US Lock Supply Stocks The Yale 5408LN Classroom Series In All Finishes & Options Ready To Ship Free On Orders Over $189.

Function: Yale 5408LN Classroom Series

Finish:

626-Satin Chrome

605-Bright Brass

606-Satin Brass

612-Satin Bronze

613-Oil Rubbed Bronze

625-Bright Chrome

Lever Design:

Augusta (AU)

 Monroe (MO)

Pacific Beach (PB)

Rugged yet refined.
Designed for industrial, commercial and institutional use, the Yale® 5400LN Series heavy-duty cylindrical lockset offers no compromise when it comes to rugged reliability and performance. With key construction features such as our Free Wheeling lever mechanism, wear-resistant chassis plates, heavy-duty lever return springs and through-bolting, this Grade 1 trendsetter proves time and again why it's the favorite among architects and building owners who demand the highest standard of product quality.

And who says a lockset can't be tough and look good at the same time? The 5400LN features three aesthetic lever designs and a diverse line of eleven architectural finishes, which allow the freedom of enhancing any dècor. With a lifetime warranty against lever sag and lever spring breakage, you'll never have to worry about your intended attraction becoming an unintended distraction.

Yale 5408LN-Classroom Lock

• For classroom or utility room doors.

• Deadlocking latchbolt.

• Either lever operates latchbolt (except when outside lever is locked by key).*

• Inside lever always active.

• Outside lever locked* or unlocked only by key

A.D.A.
The 5400LN meets accessibility guidelines of the Americans with Disabilities Act and the requirements of the Uniform Federal Accessibility Standards and ANSI 117.1, all requiring ease of accessibility for the hadicapped.

Door thickness
Patented (patent no. 6,131,970) door adjustable rose support plates allow the 5400LN to easily adjust to doors from 1-3/4" (44mm) to 2" (51mm) thick. For 1-3/8" (35mm) or 2-1/4" (57mm) thick doors, please specify door thickness on order.

Installation
5400LN series cylindrical locks conform to ANSI/BHMA Specifications A156.115 which cover hardware preparations for steel doors and steel frames and A156.115-W which cover hardware preparations for wood doors with wood or steel frames.

Free Wheeling Lever Trim
All 5400LN functions feature the Free Wheeling lever mechanism. When the outside lever is locked, it will rotate freely up and down while remaining securely locked.

Cylinder:

Less Cylinder Available

Door Range: 1-3/4" - 2" (44mm - 51mm).
Strike: 1-1/4" (32mm) curved lip ANSI (497).
Backset: Standard 2-3/4" Backset.
Certification: Certified ANSI/BHMA A156.2, Series 4000 Grade 1.

US Lock Supply Stocks The Yale 5308LN Classroom In All Finishes & Options Ready To Ship Free On Orders Over $189.

Function: Yale 5308LN Classroom

Finish:

626-Satin Chrome

605-Bright Brass

606-Satin Brass

612-Satin Bronze

613-Oil Rubbed Bronze

625-Bright Chrome

Lever Design:

Augusta (AU)

 Monroe (MO)

Pacific Beach (PB)

Innovation and Inspiration.
Thanks to state-of-the-art engineering and innovative thinking, the 5300LN is truly a source of inspiration. With three lever designs and a choice of thirteen different finishes, you have the freedom and ability to match any dècor.

But looks aren't everything. This revolutionary Grade 2 cylindrical lockset boasts design features such as a vandal-resistant Free Wheeling lever mechanism and adjustale door thickness (Patent #6,131,970) that makes installation a breeze. Through-bolting gives the 5300LN a secure fit that resists shaking and rattling. And with a lifetime warranty against lever sag, you never have to worry about your pleasing aesthetics becoming a displeasing eyesore.

5308LN-Classroom Lock

• For classroom or utility room doors.

• Deadlocking latchbolt.

• Either lever operates latchbolt (except when outside lever is locked by key).*

• Inside lever always active.

• Key releases outside lever.

