Best 9K 37 D Storeroom Lever Locks Are In Stock In Most Functions & Styles.

9K Catalog

Quick installation, proven reliability and enhanced safety all make the 9K the grade 1 cylindrical lock of choice for many. But its wide compatibility with most large format interchangeable cores, regardless of brand, make it a legend. Whether you want to upgrade old hardware or fit out a new facility, the 9K is a great match.

Schlage ND75PD Classroom Security lock is available in stock & ready to ship.

They come available in all lever styles & finishes.

Schlage ND Series Catalog

Performance beyond Grade 1
The Schlage® ND family significantly exceeds BHMA Grade
1 requirements for cycle, lever torque, hammer blow, lever
pull and other tests. This means confidence that the lock
will last—whether the application calls for high abuse
resistance or just operation over millions of cycles—
without any degradation in performance.

Comprehensive offering for every opening
Mechanical, wired electrified and wireless electronic
solutions allow a common aesthetic and consistent
user experience throughout the building while
lowering the total cost of ownership.

World-class design
A proven, easy to install product with extensive
function, keying, trim and finish capabilities that
work in nearly any applications.

Yale 5421LN Communicating Lever Series Lever by Yale Commercial

Rugged yet refined.
Designed for industrial, commercial and institutional use, the Yale® 5400LN Series heavy-duty cylindrical lockset offers no compromise when it comes to rugged reliability and performance. With key construction features such as our Free Wheeling lever mechanism, wear-resistant chassis plates, heavy-duty lever return springs and through-bolting, this Grade 1 trendsetter proves time and again why it's the favorite among architects and building owners who demand the highest standard of product quality.

And who says a lockset can't be tough and look good at the same time? The 5400LN features three aesthetic lever designs and a diverse line of eleven architectural finishes, which allow the freedom of enhancing any dècor. With a lifetime warranty against lever sag and lever spring breakage, you'll never have to worry about your intended attraction becoming an unintended distraction.

Yale 5421LN-Communicating Lock

• For communicating or store entrance doors.

• Deadlocking latchbolt.

• Either lever operates latchbolt (except when key in either lever locks or unlocks the lever independently of the other).*

• Should be used only in offices or rooms with multiple entries.

NOTE: Not available with IC core cylinders.

A.D.A.
The 5400LN meets accessibility guidelines of the Americans with Disabilities Act and the requirements of the Uniform Federal Accessibility Standards and ANSI 117.1, all requiring ease of accessibility for the hadicapped.

Door thickness
Patented (patent no. 6,131,970) door adjustable rose support plates allow the 5400LN to easily adjust to doors from 1-3/4" (44mm) to 2" (51mm) thick. For 1-3/8" (35mm) or 2-1/4" (57mm) thick doors, please specify door thickness on order.

Installation
5400LN series cylindrical locks conform to ANSI/BHMA Specifications A156.115 which cover hardware preparations for steel doors and steel frames and A156.115-W which cover hardware preparations for wood doors with wood or steel frames.

Free Wheeling Lever Trim
All 5400LN functions feature the Free Wheeling lever mechanism. When the outside lever is locked, it will rotate freely up and down while remaining securely locked.

Function: The Yale 5400LN Series Levers are available in Passage (5401LN), Privacy (5402LN), Keyed Entry (5407LN),Classroom (5408LN), Storeroom (5405LN), and Single Dummy (455LN) function.
Finish: The Yale 5400LN Series Levers come in  626, 605, 606,612, 613, & 625 Finishes.

Lever Design: The Yale 5400LN Series Levers come in Augusta (AU), Monroe (MO), and Pacific Beach (PB) design.

Cylinder:

Less Cylinder Available

Door Range: 1-3/4" - 2" (44mm - 51mm).
Strike: 1-1/4" (32mm) curved lip ANSI (497).
Backset: Standard 2-3/4" Backset.
Certification: Certified ANSI/BHMA A156.2, Series 4000 Grade 1.

US Lock Supply Stocks The Yale 5307LN Entry In All Finishes & Options Ready To Ship Free On Orders Over $189.

Function: Yale 5307LN Entry

Finish:

626-Satin Chrome

605-Bright Brass

606-Satin Brass

612-Satin Bronze

613-Oil Rubbed Bronze

625-Bright Chrome

Lever Design:

Augusta (AU)

 Monroe (MO)

Pacific Beach (PB)

Innovation and Inspiration.
Thanks to state-of-the-art engineering and innovative thinking, the 5300LN is truly a source of inspiration. With three lever designs and a choice of thirteen different finishes, you have the freedom and ability to match any dècor.

But looks aren't everything. This revolutionary Grade 2 cylindrical lockset boasts design features such as a vandal-resistant Free Wheeling lever mechanism and adjustale door thickness (Patent #6,131,970) that makes installation a breeze. Through-bolting gives the 5300LN a secure fit that resists shaking and rattling. And with a lifetime warranty against lever sag, you never have to worry about your pleasing aesthetics becoming a displeasing eyesore.

5307LN-Entry Lock

• For entrance, general home or office doors.

