Hager 500 US26D Pivot Hinge

Hager 500 US26D Pivot Hinge

by Hager
$ 249.00

Full Mortise Pivot, Standard Weight, Brass, Rack and Pinion, Satin Chrome



Single acting standard weight pivots 1-3/8″ (35 mm) thru 1-3/4″ (44 mm) thick doors Maximum weight not over 80 pounds

Hager 511 26D Pivot

Hager 511 26D Pivot

by Hager
$ 250.00

Camtrol Double Acting - Hospital Set -
Rescue Hardware - Mortise Application in
Masonry Floors - Head and Floor Pivots



Description: - ANSI A5702
- Includes head and floor pivots only - use with door release #610
- For use with square edge doors on hinge side
- Wood or metal doors up to 135 lbs
- Doors not over 3' 6" x 7' (1067 mm x 2134 mm)
- Wood or metal frames

Additional Notes: - +Plastic cinch anchors
- Self Centering, centers door at 30°
- Opens 90° in each direction

Camtrol Double Acting - Hospital Set -
Rescue Hardware - Mortise Application in
Masonry Floors - Head and Floor Pivots
Pivots

Hager 512 26D Pivot

Hager 512 26D Pivot

by Hager
$ 250.00
Camtrol Double Acting - Hospital Set -
Rescue Hardware -Surface Application in
Masonry Floors - Head and Floor Pivots with Door Release (Set)
Pivots
Description: - ANSI A5702
- Includes head and floor pivots only - use with door release #610
- For use with square edge doors on hinge side
- Wood or metal doors up to 135 lbs
- Doors not over 3' 6" x 7' (1067 mm x 2134 mm)
- Wood or metal frames

Additional Notes: - +Plastic cinch anchors
- Self Centering, centers door at 30°
- Opens 90° in each direction
Hager 780-157HD Full Surface Continuous Hinge



Application:

- For surface applications where frame face dimension is limited
- Security moldings
- 1/16" (1.5 mm) inset



Clearance: - 1/32" (1 mm) minimum recommended between doors
- Plus standard lockside clearance
- Refer to Door and Frame Dimensioning in the General Information section for further details

Fasteners: - 1/4-20 x 1-1/4" Sexbolt (Screw + Post)
- #12-24 X 11/16" Flat Head Self-Drill Screws

Length Options: - Standard and Custom

Door Reinforcement: - None required

Frame Reinforcement: - None required to 200 lbs. Heavier weigh use 16-gauge channel.

Fire Rating: - Up to 3 hr. metal and 90 min. wood composite (with studs)

Warranty: - All Roton products have a lifetime warranty. When ordering electric Roton, the electric portion of the hinge has a one-year warranty.

Material: - Aluminum 6063-T6

Options:  - Hospital Tip

EPD:  - Roton Continuous Hinges Environmental Product Declaration



780-157 HD Template 95" Rev. April 2017 780157HD95-April-2017.pdf
780-157 HDTemplate 85" Rev. April 2017 780157HD85-April-2017.pdf
780-157 HD Template 83" Rev. April 2017 780157HD83-April-2017.pdf
780-157 HDTemplate 79" Rev. April 2017 780157HD79-April-2017.pdf
Application: - Can be used with any door and frame material
- Security moldings
- 1/32" (1 mm) inset



Clearance: - 1/32" (1 mm) minimum recommended for hinge side
- Plus standard lockside clearance
- 1-5/8" (41 mm) minimum frame face required plus 3/16" (5 mm) rotational clearance

Fasteners: - 1/4-20 x 1-1/4" Sexbolt (Screw + Post)
- #12-24 X 11/16" Flat Head Self-Drill Screws

Length Options: - Standard and Custom

Door Reinforcement: - None required

Frame Reinforcement: - None required to 200 lbs. Heavier weigh use 16-gauge channel.

Fire Rating: - Up to 3 hr. metal and 90 min. wood composite (with studs)

Warranty: - All Roton products have a lifetime warranty. When ordering electric Roton, the electric portion of the hinge has a one-year warranty.