A.D.A.
The 5300LN meets accessibility guidelines of the Americans with Disabilities Act and the requirements of the Uniform Federal Accessibility Standards and ANSI 117.1, all requiring ease of accessibility for the hadicapped.

Door thickness
Patented (patent no. 6,131,970) door adjustable rose support plates allow the 5300LN to easily adjust to doors from 1-3/4" (44mm) to 2" (51mm) thick. For 1-3/8" (35mm) or 2-1/4" (57mm) thick doors, please specify door thickness on order.

Installation
5300LN series cylindrical locks conform to ANSI/BHMA Specifications A156.115 which cover hardware preparations for steel doors and steel frames and A156.115-W which cover hardware preparations for wood doors with wood or steel frames.

Free Wheeling Lever Trim
All 5300LN functions feature the Free Wheeling lever mechanism. When the outside lever is locked, it will rotate freely up and down while remaining securely locked.

Cylinder Options: All Entrance (5307LN), Classroom (5308LN), and Storeroom (5305LN) functions are sold Less Cylinder; see "Companion Items" above for all Cylinder & Keying options.

Door Range: 1-3/4" - 2" (44mm - 51mm).

Backset: Standard 2-3/4" Backset.
Certification: Certified ANSI/BHMA A156.2, Series 4000 Grade 2.

US Lock Supply Stocks The Yale 5302LN Privacy, Bedroom, or Bath In All Finishes & Options Ready To Ship Free On Orders Over $189.Function: Yale 5302LN Privacy, Bedroom, or Bath

Finish:

626-Satin Chrome

605-Bright Brass

606-Satin Brass

612-Satin Bronze

613-Oil Rubbed Bronze

625-Bright Chrome

Lever Design:

Augusta (AU)

 Monroe (MO)

Pacific Beach (PB)

Innovation and Inspiration.
Thanks to state-of-the-art engineering and innovative thinking, the 5300LN is truly a source of inspiration. With three lever designs and a choice of thirteen different finishes, you have the freedom and ability to match any dècor.

But looks aren't everything. This revolutionary Grade 2 cylindrical lockset boasts design features such as a vandal-resistant Free Wheeling lever mechanism and adjustale door thickness (Patent #6,131,970) that makes installation a breeze. Through-bolting gives the 5300LN a secure fit that resists shaking and rattling. And with a lifetime warranty against lever sag, you never have to worry about your pleasing aesthetics becoming a displeasing eyesore.

Privacy, Bedroom or Bath Lock

• For lavatory or other privacy doors.

• Either lever operates latchbolt unless outside lever is locked by pushbutton inside.*

• Button automatically releases when inside lever is turned or door is closed.

• Emergency release in outside lever. Emergency key supplied. (P/N 14-5302-1053)

• Inside lever always active.

A.D.A.
The 5300LN meets accessibility guidelines of the Americans with Disabilities Act and the requirements of the Uniform Federal Accessibility Standards and ANSI 117.1, all requiring ease of accessibility for the hadicapped.

Door thickness
Patented (patent no. 6,131,970) door adjustable rose support plates allow the 5300LN to easily adjust to doors from 1-3/4" (44mm) to 2" (51mm) thick. For 1-3/8" (35mm) or 2-1/4" (57mm) thick doors, please specify door thickness on order.

Installation
5300LN series cylindrical locks conform to ANSI/BHMA Specifications A156.115 which cover hardware preparations for steel doors and steel frames and A156.115-W which cover hardware preparations for wood doors with wood or steel frames.

Free Wheeling Lever Trim
All 5300LN functions feature the Free Wheeling lever mechanism. When the outside lever is locked, it will rotate freely up and down while remaining securely locked.

Cylinder Options: All Entrance (5307LN), Classroom (5308LN), and Storeroom (5305LN) functions are sold Less Cylinder; see "Companion Items" above for all Cylinder & Keying options.

Door Range: 1-3/4" - 2" (44mm - 51mm).
Strike: 1-1/4" (32mm) curved lip ANSI (497).
Backset: Standard 2-3/4" Backset.
Certification: Certified ANSI/BHMA A156.2, Series 4000 Grade 2.

