Schlage

Whether interior or exterior, a Schlage doorknob is designed to perform -- and to do so beautifully. US Lock Supply offers many attractive and functional Schlage products, from Schlage electrified lever locks to knobs with privacy locks for your bedroom or bath.

Our Schlage collection includes Schlage A Series knobs and AL Series lever locks in a wide range of finishes to complement any decor. We carry all the most sought after Schlage knobs, such as the Schlage A Series Levon knob, Orbit knob, F10 Plymouth knob and other Plymouth knobs, Georgian knob, Tulip knob and more.

Some of our other popular sellers in this collection include the Schlage Bell Knob; Schlage D Series knobs for heavy traffic/high security applications such as hospitals; Schlage ND Series of lever locks; Schlage B250 Series single cylinder deadlatch; Schlage B500 and B600 Series of deadbolt locks; and many more.

Whether you are looking for Schlage Georgian knobs for your home or a single cylinder deadbolt made with Schlage’s security and precision, shop US Lock Supply for great prices and excellent service.

Schlage B661 One Way Deadbolt - Barzellock.com

Schlage B661 One Way Deadbolt

by Schlage
$ 140.40

Schlage B661 One Way Deadbolt. The B600 Series is Schlage’s highest grade deadbolt locks. Choose the 600 for Grade 1 security in high-traffic commercial applications. B600 Series Schlage’s toughest heavy duty Grade 1 commercial deadbolt. Furnished with conventional cylinder standard. Also available with full size interchangeable core cylinder or small format interchangeable core (SFIC) cylinder. Requires 21 ⁄8" (54mm) prep. UL10B listing standard for auxiliary lock on A label fire doors.

Schlage B661 - One Way deadbolt ANSI-E0161

• Deadbolt thrown or retracted by key outside.

• Blank plate with exposed screws inside.



Finishes: 605-Bright Brass, 606-Satin Brass, 609-Antique Brass, 612-Satin Bronze, 613-Oil Rubbed Bronze, 619-Satin Nickel, 625-Bright Chrome, 606-Satin Chrome

Features and Benefits
• 1” (25 mm) throw, high-strength steel alloy deadbolt with hardened steel roller resists sawing and kick-in attacks
• Precision-built solid brass 6-pin cylinders with phosphor bronze springs and nickel silver pins ensure long life and smooth operation
• Tough nickel silver keys for smooth, long-lasting operation
• Exclusive concealed wood frame reinforcer protects wood jamb against kick-in attacks
• Large inside thumbturn makes it easy to throw and retract deadbolt
• Security shield protects bolt from ice-pick attack through the door
• Hardened steel ball-bearings protect mounting bolts from drill attack

Specifications
Handing: B250-Series deadlatches are reversible. All other B-Series locksets are non-handed.
Door Thickness:
B250-Series, 5-pin: 13/8” to 13/4” (35mm to 44mm) standard. Available to 21/4” (57mm), assembled to order.
B500-Series, 5-pin: 13/8” to 13/4” thick (35mm to 44 mm) standard. Available to 21/4” (57mm), assembled to order.
B600/700/800-Series: 13/4” to 2” (44mm to 51mm) standard. Available for 13/8” (35mm) and doors up to 21/2” (63mm), assembled to order. Door ranges may vary by function.
Backset:
B250-Series: 23/8” (60mm) standard. 23/4” (70mm) optional.
B500-Series: Adjustable for 23/8” (60mm) or 23/4” (70mm) standard.
B600/700/800-Series: 23/4” (70mm) standard, 23/8” (60mm), 33/4” (95mm), 5” (127mm) optional.
Front: Brass, bronze or stainless steel. 11/8” x 21/4” (29mm x 57mm) square corner, beveled.
Dead Bolt: 1” (25 mm) throw with saw-resistant hardened steel insert.
Latch Bolt: Brass, 9/16” (14mm) throw, deadlocking on keyed and exterior functions.
Exposed Trim: Wrought brass, bronze or stainless steel.
Thumbturn: Pressure cast zinc, plated to match finish symbols.
Strike:
B500 Series: 11/8” x 23/4”, metal dust box reinforcer and three 3” screws. Optional strikes, lip lengths and ANSI strike box available.
B600 and B250-Series: 11/8” x 23/4” (32mm x 70mm) with steel reinforcer and two 3” screws standard.
Certifications
ANSI
:
B500 and B250-Series meet or exceed A156.5 Grade 2 strength and operational requirements.
B600/700/800-Series meets or exceeds A156.5 Grade 1 strength and operational requirements.
UL / cUL:
B600/700/800-Series locks are UL10B Listed auxiliary locks for A label single doors, 4 ’ x 8 ’.
UL10B Listing optional for B500-Series as auxiliary locks. Letter F and UL symbol on latch front indicate listing.
UL437 Listed locking cylinder optional:
Specify Primus 20-500 Series cylinder for B500 and B250-Series Grade 2 products, or specify B800-Series Grade 1 products.
ADA Compliant: Schlage Lock Company offers a wide selection of locks designed to meet the Americans With Disabilities Act.
Cylinder & Keys: 6-pin patented Everest C123 keyway standard with two nickel silver keys per lock. Items specified in C keyway will be furnished 5-pin.
Keying Options: Interchangeable core and Primus XP high security cylinders. Master keying, grand master keying and construction keying.
Warranty:
Commercial: Three-year limited.
Residential: Full lifetime mechanical.
Schlage B662 Double Cylinder Deadbolt - Barzellock.com

Schlage B662 Double Cylinder Deadbolt. The B600 Series is Schlage’s highest grade deadbolt locks. Choose the 600 for Grade 1 security in high-traffic commercial applications. B600 Series Schlage’s toughest heavy duty Grade 1 commercial deadbolt. Furnished with conventional cylinder standard. Also available with full size interchangeable core cylinder or small format interchangeable core (SFIC) cylinder. Requires 21 ⁄8" (54mm) prep. UL10B listing standard for auxiliary lock on A label fire doors.

Schlage B662 - Double Cylinder deadbolt ANSI-E0141

• Deadbolt thrown or retracted by key on either side.



Finishes: 605-Bright Brass, 606-Satin Brass, 609-Antique Brass, 612-Satin Bronze, 613-Oil Rubbed Bronze, 619-Satin Nickel, 625-Bright Chrome, 606-Satin Chrome

Features and Benefits
• 1” (25 mm) throw, high-strength steel alloy deadbolt with hardened steel roller resists sawing and kick-in attacks
• Precision-built solid brass 6-pin cylinders with phosphor bronze springs and nickel silver pins ensure long life and smooth operation
• Tough nickel silver keys for smooth, long-lasting operation
• Exclusive concealed wood frame reinforcer protects wood jamb against kick-in attacks
• Large inside thumbturn makes it easy to throw and retract deadbolt
• Security shield protects bolt from ice-pick attack through the door
• Hardened steel ball-bearings protect mounting bolts from drill attack

Specifications
Handing: B250-Series deadlatches are reversible. All other B-Series locksets are non-handed.
Door Thickness:
B250-Series, 5-pin: 13/8” to 13/4” (35mm to 44mm) standard. Available to 21/4” (57mm), assembled to order.
B500-Series, 5-pin: 13/8” to 13/4” thick (35mm to 44 mm) standard. Available to 21/4” (57mm), assembled to order.
B600/700/800-Series: 13/4” to 2” (44mm to 51mm) standard. Available for 13/8” (35mm) and doors up to 21/2” (63mm), assembled to order. Door ranges may vary by function.
Backset:
B250-Series: 23/8” (60mm) standard. 23/4” (70mm) optional.
B500-Series: Adjustable for 23/8” (60mm) or 23/4” (70mm) standard.
B600/700/800-Series: 23/4” (70mm) standard, 23/8” (60mm), 33/4” (95mm), 5” (127mm) optional.
Front: Brass, bronze or stainless steel. 11/8” x 21/4” (29mm x 57mm) square corner, beveled.
Dead Bolt: 1” (25 mm) throw with saw-resistant hardened steel insert.
Latch Bolt: Brass, 9/16” (14mm) throw, deadlocking on keyed and exterior functions.
Exposed Trim: Wrought brass, bronze or stainless steel.
Thumbturn: Pressure cast zinc, plated to match finish symbols.
Strike:
B500 Series: 11/8” x 23/4”, metal dust box reinforcer and three 3” screws. Optional strikes, lip lengths and ANSI strike box available.
B600 and B250-Series: 11/8” x 23/4” (32mm x 70mm) with steel reinforcer and two 3” screws standard.
Certifications
ANSI
:
B500 and B250-Series meet or exceed A156.5 Grade 2 strength and operational requirements.
B600/700/800-Series meets or exceeds A156.5 Grade 1 strength and operational requirements.
UL / cUL:
B600/700/800-Series locks are UL10B Listed auxiliary locks for A label single doors, 4 ’ x 8 ’.
UL10B Listing optional for B500-Series as auxiliary locks. Letter F and UL symbol on latch front indicate listing.
UL437 Listed locking cylinder optional:
Specify Primus 20-500 Series cylinder for B500 and B250-Series Grade 2 products, or specify B800-Series Grade 1 products.
ADA Compliant: Schlage Lock Company offers a wide selection of locks designed to meet the Americans With Disabilities Act.
Cylinder & Keys: 6-pin patented Everest C123 keyway standard with two nickel silver keys per lock. Items specified in C keyway will be furnished 5-pin.
Keying Options: Interchangeable core and Primus XP high security cylinders. Master keying, grand master keying and construction keying.
Warranty:
Commercial: Three-year limited.
Residential: Full lifetime mechanical.
Schlage B663 Classroom Deadbolt - Barzellock.com

Schlage B663 Classroom Deadbolt

by Schlage
$ 111.28

Schlage B663 Classroom Deadbolt. The B600 Series is Schlage’s highest grade deadbolt locks. Choose the 600 for Grade 1 security in high-traffic commercial applications. B600 Series Schlage’s toughest heavy duty Grade 1 commercial deadbolt. Furnished with conventional cylinder standard. Also available with full size interchangeable core cylinder or small format interchangeable core (SFIC) cylinder. Requires 21 ⁄8" (54mm) prep. UL10B listing standard for auxiliary lock on A label fire doors.