Material: - Aluminum 6063-T6

Options:  - Hospital Tip

EPD:  - Roton Continuous Hinges Environmental Product Declaration



Description File Number
780-210 HD Template 119" Rev. April 2017 780210HD119-April-2017.pdf
780-210 HD Template 95" Rev. April 2017 780210HD95-April-2017.pdf
780-210 HD Template 85" Rev. April 2017 780210HD85-April-2017.pdf
780-210 HD Template 83" Rev. April 2017 780210HD83-April-2017.pdf
780-210 HD Template 79" Rev. April 2017 780210HD79-April-2017.pdf
Description File Number
Installation Instructions for UL Fire-Rated Hinge Studs 75006030
780-210HD Straight Hole Pattern Installation Instructions 75007210_780210_RevS.PDF



Hager BB1168 Heavy Weight Steel Hinge

APPLICATIONS

  • For use on heavy weight doors and doors requiring high frequency service
Hager BB1199 Heavy Weight Hinge Sold out

Hager BB1199 Heavy Weight Hinge

by Hager
Sold out
$ 62.00

SPECS

Certifications
  • ANSI A2111 (Brass), ANSI A5111 (Stainless Steel)
Finishes
  • US3, US4, US10, US10B, US15, US26, US26D, US32, US32D
Electric Modifications
  • EMN (Electric Monitor Only), ETW (Electric Through-Wire Only), ETM (Electric Through-Wire with Monitoring), Quick Connect
Box Quantity
  • 3
Case Quantity
  • 24
Features
  • Four ball bearings. Non-rising removable pin with tip and plug.
Fire Rating
  • Stainless steel model complies with NFPA80 requirements for use on fire rated door assemblies
Gauge
  • See Sizing Chart Options
Height
  • See Sizing Chart Options
Knuckles
  • 5
Material
  • Brass with Stainless Steel Pin, Stainless Steel with Stainless Steel Pin
Notes
  • Furnished with fastener hole locations that conform to standards approved by ANSI A156.7
Options
  • NRP (Non-removable pin)
  • Stamped with UL logo when ordered for export
Product Description
  • Full Mortise, Ball Bearing, Heavy Weight
Width
  • See Sizing Chart Option





TEMPLATES

Description File Number
T-Unequal Leaf Template t-unequal_leaf.pdf
Round Corner 4-1/2" - Template T311RC.pdf
Full Mortise Hinges - 5" - Template T315.pdf
Full Mortise Hinges - 127 mm - Template T315M.pdf
Reverse Safety Stud - 4 1/2" - Template T312.pdf
Reverse Safety Stud - 114 mm - Template T312M.pdf
6" T317.pdf
Reverse Safety Stud - 5" - Template T316.pdf
Reverse Safety Stud - 127 mm - Template T316M.pdf
5" x 1-3/4" Door Raised Barrel Hinge T-RB
4-1/2" x 1-3/4" Door Raised Barrel Beveled Hinges T-RBB
8" for 1-3/4" Door T318.pdf
8" for 2-1/2" Door T319.pdf
4-1/2" x 1-3/4" Raised Barrel Square Hinges T-RBS
Full Mortise Hinges - 114 mm - Template T311M.pdf
Full Mortise Hinges - 4 1/2" - Template T311.pdf
Hager BB1279 Ball Bearing Hinge

Full Mortise Ball Bearing Hinge, Standard Weight, 4-1/2" by 4-1/2", Steel, 5 Knuckle, Satin Chromium Plated Finish

Size:  - 1-6 adjustable

Certifications: - BHMA Certified ANSI A156.4, adjustable size 1-6
- ADA compliant ANSI A117.1 Accessibility Code
- UL/cUL Listed for up to 3 hours
- UL10C Positive Pressure Rated
- UL10B Neutral Pressure Rated
- Lifetime warranty

Material: - Cast Iron

Cover: - Full plastic cover - Standard
- Plated metal cover - Optional

Springs: - One piece seamless steel spring tube
- Double heat treated steel, tempered springs
- Precision machined, heat treated steel piston

Valves: - Adjustable latching and sweep speed valves
- Adjustable backcheck valve - Standard
- Delayed action valve - Optional
- Staked valves - Standard

Handing: - Non-Handed

Arms & Brackets: - Tri-Pack - Regular, Top Jamb, and Parallel Arms - Standard

Optional Arms: - Extra Heavy Duty Stop Arm
- Extra Heavy Duty Arm
- Hold Open Arm
- Extra Heavy Duty Hold Open Arm
- Extra Heavy Duty Cushion Stop Arm
- Extra Heavy Duty Hold Open Stop Arm
- Extra Heavy Duty Hold Open Cushion Stop Arm

Optional Brackets: - Regular Arm Mount - Narrow Top Rail
- Parallel Arm Mount - Narrow Top Rail

Fasteners: - Self-reaming, self-tapping wood and machine screws
- Sex nuts and bolts