US Lock Supply Stocks The Yale 5301LN Passage or Closet In All Finishes & Options Ready To Ship Free On Orders Over $189.

Function: Yale 5301LN Passage or Closet

Finish:

626-Satin Chrome

605-Bright Brass

606-Satin Brass

612-Satin Bronze

613-Oil Rubbed Bronze

625-Bright Chrome

Lever Design:

Augusta (AU)

 Monroe (MO)

Pacific Beach (PB)

Innovation and Inspiration.
Thanks to state-of-the-art engineering and innovative thinking, the 5300LN is truly a source of inspiration. With three lever designs and a choice of thirteen different finishes, you have the freedom and ability to match any dècor.

But looks aren't everything. This revolutionary Grade 2 cylindrical lockset boasts design features such as a vandal-resistant Free Wheeling lever mechanism and adjustale door thickness (Patent #6,131,970) that makes installation a breeze. Through-bolting gives the 5300LN a secure fit that resists shaking and rattling. And with a lifetime warranty against lever sag, you never have to worry about your pleasing aesthetics becoming a displeasing eyesore.

Passage or Closet Latch • For doors that do not require locking. • Either knob operates latchbolt at all times.

A.D.A.
The 5300LN meets accessibility guidelines of the Americans with Disabilities Act and the requirements of the Uniform Federal Accessibility Standards and ANSI 117.1, all requiring ease of accessibility for the hadicapped.

Door thickness
Patented (patent no. 6,131,970) door adjustable rose support plates allow the 5300LN to easily adjust to doors from 1-3/4" (44mm) to 2" (51mm) thick. For 1-3/8" (35mm) or 2-1/4" (57mm) thick doors, please specify door thickness on order.

Installation
5300LN series cylindrical locks conform to ANSI/BHMA Specifications A156.115 which cover hardware preparations for steel doors and steel frames and A156.115-W which cover hardware preparations for wood doors with wood or steel frames.

Free Wheeling Lever Trim
All 5300LN functions feature the Free Wheeling lever mechanism. When the outside lever is locked, it will rotate freely up and down while remaining securely locked.

Cylinder Options: All Entrance (5307LN), Classroom (5308LN), and Storeroom (5305LN) functions are sold Less Cylinder; see "Companion Items" above for all Cylinder & Keying options.

Door Range: 1-3/4" - 2" (44mm - 51mm).
Strike: 1-1/4" (32mm) curved lip ANSI (497).
Backset: Standard 2-3/4" Backset.
Certification: Certified ANSI/BHMA A156.2, Series 4000 Grade 2.

Sargent 7U65 Privacy/Bathroom Lever Lock. Sargent 7 Line Series is the Best overall lock in the Grade 2 class.
A key-in-lever lock designed for standard duty commercial interior and exterior applications in public buildings, medical offices, hotels/motels and government facilities. Exceeds ANSI/BHMA A156.2 standards for cycling and durability.

Sargent 7U65 Privacy/Bathroom Lever-

• Latch by either lever unless outside lever is locked by push button in inside lever

• Turning inside lever or closing door releases button

• Emergency button in outside lever unlocks, with use of a blade screw driver in outside lever and releases inside button

• ANSI F76

       Suited For:

• Medical Clinics
• Offices
• Public Buildings
• Hotels / Motels
• Government Facilities

Finishes: US26D, US03, US04, US10, US10B, US26, US15

Levers: L, B & P Style Levers

Strength and Durability

• • Cycle Test: Exceeds 2-1/2 times ANSI/BHMA A156.2 Grade 2 cycle requirements
  • 5 Year limited warranty. No service required
• Convenience
• • Installs in 1 minute or less
  • Non-handed design for ease of installation and efficient warehousing -
    with standard lever designs (Except G & Y)
  • User friendly packaging and instructions
  • Convenient installation diagram on box

  Design

  • Solid feel and precise lever action
  • Decorative Levers - Coastal Series designs - Gulfport and Yarmouth
  • Levers are solid one piece cast construction