Schlage B663 - Classroom deadbolt ANSI-E0171

• Deadbolt thrown only by key outside.

• Deadbolt retracted by key outside or thumbturn inside.

Finishes: 605-Bright Brass, 606-Satin Brass, 609-Antique Brass, 612-Satin Bronze, 613-Oil Rubbed Bronze, 619-Satin Nickel, 625-Bright Chrome, 606-Satin Chrome

Features and Benefits
• 1” (25 mm) throw, high-strength steel alloy deadbolt with hardened steel roller resists sawing and kick-in attacks
• Precision-built solid brass 6-pin cylinders with phosphor bronze springs and nickel silver pins ensure long life and smooth operation
• Tough nickel silver keys for smooth, long-lasting operation
• Exclusive concealed wood frame reinforcer protects wood jamb against kick-in attacks
• Large inside thumbturn makes it easy to throw and retract deadbolt
• Security shield protects bolt from ice-pick attack through the door
• Hardened steel ball-bearings protect mounting bolts from drill attack

Specifications
Handing: B250-Series deadlatches are reversible. All other B-Series locksets are non-handed.
Door Thickness:
B250-Series, 5-pin: 13/8” to 13/4” (35mm to 44mm) standard. Available to 21/4” (57mm), assembled to order.
B500-Series, 5-pin: 13/8” to 13/4” thick (35mm to 44 mm) standard. Available to 21/4” (57mm), assembled to order.
B600/700/800-Series: 13/4” to 2” (44mm to 51mm) standard. Available for 13/8” (35mm) and doors up to 21/2” (63mm), assembled to order. Door ranges may vary by function.
Backset:
B250-Series: 23/8” (60mm) standard. 23/4” (70mm) optional.
B500-Series: Adjustable for 23/8” (60mm) or 23/4” (70mm) standard.
B600/700/800-Series: 23/4” (70mm) standard, 23/8” (60mm), 33/4” (95mm), 5” (127mm) optional.
Front: Brass, bronze or stainless steel. 11/8” x 21/4” (29mm x 57mm) square corner, beveled.
Dead Bolt: 1” (25 mm) throw with saw-resistant hardened steel insert.
Latch Bolt: Brass, 9/16” (14mm) throw, deadlocking on keyed and exterior functions.
Exposed Trim: Wrought brass, bronze or stainless steel.
Thumbturn: Pressure cast zinc, plated to match finish symbols.
Strike:
B500 Series: 11/8” x 23/4”, metal dust box reinforcer and three 3” screws. Optional strikes, lip lengths and ANSI strike box available.
B600 and B250-Series: 11/8” x 23/4” (32mm x 70mm) with steel reinforcer and two 3” screws standard.
Certifications
ANSI
:
B500 and B250-Series meet or exceed A156.5 Grade 2 strength and operational requirements.
B600/700/800-Series meets or exceeds A156.5 Grade 1 strength and operational requirements.
UL / cUL:
B600/700/800-Series locks are UL10B Listed auxiliary locks for A label single doors, 4 ’ x 8 ’.
UL10B Listing optional for B500-Series as auxiliary locks. Letter F and UL symbol on latch front indicate listing.
UL437 Listed locking cylinder optional:
Specify Primus 20-500 Series cylinder for B500 and B250-Series Grade 2 products, or specify B800-Series Grade 1 products.
ADA Compliant: Schlage Lock Company offers a wide selection of locks designed to meet the Americans With Disabilities Act.
Cylinder & Keys: 6-pin patented Everest C123 keyway standard with two nickel silver keys per lock. Items specified in C keyway will be furnished 5-pin.
Keying Options: Interchangeable core and Primus XP high security cylinders. Master keying, grand master keying and construction keying.
Warranty:
Commercial: Three-year limited.
Residential: Full lifetime mechanical.
Schlage B664 Cylinder Only Deadbolt - Barzellock.com

Schlage B664 Cylinder Only Deadbolt. The B600 Series is Schlage’s highest grade deadbolt locks. Choose the 600 for Grade 1 security in high-traffic commercial applications. B600 Series Schlage’s toughest heavy duty Grade 1 commercial deadbolt. Furnished with conventional cylinder standard. Also available with full size interchangeable core cylinder or small format interchangeable core (SFIC) cylinder. Requires 21 ⁄8" (54mm) prep. UL10B listing standard for auxiliary lock on A label fire doors.

Schlage B664 - Cylinder Only deadbolt ANSI-E0101

• Deadbolt thrown or retracted by key one side.

• No trim on inside

Finishes: 605-Bright Brass, 606-Satin Brass, 609-Antique Brass, 612-Satin Bronze, 613-Oil Rubbed Bronze, 619-Satin Nickel, 625-Bright Chrome, 606-Satin Chrome

Features and Benefits
• 1” (25 mm) throw, high-strength steel alloy deadbolt with hardened steel roller resists sawing and kick-in attacks
• Precision-built solid brass 6-pin cylinders with phosphor bronze springs and nickel silver pins ensure long life and smooth operation
• Tough nickel silver keys for smooth, long-lasting operation
• Exclusive concealed wood frame reinforcer protects wood jamb against kick-in attacks
• Large inside thumbturn makes it easy to throw and retract deadbolt
• Security shield protects bolt from ice-pick attack through the door
• Hardened steel ball-bearings protect mounting bolts from drill attack

Specifications
Handing: B250-Series deadlatches are reversible. All other B-Series locksets are non-handed.
Door Thickness:
B250-Series, 5-pin: 13/8” to 13/4” (35mm to 44mm) standard. Available to 21/4” (57mm), assembled to order.
B500-Series, 5-pin: 13/8” to 13/4” thick (35mm to 44 mm) standard. Available to 21/4” (57mm), assembled to order.
B600/700/800-Series: 13/4” to 2” (44mm to 51mm) standard. Available for 13/8” (35mm) and doors up to 21/2” (63mm), assembled to order. Door ranges may vary by function.
Backset:
B250-Series: 23/8” (60mm) standard. 23/4” (70mm) optional.
B500-Series: Adjustable for 23/8” (60mm) or 23/4” (70mm) standard.
B600/700/800-Series: 23/4” (70mm) standard, 23/8” (60mm), 33/4” (95mm), 5” (127mm) optional.
Front: Brass, bronze or stainless steel. 11/8” x 21/4” (29mm x 57mm) square corner, beveled.
Dead Bolt: 1” (25 mm) throw with saw-resistant hardened steel insert.
Latch Bolt: Brass, 9/16” (14mm) throw, deadlocking on keyed and exterior functions.
Exposed Trim: Wrought brass, bronze or stainless steel.
Thumbturn: Pressure cast zinc, plated to match finish symbols.
Strike:
B500 Series: 11/8” x 23/4”, metal dust box reinforcer and three 3” screws. Optional strikes, lip lengths and ANSI strike box available.
B600 and B250-Series: 11/8” x 23/4” (32mm x 70mm) with steel reinforcer and two 3” screws standard.
Certifications
ANSI
:
B500 and B250-Series meet or exceed A156.5 Grade 2 strength and operational requirements.
B600/700/800-Series meets or exceeds A156.5 Grade 1 strength and operational requirements.
UL / cUL:
B600/700/800-Series locks are UL10B Listed auxiliary locks for A label single doors, 4 ’ x 8 ’.
UL10B Listing optional for B500-Series as auxiliary locks. Letter F and UL symbol on latch front indicate listing.
UL437 Listed locking cylinder optional:
Specify Primus 20-500 Series cylinder for B500 and B250-Series Grade 2 products, or specify B800-Series Grade 1 products.
ADA Compliant: Schlage Lock Company offers a wide selection of locks designed to meet the Americans With Disabilities Act.
Cylinder & Keys: 6-pin patented Everest C123 keyway standard with two nickel silver keys per lock. Items specified in C keyway will be furnished 5-pin.
Keying Options: Interchangeable core and Primus XP high security cylinders. Master keying, grand master keying and construction keying.
Warranty:
Commercial: Three-year limited.
Residential: Full lifetime mechanical.
Schlage B680 Door Bolt - Barzellock.com

Schlage B680 Door Bolt

by Schlage
$ 109.20

Schlage B680 Door Bolt. The B600 Series is Schlage’s highest grade deadbolt locks. Choose the 600 for Grade 1 security in high-traffic commercial applications. B600 Series Schlage’s toughest heavy duty Grade 1 commercial deadbolt. Furnished with conventional cylinder standard. Also available with full size interchangeable core cylinder or small format interchangeable core (SFIC) cylinder. Requires 21 ⁄8" (54mm) prep. UL10B listing standard for auxiliary lock on A label fire doors.

Schlage B680 - Door Bolt

• Deadbolt thrown or retracted by thumbturn inside.

• No outside trim.