• Deadlocking latchbolt.

• Either lever operates latchbolt (except when outside lever is locked from inside).*

• Pushing turn button in inside lever locks outside lever. (Automatically releases when inside lever is turned or key is rotated in locked outside lever.)

• Outside lever may be retained in locked position by pushing and rotating turn button 90° clockwise to a horizontal position; not released until turn button is manually returned to the vertical position.

• Latchbolt is operated by key in outside lever or by rotating inside lever.

• Inside lever always active.

A.D.A.
The 5300LN meets accessibility guidelines of the Americans with Disabilities Act and the requirements of the Uniform Federal Accessibility Standards and ANSI 117.1, all requiring ease of accessibility for the hadicapped.

Door thickness
Patented (patent no. 6,131,970) door adjustable rose support plates allow the 5300LN to easily adjust to doors from 1-3/4" (44mm) to 2" (51mm) thick. For 1-3/8" (35mm) or 2-1/4" (57mm) thick doors, please specify door thickness on order.

Installation
5300LN series cylindrical locks conform to ANSI/BHMA Specifications A156.115 which cover hardware preparations for steel doors and steel frames and A156.115-W which cover hardware preparations for wood doors with wood or steel frames.

Free Wheeling Lever Trim
All 5300LN functions feature the Free Wheeling lever mechanism. When the outside lever is locked, it will rotate freely up and down while remaining securely locked.

Cylinder Options: All Entrance (5307LN), Classroom (5308LN), and Storeroom (5305LN) functions are sold Less Cylinder; see "Companion Items" above for all Cylinder & Keying options.

Door Range: 1-3/4" - 2" (44mm - 51mm).

Backset: Standard 2-3/4" Backset.
Certification: Certified ANSI/BHMA A156.2, Series 4000 Grade 2.

Sargent 65G04 Storeroom or Closet Lever Lock. The SARGENT 6500 Line is a standard duty key-in-lever lock designed to exceed the requirements of ANSI A156.2 Series 4000 Grade 2.

Sargent 65G04 Storeroom or Closet Lever-

• Deadlocking latch

• Latch by lever inside or key outside

• Outside lever rigid at all times

• ANSI F86

                Suited For:

• Light to Medium commercial
• Offices
• Apartments
• Hotels / Motels

• All locks shall meet the new ANSI/BHMA A156.2, Series 4000, Grade 2 test requirements for key-in-lever locksets.
• Locksets shall be UL Listed 3-hour, A Label.
• Lever trim shall have individual heavy-duty springs for lever return and to prevent lever sag. Trim shall be through-bolted with screws coated with thread sealant to provide strength and resistance to loosening.
• Roses shall be 3-1/2” diameter.
• All lever designs shall be solid (no inserts) and meet the federal ADA and state disability requirements.
• Locksets shall adjust to fit door thickness from 1 3/8” to 2”.
• All locksets shall be non-handed and not require field disassembly for re-handing.
• Preparation for door must be non-handed.

Specifications
Door Thickness: 1 3/8” to 2” standard.
Backset: 2 3/4” standard. 2 3/8” also available.
Mechanism: Parts constructed of brass or cold formed steel, zinc plated and dichromated for rust resistance. Springs are stainless steel.
Attachment: Lock chassis secured to door by two screws which pass through a steel rose insert inside and thread directly into the outer rose mounting assembly.
Handing: Locks are non-handed.
Cylinders: Drilled with 6-pin chambers, pinned in 5. Pinning in 6 chambers available when specified, at no cost. Cylinder assemblies removable to rekey. Also available with 6 or 7-pin interchangeable core cylinders. Cylinder housings and plugs machined from solid brass. Springs are phosphor bronze. Two nickel silver keys furnished standard.
Competitor Cylinders: The B Series accepts these standard 6-pin cylinders: Assa, Kaba, Lori, Medeco, Primus and Schlage.
Keyways: “C” keyway standard on standard cylinders. Also available with some optional keyways.
Trim: Roses are 3 1/2” diameter, heavy wrought brass or bronze, installed over steel rose inserts which are through-bolted through door. Levers are pressure cast zinc (solid levers-no inserts) material finished to match mating parts.
Latches: 1/2” bolt projection. UL (3-hour, A Label) listed. Latches have self-adjusting fronts to accommodate beveled or flat doors. 2 3/8” backset with 2 1/4” x 1” latchfaces, 2 3/4” backset with 2 1/4” x 1 1/8” latchfaces. Deadlocking latches have a solid round bar stock DL bar preventing latch jamming and/or lock outs.
Strikes: 4 7/8” x 1 1/4” ANSI strike with curved lip to meet ANSI A115.2 door frame preparation standard. Consult Options and Accessories section for other available strike size and configurations.
Screws: Furnished with combination screws for use in wood or metal doors and frames.
ANSI/BHMA: Exceeds ANSI/BHMA A156.2, Series 4000, Grade 2.
UL: 3-hour, A Label.

