thick

    Door Handing
    All Schlage locks are reversible. Hand information is necessary to ensure proper cylinder orientation in keyed functions, and finish of latchbolt and strike for locks that are to be installed on reverse bevel doors. Follow the diagram to correctly determine the hand of the door.
    • LEVER STYLES:          FINISHES:
    • Saturn                          626-605-606
    • Neptune                       612-613-625
    • Jupiter
    • Omega
    Specifications
    Handing: Non-handed.
    Door Thickness: 1 3/8” to 1 7/8” (35 mm to 48 mm) standard. 2” (51 mm) optional.
    Backset: 2 3/4” (70 mm) standard. 2 3/8” (60 mm), 3 3/4” (95 mm) and 5” (127 mm) optional.
    Front: Steel. 2 1/4” x 1 1/8” square corner, beveled, for 2 3/4” backset standard. Optional 1” square corner, 1” radius corner, and non-UL drive-in / round face. For availability with specific backsets.
    Lock Chassis: Steel, zinc dichromated for corrosion resistance
    Latch Bolt: Brass, chrome plated, 1/2” throw, deadlocking on keyed and exterior functions.
    Exposed Trim: Wrought brass and bronze. Levers are pressure cast zinc, plated to match finish symbols.
    Strike: ANSI curved lip strike 4 7/8” x 1 1/4” x 1 1/4” lip to center standard. Optional strikes, lip lengths and ANSI wrought strike box available.
    Cylinder & Keys: 6-pin patented Everest 29 S123 keyway standard with two nickel silver keys per lock.
    Keying Options: Interchangeable core and Primus® high security cylinders. Master keying, grand master keying, and construction keying.
    Warranty: Three-year limited.

    Certifications
    ANSI: Meets or exceeds A156.2 Series 4000, Grade 2 strength and operational requirements. Meets A117.1 Accessibility Code.
    Federal: Meets FF-H-106C.
    California State Reference Code: (Formerly Title 19, California State Fire Marshal Standard) All levers with returns comply; levers return to within 1/2” of door face.
    UL / cUL: All locks listed for A label single doors, 4’ x 8’. Letter F and UL symbol on latch front indicate listing. UL437 Listed locking cylinder optional: specify Primus 20-500 Series cylinder.
    ADA Compliant: Schlage Lock Company offers a wide selection of locks designed to meet the Americans With Disabilities Act. In compliance with the American National Standards Institute (ANSI A117.1) and the Americans with Disabilities Act (ADA), Schlage Lock Company offers a wide selection of locks designed for the needs of the physically challenged. This act is designed to provide protection for people with disabilities. The intent of ADA is that owners of certain types of buildings must remove barriers and provide people with disabilities with access equal to, or similar to, that available to the general public.
    Schlage AL50PD Entrance/Office Lever Lock - Barzellock.com

    ALX50PD Entrance/Office Lever Lock

    Dependable performance for high traffic commercial applications.
    At Schlage we know that every product you specify has to stand up to constant use, while meeting your needs for security at every level. Our ALX-Series locks are designed to deliver ADA compliant accessibility and constant, reliable performance. The ALX-Series is best for buildings with medium to high traffic flow, such as interior office doors, banks, retailspaces and hotel guest areas. With a Grade 2 ANSI rating, and styles and finishes to suit your building’s design, the AL-Series fits right where you need it.