  Flexibility

  • Fits modified 161 door preps. Internal through-bolts supply strength and stability without requiring additional door preparation
  • 11 Architectural grade finishes
  • 10 Standard Functions (special functions available- 13, 16, 17, 24, 26, 30 and 44-Consult factory)
  • SARGENT uses engineered solutions and flexible manufacturing processes to accommodate special applications

  Security

  • Torx® and spanner screws optional
  • Security key systems available (V-10, Signature, XC, Keso and Keso F1)
  • Vandal resistant trim optional (FW- prefix)                                                                                                                                                                                                   Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.

Sargent 65G05 Entrance or Office Lever Lock. The SARGENT 6500 Line is a standard duty key-in-lever lock designed to exceed the requirements of ANSI A156.2 Series 4000 Grade 2.

Sargent 65G05 Entrance or Office Lever-

• Deadlocking latch

• Latch by either lever unless outside lever is locked by push/turn button in inside lever

• Push button released by key outside or lever inside

• Turn button must be released manually

• Key retracts latch when outside lever is locked

• ANSI F109

                Suited For:

• Light to Medium commercial
• Offices
• Apartments
• Hotels / Motels

Yale 5422LN Corridor or Dormitory Series Lever by Yale Commercial

Rugged yet refined.
Designed for industrial, commercial and institutional use, the Yale® 5400LN Series heavy-duty cylindrical lockset offers no compromise when it comes to rugged reliability and performance. With key construction features such as our Free Wheeling lever mechanism, wear-resistant chassis plates, heavy-duty lever return springs and through-bolting, this Grade 1 trendsetter proves time and again why it's the favorite among architects and building owners who demand the highest standard of product quality.

And who says a lockset can't be tough and look good at the same time? The 5400LN features three aesthetic lever designs and a diverse line of eleven architectural finishes, which allow the freedom of enhancing any dècor. With a lifetime warranty against lever sag and lever spring breakage, you'll never have to worry about your intended attraction becoming an unintended distraction.

Yale 5422LN-Corridor or Dormitory Lock

• Deadlocking latchbolt.

• Either lever operates latchbolt (except when outside lever is locked by inside pushbutton or key in outside lever).* Inside lever always active.

• When locked by button, the button automatically releases when inside lever is turned or door is closed.

• When locked by key, the automatic release is made inoperative and must be manually unlocked by the key.

A.D.A.
The 5400LN meets accessibility guidelines of the Americans with Disabilities Act and the requirements of the Uniform Federal Accessibility Standards and ANSI 117.1, all requiring ease of accessibility for the hadicapped.

Door thickness
Patented (patent no. 6,131,970) door adjustable rose support plates allow the 5400LN to easily adjust to doors from 1-3/4" (44mm) to 2" (51mm) thick. For 1-3/8" (35mm) or 2-1/4" (57mm) thick doors, please specify door thickness on order.

Installation
5400LN series cylindrical locks conform to ANSI/BHMA Specifications A156.115 which cover hardware preparations for steel doors and steel frames and A156.115-W which cover hardware preparations for wood doors with wood or steel frames.

Free Wheeling Lever Trim
All 5400LN functions feature the Free Wheeling lever mechanism. When the outside lever is locked, it will rotate freely up and down while remaining securely locked.

Function: The Yale 5400LN Series Levers are available in Passage (5401LN), Privacy (5402LN), Keyed Entry (5407LN),Classroom (5408LN), Storeroom (5405LN), and Single Dummy (455LN) function.
Finish: The Yale 5400LN Series Levers come in  626, 605, 606,612, 613, & 625 Finishes.

Lever Design: The Yale 5400LN Series Levers come in Augusta (AU), Monroe (MO), and Pacific Beach (PB) design.

Cylinder:

Less Cylinder Available

Door Range: 1-3/4" - 2" (44mm - 51mm).
Strike: 1-1/4" (32mm) curved lip ANSI (497).
Backset: Standard 2-3/4" Backset.
Certification: Certified ANSI/BHMA A156.2, Series 4000 Grade 1.