• All locks shall meet the new ANSI/BHMA A156.2, Series 4000, Grade 2 test requirements for key-in-lever locksets.
• Locksets shall be UL Listed 3-hour, A Label.
• Lever trim shall have individual heavy-duty springs for lever return and to prevent lever sag. Trim shall be through-bolted with screws coated with thread sealant to provide strength and resistance to loosening.
• Roses shall be 3-1/2” diameter.
• All lever designs shall be solid (no inserts) and meet the federal ADA and state disability requirements.
• Locksets shall adjust to fit door thickness from 1 3/8” to 2”.
• All locksets shall be non-handed and not require field disassembly for re-handing.
• Preparation for door must be non-handed.

Specifications
Door Thickness: 1 3/8” to 2” standard.
Backset: 2 3/4” standard. 2 3/8” also available.
Mechanism: Parts constructed of brass or cold formed steel, zinc plated and dichromated for rust resistance. Springs are stainless steel.
Attachment: Lock chassis secured to door by two screws which pass through a steel rose insert inside and thread directly into the outer rose mounting assembly.
Handing: Locks are non-handed.
Cylinders: Drilled with 6-pin chambers, pinned in 5. Pinning in 6 chambers available when specified, at no cost. Cylinder assemblies removable to rekey. Also available with 6 or 7-pin interchangeable core cylinders. Cylinder housings and plugs machined from solid brass. Springs are phosphor bronze. Two nickel silver keys furnished standard.
Competitor Cylinders: The B Series accepts these standard 6-pin cylinders: Assa, Kaba, Lori, Medeco, Primus and Schlage.
Keyways: “C” keyway standard on standard cylinders. Also available with some optional keyways.
Trim: Roses are 3 1/2” diameter, heavy wrought brass or bronze, installed over steel rose inserts which are through-bolted through door. Levers are pressure cast zinc (solid levers-no inserts) material finished to match mating parts.
Latches: 1/2” bolt projection. UL (3-hour, A Label) listed. Latches have self-adjusting fronts to accommodate beveled or flat doors. 2 3/8” backset with 2 1/4” x 1” latchfaces, 2 3/4” backset with 2 1/4” x 1 1/8” latchfaces. Deadlocking latches have a solid round bar stock DL bar preventing latch jamming and/or lock outs.
Strikes: 4 7/8” x 1 1/4” ANSI strike with curved lip to meet ANSI A115.2 door frame preparation standard. Consult Options and Accessories section for other available strike size and configurations.
Screws: Furnished with combination screws for use in wood or metal doors and frames.
ANSI/BHMA: Exceeds ANSI/BHMA A156.2, Series 4000, Grade 2.
UL: 3-hour, A Label.

• All locks shall meet the new ANSI/BHMA A156.2, Series 4000, Grade 2 test requirements for key-in-lever locksets.
• Locksets shall be UL Listed 3-hour, A Label.
• Lever trim shall have individual heavy-duty springs for lever return and to prevent lever sag. Trim shall be through-bolted with screws coated with thread sealant to provide strength and resistance to loosening.
• Roses shall be 3-1/2” diameter.
• All lever designs shall be solid (no inserts) and meet the federal ADA and state disability requirements.
• Locksets shall adjust to fit door thickness from 1 3/8” to 2”.
• All locksets shall be non-handed and not require field disassembly for re-handing.
• Preparation for door must be non-handed.

Specifications
Door Thickness: 1 3/8” to 2” standard.
Backset: 2 3/4” standard. 2 3/8” also available.
Mechanism: Parts constructed of brass or cold formed steel, zinc plated and dichromated for rust resistance. Springs are stainless steel.
Attachment: Lock chassis secured to door by two screws which pass through a steel rose insert inside and thread directly into the outer rose mounting assembly.
Handing: Locks are non-handed.
Cylinders: Drilled with 6-pin chambers, pinned in 5. Pinning in 6 chambers available when specified, at no cost. Cylinder assemblies removable to rekey. Also available with 6 or 7-pin interchangeable core cylinders. Cylinder housings and plugs machined from solid brass. Springs are phosphor bronze. Two nickel silver keys furnished standard.
Competitor Cylinders: The B Series accepts these standard 6-pin cylinders: Assa, Kaba, Lori, Medeco, Primus and Schlage.
Keyways: “C” keyway standard on standard cylinders. Also available with some optional keyways.
Trim: Roses are 3 1/2” diameter, heavy wrought brass or bronze, installed over steel rose inserts which are through-bolted through door. Levers are pressure cast zinc (solid levers-no inserts) material finished to match mating parts.
Latches: 1/2” bolt projection. UL (3-hour, A Label) listed. Latches have self-adjusting fronts to accommodate beveled or flat doors. 2 3/8” backset with 2 1/4” x 1” latchfaces, 2 3/4” backset with 2 1/4” x 1 1/8” latchfaces. Deadlocking latches have a solid round bar stock DL bar preventing latch jamming and/or lock outs.
Strikes: 4 7/8” x 1 1/4” ANSI strike with curved lip to meet ANSI A115.2 door frame preparation standard. Consult Options and Accessories section for other available strike size and configurations.
Screws: Furnished with combination screws for use in wood or metal doors and frames.
ANSI/BHMA: Exceeds ANSI/BHMA A156.2, Series 4000, Grade 2.
UL: 3-hour, A Label.

