Application: |
- For surface applications where frame face dimension is limited |
Clearance: | - 1/32" (1 mm) minimum recommended between doors - Plus standard lockside clearance - Refer to Door and Frame Dimensioning in the General Information section for further details |
Fasteners: | - 1/4-20 x 1-1/4" Sexbolt (Screw + Post) - #12-24 X 11/16" Flat Head Self-Drill Screws |
Length Options: | - Standard and Custom |
Door Reinforcement: | - None required |
Frame Reinforcement: | - None required to 200 lbs. Heavier weigh use 16-gauge channel. |
Fire Rating: | - Up to 3 hr. metal and 90 min. wood composite (with studs) |
Warranty: | - All Roton products have a lifetime warranty. When ordering electric Roton, the electric portion of the hinge has a one-year warranty. |
Material: | - Aluminum 6063-T6 |
Options: | - Hospital Tip |
EPD: | - Roton Continuous Hinges Environmental Product Declaration |
780-157 HD Template 95" Rev. April 2017 | 780157HD95-April-2017.pdf |
780-157 HDTemplate 85" Rev. April 2017 | 780157HD85-April-2017.pdf |
780-157 HD Template 83" Rev. April 2017 | 780157HD83-April-2017.pdf |
780-157 HDTemplate 79" Rev. April 2017 | 780157HD79-April-2017.pdf |