    Entrance/office lock Features

    • Push-button locking.
    • Push-button locks outside lever until it is unlocked with a key or by rotating the inside lever.
    • Inside lever always free for immediate egress.
    The lever that looks as good as it performs.
    •Cold-rolled steel, machined and threaded hubs, and locking nuts prevent loosening of the lockset by securely bolting chassis to the door
    •Large diameter of mounting plate and rose covers new ANSI hollow metal door cutout
    •Patented door range adjuster allows quick and easy adjustment for doors ranging from 1 3/8” to 1 7/8” (35 mm to 48 mm) thick

    Door Handing
    All Schlage locks are reversible. Hand information is necessary to ensure proper cylinder orientation in keyed functions, and finish of latchbolt and strike for locks that are to be installed on reverse bevel doors. Follow the diagram to correctly determine the hand of the door.
    • LEVER STYLES:         FINISHES:
    • Saturn                          626-605-606
    • Neptune                       612-613-625
    • Jupiter
    • Omega

    Specifications

    Handing: Non-handed.
    Door Thickness: 1 3/8” to 1 7/8” (35 mm to 48 mm) standard. 2” (51 mm) optional.
    Backset: 2 3/4” (70 mm) standard. 2 3/8” (60 mm), 3 3/4” (95 mm) and 5” (127 mm) optional.
    Front: Steel. 2 1/4” x 1 1/8” square corner, beveled, for 2 3/4” backset standard. Optional 1” square corner, 1” radius corner, and non-UL drive-in / round face. For availability with specific backsets.
    Lock Chassis: Steel, zinc dichromated for corrosion resistance
    Latch Bolt: Brass, chrome plated, 1/2” throw, deadlocking on keyed and exterior functions.
    Exposed Trim: Wrought brass and bronze. Levers are pressure cast zinc, plated to match finish symbols.
    Strike: ANSI curved lip strike 4 7/8” x 1 1/4” x 1 1/4” lip to center standard. Optional strikes, lip lengths and ANSI wrought strike box available.
    Cylinder & Keys: 6-pin patented Everest 29 S123 keyway standard with two nickel silver keys per lock.
    Keying Options: Interchangeable core and Primus® high security cylinders. Master keying, grand master keying, and construction keying.
    Warranty: Three-year limited.

    Certifications:
    ANSI: Meets or exceeds A156.2 Series 4000, Grade 2 strength and operational requirements. Meets A117.1 Accessibility Code.
    Federal: Meets FF-H-106C.
    California State Reference Code: (Formerly Title 19, California State Fire Marshal Standard) All levers with returns comply; levers return to within 1/2” of door face.
    UL / cUL: All locks listed for A label single doors, 4’ x 8’. Letter F and UL symbol on latch front indicate listing. UL437 Listed locking cylinder optional: specify Primus 20-500 Series cylinder.
    ADA Compliant: Schlage Lock Company offers a wide selection of locks designed to meet the Americans With Disabilities Act. In compliance with the American National Standards Institute (ANSI A117.1) and the Americans with Disabilities Act (ADA), Schlage Lock Company offers a wide selection of locks designed for the needs of the physically challenged. This act is designed to provide protection for people with disabilities. The intent of ADA is that owners of certain types of buildings must remove barriers and provide people with disabilities with access equal to, or similar to, that available to the general public.
    Schlage B562 Double Cylinder Deadbolt - Barzellock.com

    Schlage B562 Double Cylinder Deadbolt. The B500 Series deadbolt is a revolutionary new deadbolt that delivers higher security, tougher performance and the ultimate in installation versatility. Designed by locksmiths for locksmiths, the B500 Series deadbolt can be fitted with any Schlage cylinder, fits virtually every door you service, enhances lock strength on the jamb side of the door and will change forever the way you look at deadbolts.

    Schlage B562 - Double Cylinder deadbolt- ANSI - EO142

    • Deadbolt thrown or retracted by key either side

    Finishes: 605-Bright Brass, 606-Satin Brass, 609-Antique Brass, 612-Satin Bronze, 613-Oil Rubbed Bronze, 619-Satin Nickel, 625-Bright Chrome, 606-Satin Chrome, 643e-Aged Bronze