A heavy-duty Grade 1 lever lockset, ideal for commercial, institutional and multifamily applications such as:

• Interior offices
• Apartment complexes
• Convalescent and elderly care facilities
• Hotels
• Restaurants
• Retail centers

• Deadlocking latchbolt by lever either side except when key outside locks outside lever.

• Outside lever unlocked by key outside.

• Inside lever always free.

Advantages

• Non-handed
• Solid cast levers
• Independent return springs to prevent lever sag
• Through-bolted cylindrical chassis prevents rotation and ensures proper alignment
• ANSI Grade 1 certification
• Trim and keying compatible with other Corbin Russwin locksets

Arrow’s MLX Series cylindrical lever locks are BHMA Grade 2 Certified, ANSI/BHMA A156.2, Series 4000, while Arrow’s QL Series is BHMA Grade 1 Certified, ANSI/BHMA A156.2, Series 4000. Both lever locks are U.L and c.U.L listed for use on 3 hour, ‘A’ label or lesser doors and meet American with Disabilities Act requirements while also having a 10-year mechanical warranty for ultimate customer satisfaction.

Features:

Door Preparation – Requires standard 2-1/8" (53.97mm) bore through door.
Backset – 2-3/4" (69.85mm)
Door Thickness – Fits 1-3/8" (34.93mm) to 1-3/4" (44.45mm) doors standard.
Latch – Stainless Steel 1/2" (12.7mm) throw, UL Listed, guarded latchbolt on all locking functions
Latch Front – 1-1/8" x 2-1/4" for 2-3/4" (69.85mm) backset.
Warranty – Ten Year Warranty
Handing – Non-handed
Packaging – 6 per case
Strike – 4-7/8" ANSI (123.83mm)
Cylinder – Solid brass 6 pin, Arrow AR and Schlage CS Keyway, keyed different
Keys – 2 brass keys
Available in SFIC
Freewheeling Lever

Grade 2 Survivor Series, American Lever, Storeroom, 2-3/4" Backset, ASA Strike, C Keyway, US26D Satin Chrome

Best 7KC 37 D Storeroom Lever Lock In Stock In Most Functions & Finishes

Best 7KC Catalog

The BEST 7KC Series, a Grade 2 cylindrical lever set, is a popular choice for commercial office spaces, college dorms and military bases. This medium-duty cylindrical lock fits a standard door prep. And because it’s comparable to the BEST 9K lever set, it’s been specified at times for heavy-duty residential applications.

• Cylindrical chassis to fit common door preparation.
• Standard and Drive-in latches available.
• Through-bolt mounting studs increase torque resistance.
• Quick rekeying with BEST interchangeable core.
• No exposed keeper hole on keyed levers for
increased security.
• Hub torque spring provides extra resistance to lever sag.
• Snap-on inside rose (no exposed mounting screws).
• Keyed lever is removable only after removal of core.
• Internal steel mechanisms are corrosion treated for
normal atmospheric conditions.
• ADA–Americans With Disabilities Act: 7KC series – The design and operation
of the BEST® cylindrical lock meets the intent of the standard for ANSI A117.1
section 404.2.6 and Illinois Accessibility Standard 400.310 (j)(8).
• Lockset reversible for either hand of door without removing keyed lever.
• Underwriters Laboratories®: 7KC series – Listed by Underwriters Laboratories
for use on 3 Hr, A label for single (4’ x 8’) doors.
• Builders Hardware Manufacturers Association:
7KC series – Listed by BHMA for A156.2, Series 4000, Grade 2.
• ADA–Americans With Disabilities Act: 7KC series – The design and operation of the BEST®
cylindrical lock meets the intent of the standard for ANSI A117.1 section 404.2.6 and Illinois
• Accessibility Standard 400.310 (j)(8).
• California State Fire Marshal: 7KC - series 14 & 15 lever conforms with California Title 24.

7KC Series FAQs

7KC Series Catalog

7KC Sell Sheet

7KC Series Service Manual

Cylindrical Adaptations Catalog

EAD & DHW Warranty Statement

FAQ

Q: What is the BEST 7KC?
A: The BEST 7KC is a grade 2 cylindrical lever set that was introduced to the
commercial market in 2001. The BEST 7KC lever set is comparable to the BEST 9K
lever set, however is a Grade 2 lockset, opposed to the 9K Grade 1 rating.

Q: Why is it called 7KC opposed to 7K?
A: The current BEST grade 2 cylindrical lever set series is called 7KC. Prior to
launching the 7KC cylindrical lock set in 2001, BEST offered a 7K tubular lock set. The
7K was a completely different lock with different components, door prep guidelines,
etc. The 7K product is no longer available in the market. The “C” was added to the
new 7K cylindrical product offering to differentiate the old tubular 7K from the new
cylindrical 7KC.

Q: In what type of applications is the 7KC primarily used?
A: The 7KC is very popular in commercial offices spaces, college dorms, and military
bases. The 7KC has also been seen in heavy duty residential applications even though
it far exceeds residential requirements.

