Schlage ND53PD entrance lock is available in stock & ready to ship.

They come available in all lever styles & finished.

Schlage ND Series Catalog

Performance beyond Grade 1
The Schlage® ND family significantly exceeds BHMA Grade
1 requirements for cycle, lever torque, hammer blow, lever
pull and other tests. This means confidence that the lock
will last—whether the application calls for high abuse
resistance or just operation over millions of cycles—
without any degradation in performance.

Comprehensive offering for every opening
Mechanical, wired electrified and wireless electronic
solutions allow a common aesthetic and consistent
user experience throughout the building while
lowering the total cost of ownership.

World-class design
A proven, easy to install product with extensive
function, keying, trim and finish capabilities that
work in nearly any applications.

Schlage ND40S privacy lock is available in stock & ready to ship.

They come available in all lever styles & finished.

Schlage ND Series Catalog

Performance beyond Grade 1
The Schlage® ND family significantly exceeds BHMA Grade
1 requirements for cycle, lever torque, hammer blow, lever
pull and other tests. This means confidence that the lock
will last—whether the application calls for high abuse
resistance or just operation over millions of cycles—
without any degradation in performance.

Comprehensive offering for every opening
Mechanical, wired electrified and wireless electronic
solutions allow a common aesthetic and consistent
user experience throughout the building while
lowering the total cost of ownership.

World-class design
A proven, easy to install product with extensive
function, keying, trim and finish capabilities that
work in nearly any applications.

Yale 5430LN Utility, Asylum or Institutional  Lever Series Lever by Yale Commercial

Rugged yet refined.
Designed for industrial, commercial and institutional use, the Yale® 5400LN Series heavy-duty cylindrical lockset offers no compromise when it comes to rugged reliability and performance. With key construction features such as our Free Wheeling lever mechanism, wear-resistant chassis plates, heavy-duty lever return springs and through-bolting, this Grade 1 trendsetter proves time and again why it's the favorite among architects and building owners who demand the highest standard of product quality.

And who says a lockset can't be tough and look good at the same time? The 5400LN features three aesthetic lever designs and a diverse line of eleven architectural finishes, which allow the freedom of enhancing any dècor. With a lifetime warranty against lever sag and lever spring breakage, you'll never have to worry about your intended attraction becoming an unintended distraction.

Yale 5430LN-Utility, Asylum or Institutional Lock

• Deadlocking latchbolt.

• Latchbolt operated by key in lever from either side.

• Both levers always locked.*

Note: Not available with IC core cylinders.

A.D.A.
The 5400LN meets accessibility guidelines of the Americans with Disabilities Act and the requirements of the Uniform Federal Accessibility Standards and ANSI 117.1, all requiring ease of accessibility for the hadicapped.

Door thickness
Patented (patent no. 6,131,970) door adjustable rose support plates allow the 5400LN to easily adjust to doors from 1-3/4" (44mm) to 2" (51mm) thick. For 1-3/8" (35mm) or 2-1/4" (57mm) thick doors, please specify door thickness on order.

Installation
5400LN series cylindrical locks conform to ANSI/BHMA Specifications A156.115 which cover hardware preparations for steel doors and steel frames and A156.115-W which cover hardware preparations for wood doors with wood or steel frames.

Free Wheeling Lever Trim
All 5400LN functions feature the Free Wheeling lever mechanism. When the outside lever is locked, it will rotate freely up and down while remaining securely locked.

Function: The Yale 5400LN Series Levers are available in Passage (5401LN), Privacy (5402LN), Keyed Entry (5407LN),Classroom (5408LN), Storeroom (5405LN), and Single Dummy (455LN) function.
Finish: The Yale 5400LN Series Levers come in  626, 605, 606,612, 613, & 625 Finishes.

Lever Design: The Yale 5400LN Series Levers come in Augusta (AU), Monroe (MO), and Pacific Beach (PB) design.

Cylinder:

Less Cylinder Available

Door Range: 1-3/4" - 2" (44mm - 51mm).
Strike: 1-1/4" (32mm) curved lip ANSI (497).
Backset: Standard 2-3/4" Backset.
Certification: Certified ANSI/BHMA A156.2, Series 4000 Grade 1.