     • Adjustable backset with lock-in-place helix design • Integrated anti-pry shield protects latch • Thicker metal security strike back-up on jamb side • Security strike on jamb has third screw for stronger, deeper anchoring • Added space inside strike box for true deadlatch • Seamless steel construction from beginning of latch to back of bolt • 10% larger diameter deadbolt • Zinc bolt with spinning hardened steel pin inside • Tapered front housing that can’t be unscrewed • Integrated trim piece for fewer pieces out of the box • Large, easy-to-use, ADA compliant thumbturn

    Features and Benefits
    • 1” (25 mm) throw, high-strength steel alloy deadbolt with hardened steel roller resists sawing and kick-in attacks
    • Precision-built solid brass 6-pin cylinders with phosphor bronze springs and nickel silver pins ensure long life and smooth operation
    • Tough nickel silver keys for smooth, long-lasting operation
    • Exclusive concealed wood frame reinforcer protects wood jamb against kick-in attacks
    • Large inside thumbturn makes it easy to throw and retract deadbolt
    • Security shield protects bolt from ice-pick attack through the door
    • Hardened steel ball-bearings protect mounting bolts from drill attack

    Specifications
    Handing: B250-Series deadlatches are reversible. All other B-Series locksets are non-handed.
    Door Thickness:
    B250-Series, 5-pin: 13/8” to 13/4” (35mm to 44mm) standard. Available to 21/4” (57mm), assembled to order.
    B500-Series, 5-pin: 13/8” to 13/4” thick (35mm to 44 mm) standard. Available to 21/4” (57mm), assembled to order.
    B600/700/800-Series: 13/4” to 2” (44mm to 51mm) standard. Available for 13/8” (35mm) and doors up to 21/2” (63mm), assembled to order. Door ranges may vary by function.
    Backset:
    B250-Series: 23/8” (60mm) standard. 23/4” (70mm) optional.
    B500-Series: Adjustable for 23/8” (60mm) or 23/4” (70mm) standard.
    B600/700/800-Series: 23/4” (70mm) standard, 23/8” (60mm), 33/4” (95mm), 5” (127mm) optional.
    Front: Brass, bronze or stainless steel. 11/8” x 21/4” (29mm x 57mm) square corner, beveled.
    Dead Bolt: 1” (25 mm) throw with saw-resistant hardened steel insert.
    Latch Bolt: Brass, 9/16” (14mm) throw, deadlocking on keyed and exterior functions.
    Exposed Trim: Wrought brass, bronze or stainless steel.
    Thumbturn: Pressure cast zinc, plated to match finish symbols.
    Strike:
    B500 Series: 11/8” x 23/4”, metal dust box reinforcer and three 3” screws. Optional strikes, lip lengths and ANSI strike box available.
    B600 and B250-Series: 11/8” x 23/4” (32mm x 70mm) with steel reinforcer and two 3” screws standard.
    Certifications
    ANSI
    :
    B500 and B250-Series meet or exceed A156.5 Grade 2 strength and operational requirements.
    B600/700/800-Series meets or exceeds A156.5 Grade 1 strength and operational requirements.
    UL / cUL:
    B600/700/800-Series locks are UL10B Listed auxiliary locks for A label single doors, 4 ’ x 8 ’.
    UL10B Listing optional for B500-Series as auxiliary locks. Letter F and UL symbol on latch front indicate listing.
    UL437 Listed locking cylinder optional:
    Specify Primus 20-500 Series cylinder for B500 and B250-Series Grade 2 products, or specify B800-Series Grade 1 products.
    ADA Compliant: Schlage Lock Company offers a wide selection of locks designed to meet the Americans With Disabilities Act.
    Cylinder & Keys: 6-pin patented Everest C123 keyway standard with two nickel silver keys per lock. Items specified in C keyway will be furnished 5-pin.
    Keying Options: Interchangeable core and Primus XP high security cylinders. Master keying, grand master keying and construction keying.
    Warranty:
    Commercial: Three-year limited.
    Residential: Full lifetime mechanical.
    Schlage AL10S Passage Lever Lock AL Series - Barzellock.com