Q: Does the 7KC fit the standard door prep?
A: Yes, the 7KC fits the standard door prep (161). With the use of the ATB option, the
7KC will also fit the Schlage ND80 door prep.

Q: How long does it take to install the 7KC?
A: Once the door is prepped, installation is a simple 3-step process: Step 1: Install latch;
Step 2: Install preassembled chassis and outside lever; Step 3: Install inside trim and
lever. The entire installation process takes an average of 2 minutes. Since the 7KC
has only three individual parts, and our packaging is designed with the installer in
mind, installation for the 7KC product can be done quickly, efficiently and accurately
ultimately reducing install related errors and call-backs.

Q: What door thickness range can the 7KC accommodate?
A: The 7KC comes preset from the factory to fit 1 3/4" thick doors but can be field
adjusted to fit 1 3/8" – 2" thick doors.

Q: What back sets are available for the 7KC?
A: The 7KC can be ordered with a 2 3/8, 2 3/4", 3 9/4", or 5" back set dead locking
latch. The standard latch front is 1" in width; however, a 1 1/8" latch front is available
to order with the 2 3/4"back set. A drive-in latch is also available on 2 3/8” and 2
3/4"back sets.

Q: What differentiates the 7KC from other grade 2 cylindrical locks?
A: The 7KC is known for its durability and meets several grade 1 requirements. The
7KC is available in numerous functions and finishes whereas it is common to offer
just a few basic functions and finishes for grade 2 locks.

Q: What functions are offered for the 7KC?
A: The 7KC is available in 3 single key functions (i.e., entrance, storeroom &
classroom) and 4 keyless functions (i.e., passage, exit, privacy & single dummy trim).

Q: What finishes are offered for the 7KC?
A: The 7KC is available in 6 finishes: Standard (626), Satin (606, 612, 613), and Bright
(605, 625).

Q: What is the lead time for a 7KC?
A: The average lead time for a 7KC is less than 2 weeks.

Q: What warranty does the 7KC have?
A: The 7KC has a 3 year warranty.

Q: What is the standard core for the 7KC?
A: The standard core is the BEST SFIC (Small Format Interchangeable Core).

Q: Do you have 7KC levers to fit competitive core offerings?
A: Yes, we offer levers to fit the Schlage Non-IC (Non- Interchangeable Core).

Best 7KC 30 L Privacy Lever Lock In Stock In Most Functions & Finishes

Best 7KC Catalog

The BEST 7KC Series, a Grade 2 cylindrical lever set, is a popular choice for commercial office spaces, college dorms and military bases. This medium-duty cylindrical lock fits a standard door prep. And because it’s comparable to the BEST 9K lever set, it’s been specified at times for heavy-duty residential applications.

• Cylindrical chassis to fit common door preparation.
• Standard and Drive-in latches available.
• Through-bolt mounting studs increase torque resistance.
• Quick rekeying with BEST interchangeable core.
• No exposed keeper hole on keyed levers for
increased security.
• Hub torque spring provides extra resistance to lever sag.
• Snap-on inside rose (no exposed mounting screws).
• Keyed lever is removable only after removal of core.
• Internal steel mechanisms are corrosion treated for
normal atmospheric conditions.
• ADA–Americans With Disabilities Act: 7KC series – The design and operation
of the BEST® cylindrical lock meets the intent of the standard for ANSI A117.1
section 404.2.6 and Illinois Accessibility Standard 400.310 (j)(8).
• Lockset reversible for either hand of door without removing keyed lever.
• Underwriters Laboratories®: 7KC series – Listed by Underwriters Laboratories
for use on 3 Hr, A label for single (4’ x 8’) doors.
• Builders Hardware Manufacturers Association:
7KC series – Listed by BHMA for A156.2, Series 4000, Grade 2.
• ADA–Americans With Disabilities Act: 7KC series – The design and operation of the BEST®
cylindrical lock meets the intent of the standard for ANSI A117.1 section 404.2.6 and Illinois
• Accessibility Standard 400.310 (j)(8).
• California State Fire Marshal: 7KC - series 14 & 15 lever conforms with California Title 24.

7KC Series FAQs

7KC Series Catalog

7KC Sell Sheet

7KC Series Service Manual

Cylindrical Adaptations Catalog

EAD & DHW Warranty Statement

FAQ

Q: What is the BEST 7KC?
A: The BEST 7KC is a grade 2 cylindrical lever set that was introduced to the
commercial market in 2001. The BEST 7KC lever set is comparable to the BEST 9K
lever set, however is a Grade 2 lockset, opposed to the 9K Grade 1 rating.

Q: Why is it called 7KC opposed to 7K?
A: The current BEST grade 2 cylindrical lever set series is called 7KC. Prior to
launching the 7KC cylindrical lock set in 2001, BEST offered a 7K tubular lock set. The
7K was a completely different lock with different components, door prep guidelines,
etc. The 7K product is no longer available in the market. The “C” was added to the
new 7K cylindrical product offering to differentiate the old tubular 7K from the new
cylindrical 7KC.