Finishes: 605-Bright Brass, 606-Satin Brass, 609-Antique Brass, 612-Satin Bronze, 613-Oil Rubbed Bronze, 619-Satin Nickel, 625-Bright Chrome, 606-Satin Chrome



Features and Benefits
• 1” (25 mm) throw, high-strength steel alloy deadbolt with hardened steel roller resists sawing and kick-in attacks
• Precision-built solid brass 6-pin cylinders with phosphor bronze springs and nickel silver pins ensure long life and smooth operation
• Tough nickel silver keys for smooth, long-lasting operation
• Exclusive concealed wood frame reinforcer protects wood jamb against kick-in attacks
• Large inside thumbturn makes it easy to throw and retract deadbolt
• Security shield protects bolt from ice-pick attack through the door
• Hardened steel ball-bearings protect mounting bolts from drill attack

Specifications
Handing: B250-Series deadlatches are reversible. All other B-Series locksets are non-handed.
Door Thickness:
B250-Series, 5-pin: 13/8” to 13/4” (35mm to 44mm) standard. Available to 21/4” (57mm), assembled to order.
B500-Series, 5-pin: 13/8” to 13/4” thick (35mm to 44 mm) standard. Available to 21/4” (57mm), assembled to order.
B600/700/800-Series: 13/4” to 2” (44mm to 51mm) standard. Available for 13/8” (35mm) and doors up to 21/2” (63mm), assembled to order. Door ranges may vary by function.
Backset:
B250-Series: 23/8” (60mm) standard. 23/4” (70mm) optional.
B500-Series: Adjustable for 23/8” (60mm) or 23/4” (70mm) standard.
B600/700/800-Series: 23/4” (70mm) standard, 23/8” (60mm), 33/4” (95mm), 5” (127mm) optional.
Front: Brass, bronze or stainless steel. 11/8” x 21/4” (29mm x 57mm) square corner, beveled.
Dead Bolt: 1” (25 mm) throw with saw-resistant hardened steel insert.
Latch Bolt: Brass, 9/16” (14mm) throw, deadlocking on keyed and exterior functions.
Exposed Trim: Wrought brass, bronze or stainless steel.
Thumbturn: Pressure cast zinc, plated to match finish symbols.
Strike:
B500 Series: 11/8” x 23/4”, metal dust box reinforcer and three 3” screws. Optional strikes, lip lengths and ANSI strike box available.
B600 and B250-Series: 11/8” x 23/4” (32mm x 70mm) with steel reinforcer and two 3” screws standard.
Certifications
ANSI
:
B500 and B250-Series meet or exceed A156.5 Grade 2 strength and operational requirements.
B600/700/800-Series meets or exceeds A156.5 Grade 1 strength and operational requirements.
UL / cUL:
B600/700/800-Series locks are UL10B Listed auxiliary locks for A label single doors, 4 ’ x 8 ’.
UL10B Listing optional for B500-Series as auxiliary locks. Letter F and UL symbol on latch front indicate listing.
UL437 Listed locking cylinder optional:
Specify Primus 20-500 Series cylinder for B500 and B250-Series Grade 2 products, or specify B800-Series Grade 1 products.
ADA Compliant: Schlage Lock Company offers a wide selection of locks designed to meet the Americans With Disabilities Act.
Cylinder & Keys: 6-pin patented Everest C123 keyway standard with two nickel silver keys per lock. Items specified in C keyway will be furnished 5-pin.
Keying Options: Interchangeable core and Primus XP high security cylinders. Master keying, grand master keying and construction keying.
Warranty:
Commercial: Three-year limited.
Residential: Full lifetime mechanical.
Schlage BE467F Smart Deadbolt

Schlage BE467F Smart Deadbolt

by Schlage
$ 333.00

MANY COLORS IN STOCK IN ADD OR GRW.

PLEASE CALL US AT 718-957-0007 TO CHECK AVAILABILITY.



Designed for multi-family properties

Eliminates the cost and hassle of managing keys

Two styles with a broad selection of finishes and suited decorative lever designs

Modern credentials - use a smart credential or smartphone as key

Upgrades property visual appeal

Increases intelligence and efficiency for property managers

Lock programming via mobile application on phone or tablet (Bluetooth connection)

Improves security and safety, reduces liability

ADA compliant

Supports networked (Gateway required), No-Tour and standalone applications

Up to 500 users per lock*

Audit trail reports up to 1,000 events**

Easy installation no wires to run and fits standard door prep

Up to 1 years (offline mode), up to 1 year (BLE credential enabled)

Also available as interconnected lock

*Maximum database storage capacity of lock. Can vary by access control software database capacity

** Maximum audit storage capacity of lock. Can vary by access control software audit storage capacity



Schlage Control Smart Lock Catalog

ADA Compliant: Yes



Applications: Residential single- and multi-family doors



Backset: Adjustable backset, fits 2-3/8 to 2-3/4 backsets



Battery: 4-AA batteries (included), 9V Battery Backup (If loss of battery power occurs, a 9V battery can be used to jump start the lock and provide access with an assigned credential.)



Door thickness range: 1-3/8 to 1-3/4 (thick door kit available up to 2-1/4)



Latch: 1" x 2-1/4" square and round corner faceplate (round corner standard, square corner included in package), 1" edge bore required



Material: All-metal chassis and escutcheons



Strike: 1-1/8 x 2-3/4, round corner, no box, latch strike



Warranty: Lifetime limited mechanical and finish; 1-year limited electronics

FEATURES:

  • Non-locking - ideal for closets and rooms where locking is not needed (Passage).
  • Privacy locking - ideal for bedrooms and bathrooms (Privacy).
  • Resistant to pick and bump security attacks, certified as meeting ANSI Grade 2 standards (Entrance).
  • Decorative door pull, non-turning(Dummy).
  • Easy 3-step installation, only a screwdriver needed.
  • Quality materials and construction for exceptional security.
  • Lifetime finish and mechanical guarantee.
  • Quality finishes coordinate with plumbing and lighting.

Specifications:

  • Applications: Residential single- and multi-family doors.
  • Certifications: ANSI A156.2, 1996, Series 4000 Grade 2.
  • U.L. Listed: Locks for up to three-hour fire doors available.
  • Door thickness range: 1-3/8" to 1-3/4" (35mm-44mm) standard.
  • Backset: Universal latch standard, fits either 2-3/8" (60mm) or 2-3/4" (70mm) backsets. 5" (127mm) backset  available.
  • ADA compliant: No.

Finishes:

Bright Brass, Satin Chrome, & Antique Brass.



Schlage CS210 Interconnected Lock

Schlage CS210 Interconnected Lock

by Schlage
$ 349.00

The CS210 interconnected lock provides exceptional performance, aesthetics, and flexibility for both residential and commercial applications. The CS210 features single motion egress (retracting both the latch and deadbolt simply by rotating the inside lever) to meet Life and Safety code requirements, while exceeding BHMA Grade 2 requirements for operational usage, security, cycle and finish. Eighteen lever designs, two outside deadbolt designs and two inside escutcheon designs - each in a choice of seven finishes - ensure the right aesthetics for whatever type of project. The adjustable escutcheon allows each lock to easily support either 4" or 5 1 ⁄2" door preps, eliminating any job-site surprises.



Security

  • Exceeds ANSI/BHMA Grade 2 requirements
  • UL listed for 3-hour fire door
  • Solid zinc bolt with hardened steel anti-saw pin
  • Metal wood frame reinforcer uses 3" screws to anchor deep into wood door frame to protect against kick-in attacks
  • Free spinning, cylinder collar resists wrenching and prying
  • Removeable security shield protects bolt from ice-pick attack through the door
  • Patented Everest 29™ S123 keyway is provided standard which prohibits unauthorized key duplication



Aesthetics

  • 18 lever styles
  • Two deadbolt designs
  • Two escutcheon designs
  • Seven available finishes
  • Suites with F Series and S Series tubular locks



Functional features

  • Entrance function
  • Adjustable backset has a lock-in-place helix design
  • Field configurable to fit a 4" or 5-1/2" door prep



Built to Last

  • Every Schlage lock undergoes intensive testing to determine its ANSI grade level including: cycle, resistance, door impact, warped door and bolt strength tests

Material

  • Deadbolt: Zinc with hardened steel anti-saw pin insert
  • Deadbolt trim ring: 7/16" and 1/8" solid brass
  • Cylinder: Solid brass in a solid zinc housing
  • Deadbolt wood frame reinforcer: Metal with 3" screws standard
  • Chassis: Zinc and steel components zinc dichromate plated for corrosion resistance



Door Thickness

  • Door thickness: 1-3/4" to 2" (44 mm to 51 mm) standard; 1-3/8" (35 mm) available



Trim Options

  • 18 lever designs made of pressure cast zinc, plated to match product finish specification
  • Escutcheons: wrought brass, plated to match product finish specification



Deadbolt

  • 1" housing diameter; 0.81" x 0.62" x 1" throw
  • Backset: Adjustable 2-3/8" or 2-3/4" backset (60 mm or 70 mm) standard; 5" optional
  • Faceplate: square corner 1-1⁄8" x 2-1/4" (29 mm x 57 mm) standard; round corner options available
  • Strike: 1-1/8" x 2-3/4" with square corners standard; round cornered options available



Latch

  • Backset: Adjustable 2-3/8" or 2-3/4" backset (60 mm or 70 mm) standard; 5" optional
  • Latchbolt: 1/2" (13 mm) throw brass, chrome plated standard
  • Faceplate: square and round corner dual option 1" x 2-1/4" (25 mm x 57 mm) standard
  • Strike: 1-5/8" x 2-1/4" (41 mm x 57 mm) T-strike standard; T-strike and round corner options available
  • Strike lip length: 1-1⁄8" (29 mm) standard
Product Information



Related Product Information



Technical resources

Schlage CTE-MTB15-485-B Door Controller

Designed for flexibility, the CTE ENGAGE single door controller is ideal for multifamily, commercial mixed use, narrow stile and retail storefront applications. It allows perimeter and common area openings to be managed in a single system along with Schlage Control® smart deadbolts, NDE cylindrical and LE mortise wireless locks.

