ISO 9227 KTL / E-coated lock box withstands 1000 hours of salt spray test
Gate Lock with double cylinder dead bolt. Designed for 1-1/8" Mortise profile cylinder
Fixing cylinder inch thread 1/4'
Easy left or right changing of the self-latching daybolt
Throw of the dead bolt, 7/8" in 1 turn of the key
Key-operated self-latching bolt
Adjustment of the bolts up to 3/8" continuous without removing the lock
4-hole mounting with two hex head socket screws
Interchangeable with all Locinox surface mounted locks
The lock box requires a 3-3/8" spacing to the first picket, fitting nicely into most gates
Stainless steel keep with polyamide finish. Used as a standard for all your gates (garden, ornamental, industrial,...) The unique Quick-Fix ensures a fast and strong installation. The adjustable, aluminum stop plate with rubber accepts different gate profiles (1-1/2” to 2-1/2”). Redesigned to make the latch bolt fall into the keep easier.
Easy to fix with Quick-Fix
Vandal-proof eyebolt & crossbolt
180° opening
Eliminates the need to stock left and right swinging gates
9/16" adjustable in height
1" adjustable in depth
U clamp and GRIP in aluminum
Hot-dip galvanized eyebolt and crossbolt
Max width of the gate: 6-1/2 ft
The B-Safe gate safety cable provides additional security to your gates. Should the gate become detached, the B-Safe will keep it from falling down. Thanks to the patented Quick-Fix anchor bolts, the B-Safe easily installs onto the post and gate frame. The B-Safe is recommended for gates up to 1,100 lbs, being rated up to 2,200 lbs, and has been developed to secure a gate in accordance with EN 12604.