Q: In what type of applications is the 7KC primarily used?
A: The 7KC is very popular in commercial offices spaces, college dorms, and military
bases. The 7KC has also been seen in heavy duty residential applications even though
it far exceeds residential requirements.

Q: Does the 7KC fit the standard door prep?
A: Yes, the 7KC fits the standard door prep (161). With the use of the ATB option, the
7KC will also fit the Schlage ND80 door prep.

Q: How long does it take to install the 7KC?
A: Once the door is prepped, installation is a simple 3-step process: Step 1: Install latch;
Step 2: Install preassembled chassis and outside lever; Step 3: Install inside trim and
lever. The entire installation process takes an average of 2 minutes. Since the 7KC
has only three individual parts, and our packaging is designed with the installer in
mind, installation for the 7KC product can be done quickly, efficiently and accurately
ultimately reducing install related errors and call-backs.

Q: What door thickness range can the 7KC accommodate?
A: The 7KC comes preset from the factory to fit 1 3/4" thick doors but can be field
adjusted to fit 1 3/8" – 2" thick doors.

Q: What back sets are available for the 7KC?
A: The 7KC can be ordered with a 2 3/8, 2 3/4", 3 9/4", or 5" back set dead locking
latch. The standard latch front is 1" in width; however, a 1 1/8" latch front is available
to order with the 2 3/4"back set. A drive-in latch is also available on 2 3/8” and 2
3/4"back sets.

Q: What differentiates the 7KC from other grade 2 cylindrical locks?
A: The 7KC is known for its durability and meets several grade 1 requirements. The
7KC is available in numerous functions and finishes whereas it is common to offer
just a few basic functions and finishes for grade 2 locks.

Q: What functions are offered for the 7KC?
A: The 7KC is available in 3 single key functions (i.e., entrance, storeroom &
classroom) and 4 keyless functions (i.e., passage, exit, privacy & single dummy trim).

Q: What finishes are offered for the 7KC?
A: The 7KC is available in 6 finishes: Standard (626), Satin (606, 612, 613), and Bright
(605, 625).

Q: What is the lead time for a 7KC?
A: The average lead time for a 7KC is less than 2 weeks.

Q: What warranty does the 7KC have?
A: The 7KC has a 3 year warranty.

Q: What is the standard core for the 7KC?
A: The standard core is the BEST SFIC (Small Format Interchangeable Core).

Q: Do you have 7KC levers to fit competitive core offerings?
A: Yes, we offer levers to fit the Schlage Non-IC (Non- Interchangeable Core).

Best 7KC 30 N Passage Lever Lock In Stock In Most Functions & Finishes

Best 7KC Catalog

The BEST 7KC Series, a Grade 2 cylindrical lever set, is a popular choice for commercial office spaces, college dorms and military bases. This medium-duty cylindrical lock fits a standard door prep. And because it’s comparable to the BEST 9K lever set, it’s been specified at times for heavy-duty residential applications.

• Cylindrical chassis to fit common door preparation.
• Standard and Drive-in latches available.
• Through-bolt mounting studs increase torque resistance.
• Quick rekeying with BEST interchangeable core.
• No exposed keeper hole on keyed levers for
increased security.
• Hub torque spring provides extra resistance to lever sag.
• Snap-on inside rose (no exposed mounting screws).
• Keyed lever is removable only after removal of core.
• Internal steel mechanisms are corrosion treated for
normal atmospheric conditions.
• ADA–Americans With Disabilities Act: 7KC series – The design and operation
of the BEST® cylindrical lock meets the intent of the standard for ANSI A117.1
section 404.2.6 and Illinois Accessibility Standard 400.310 (j)(8).
• Lockset reversible for either hand of door without removing keyed lever.
• Underwriters Laboratories®: 7KC series – Listed by Underwriters Laboratories
for use on 3 Hr, A label for single (4’ x 8’) doors.
• Builders Hardware Manufacturers Association:
7KC series – Listed by BHMA for A156.2, Series 4000, Grade 2.
• ADA–Americans With Disabilities Act: 7KC series – The design and operation of the BEST®
cylindrical lock meets the intent of the standard for ANSI A117.1 section 404.2.6 and Illinois
• Accessibility Standard 400.310 (j)(8).
• California State Fire Marshal: 7KC - series 14 & 15 lever conforms with California Title 24.

7KC Series FAQs

7KC Series Catalog

7KC Sell Sheet

7KC Series Service Manual

Cylindrical Adaptations Catalog

EAD & DHW Warranty Statement

FAQ

Q: What is the BEST 7KC?
A: The BEST 7KC is a grade 2 cylindrical lever set that was introduced to the
commercial market in 2001. The BEST 7KC lever set is comparable to the BEST 9K
lever set, however is a Grade 2 lockset, opposed to the 9K Grade 1 rating.