The CTE is sold with a Schlage® MTB mobile enabled multi-technology credential reader (MTB11-485 or MTB15-485) and is designed to interface with an electrified lock, electromagnetic lock, electric strike, automatic operator or exit device to control an opening.

The CTE single door controller is designed for flexibility and can be managed with ENGAGE mobile apps or with one of our Physical Access Control Software (PACS) Alliance Member systems.

Security

  • Electronics bring more visibility and control to the opening
  • Allows an up to 5,000  users with audit trail of up to 2,000 events
  • Inputs include door position (DPS), request to exit (REX), request to enter (REN) and remote release (REL)



Efficiency

  • Manage users and assign access privileges from virtually anywhere
  • Send updates wirelessly at the CTE with the ENGAGE™ mobile application on a Bluetooth® enabled smart phone or tablet. Or leverage the existing Wi-Fi network to send periodic updates without visiting the lock
  • Supports holidays and time zones to enable auto lock and unlock during specified periods



Convenience

  • Works with most proximity or high security Schlage smart credentials(^1)
  • Compatible with Schlage MTB11-485 and MTB15-485 readers

Reader

  • Requires Schlage MTB11 or MTB15 Reader



Communication standards

  • Bluetooth low energy (version 4.2)
  • 2.4 GHz Wi-Fi® (IEEE 802.11b/g/n)
  • WPA2, WPA, WEP, 802.1x (PEAP)
  • Transport Layer Security (TLS) version 1.2
  • Advanced Encryption Standard (AES), 256-bit



Connectivity options

  • Mobile (send updates at CTE)
  • Wi-Fi access point (automatic daily updates)
  • ENGAGE Gateway, IP to host (Networked wireless reader interface)
  • No Tour with MT20W and smart credential or mobile credential (consult your access control software provider for specific support)



Additional

  • Operating temperatures: -31 °F to 151 °F (-35 °C to 66 °C)
  • Operating humidity 0 - 100% non-condensing
  • Dimensions 2.96″ x 5.89″  x 7.86″
  • BLE communication range:  Up to 30’ in typical building environments
  • For signal inputs as well as power inputs/outputs see the CTE data sheet



For full electronic specifications, please reference the CTE data sheet

CTE-MTB11: CTE with mobile enabled multi-technology mullion reader kit
• CTE-MTB15: CTE with mobile enabled multi-technology single gang reader kit
Schlage D10S Passage Knob Lock. Heavy duty performance for high traffic applications.
At Schlage we know that every product you specify has to stand up to constant use and abuse without compromising security. The D-Series gets the job done with tough, dependable ANSI Grade 1 locks designed for use in military barracks, back-of-house hospitality and retrofit applications. Built for heavy traffic applications, D-Series locks are easy to service and maintain, and come in a range of styles and finishes to fit your building.
SCHLAGE
ANSI
Description
D10S
F75
Passage Latch
D10S Passage latch:
• Both knobs always unlocked.
• Inside knob is always free for immediate egress.
Knob Designs
Orbit
Plymouth
Tulip

Schlage D-Series
Schlage D-Series knobs are built to tough manufacturing standards that ensure a long life with smooth performance. With finishes to fit your building design, and a choice of styles, the D-Series is one of the toughest knobs we make.

We don’t compromise on security.

The safety and security of your clients’ buildings is something we take very seriously. That’s why every Schlage lock and deadbolt undergoes intensive testing to determine its ANSI grade level:
• Cycle tests
• Resistance tests
• Door impact tests
• Warped door tests
• Bolt strength tests

We pay attention to these details so you can focus on creating a functional and aesthetically pleasing environment for your clients. In fact, every one of our D-Series locks meets ANSI Grade 1 standards for safety.

Features and Benefits
• Exceeds 800,000-cycle ANSI Grade 1 requirements
• Exceeds ANSI A156.2, Series 4000 Grade 1 lock knob torque requirements
• Heavy-gauge, cold-rolled steel mechanisms are corrosion treated for normal atmosphere conditions

Door Handing
All Schlage locks are reversible. Hand information is necessary to ensure proper cylinder orientation in keyed functions, and finish of latchbolt and strike for locks that are to be installed on reverse bevel doors. Consult your catalog for door handing information.

Specifications
Handing: Keyed functions of knob designs are field reversible.
Door Thickness: 1 3/8” to 2” (35mm–51mm) standard.
2” to 2 1/2” (51mm–64mm) optional.
Backset: 2 3/4” (70 mm) standard. 2 3/8”, 3 3/4” and 5”
(60 mm, 95 mm, 127 mm) optional.
Faceplate: Brass, bronze or stainless steel. 11/8” x 21/4”
(29 mm x 57mm) square corner, beveled.
Lock Chassis: Steel, zinc dichromate plated for corrosion resistance.
Latch Bolt: Brass, 1/2” (12mm) throw, deadlocking on keyed and exterior functions. 3/4” (19 mm) throw anti-friction latch available for pairs of fire doors.
Exposed Trim: Wrought brass, bronze or stainless steel.
Strike: ANSI curved lip strike 11/4” x 4 7/8” x 13/16”lip to center standard. Optional strikes, lip lengths and ANSI strike box available. See page 20.
Cylinder & Keys: 6-pin Everest 29 S123 keyway standard with two patented nickel silver keys per lock.
Keying Options: Full size interchangeable core and Primus® high security cylinders. Master keying, grand master keying and construction keying.
Warranty: Three-year limited warranty.

Certifications
ANSI: Meets or exceeds A156.2 Series 4000, Grade 1 strength and operational requirements.
Federal: Meets FF-H-106C Series 161.
UL / cUL: All locks listed for A label single doors, 4’ x 8’. Letter F and UL symbol on latch front indicate listing. Electrified functions are UL19X Listed for single point locking applications. UL437 Listed locking cylinder optional: specify Primus 20-500 Series cylinder.
ADA Compliant: Schlage Lock Company offers a wide selection of locks designed to meet the Americans With Disabilities Act.
Schlage D44S Hospital privacy Knob Lock. Heavy duty performance for high traffic applications.
At Schlage we know that every product you specify has to stand up to constant use and abuse without compromising security. The D-Series gets the job done with tough, dependable ANSI Grade 1 locks designed for use in military barracks, back-of-house hospitality and retrofit applications. Built for heavy traffic applications, D-Series locks are easy to service and maintain, and come in a range of styles and finishes to fit your building.
SCHLAGE
ANSI
Description
D170
Single Dummy Trim
D170 Single Dummy Lock:
• Dummy trim for one side of door.
• Used for door pull or as matching inactive trim.
Knob Designs
Orbit
Plymouth
Tulip

Schlage D-Series
Schlage D-Series knobs are built to tough manufacturing standards that ensure a long life with smooth performance. With finishes to fit your building design, and a choice of styles, the D-Series is one of the toughest knobs we make.

We don’t compromise on security.

The safety and security of your clients’ buildings is something we take very seriously. That’s why every Schlage lock and deadbolt undergoes intensive testing to determine its ANSI grade level:
• Cycle tests
• Resistance tests
• Door impact tests
• Warped door tests
• Bolt strength tests

We pay attention to these details so you can focus on creating a functional and aesthetically pleasing environment for your clients. In fact, every one of our D-Series locks meets ANSI Grade 1 standards for safety.

Features and Benefits
• Exceeds 800,000-cycle ANSI Grade 1 requirements
• Exceeds ANSI A156.2, Series 4000 Grade 1 lock knob torque requirements
• Heavy-gauge, cold-rolled steel mechanisms are corrosion treated for normal atmosphere conditions

Door Handing
All Schlage locks are reversible. Hand information is necessary to ensure proper cylinder orientation in keyed functions, and finish of latchbolt and strike for locks that are to be installed on reverse bevel doors. Consult your catalog for door handing information.

Specifications
Handing: Keyed functions of knob designs are field reversible.
Door Thickness: 1 3/8” to 2” (35mm–51mm) standard.
2” to 2 1/2” (51mm–64mm) optional.
Backset: 2 3/4” (70 mm) standard. 2 3/8”, 3 3/4” and 5”
(60 mm, 95 mm, 127 mm) optional.
Faceplate: Brass, bronze or stainless steel. 11/8” x 21/4”
(29 mm x 57mm) square corner, beveled.
Lock Chassis: Steel, zinc dichromate plated for corrosion resistance.
Latch Bolt: Brass, 1/2” (12mm) throw, deadlocking on keyed and exterior functions. 3/4” (19 mm) throw anti-friction latch available for pairs of fire doors.
Exposed Trim: Wrought brass, bronze or stainless steel.
Strike: ANSI curved lip strike 11/4” x 4 7/8” x 13/16”lip to center standard. Optional strikes, lip lengths and ANSI strike box available. See page 20.
Cylinder & Keys: 6-pin Everest 29 S123 keyway standard with two patented nickel silver keys per lock.
Keying Options: Full size interchangeable core and Primus® high security cylinders. Master keying, grand master keying and construction keying.
Warranty: Three-year limited warranty.