US Lock Supply Stocks The Yale 5404LN Entry In All Finishes & Options Ready To Ship Free On Orders Over $189.

Function: Yale 5404LN Entry

Finish:

626-Satin Chrome

605-Bright Brass

606-Satin Brass

612-Satin Bronze

613-Oil Rubbed Bronze

625-Bright Chrome

Lever Design:

Augusta (AU)

 Monroe (MO)

Pacific Beach (PB)

Rugged yet refined.
Designed for industrial, commercial and institutional use, the Yale® 5400LN Series heavy-duty cylindrical lockset offers no compromise when it comes to rugged reliability and performance. With key construction features such as our Free Wheeling lever mechanism, wear-resistant chassis plates, heavy-duty lever return springs and through-bolting, this Grade 1 trendsetter proves time and again why it's the favorite among architects and building owners who demand the highest standard of product quality.

And who says a lockset can't be tough and look good at the same time? The 5400LN features three aesthetic lever designs and a diverse line of eleven architectural finishes, which allow the freedom of enhancing any dècor. With a lifetime warranty against lever sag and lever spring breakage, you'll never have to worry about your intended attraction becoming an unintended distraction.

Yale 5404LN-Entry Lock

• For entrance or office doors.

• Deadlocking latchbolt.

• Either lever operates latchbolt (except when outside lever is locked from inside).*

• Pushing button in inside lever locks outside lever. (Automatically releases when inside lever is turned or key is rotated in locked outside lever.)

• Latchbolt is operated by key in outside lever or by rotating inside lever.

• Inside lever always active.

A.D.A.
The 5400LN meets accessibility guidelines of the Americans with Disabilities Act and the requirements of the Uniform Federal Accessibility Standards and ANSI 117.1, all requiring ease of accessibility for the hadicapped.

Door thickness
Patented (patent no. 6,131,970) door adjustable rose support plates allow the 5400LN to easily adjust to doors from 1-3/4" (44mm) to 2" (51mm) thick. For 1-3/8" (35mm) or 2-1/4" (57mm) thick doors, please specify door thickness on order.

Installation
5400LN series cylindrical locks conform to ANSI/BHMA Specifications A156.115 which cover hardware preparations for steel doors and steel frames and A156.115-W which cover hardware preparations for wood doors with wood or steel frames.

Free Wheeling Lever Trim
All 5400LN functions feature the Free Wheeling lever mechanism. When the outside lever is locked, it will rotate freely up and down while remaining securely locked.

Cylinder:

Less Cylinder Available

Door Range: 1-3/4" - 2" (44mm - 51mm).
Strike: 1-1/4" (32mm) curved lip ANSI (497).
Backset: Standard 2-3/4" Backset.
Certification: Certified ANSI/BHMA A156.2, Series 4000 Grade 1.

US Lock Supply Stocks The Yale 5401LN Passage or Closet In All Finishes & Options Ready To Ship Free On Orders Over $189.

Function: Yale 5401LN Passage or Closet

Finish:

626-Satin Chrome

605-Bright Brass

606-Satin Brass

612-Satin Bronze

613-Oil Rubbed Bronze

625-Bright Chrome

Rugged yet refined.
Designed for industrial, commercial and institutional use, the Yale® 5400LN Series heavy-duty cylindrical lockset offers no compromise when it comes to rugged reliability and performance. With key construction features such as our Free Wheeling lever mechanism, wear-resistant chassis plates, heavy-duty lever return springs and through-bolting, this Grade 1 trendsetter proves time and again why it's the favorite among architects and building owners who demand the highest standard of product quality.

And who says a lockset can't be tough and look good at the same time? The 5400LN features three aesthetic lever designs and a diverse line of eleven architectural finishes, which allow the freedom of enhancing any dècor. With a lifetime warranty against lever sag and lever spring breakage, you'll never have to worry about your intended attraction becoming an unintended distraction.