Q: Why is it called 7KC opposed to 7K?
A: The current BEST grade 2 cylindrical lever set series is called 7KC. Prior to
launching the 7KC cylindrical lock set in 2001, BEST offered a 7K tubular lock set. The
7K was a completely different lock with different components, door prep guidelines,
etc. The 7K product is no longer available in the market. The “C” was added to the
new 7K cylindrical product offering to differentiate the old tubular 7K from the new
cylindrical 7KC.

Q: In what type of applications is the 7KC primarily used?
A: The 7KC is very popular in commercial offices spaces, college dorms, and military
bases. The 7KC has also been seen in heavy duty residential applications even though
it far exceeds residential requirements.

Q: Does the 7KC fit the standard door prep?
A: Yes, the 7KC fits the standard door prep (161). With the use of the ATB option, the
7KC will also fit the Schlage ND80 door prep.

Q: How long does it take to install the 7KC?
A: Once the door is prepped, installation is a simple 3-step process: Step 1: Install latch;
Step 2: Install preassembled chassis and outside lever; Step 3: Install inside trim and
lever. The entire installation process takes an average of 2 minutes. Since the 7KC
has only three individual parts, and our packaging is designed with the installer in
mind, installation for the 7KC product can be done quickly, efficiently and accurately
ultimately reducing install related errors and call-backs.

Q: What door thickness range can the 7KC accommodate?
A: The 7KC comes preset from the factory to fit 1 3/4" thick doors but can be field
adjusted to fit 1 3/8" – 2" thick doors.

Q: What back sets are available for the 7KC?
A: The 7KC can be ordered with a 2 3/8, 2 3/4", 3 9/4", or 5" back set dead locking
latch. The standard latch front is 1" in width; however, a 1 1/8" latch front is available
to order with the 2 3/4"back set. A drive-in latch is also available on 2 3/8” and 2
3/4"back sets.

Q: What differentiates the 7KC from other grade 2 cylindrical locks?
A: The 7KC is known for its durability and meets several grade 1 requirements. The
7KC is available in numerous functions and finishes whereas it is common to offer
just a few basic functions and finishes for grade 2 locks.

Q: What functions are offered for the 7KC?
A: The 7KC is available in 3 single key functions (i.e., entrance, storeroom &
classroom) and 4 keyless functions (i.e., passage, exit, privacy & single dummy trim).

Q: What finishes are offered for the 7KC?
A: The 7KC is available in 6 finishes: Standard (626), Satin (606, 612, 613), and Bright
(605, 625).

Q: What is the lead time for a 7KC?
A: The average lead time for a 7KC is less than 2 weeks.

Q: What warranty does the 7KC have?
A: The 7KC has a 3 year warranty.

Q: What is the standard core for the 7KC?
A: The standard core is the BEST SFIC (Small Format Interchangeable Core).

Q: Do you have 7KC levers to fit competitive core offerings?
A: Yes, we offer levers to fit the Schlage Non-IC (Non- Interchangeable Core).

Schlage ND80PD Storeroom lock is available in stock & ready to ship.

They come available in all lever styles & finishes.

Schlage ND Series Catalog

Performance beyond Grade 1
The Schlage® ND family significantly exceeds BHMA Grade
1 requirements for cycle, lever torque, hammer blow, lever
pull and other tests. This means confidence that the lock
will last—whether the application calls for high abuse
resistance or just operation over millions of cycles—
without any degradation in performance.

Comprehensive offering for every opening
Mechanical, wired electrified and wireless electronic
solutions allow a common aesthetic and consistent
user experience throughout the building while
lowering the total cost of ownership.

World-class design
A proven, easy to install product with extensive
function, keying, trim and finish capabilities that
work in nearly any applications.

Schlage ND53PD entrance lock is available in stock & ready to ship.

They come available in all lever styles & finished.

Schlage ND Series Catalog

Performance beyond Grade 1
The Schlage® ND family significantly exceeds BHMA Grade
1 requirements for cycle, lever torque, hammer blow, lever
pull and other tests. This means confidence that the lock
will last—whether the application calls for high abuse
resistance or just operation over millions of cycles—
without any degradation in performance.

Comprehensive offering for every opening
Mechanical, wired electrified and wireless electronic
solutions allow a common aesthetic and consistent
user experience throughout the building while
lowering the total cost of ownership.

World-class design
A proven, easy to install product with extensive
function, keying, trim and finish capabilities that
work in nearly any applications.

Schlage ND40S privacy lock is available in stock & ready to ship.

They come available in all lever styles & finished.

Schlage ND Series Catalog

Performance beyond Grade 1
The Schlage® ND family significantly exceeds BHMA Grade
1 requirements for cycle, lever torque, hammer blow, lever
pull and other tests. This means confidence that the lock
will last—whether the application calls for high abuse
resistance or just operation over millions of cycles—
without any degradation in performance.

Comprehensive offering for every opening
Mechanical, wired electrified and wireless electronic
solutions allow a common aesthetic and consistent
user experience throughout the building while
lowering the total cost of ownership.

World-class design
A proven, easy to install product with extensive
function, keying, trim and finish capabilities that
work in nearly any applications.