Certifications
ANSI: Meets or exceeds A156.2 Series 4000, Grade 1 strength and operational requirements.
Federal: Meets FF-H-106C Series 161.
UL / cUL: All locks listed for A label single doors, 4’ x 8’. Letter F and UL symbol on latch front indicate listing. Electrified functions are UL19X Listed for single point locking applications. UL437 Listed locking cylinder optional: specify Primus 20-500 Series cylinder.
ADA Compliant: Schlage Lock Company offers a wide selection of locks designed to meet the Americans With Disabilities Act.
Schlage D25D Exit Lock With blank Plate Knob Lock. Heavy duty performance for high traffic applications.
At Schlage we know that every product you specify has to stand up to constant use and abuse without compromising security. The D-Series gets the job done with tough, dependable ANSI Grade 1 locks designed for use in military barracks, back-of-house hospitality and retrofit applications. Built for heavy traffic applications, D-Series locks are easy to service and maintain, and come in a range of styles and finishes to fit your building.
SCHLAGE
ANSI
Description
D25D
Exit Lock with Blank Plate
• Blank plate outside.
• Inside knob always unlocked.
• Inside knob is always free for immediate egress.
• Specify door thickness.
Knob Designs
Orbit
Plymouth
Tulip

Schlage D-Series
Schlage D-Series knobs are built to tough manufacturing standards that ensure a long life with smooth performance. With finishes to fit your building design, and a choice of styles, the D-Series is one of the toughest knobs we make.

We don’t compromise on security.

The safety and security of your clients’ buildings is something we take very seriously. That’s why every Schlage lock and deadbolt undergoes intensive testing to determine its ANSI grade level:
• Cycle tests
• Resistance tests
• Door impact tests
• Warped door tests
• Bolt strength tests

We pay attention to these details so you can focus on creating a functional and aesthetically pleasing environment for your clients. In fact, every one of our D-Series locks meets ANSI Grade 1 standards for safety.

Features and Benefits
• Exceeds 800,000-cycle ANSI Grade 1 requirements
• Exceeds ANSI A156.2, Series 4000 Grade 1 lock knob torque requirements
• Heavy-gauge, cold-rolled steel mechanisms are corrosion treated for normal atmosphere conditions

Door Handing
All Schlage locks are reversible. Hand information is necessary to ensure proper cylinder orientation in keyed functions, and finish of latchbolt and strike for locks that are to be installed on reverse bevel doors. Consult your catalog for door handing information.

Specifications
Handing: Keyed functions of knob designs are field reversible.
Door Thickness: 1 3/8” to 2” (35mm–51mm) standard.
2” to 2 1/2” (51mm–64mm) optional.
Backset: 2 3/4” (70 mm) standard. 2 3/8”, 3 3/4” and 5”
(60 mm, 95 mm, 127 mm) optional.
Faceplate: Brass, bronze or stainless steel. 11/8” x 21/4”
(29 mm x 57mm) square corner, beveled.
Lock Chassis: Steel, zinc dichromate plated for corrosion resistance.
Latch Bolt: Brass, 1/2” (12mm) throw, deadlocking on keyed and exterior functions. 3/4” (19 mm) throw anti-friction latch available for pairs of fire doors.
Exposed Trim: Wrought brass, bronze or stainless steel.
Strike: ANSI curved lip strike 11/4” x 4 7/8” x 13/16”lip to center standard. Optional strikes, lip lengths and ANSI strike box available. See page 20.
Cylinder & Keys: 6-pin Everest 29 S123 keyway standard with two patented nickel silver keys per lock.
Keying Options: Full size interchangeable core and Primus® high security cylinders. Master keying, grand master keying and construction keying.
Warranty: Three-year limited warranty.

Certifications
ANSI: Meets or exceeds A156.2 Series 4000, Grade 1 strength and operational requirements.
Federal: Meets FF-H-106C Series 161.
UL / cUL: All locks listed for A label single doors, 4’ x 8’. Letter F and UL symbol on latch front indicate listing. Electrified functions are UL19X Listed for single point locking applications. UL437 Listed locking cylinder optional: specify Primus 20-500 Series cylinder.
ADA Compliant: Schlage Lock Company offers a wide selection of locks designed to meet the Americans With Disabilities Act.
Schlage D40S Bath/bedroom privacy Knob Lock. Heavy duty performance for high traffic applications.
At Schlage we know that every product you specify has to stand up to constant use and abuse without compromising security. The D-Series gets the job done with tough, dependable ANSI Grade 1 locks designed for use in military barracks, back-of-house hospitality and retrofit applications. Built for heavy traffic applications, D-Series locks are easy to service and maintain, and come in a range of styles and finishes to fit your building.
SCHLAGE
ANSI
Description
D40S
F76
Bath/Bedroom Privacy Lock
D40S Bath/Bedroom Privacy Lock:
• Push-button locking.
• Can be opened from outside with small screwdriver.
• Turn the inside knob or close the door to release button.
• Inside knob is always free for immediate egress.
Knob Designs
Orbit
Plymouth
Tulip

Schlage D-Series
Schlage D-Series knobs are built to tough manufacturing standards that ensure a long life with smooth performance. With finishes to fit your building design, and a choice of styles, the D-Series is one of the toughest knobs we make.

We don’t compromise on security.

The safety and security of your clients’ buildings is something we take very seriously. That’s why every Schlage lock and deadbolt undergoes intensive testing to determine its ANSI grade level:
• Cycle tests
• Resistance tests
• Door impact tests
• Warped door tests
• Bolt strength tests

We pay attention to these details so you can focus on creating a functional and aesthetically pleasing environment for your clients. In fact, every one of our D-Series locks meets ANSI Grade 1 standards for safety.

Features and Benefits
• Exceeds 800,000-cycle ANSI Grade 1 requirements
• Exceeds ANSI A156.2, Series 4000 Grade 1 lock knob torque requirements
• Heavy-gauge, cold-rolled steel mechanisms are corrosion treated for normal atmosphere conditions

Door Handing
All Schlage locks are reversible. Hand information is necessary to ensure proper cylinder orientation in keyed functions, and finish of latchbolt and strike for locks that are to be installed on reverse bevel doors. Consult your catalog for door handing information.

Specifications
Handing: Keyed functions of knob designs are field reversible.
Door Thickness: 1 3/8” to 2” (35mm–51mm) standard.
2” to 2 1/2” (51mm–64mm) optional.
Backset: 2 3/4” (70 mm) standard. 2 3/8”, 3 3/4” and 5”
(60 mm, 95 mm, 127 mm) optional.
Faceplate: Brass, bronze or stainless steel. 11/8” x 21/4”
(29 mm x 57mm) square corner, beveled.
Lock Chassis: Steel, zinc dichromate plated for corrosion resistance.
Latch Bolt: Brass, 1/2” (12mm) throw, deadlocking on keyed and exterior functions. 3/4” (19 mm) throw anti-friction latch available for pairs of fire doors.
Exposed Trim: Wrought brass, bronze or stainless steel.
Strike: ANSI curved lip strike 11/4” x 4 7/8” x 13/16”lip to center standard. Optional strikes, lip lengths and ANSI strike box available. See page 20.
Cylinder & Keys: 6-pin Everest 29 S123 keyway standard with two patented nickel silver keys per lock.
Keying Options: Full size interchangeable core and Primus® high security cylinders. Master keying, grand master keying and construction keying.
Warranty: Three-year limited warranty.

Certifications
ANSI: Meets or exceeds A156.2 Series 4000, Grade 1 strength and operational requirements.
Federal: Meets FF-H-106C Series 161.
UL / cUL: All locks listed for A label single doors, 4’ x 8’. Letter F and UL symbol on latch front indicate listing. Electrified functions are UL19X Listed for single point locking applications. UL437 Listed locking cylinder optional: specify Primus 20-500 Series cylinder.
ADA Compliant: Schlage Lock Company offers a wide selection of locks designed to meet the Americans With Disabilities Act.
Schlage D44S Hospital privacy Knob Lock. Heavy duty performance for high traffic applications.
At Schlage we know that every product you specify has to stand up to constant use and abuse without compromising security. The D-Series gets the job done with tough, dependable ANSI Grade 1 locks designed for use in military barracks, back-of-house hospitality and retrofit applications. Built for heavy traffic applications, D-Series locks are easy to service and maintain, and come in a range of styles and finishes to fit your building.
SCHLAGE
ANSI
Description
D44S
Hospital privacy lock
D44S Hospital Privacy Lock:
• Push-button locking.
• Unlock from outside by pushing emergency turn-button.
• Turn inside knob or close door to release button.
• Inside knob is always free for immediate egress.
Knob Designs
Orbit
Plymouth
Tulip

Schlage D-Series
Schlage D-Series knobs are built to tough manufacturing standards that ensure a long life with smooth performance. With finishes to fit your building design, and a choice of styles, the D-Series is one of the toughest knobs we make.

We don’t compromise on security.

The safety and security of your clients’ buildings is something we take very seriously. That’s why every Schlage lock and deadbolt undergoes intensive testing to determine its ANSI grade level:
• Cycle tests
• Resistance tests
• Door impact tests
• Warped door tests
• Bolt strength tests

We pay attention to these details so you can focus on creating a functional and aesthetically pleasing environment for your clients. In fact, every one of our D-Series locks meets ANSI Grade 1 standards for safety.