Yale 5428LN Communicating Passage Series Lever by Yale Commercial

Rugged yet refined.
Designed for industrial, commercial and institutional use, the Yale® 5400LN Series heavy-duty cylindrical lockset offers no compromise when it comes to rugged reliability and performance. With key construction features such as our Free Wheeling lever mechanism, wear-resistant chassis plates, heavy-duty lever return springs and through-bolting, this Grade 1 trendsetter proves time and again why it's the favorite among architects and building owners who demand the highest standard of product quality.

And who says a lockset can't be tough and look good at the same time? The 5400LN features three aesthetic lever designs and a diverse line of eleven architectural finishes, which allow the freedom of enhancing any dècor. With a lifetime warranty against lever sag and lever spring breakage, you'll never have to worry about your intended attraction becoming an unintended distraction.

5428LN- Communicating Passage Lock

• For twin communicating or exit doors where one side operation is required.

• Use where space is limited.

• Deadlocking latchbolt.

• One lever operation.

• Blank rose.

• Should be used only where rooms have more than one entrance.

A.D.A.
The 5400LN meets accessibility guidelines of the Americans with Disabilities Act and the requirements of the Uniform Federal Accessibility Standards and ANSI 117.1, all requiring ease of accessibility for the hadicapped.

Door thickness
Patented (patent no. 6,131,970) door adjustable rose support plates allow the 5400LN to easily adjust to doors from 1-3/4" (44mm) to 2" (51mm) thick. For 1-3/8" (35mm) or 2-1/4" (57mm) thick doors, please specify door thickness on order.

Installation
5400LN series cylindrical locks conform to ANSI/BHMA Specifications A156.115 which cover hardware preparations for steel doors and steel frames and A156.115-W which cover hardware preparations for wood doors with wood or steel frames.

Free Wheeling Lever Trim
All 5400LN functions feature the Free Wheeling lever mechanism. When the outside lever is locked, it will rotate freely up and down while remaining securely locked.

Function: The Yale 5400LN Series Levers are available in Passage (5401LN), Privacy (5402LN), Keyed Entry (5407LN),Classroom (5408LN), Storeroom (5405LN), and Single Dummy (455LN) function.
Finish: The Yale 5400LN Series Levers come in  626, 605, 606,612, 613, & 625 Finishes.

Lever Design: The Yale 5400LN Series Levers come in Augusta (AU), Monroe (MO), and Pacific Beach (PB) design.

US Lock Supply Stocks The 5406LN Service Station In All Finishes & Options Ready To Ship Free On Orders Over $189.

Function: 5406LN Service Station

Finish:

626-Satin Chrome

605-Bright Brass

606-Satin Brass

612-Satin Bronze

613-Oil Rubbed Bronze

625-Bright Chrome

Lever Design:

Augusta (AU)

 Monroe (MO)

Pacific Beach (PB)

Rugged yet refined.
Designed for industrial, commercial and institutional use, the Yale® 5400LN Series heavy-duty cylindrical lockset offers no compromise when it comes to rugged reliability and performance. With key construction features such as our Free Wheeling lever mechanism, wear-resistant chassis plates, heavy-duty lever return springs and through-bolting, this Grade 1 trendsetter proves time and again why it's the favorite among architects and building owners who demand the highest standard of product quality.

And who says a lockset can't be tough and look good at the same time? The 5400LN features three aesthetic lever designs and a diverse line of eleven architectural finishes, which allow the freedom of enhancing any dècor. With a lifetime warranty against lever sag and lever spring breakage, you'll never have to worry about your intended attraction becoming an unintended distraction.

Yale 5406LN-Service Station Lock

• Deadlocking latchbolt.

• Either lever operates latchbolt.

• Pushbutton in inside lever locks outside lever. (Automatically releases when inside lever is turned, door is closed or key is rotated in outside lever, except when slotted pushbutton is rotated 90˚ clockwise to retain outside lever in locked position.)*

• Latchbolt operated by key in outside lever, inside lever always active.

A.D.A.
The 5400LN meets accessibility guidelines of the Americans with Disabilities Act and the requirements of the Uniform Federal Accessibility Standards and ANSI 117.1, all requiring ease of accessibility for the hadicapped.