Yale 5430LN Utility, Asylum or Institutional  Lever Series Lever by Yale Commercial

Rugged yet refined.
Designed for industrial, commercial and institutional use, the Yale® 5400LN Series heavy-duty cylindrical lockset offers no compromise when it comes to rugged reliability and performance. With key construction features such as our Free Wheeling lever mechanism, wear-resistant chassis plates, heavy-duty lever return springs and through-bolting, this Grade 1 trendsetter proves time and again why it's the favorite among architects and building owners who demand the highest standard of product quality.

And who says a lockset can't be tough and look good at the same time? The 5400LN features three aesthetic lever designs and a diverse line of eleven architectural finishes, which allow the freedom of enhancing any dècor. With a lifetime warranty against lever sag and lever spring breakage, you'll never have to worry about your intended attraction becoming an unintended distraction.

Yale 5430LN-Utility, Asylum or Institutional Lock

• Deadlocking latchbolt.

• Latchbolt operated by key in lever from either side.

• Both levers always locked.*

Note: Not available with IC core cylinders.

A.D.A.
The 5400LN meets accessibility guidelines of the Americans with Disabilities Act and the requirements of the Uniform Federal Accessibility Standards and ANSI 117.1, all requiring ease of accessibility for the hadicapped.

Door thickness
Patented (patent no. 6,131,970) door adjustable rose support plates allow the 5400LN to easily adjust to doors from 1-3/4" (44mm) to 2" (51mm) thick. For 1-3/8" (35mm) or 2-1/4" (57mm) thick doors, please specify door thickness on order.

Installation
5400LN series cylindrical locks conform to ANSI/BHMA Specifications A156.115 which cover hardware preparations for steel doors and steel frames and A156.115-W which cover hardware preparations for wood doors with wood or steel frames.

Free Wheeling Lever Trim
All 5400LN functions feature the Free Wheeling lever mechanism. When the outside lever is locked, it will rotate freely up and down while remaining securely locked.

Function: The Yale 5400LN Series Levers are available in Passage (5401LN), Privacy (5402LN), Keyed Entry (5407LN),Classroom (5408LN), Storeroom (5405LN), and Single Dummy (455LN) function.
Finish: The Yale 5400LN Series Levers come in  626, 605, 606,612, 613, & 625 Finishes.

Lever Design: The Yale 5400LN Series Levers come in Augusta (AU), Monroe (MO), and Pacific Beach (PB) design.

Cylinder:

Less Cylinder Available

Door Range: 1-3/4" - 2" (44mm - 51mm).
Strike: 1-1/4" (32mm) curved lip ANSI (497).
Backset: Standard 2-3/4" Backset.
Certification: Certified ANSI/BHMA A156.2, Series 4000 Grade 1.

Yale 5428LN Communicating Passage Series Lever by Yale Commercial

Rugged yet refined.
Designed for industrial, commercial and institutional use, the Yale® 5400LN Series heavy-duty cylindrical lockset offers no compromise when it comes to rugged reliability and performance. With key construction features such as our Free Wheeling lever mechanism, wear-resistant chassis plates, heavy-duty lever return springs and through-bolting, this Grade 1 trendsetter proves time and again why it's the favorite among architects and building owners who demand the highest standard of product quality.

And who says a lockset can't be tough and look good at the same time? The 5400LN features three aesthetic lever designs and a diverse line of eleven architectural finishes, which allow the freedom of enhancing any dècor. With a lifetime warranty against lever sag and lever spring breakage, you'll never have to worry about your intended attraction becoming an unintended distraction.

5428LN- Communicating Passage Lock

• For twin communicating or exit doors where one side operation is required.

• Use where space is limited.

• Deadlocking latchbolt.

• One lever operation.

• Blank rose.

• Should be used only where rooms have more than one entrance.

A.D.A.
The 5400LN meets accessibility guidelines of the Americans with Disabilities Act and the requirements of the Uniform Federal Accessibility Standards and ANSI 117.1, all requiring ease of accessibility for the hadicapped.

Door thickness
Patented (patent no. 6,131,970) door adjustable rose support plates allow the 5400LN to easily adjust to doors from 1-3/4" (44mm) to 2" (51mm) thick. For 1-3/8" (35mm) or 2-1/4" (57mm) thick doors, please specify door thickness on order.

Installation
5400LN series cylindrical locks conform to ANSI/BHMA Specifications A156.115 which cover hardware preparations for steel doors and steel frames and A156.115-W which cover hardware preparations for wood doors with wood or steel frames.

Free Wheeling Lever Trim
All 5400LN functions feature the Free Wheeling lever mechanism. When the outside lever is locked, it will rotate freely up and down while remaining securely locked.

Function: The Yale 5400LN Series Levers are available in Passage (5401LN), Privacy (5402LN), Keyed Entry (5407LN),Classroom (5408LN), Storeroom (5405LN), and Single Dummy (455LN) function.
Finish: The Yale 5400LN Series Levers come in  626, 605, 606,612, 613, & 625 Finishes.

Lever Design: The Yale 5400LN Series Levers come in Augusta (AU), Monroe (MO), and Pacific Beach (PB) design.