Features and Benefits
• Exceeds 800,000-cycle ANSI Grade 1 requirements
• Exceeds ANSI A156.2, Series 4000 Grade 1 lock knob torque requirements
• Heavy-gauge, cold-rolled steel mechanisms are corrosion treated for normal atmosphere conditions

Door Handing
All Schlage locks are reversible. Hand information is necessary to ensure proper cylinder orientation in keyed functions, and finish of latchbolt and strike for locks that are to be installed on reverse bevel doors. Consult your catalog for door handing information.

Specifications
Handing: Keyed functions of knob designs are field reversible.
Door Thickness: 1 3/8” to 2” (35mm–51mm) standard.
2” to 2 1/2” (51mm–64mm) optional.
Backset: 2 3/4” (70 mm) standard. 2 3/8”, 3 3/4” and 5”
(60 mm, 95 mm, 127 mm) optional.
Faceplate: Brass, bronze or stainless steel. 11/8” x 21/4”
(29 mm x 57mm) square corner, beveled.
Lock Chassis: Steel, zinc dichromate plated for corrosion resistance.
Latch Bolt: Brass, 1/2” (12mm) throw, deadlocking on keyed and exterior functions. 3/4” (19 mm) throw anti-friction latch available for pairs of fire doors.
Exposed Trim: Wrought brass, bronze or stainless steel.
Strike: ANSI curved lip strike 11/4” x 4 7/8” x 13/16”lip to center standard. Optional strikes, lip lengths and ANSI strike box available. See page 20.
Cylinder & Keys: 6-pin Everest 29 S123 keyway standard with two patented nickel silver keys per lock.
Keying Options: Full size interchangeable core and Primus® high security cylinders. Master keying, grand master keying and construction keying.
Warranty: Three-year limited warranty.

Certifications
ANSI: Meets or exceeds A156.2 Series 4000, Grade 1 strength and operational requirements.
Federal: Meets FF-H-106C Series 161.
UL / cUL: All locks listed for A label single doors, 4’ x 8’. Letter F and UL symbol on latch front indicate listing. Electrified functions are UL19X Listed for single point locking applications. UL437 Listed locking cylinder optional: specify Primus 20-500 Series cylinder.
ADA Compliant: Schlage Lock Company offers a wide selection of locks designed to meet the Americans With Disabilities Act.
Schlage D53PD Entrance Knob Lock D Series - Barzellock.com
Schlage D53PD Entrance Knob Lock. Heavy duty performance for high traffic applications.
At Schlage we know that every product you specify has to stand up to constant use and abuse without compromising security. The D-Series gets the job done with tough, dependable ANSI Grade 1 locks designed for use in military barracks, back-of-house hospitality and retrofit applications. Built for heavy traffic applications, D-Series locks are easy to service and maintain, and come in a range of styles and finishes to fit your building.
SCHLAGE
ANSI
Description
D53PD F109
Entrance Lock
D53PD Entrance Lock:
• Push button to lock outside knob.
• Knob stays locked until unlocked by key or by turning inside knob.
• Pushing and turning button locks outside knob, which stays locked until opened with a key.
• Inside knob is always free for immediate egress
Knob Designs
Orbit
Plymouth
Tulip

Schlage D-Series
Schlage D-Series knobs are built to tough manufacturing standards that ensure a long life with smooth performance. With finishes to fit your building design, and a choice of styles, the D-Series is one of the toughest knobs we make.

We don’t compromise on security.

The safety and security of your clients’ buildings is something we take very seriously. That’s why every Schlage lock and deadbolt undergoes intensive testing to determine its ANSI grade level:
• Cycle tests
• Resistance tests
• Door impact tests
• Warped door tests
• Bolt strength tests

We pay attention to these details so you can focus on creating a functional and aesthetically pleasing environment for your clients. In fact, every one of our D-Series locks meets ANSI Grade 1 standards for safety.

Features and Benefits
• Exceeds 800,000-cycle ANSI Grade 1 requirements
• Exceeds ANSI A156.2, Series 4000 Grade 1 lock knob torque requirements
• Heavy-gauge, cold-rolled steel mechanisms are corrosion treated for normal atmosphere conditions

Door Handing
All Schlage locks are reversible. Hand information is necessary to ensure proper cylinder orientation in keyed functions, and finish of latchbolt and strike for locks that are to be installed on reverse bevel doors. Consult your catalog for door handing information.

Specifications
Handing: Keyed functions of knob designs are field reversible.
Door Thickness: 1 3/8” to 2” (35mm–51mm) standard.
2” to 2 1/2” (51mm–64mm) optional.
Backset: 2 3/4” (70 mm) standard. 2 3/8”, 3 3/4” and 5”
(60 mm, 95 mm, 127 mm) optional.
Faceplate: Brass, bronze or stainless steel. 11/8” x 21/4”
(29 mm x 57mm) square corner, beveled.
Lock Chassis: Steel, zinc dichromate plated for corrosion resistance.
Latch Bolt: Brass, 1/2” (12mm) throw, deadlocking on keyed and exterior functions. 3/4” (19 mm) throw anti-friction latch available for pairs of fire doors.
Exposed Trim: Wrought brass, bronze or stainless steel.
Strike: ANSI curved lip strike 11/4” x 4 7/8” x 13/16”lip to center standard. Optional strikes, lip lengths and ANSI strike box available. See page 20.
Cylinder & Keys: 6-pin Everest 29 S123 keyway standard with two patented nickel silver keys per lock.
Keying Options: Full size interchangeable core and Primus® high security cylinders. Master keying, grand master keying and construction keying.
Warranty: Three-year limited warranty.

Certifications
ANSI: Meets or exceeds A156.2 Series 4000, Grade 1 strength and operational requirements.
Federal: Meets FF-H-106C Series 161.
UL / cUL: All locks listed for A label single doors, 4’ x 8’. Letter F and UL symbol on latch front indicate listing. Electrified functions are UL19X Listed for single point locking applications. UL437 Listed locking cylinder optional: specify Primus 20-500 Series cylinder.
ADA Compliant: Schlage Lock Company offers a wide selection of locks designed to meet the Americans With Disabilities Act.
Schlage D60PD Vestibule Knob Lock D Series - Barzellock.com
Schlage D60PD Vestibule Knob Lock. Heavy duty performance for high traffic applications.
At Schlage we know that every product you specify has to stand up to constant use and abuse without compromising security. The D-Series gets the job done with tough, dependable ANSI Grade 1 locks designed for use in military barracks, back-of-house hospitality and retrofit applications. Built for heavy traffic applications, D-Series locks are easy to service and maintain, and come in a range of styles and finishes to fit your building.
SCHLAGE
ANSI
Description
D60PD F88 Vestibule Lock
Schlage D60PD Vestibule Lock:
• Latch is retracted by key from the outside when the outside knob is locked by a key in the inside knob.
• Inside knob is always free for immediate egress
Knob Designs
Orbit
Plymouth
Tulip

Schlage D-Series
Schlage D-Series knobs are built to tough manufacturing standards that ensure a long life with smooth performance. With finishes to fit your building design, and a choice of styles, the D-Series is one of the toughest knobs we make.

We don’t compromise on security.

The safety and security of your clients’ buildings is something we take very seriously. That’s why every Schlage lock and deadbolt undergoes intensive testing to determine its ANSI grade level:
• Cycle tests
• Resistance tests
• Door impact tests
• Warped door tests
• Bolt strength tests

We pay attention to these details so you can focus on creating a functional and aesthetically pleasing environment for your clients. In fact, every one of our D-Series locks meets ANSI Grade 1 standards for safety.

Features and Benefits
• Exceeds 800,000-cycle ANSI Grade 1 requirements
• Exceeds ANSI A156.2, Series 4000 Grade 1 lock knob torque requirements
• Heavy-gauge, cold-rolled steel mechanisms are corrosion treated for normal atmosphere conditions

Door Handing
All Schlage locks are reversible. Hand information is necessary to ensure proper cylinder orientation in keyed functions, and finish of latchbolt and strike for locks that are to be installed on reverse bevel doors. Consult your catalog for door handing information.

Specifications
Handing: Keyed functions of knob designs are field reversible.
Door Thickness: 1 3/8” to 2” (35mm–51mm) standard.
2” to 2 1/2” (51mm–64mm) optional.
Backset: 2 3/4” (70 mm) standard. 2 3/8”, 3 3/4” and 5”
(60 mm, 95 mm, 127 mm) optional.
Faceplate: Brass, bronze or stainless steel. 11/8” x 21/4”
(29 mm x 57mm) square corner, beveled.
Lock Chassis: Steel, zinc dichromate plated for corrosion resistance.
Latch Bolt: Brass, 1/2” (12mm) throw, deadlocking on keyed and exterior functions. 3/4” (19 mm) throw anti-friction latch available for pairs of fire doors.
Exposed Trim: Wrought brass, bronze or stainless steel.
Strike: ANSI curved lip strike 11/4” x 4 7/8” x 13/16”lip to center standard. Optional strikes, lip lengths and ANSI strike box available. See page 20.
Cylinder & Keys: 6-pin Everest 29 S123 keyway standard with two patented nickel silver keys per lock.
Keying Options: Full size interchangeable core and Primus® high security cylinders. Master keying, grand master keying and construction keying.
Warranty: Three-year limited warranty.