Door thickness
Patented (patent no. 6,131,970) door adjustable rose support plates allow the 5400LN to easily adjust to doors from 1-3/4" (44mm) to 2" (51mm) thick. For 1-3/8" (35mm) or 2-1/4" (57mm) thick doors, please specify door thickness on order.

Installation
5400LN series cylindrical locks conform to ANSI/BHMA Specifications A156.115 which cover hardware preparations for steel doors and steel frames and A156.115-W which cover hardware preparations for wood doors with wood or steel frames.

Free Wheeling Lever Trim
All 5400LN functions feature the Free Wheeling lever mechanism. When the outside lever is locked, it will rotate freely up and down while remaining securely locked.

Cylinder:

Less Cylinder Available

Door Range: 1-3/4" - 2" (44mm - 51mm).
Strike: 1-1/4" (32mm) curved lip ANSI (497).
Backset: Standard 2-3/4" Backset.
Certification: Certified ANSI/BHMA A156.2, Series 4000 Grade 1.

Sargent 11U94-2 Double Lever Pull Lever Lock. The SARGENT® 11 Line sets a higher standard for Grade 1 bored-in locks. The unique T-Zone® construction provides unequalled strength and durability for the most demanding applications such as schools and hospitals. This is accomplished by true interlocking between the lockbody and the latch far exceeding the 156.2 Series 4000 Grade 1 standards like no other lock can.

Sargent 11U94-2 Double Lever Pull Lever-

 • For 161 and ANSI A115.2 prepared doors

• Lever and rose both sides joined by aligning tube and latchbolt tube

• Dummy latch plate

Ideally Suited For:

• High traffic doors
• Areas subject to severe abuse
• Schools, hospitals, other public buildings
• Retrofit applications

Finishes: US26D, US26, US10B, US10, US4, US3

Levers: Lever L, Lever P, Lever B

Sargent 7U94 Double Lever Pull Dummy Lever Lock. Sargent 7 Line Series is the Best overall lock in the Grade 2 class.
A key-in-lever lock designed for standard duty commercial interior and exterior applications in public buildings, medical offices, hotels/motels and government facilities. Exceeds ANSI/BHMA A156.2 standards for cycling and durability.

Sargent 7U94 Double Lever Pull Dummy-

• For wood or custom hollow metal doors

• Lever and rose both sides by two through-bolts and four surface applied screws

• Requires special door preparation

       Suited For:

• Medical Clinics
• Offices
• Public Buildings
• Hotels / Motels
• Government Facilities

Finishes: US26D, US03, US04, US10, US10B, US26, US15

Levers: L, B & P Style Levers

Strength and Durability

• • Cycle Test: Exceeds 2-1/2 times ANSI/BHMA A156.2 Grade 2 cycle requirements
  • 5 Year limited warranty. No service required
• Convenience
• • Installs in 1 minute or less
  • Non-handed design for ease of installation and efficient warehousing -
    with standard lever designs (Except G & Y)
  • User friendly packaging and instructions
  • Convenient installation diagram on box

  Design

  • Solid feel and precise lever action
  • Decorative Levers - Coastal Series designs - Gulfport and Yarmouth
  • Levers are solid one piece cast construction

  Flexibility

  • Fits modified 161 door preps. Internal through-bolts supply strength and stability without requiring additional door preparation
  • 11 Architectural grade finishes
  • 10 Standard Functions (special functions available- 13, 16, 17, 24, 26, 30 and 44-Consult factory)
  • SARGENT uses engineered solutions and flexible manufacturing processes to accommodate special applications

  Security

  • Torx® and spanner screws optional
  • Security key systems available (V-10, Signature, XC, Keso and Keso F1)
  • Vandal resistant trim optional (FW- prefix)                                                                                                                                                                                                   Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.

Sargent 7G37 Classroom Lever Lock. Sargent 7 Line Series is the Best overall lock in the Grade 2 class. A key-in-lever lock designed for standard duty commercial interior and exterior applications in public buildings, medical offices, hotels/motels and government facilities. Exceeds ANSI/BHMA A156.2 standards for cycling and durability.