Door Thickness: - 1-3/4" (44 mm) - Standard
- 1-3/8'' - 2-1/4'' (36 mm - 57 mm) thick door - Optional

Painted Finishes: - ALM, BRZ, DBZ, GOL
- Rust inhibiting primer - Standard

Contents: - Standard package contains 5101 closer body, 5102 closer cover, 5103 main arm assembly, 5104 standard screw pack, 5909 parallel arm bracket, and 5940 SNB screw pack for 1-3/4" (44 mm) doors

Note: - Full rack and pinion operation
Hager Grade 1 Heavy Duty Door Closer 5200 Series - Barzellock.com
Size:  - 1-6 adjustable

Certifications: - BHMA Certified ANSI A156.4, adjustable sizes 2 to 5 - Standard
- ADA Compliant ANSI A117.1 Accessibility Code
- UL/cUL Listed for up to 3 hours
- UL10C Positive Pressure Rated
- UL10B Neutral Pressure Rated
- Lifetime Warranty

Material: - Aluminum alloy

Cover: - Full plastic cover - Standard
- Slim line plastic cover - Optional
- Full size plated metal cover - Optional

Springs: - Double heat treated steel, tempered springs
- Precision machined, heat treated Steel piston

Valves: - Adjustable latching and sweep speed valve
- Adjustable backcheck valve - Standard
- Delayed action valve - Optional

Handing: - Non-Handed
Arms & Brackets: - Tri-Pack - Regular, parallel arm, and top jamb mount - Standard
- 15% power adjustment in standard arm for regular and top jamb mount

Optional Arms: - Hold Open Arm
- Extra Heavy Duty Hold Open Stop Arm
- Extra Heavy Duty Stop Arm
- Extra Heavy Duty Arm
- Extra Heavy Duty Hold Open Arm
- Extra Heavy Duty Cushion Stop Arm
- Extra Heavy Duty Hold Open Cushion Stop Arm

Fasteners: - Self-reaming, self-tapping wood and machine screws
- Sex nuts and bolts

Door Thickness: - 1-3/4" (44 mm)
- 1-3/8'' - 2-1/4'' (36 mm - 57 mm) - Optional


Finishes:
- ALM, BRZ, DBZ, GOL
- Rust inhibiting primer - Standard
Size:  - 1-6 adjustable
Certifications: - BHMA Certified ANSI A156.4, adjustable sizes 2 to 6 - Standard
- ADA Compliant ANSI A117.1 Accessability Code
- UL/cUL Listed for up to 3 hours
- UL10C Positive Pressure Rated
- UL10B Neutral Pressure Rated
- Lifetime warranty

Material: - Aluminum alloy

Cover: - Full plastic cover and pinion cap

Springs: - Double heat treated steel, tempered springs
Valves: - Adjustable latching and sweep speed valves
- Adjustable backcheck valve - Standard
- Delayed action valve - Optional
- Staked valves - Standard

Handing: - Non-handed

Arms & Brackets: - Slide Adjustable Arm
- Tri-Pack - regular, top jamb, and parallel arms - Standard
- 15% power adjustment in standard arm for regular and top jamb mount

Fasteners: - Self-reaming, self-tapping wood and machine screws
- Sex nuts and bolts

Door Thickness - 1-3/4" (44 mm)
- 1-3/8'' - 2-1/4'' (36 mm - 57 mm) Optional

Finishes: - ALM, BRZ, DBZ, GOL
- Rust inhibiting primer - Standard
Certifications: - BHMA Certified ANSI A156.4, sizes 2, 3, 4, 5 - Must specify
- UL/cUL Listed for up to 3 hours
- UL10C Positive Pressure Rated
- UL10B Neutral Pressure Rated
- Five-year warranty
Material: - Aluminum alloy
Springs: - Double heat treated steel, tempered springs
Valves: - Adjustable latching and sweep speed valves
- Adjustable backcheck valve - Optional
- Staked valves - Standard
Handing: - Non-Handed
Arms & Brackets: - Tri-Pack - Regular, parallel, and top jamb arm mount - standard
- 15% power adjustment in standard arm for regular and top jamb mount
Fasteners: - Self-reaming self-tapping wood and machine screws
- Sex nuts and bolts
Door Thickness: - 1-3/4" (44 mm) - Standard
- 1-3/8" - 2-1/4" (36 mm - 57 mm) - Optional
Finishes: - ALM, BRZ, DBZ, GOL
- Rust inhibiting primer - Standard
Cover: - Pinion cap