Certifications
ANSI: Meets or exceeds A156.2 Series 4000, Grade 1 strength and operational requirements.
Federal: Meets FF-H-106C Series 161.
UL / cUL: All locks listed for A label single doors, 4’ x 8’. Letter F and UL symbol on latch front indicate listing. Electrified functions are UL19X Listed for single point locking applications. UL437 Listed locking cylinder optional: specify Primus 20-500 Series cylinder.
ADA Compliant: Schlage Lock Company offers a wide selection of locks designed to meet the Americans With Disabilities Act.
Schlage D66PD Store Door Knob Lock D Series - Barzellock.com
Schlage D66PD Store Door Knob Lock. Heavy duty performance for high traffic applications.
At Schlage we know that every product you specify has to stand up to constant use and abuse without compromising security. The D-Series gets the job done with tough, dependable ANSI Grade 1 locks designed for use in military barracks, back-of-house hospitality and retrofit applications. Built for heavy traffic applications, D-Series locks are easy to service and maintain, and come in a range of styles and finishes to fit your building.
SCHLAGE
ANSI
Description
D66PD F91 Store Door Lock
Schlage D66PD Store Door Lock:
• Key in either knob locks or unlocks both knobs.
Caution: Double cylinder locks are a life safety hazard in times of emergency and their use is not recommended. Installation should be in accordance with existing codes only.
Knob Designs
Orbit
Plymouth
Tulip

Schlage D-Series
Schlage D-Series knobs are built to tough manufacturing standards that ensure a long life with smooth performance. With finishes to fit your building design, and a choice of styles, the D-Series is one of the toughest knobs we make.

We don’t compromise on security.

The safety and security of your clients’ buildings is something we take very seriously. That’s why every Schlage lock and deadbolt undergoes intensive testing to determine its ANSI grade level:
• Cycle tests
• Resistance tests
• Door impact tests
• Warped door tests
• Bolt strength tests

We pay attention to these details so you can focus on creating a functional and aesthetically pleasing environment for your clients. In fact, every one of our D-Series locks meets ANSI Grade 1 standards for safety.

Features and Benefits
• Exceeds 800,000-cycle ANSI Grade 1 requirements
• Exceeds ANSI A156.2, Series 4000 Grade 1 lock knob torque requirements
• Heavy-gauge, cold-rolled steel mechanisms are corrosion treated for normal atmosphere conditions

Door Handing
All Schlage locks are reversible. Hand information is necessary to ensure proper cylinder orientation in keyed functions, and finish of latchbolt and strike for locks that are to be installed on reverse bevel doors. Consult your catalog for door handing information.

Specifications
Handing: Keyed functions of knob designs are field reversible.
Door Thickness: 1 3/8” to 2” (35mm–51mm) standard.
2” to 2 1/2” (51mm–64mm) optional.
Backset: 2 3/4” (70 mm) standard. 2 3/8”, 3 3/4” and 5”
(60 mm, 95 mm, 127 mm) optional.
Faceplate: Brass, bronze or stainless steel. 11/8” x 21/4”
(29 mm x 57mm) square corner, beveled.
Lock Chassis: Steel, zinc dichromate plated for corrosion resistance.
Latch Bolt: Brass, 1/2” (12mm) throw, deadlocking on keyed and exterior functions. 3/4” (19 mm) throw anti-friction latch available for pairs of fire doors.
Exposed Trim: Wrought brass, bronze or stainless steel.
Strike: ANSI curved lip strike 11/4” x 4 7/8” x 13/16”lip to center standard. Optional strikes, lip lengths and ANSI strike box available. See page 20.
Cylinder & Keys: 6-pin Everest 29 S123 keyway standard with two patented nickel silver keys per lock.
Keying Options: Full size interchangeable core and Primus® high security cylinders. Master keying, grand master keying and construction keying.
Warranty: Three-year limited warranty.

Certifications
ANSI: Meets or exceeds A156.2 Series 4000, Grade 1 strength and operational requirements.
Federal: Meets FF-H-106C Series 161.
UL / cUL: All locks listed for A label single doors, 4’ x 8’. Letter F and UL symbol on latch front indicate listing. Electrified functions are UL19X Listed for single point locking applications. UL437 Listed locking cylinder optional: specify Primus 20-500 Series cylinder.
ADA Compliant: Schlage Lock Company offers a wide selection of locks designed to meet the Americans With Disabilities Act.
Schlage D70PD Classroom Knob Lock D Series - Barzellock.com
Schlage D70PD Classroom Knob Lock. Heavy duty performance for high traffic applications.
At Schlage we know that every product you specify has to stand up to constant use and abuse without compromising security. The D-Series gets the job done with tough, dependable ANSI Grade 1 locks designed for use in military barracks, back-of-house hospitality and retrofit applications. Built for heavy traffic applications, D-Series locks are easy to service and maintain, and come in a range of styles and finishes to fit your building.
SCHLAGE
ANSI
Description
D70PD F84 Classroom Lock
Schlage D70PD Classroom Lock:
Outside knob is locked and unlocked by key.
• Inside knob is always free for immediate egress.
Knob Designs
Orbit
Plymouth
Tulip

Schlage D-Series
Schlage D-Series knobs are built to tough manufacturing standards that ensure a long life with smooth performance. With finishes to fit your building design, and a choice of styles, the D-Series is one of the toughest knobs we make.

We don’t compromise on security.

The safety and security of your clients’ buildings is something we take very seriously. That’s why every Schlage lock and deadbolt undergoes intensive testing to determine its ANSI grade level:
• Cycle tests
• Resistance tests
• Door impact tests
• Warped door tests
• Bolt strength tests

We pay attention to these details so you can focus on creating a functional and aesthetically pleasing environment for your clients. In fact, every one of our D-Series locks meets ANSI Grade 1 standards for safety.

Features and Benefits
• Exceeds 800,000-cycle ANSI Grade 1 requirements
• Exceeds ANSI A156.2, Series 4000 Grade 1 lock knob torque requirements
• Heavy-gauge, cold-rolled steel mechanisms are corrosion treated for normal atmosphere conditions

Door Handing
All Schlage locks are reversible. Hand information is necessary to ensure proper cylinder orientation in keyed functions, and finish of latchbolt and strike for locks that are to be installed on reverse bevel doors. Consult your catalog for door handing information.

Specifications
Handing: Keyed functions of knob designs are field reversible.
Door Thickness: 1 3/8” to 2” (35mm–51mm) standard.
2” to 2 1/2” (51mm–64mm) optional.
Backset: 2 3/4” (70 mm) standard. 2 3/8”, 3 3/4” and 5”
(60 mm, 95 mm, 127 mm) optional.
Faceplate: Brass, bronze or stainless steel. 11/8” x 21/4”
(29 mm x 57mm) square corner, beveled.
Lock Chassis: Steel, zinc dichromate plated for corrosion resistance.
Latch Bolt: Brass, 1/2” (12mm) throw, deadlocking on keyed and exterior functions. 3/4” (19 mm) throw anti-friction latch available for pairs of fire doors.
Exposed Trim: Wrought brass, bronze or stainless steel.
Strike: ANSI curved lip strike 11/4” x 4 7/8” x 13/16”lip to center standard. Optional strikes, lip lengths and ANSI strike box available. See page 20.
Cylinder & Keys: 6-pin Everest 29 S123 keyway standard with two patented nickel silver keys per lock.
Keying Options: Full size interchangeable core and Primus® high security cylinders. Master keying, grand master keying and construction keying.
Warranty: Three-year limited warranty.

Certifications
ANSI: Meets or exceeds A156.2 Series 4000, Grade 1 strength and operational requirements.
Federal: Meets FF-H-106C Series 161.
UL / cUL: All locks listed for A label single doors, 4’ x 8’. Letter F and UL symbol on latch front indicate listing. Electrified functions are UL19X Listed for single point locking applications. UL437 Listed locking cylinder optional: specify Primus 20-500 Series cylinder.
ADA Compliant: Schlage Lock Company offers a wide selection of locks designed to meet the Americans With Disabilities Act.
Schlage D72PD Communicating Knob Lock D Series - Barzellock.com
Schlage D72PD Communicating Knob Lock. Heavy duty performance for high traffic applications.
At Schlage we know that every product you specify has to stand up to constant use and abuse without compromising security. The D-Series gets the job done with tough, dependable ANSI Grade 1 locks designed for use in military barracks, back-of-house hospitality and retrofit applications. Built for heavy traffic applications, D-Series locks are easy to service and maintain, and come in a range of styles and finishes to fit your building.
SCHLAGE
ANSI
Description
D72PD F80 Communicating Lock
Schlage D72PD Communicating Lock:
• Key in either knob locks or unlocks its own knob independently.
Caution: Double cylinder locks are a life safety hazard in times of emergency and their use is not recommended. Installation should be in accordance with existing codes only.
Knob Styles:
Orbit
Plymouth
Tulip

Schlage D-Series
Schlage D-Series knobs are built to tough manufacturing standards that ensure a long life with smooth performance. With finishes to fit your building design, and a choice of styles, the D-Series is one of the toughest knobs we make.

We don’t compromise on security.

The safety and security of your clients’ buildings is something we take very seriously. That’s why every Schlage lock and deadbolt undergoes intensive testing to determine its ANSI grade level:
• Cycle tests
• Resistance tests
• Door impact tests
• Warped door tests
• Bolt strength tests

We pay attention to these details so you can focus on creating a functional and aesthetically pleasing environment for your clients. In fact, every one of our D-Series locks meets ANSI Grade 1 standards for safety.