Passage or Closet Latch

• For doors that do not require locking.

• Either lever operates latchbolt at all times.

A.D.A.
The 5400LN meets accessibility guidelines of the Americans with Disabilities Act and the requirements of the Uniform Federal Accessibility Standards and ANSI 117.1, all requiring ease of accessibility for the hadicapped.

Door thickness
Patented (patent no. 6,131,970) door adjustable rose support plates allow the 5400LN to easily adjust to doors from 1-3/4" (44mm) to 2" (51mm) thick. For 1-3/8" (35mm) or 2-1/4" (57mm) thick doors, please specify door thickness on order.

Installation
5400LN series cylindrical locks conform to ANSI/BHMA Specifications A156.115 which cover hardware preparations for steel doors and steel frames and A156.115-W which cover hardware preparations for wood doors with wood or steel frames.

Free Wheeling Lever Trim
All 5400LN functions feature the Free Wheeling lever mechanism. When the outside lever is locked, it will rotate freely up and down while remaining securely locked.

Function: Yale 5401LN Passage or Closet

Finish:

626-Satin Chrome

605-Bright Brass

606-Satin Brass

612-Satin Bronze

613-Oil Rubbed Bronze

625-Bright Chrome

Lever Design: The Yale 5400LN Series Levers come in Augusta (AU), Monroe (MO), and Pacific Beach (PB) design.

Cylinder:

Less Cylinder Available

Door Range: 1-3/4" - 2" (44mm - 51mm).
Strike: 1-1/4" (32mm) curved lip ANSI (497).
Backset: Standard 2-3/4" Backset.
Certification: Certified ANSI/BHMA A156.2, Series 4000 Grade 1.

Sargent 11G37 Classroom Lever Lock. The SARGENT® 11 Line sets a higher standard for Grade 1 bored-in locks. The unique T-Zone® construction provides unequalled strength and durability for the most demanding applications such as schools and hospitals. This is accomplished by true interlocking between the lockbody and the latch far exceeding the 156.2 Series 4000 Grade 1 standards like no other lock can.

Sargent 11G37 Classroom Lever-

• Deadlocking latch

• Latchbolt by either lever unless outside lever is locked by key

• Key in outside lever locks or unlocks outside lever

• Inside lever always operative

• ANSI F84

Ideally Suited For:

• High traffic doors
• Areas subject to severe abuse
• Schools, hospitals, other public buildings
• Retrofit applications

Finishes: US26D, US26, US10B, US10, US4, US3

Levers: Lever L, Lever P, Lever B

Sargent 7G05 Entrance or Office Lever Lock. Sargent 7 Line Series is the Best overall lock in the Grade 2 class. A key-in-lever lock designed for standard duty commercial interior and exterior applications in public buildings, medical offices, hotels/motels and government facilities. Exceeds ANSI/BHMA A156.2 standards for cycling and durability.

Sargent 7G05 Entrance or Office Lever-

• Deadlocking latch

• Latch by either lever unless outside lever is locked by push/turn button in inside lever

• Push button released by key outside or lever inside

• Turn button must be released manually

• Key retracts latch when outside lever is locked

• ANSI F109

       Suited For:

• Medical Clinics
• Offices
• Public Buildings
• Hotels / Motels
• Government Facilities

Finishes: US26D, US03, US04, US10, US10B, US26, US15

Levers: L, B & P Style Levers

Strength and Durability

• • Cycle Test: Exceeds 2-1/2 times ANSI/BHMA A156.2 Grade 2 cycle requirements
  • 5 Year limited warranty. No service required
• Convenience
• • Installs in 1 minute or less
  • Non-handed design for ease of installation and efficient warehousing -
    with standard lever designs (Except G & Y)
  • User friendly packaging and instructions
  • Convenient installation diagram on box

  Design

  • Solid feel and precise lever action
  • Decorative Levers - Coastal Series designs - Gulfport and Yarmouth
  • Levers are solid one piece cast construction

  Flexibility

  • Fits modified 161 door preps. Internal through-bolts supply strength and stability without requiring additional door preparation
  • 11 Architectural grade finishes
  • 10 Standard Functions (special functions available- 13, 16, 17, 24, 26, 30 and 44-Consult factory)
  • SARGENT uses engineered solutions and flexible manufacturing processes to accommodate special applications

  Security

  • Torx® and spanner screws optional
  • Security key systems available (V-10, Signature, XC, Keso and Keso F1)
  • Vandal resistant trim optional (FW- prefix)                                                                                                                                                                                                   Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.