Sargent 7G37 Classroom Lever-

• Deadlocking latch

• Latch by either lever unless outside lever is locked by key

• Key in outside lever locks or unlocks outside lever and retracts latch

• Inside lever always operative

• ANSI F84

       Suited For:

• Medical Clinics
• Offices
• Public Buildings
• Hotels / Motels
• Government Facilities

Finishes: US26D, US03, US04, US10, US10B, US26, US15

Levers: L, B & P Style Levers

Strength and Durability

• • Cycle Test: Exceeds 2-1/2 times ANSI/BHMA A156.2 Grade 2 cycle requirements
  • 5 Year limited warranty. No service required
• Convenience
• • Installs in 1 minute or less
  • Non-handed design for ease of installation and efficient warehousing -
    with standard lever designs (Except G & Y)
  • User friendly packaging and instructions
  • Convenient installation diagram on box

  Design

  • Solid feel and precise lever action
  • Decorative Levers - Coastal Series designs - Gulfport and Yarmouth
  • Levers are solid one piece cast construction

  Flexibility

  • Fits modified 161 door preps. Internal through-bolts supply strength and stability without requiring additional door preparation
  • 11 Architectural grade finishes
  • 10 Standard Functions (special functions available- 13, 16, 17, 24, 26, 30 and 44-Consult factory)
  • SARGENT uses engineered solutions and flexible manufacturing processes to accommodate special applications

  Security

  • Torx® and spanner screws optional
  • Security key systems available (V-10, Signature, XC, Keso and Keso F1)
  • Vandal resistant trim optional (FW- prefix)                                                                                                                                                                                                   Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.

Sargent 65U93 Single Lever Pull Dummy Lever Lock. The SARGENT 6500 Line is a standard duty key-in-lever lock designed to exceed the requirements of ANSI A156.2 Series 4000 Grade 2.

Sargent 65U93 Single Lever Pull Dummy Lever-

• For wood or custom hollow metal doors

• Lever and rose attached by three surface applied screws

                Suited For:

• Light to Medium commercial
• Offices
• Apartments
• Hotels / Motels

Sargent 10U68 Hospital Privacy Lever. The SARGENT® 10 Line is a heavy duty cylindrical key-in-lever handle lockset exceeds by five times the ANSI 156.2 Series 4000 Grade 1 standards. At over 4 million cycles, the 10 Line beats the competitor by 30%. As for abusive force, this lock endures more than two times the standard without allowing entry. The 10 line trim is designed to conform to national and state fire and handicapped requirements.

• Sargent 10U68 Hospital Privacy Lever-

• All locks shall meet the new ANSI/BHMA A156.2, Series 4000, Grade 2 test requirements for key-in-lever locksets.
• Locksets shall be UL Listed 3-hour, A Label.
• Lever trim shall have individual heavy-duty springs for lever return and to prevent lever sag. Trim shall be through-bolted with screws coated with thread sealant to provide strength and resistance to loosening.
• Roses shall be 3-1/2” diameter.
• All lever designs shall be solid (no inserts) and meet the federal ADA and state disability requirements.
• Locksets shall adjust to fit door thickness from 1 3/8” to 2”.
• All locksets shall be non-handed and not require field disassembly for re-handing.
• Preparation for door must be non-handed.

Specifications
Door Thickness: 1 3/8” to 2” standard.
Backset: 2 3/4” standard. 2 3/8” also available.
Mechanism: Parts constructed of brass or cold formed steel, zinc plated and dichromated for rust resistance. Springs are stainless steel.
Attachment: Lock chassis secured to door by two screws which pass through a steel rose insert inside and thread directly into the outer rose mounting assembly.
Handing: Locks are non-handed.
Cylinders: Drilled with 6-pin chambers, pinned in 5. Pinning in 6 chambers available when specified, at no cost. Cylinder assemblies removable to rekey. Also available with 6 or 7-pin interchangeable core cylinders. Cylinder housings and plugs machined from solid brass. Springs are phosphor bronze. Two nickel silver keys furnished standard.
Competitor Cylinders: The B Series accepts these standard 6-pin cylinders: Assa, Kaba, Lori, Medeco, Primus and Schlage.
Keyways: “C” keyway standard on standard cylinders. Also available with some optional keyways.
Trim: Roses are 3 1/2” diameter, heavy wrought brass or bronze, installed over steel rose inserts which are through-bolted through door. Levers are pressure cast zinc (solid levers-no inserts) material finished to match mating parts.
Latches: 1/2” bolt projection. UL (3-hour, A Label) listed. Latches have self-adjusting fronts to accommodate beveled or flat doors. 2 3/8” backset with 2 1/4” x 1” latchfaces, 2 3/4” backset with 2 1/4” x 1 1/8” latchfaces. Deadlocking latches have a solid round bar stock DL bar preventing latch jamming and/or lock outs.
Strikes: 4 7/8” x 1 1/4” ANSI strike with curved lip to meet ANSI A115.2 door frame preparation standard. Consult Options and Accessories section for other available strike size and configurations.
Screws: Furnished with combination screws for use in wood or metal doors and frames.
ANSI/BHMA: Exceeds ANSI/BHMA A156.2, Series 4000, Grade 2.
UL: 3-hour, A Label.

