Corbin Russwin ED 8200 Rim Exit Device
691-Light Bronze Painted
Bar Length: Easily field cut to size.
Standard: 36" bar fits 31" - 36" (787mm-914mm) door.
Optional: 30" bar fits 28" - 30" (711mm-762mm) door; .
Optional: 42" bar fits 37" - 42" (940mm-1067mm) door; .
Optional: 48" bar fits 43" - 48" (1092mm-1219mm) door; .
Door Thickness: 1-3/4" (44mm) standard.
Backset: 2-3/4" (70mm). Device and trim cover standard
Latchbolt: 3/4" (19mm) stainless steel pullman-type with stainless steel deadlocking latch
Materials: Heavy-duty wrought steel chassis and pushpad; aluminum front and rear bar covers; stainless steel springs; nylon bearings.
Dogging: Standard on ED8200 devices: single point 1/4 turn dogging.
Optional: less dogging; specify M51(Call To See If Its Avail.).
Fasteners: Standard on ED8200 devices: machine screws and wood door fasteners.
Certification/Compliance ANSI Meets A156.3, Type 1, Grade 1. Meets A117.1 Accessibility Code. C-UL US All devices listed for safety as panic hardware; devices comply with UL 305 standards for panic hardware. UL symbol on rear cover label indicates listing. Three-hour fire-rated devices listed as fire exit hardware for A label and lesser class 4' x 8' single or 8' x 8' double doors; UL symbol on rear cover label indicates listing. Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Corbin Russwin, Inc. makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings. Warnock Hersey International Inc. ED8200B listed as fire exit hardware for installation on up to 1-1/2 hour fire doors, up to 8' x 8'. California State Reference Code This product has been approved by the California State Fire Marshal (CSFM) pursuant to Section 13144.1 of the California Health and Safety Code. NFPA All exit devices comply with NFPA 101 Life Safety Code. All fire-rated devices comply with NFPA 80 Fire Doors and Windows. ADA Exit devices, lever trims and pulls comply with Americans with Disabilities Act.