Sargent 10G05 Entrance or Office Lever. The SARGENT® 10 Line is a heavy duty cylindrical key-in-lever handle lockset exceeds by five times the ANSI 156.2 Series 4000 Grade 1 standards. At over 4 million cycles, the 10 Line beats the competitor by 30%. As for abusive force, this lock endures more than two times the standard without allowing entry. The 10 line trim is designed to conform to national and state fire and handicapped requirements.

• Sargent 10G05 Entrance or Office Lever-

CL3800 Series Is an economical, Grade 2 standard-duty lever lockset which provides an outstanding combination of value and performance. It’s the ideal lever lockset for standard commercial applications. When used in conjunction with the CL3300 Series Extra Heavy-Duty Grade 1 and the CL3500 Series Heavy-Duty Grade 1 Cylindrical Lever Locksets, the overall cost of many projects may be reduced without compromising functionality and durability.

Typical applications

• Interior offices
• Closets
• Multi-family housing
• Restaurants
• Retail complexes

• Deadlocking latchbolt by key in outside lever or by rotating inside lever.

• Outside lever always locked (lever handle is free-wheeling in locked position).

• Inside lever always free.

Advantages

• Lever Release™ for vandal resistance
• Solid cast levers
• ANSI Grade 2 certification
• UL 3-hour fire rating
• Independent lever return springs
• Through-bolts on door for solid attachment
• Covers ANSI/DHI door prep A115.18 - 1994 “Spider Cut Out”

CL3800 Series Is an economical, Grade 2 standard-duty lever lockset which provides an outstanding combination of value and performance. It’s the ideal lever lockset for standard commercial applications. When used in conjunction with the CL3300 Series Extra Heavy-Duty Grade 1 and the CL3500 Series Heavy-Duty Grade 1 Cylindrical Lever Locksets, the overall cost of many projects may be reduced without compromising functionality and durability.

Typical applications

• Interior offices
• Closets
• Multi-family housing
• Restaurants
• Retail complexes

 • Latchbolt by lever either side.

• Both levers always free.

Advantages

• Lever Release™ for vandal resistance
• Solid cast levers
• ANSI Grade 2 certification
• UL 3-hour fire rating
• Independent lever return springs
• Through-bolts on door for solid attachment
• Covers ANSI/DHI door prep A115.18 - 1994 “Spider Cut Out”

The CL3300 series is a Grade 1 cylindrical lockset manufactured with the highest quality materials to ensure strength, durability and quiet operation. Available in all standard architectural finishes and four lever designs, the CL3300 series subtly complements any high-use commercial, industrial and institutional application.

• Deadlocking latchbolt by lever either side, except when turn button locks outside lever. Pushing turn button in locks outside lever, requiring use of key outside to unlock. (Lever handle is freewheeling in locked position.)

• Turning inside lever unlocks outside lever.

• Pushing in and turning button locks outside lever, requiring key at all times. Turning inside lever does not unlock outside lever until button is manually turned to unlocked position.

• Inside lever always free.

Vandal Resistance

Engineered to meet today’s increased security needs, the CL3300 series offers several advantages. All functions feature the Lever Release™ design for vandal resistance, allowing the outside lever to rotate when in the locked position. All CL3300 series locksets, including the CL33900 series, are available with Corbin Russwin Pyramid patented security or high security cylinders, the most secure locking system available. Pyramid is especially recommende

d for installations that require superior protection against picking, drilling and other surreptitious entry. See the Pyramid catalog for additional information.