A heavy-duty Grade 1 lever lockset, ideal for commercial, institutional and multifamily applications such as:

• Interior offices
• Apartment complexes
• Convalescent and elderly care facilities
• Hotels
• Restaurants
• Retail centers

• Deadlocking latchbolt by lever either side except when turn button locks outside lever. Pushing turn button locks outside lever, requiring use of key outside to unlock.

• Turning inside lever unlocks outside lever (when button is pushed in but not turned).

• Pushing in and turning button locks outside lever, requiring key at all times. Turning inside lever does not unlock outside lever until button is manually turned to unlocked position.

• Inside lever always free.

Advantages

• Non-handed
• Solid cast levers
• Independent return springs to prevent lever sag
• Through-bolted cylindrical chassis prevents rotation and ensures proper alignment
• ANSI Grade 1 certification
• Trim and keying compatible with other Corbin Russwin locksets

The CL3300 series is a Grade 1 cylindrical lockset manufactured with the highest quality materials to ensure strength, durability and quiet operation. Available in all standard architectural finishes and four lever designs, the CL3300 series subtly complements any high-use commercial, industrial and institutional application.

• Throw-off latchbolt by lever.

• Outside lever locked by push button. (Lever handle is freewheeling in locked position.)

• Outside lever unlocked by emergency release tool outside, by rotating inside lever or by closing door.

• Inside lever always free.

Vandal Resistance

Engineered to meet today’s increased security needs, the CL3300 series offers several advantages. All functions feature the Lever Release™ design for vandal resistance, allowing the outside lever to rotate when in the locked position. All CL3300 series locksets, including the CL33900 series, are available with Corbin Russwin Pyramid patented security or high security cylinders, the most secure locking system available. Pyramid is especially recommende

d for installations that require superior protection against picking, drilling and other surreptitious entry. See the Pyramid catalog for additional information.

Arrow’s MLX Series cylindrical lever locks are BHMA Grade 2 Certified, ANSI/BHMA A156.2, Series 4000, while Arrow’s QL Series is BHMA Grade 1 Certified, ANSI/BHMA A156.2, Series 4000. Both lever locks are U.L and c.U.L listed for use on 3 hour, ‘A’ label or lesser doors and meet American with Disabilities Act requirements while also having a 10-year mechanical warranty for ultimate customer satisfaction.

Features:

Door Preparation – Requires standard 2-1/8" (53.97mm) bore through door.
Backset – 2-3/4" (69.85mm)
Door Thickness – Fits 1-3/8" (34.93mm) to 1-3/4" (44.45mm) doors standard.
Latch – Stainless Steel 1/2" (12.7mm) throw, UL Listed, guarded latchbolt on all locking functions
Latch Front – 1-1/8" x 2-1/4" for 2-3/4" (69.85mm) backset.
Warranty – Ten Year Warranty
Handing – Non-handed
Packaging – 6 per case
Strike – 4-7/8" ANSI (123.83mm)
Cylinder – Solid Brass 6 pin, Arrow AR and Schlage CS Keyway, keyed different
Keys – 2 brass keys
Available in SFIC
Freewheeling Lever

Grade 2 Survivor Series, American Lever, Passage, 2-3/4" Backset, ASA Strike, US26D Satin Chrome