Features and Benefits
• Exceeds 800,000-cycle ANSI Grade 1 requirements
• Exceeds ANSI A156.2, Series 4000 Grade 1 lock knob torque requirements
• Heavy-gauge, cold-rolled steel mechanisms are corrosion treated for normal atmosphere conditions

Door Handing
All Schlage locks are reversible. Hand information is necessary to ensure proper cylinder orientation in keyed functions, and finish of latchbolt and strike for locks that are to be installed on reverse bevel doors. Consult your catalog for door handing information.

Specifications
Handing: Keyed functions of knob designs are field reversible.
Door Thickness: 1 3/8” to 2” (35mm–51mm) standard.
2” to 2 1/2” (51mm–64mm) optional.
Backset: 2 3/4” (70 mm) standard. 2 3/8”, 3 3/4” and 5”
(60 mm, 95 mm, 127 mm) optional.
Faceplate: Brass, bronze or stainless steel. 11/8” x 21/4”
(29 mm x 57mm) square corner, beveled.
Lock Chassis: Steel, zinc dichromate plated for corrosion resistance.
Latch Bolt: Brass, 1/2” (12mm) throw, deadlocking on keyed and exterior functions. 3/4” (19 mm) throw anti-friction latch available for pairs of fire doors.
Exposed Trim: Wrought brass, bronze or stainless steel.
Strike: ANSI curved lip strike 11/4” x 4 7/8” x 13/16”lip to center standard. Optional strikes, lip lengths and ANSI strike box available. See page 20.
Cylinder & Keys: 6-pin Everest 29 S123 keyway standard with two patented nickel silver keys per lock.
Keying Options: Full size interchangeable core and Primus® high security cylinders. Master keying, grand master keying and construction keying.
Warranty: Three-year limited warranty.

Certifications
ANSI: Meets or exceeds A156.2 Series 4000, Grade 1 strength and operational requirements.
Federal: Meets FF-H-106C Series 161.
UL / cUL: All locks listed for A label single doors, 4’ x 8’. Letter F and UL symbol on latch front indicate listing. Electrified functions are UL19X Listed for single point locking applications. UL437 Listed locking cylinder optional: specify Primus 20-500 Series cylinder.
ADA Compliant: Schlage Lock Company offers a wide selection of locks designed to meet the Americans With Disabilities Act.
Schlage D73PD Corridor Knob Lock D Series - Barzellock.com
Schlage D73PD Corridor Knob Lock. Heavy duty performance for high traffic applications.
At Schlage we know that every product you specify has to stand up to constant use and abuse without compromising security. The D-Series gets the job done with tough, dependable ANSI Grade 1 locks designed for use in military barracks, back-of-house hospitality and retrofit applications. Built for heavy traffic applications, D-Series locks are easy to service and maintain, and come in a range of styles and finishes to fit your building.
SCHLAGE
ANSI
Description
D73PD F90 Corridor Lock
Schlage D73PD Corridor Lock:
• Locked or unlocked by key from outside.
• Push-button locking from inside.
• Turn inside knob or close door to release button.
• Inside knob is always free for immediate egress
Knob Designs
Orbit
Plymouth
Tulip

Schlage D-Series
Schlage D-Series knobs are built to tough manufacturing standards that ensure a long life with smooth performance. With finishes to fit your building design, and a choice of styles, the D-Series is one of the toughest knobs we make.

We don’t compromise on security.

The safety and security of your clients’ buildings is something we take very seriously. That’s why every Schlage lock and deadbolt undergoes intensive testing to determine its ANSI grade level:
• Cycle tests
• Resistance tests
• Door impact tests
• Warped door tests
• Bolt strength tests

We pay attention to these details so you can focus on creating a functional and aesthetically pleasing environment for your clients. In fact, every one of our D-Series locks meets ANSI Grade 1 standards for safety.

Features and Benefits
• Exceeds 800,000-cycle ANSI Grade 1 requirements
• Exceeds ANSI A156.2, Series 4000 Grade 1 lock knob torque requirements
• Heavy-gauge, cold-rolled steel mechanisms are corrosion treated for normal atmosphere conditions

Door Handing
All Schlage locks are reversible. Hand information is necessary to ensure proper cylinder orientation in keyed functions, and finish of latchbolt and strike for locks that are to be installed on reverse bevel doors. Consult your catalog for door handing information.

Specifications
Handing: Keyed functions of knob designs are field reversible.
Door Thickness: 1 3/8” to 2” (35mm–51mm) standard.
2” to 2 1/2” (51mm–64mm) optional.
Backset: 2 3/4” (70 mm) standard. 2 3/8”, 3 3/4” and 5”
(60 mm, 95 mm, 127 mm) optional.
Faceplate: Brass, bronze or stainless steel. 11/8” x 21/4”
(29 mm x 57mm) square corner, beveled.
Lock Chassis: Steel, zinc dichromate plated for corrosion resistance.
Latch Bolt: Brass, 1/2” (12mm) throw, deadlocking on keyed and exterior functions. 3/4” (19 mm) throw anti-friction latch available for pairs of fire doors.
Exposed Trim: Wrought brass, bronze or stainless steel.
Strike: ANSI curved lip strike 11/4” x 4 7/8” x 13/16”lip to center standard. Optional strikes, lip lengths and ANSI strike box available. See page 20.
Cylinder & Keys: 6-pin Everest 29 S123 keyway standard with two patented nickel silver keys per lock.
Keying Options: Full size interchangeable core and Primus® high security cylinders. Master keying, grand master keying and construction keying.
Warranty: Three-year limited warranty.

Certifications
ANSI: Meets or exceeds A156.2 Series 4000, Grade 1 strength and operational requirements.
Federal: Meets FF-H-106C Series 161.
UL / cUL: All locks listed for A label single doors, 4’ x 8’. Letter F and UL symbol on latch front indicate listing. Electrified functions are UL19X Listed for single point locking applications. UL437 Listed locking cylinder optional: specify Primus 20-500 Series cylinder.
ADA Compliant: Schlage Lock Company offers a wide selection of locks designed to meet the Americans With Disabilities Act.
Schlage D80PD Storeroom Knob Lock D Series - Barzellock.com
Schlage D80PD Storeroom Knob Lock. Heavy duty performance for high traffic applications.
At Schlage we know that every product you specify has to stand up to constant use and abuse without compromising security. The D-Series gets the job done with tough, dependable ANSI Grade 1 locks designed for use in military barracks, back-of-house hospitality and retrofit applications. Built for heavy traffic applications, D-Series locks are easy to service and maintain, and come in a range of styles and finishes to fit your building.
SCHLAGE
ANSI
Description
D80PD F86 Storeroom Lock
Schlage D80PD Storeroom Lock:
 Outside knob is fixed.
• Entrance by key only.
• Inside knob is always free for immediate egress.
Knob Designs
Orbit
Plymouth
Tulip

Schlage D-Series
Schlage D-Series knobs are built to tough manufacturing standards that ensure a long life with smooth performance. With finishes to fit your building design, and a choice of styles, the D-Series is one of the toughest knobs we make.

We don’t compromise on security.

The safety and security of your clients’ buildings is something we take very seriously. That’s why every Schlage lock and deadbolt undergoes intensive testing to determine its ANSI grade level:
• Cycle tests
• Resistance tests
• Door impact tests
• Warped door tests
• Bolt strength tests

We pay attention to these details so you can focus on creating a functional and aesthetically pleasing environment for your clients. In fact, every one of our D-Series locks meets ANSI Grade 1 standards for safety.

Features and Benefits
• Exceeds 800,000-cycle ANSI Grade 1 requirements
• Exceeds ANSI A156.2, Series 4000 Grade 1 lock knob torque requirements
• Heavy-gauge, cold-rolled steel mechanisms are corrosion treated for normal atmosphere conditions

Door Handing
All Schlage locks are reversible. Hand information is necessary to ensure proper cylinder orientation in keyed functions, and finish of latchbolt and strike for locks that are to be installed on reverse bevel doors. Consult your catalog for door handing information.

Specifications
Handing: Keyed functions of knob designs are field reversible.
Door Thickness: 1 3/8” to 2” (35mm–51mm) standard.
2” to 2 1/2” (51mm–64mm) optional.
Backset: 2 3/4” (70 mm) standard. 2 3/8”, 3 3/4” and 5”
(60 mm, 95 mm, 127 mm) optional.
Faceplate: Brass, bronze or stainless steel. 11/8” x 21/4”
(29 mm x 57mm) square corner, beveled.
Lock Chassis: Steel, zinc dichromate plated for corrosion resistance.
Latch Bolt: Brass, 1/2” (12mm) throw, deadlocking on keyed and exterior functions. 3/4” (19 mm) throw anti-friction latch available for pairs of fire doors.
Exposed Trim: Wrought brass, bronze or stainless steel.
Strike: ANSI curved lip strike 11/4” x 4 7/8” x 13/16”lip to center standard. Optional strikes, lip lengths and ANSI strike box available. See page 20.
Cylinder & Keys: 6-pin Everest 29 S123 keyway standard with two patented nickel silver keys per lock.
Keying Options: Full size interchangeable core and Primus® high security cylinders. Master keying, grand master keying and construction keying.
Warranty: Three-year limited warranty.

Certifications
ANSI: Meets or exceeds A156.2 Series 4000, Grade 1 strength and operational requirements.
Federal: Meets FF-H-106C Series 161.
UL / cUL: All locks listed for A label single doors, 4’ x 8’. Letter F and UL symbol on latch front indicate listing. Electrified functions are UL19X Listed for single point locking applications. UL437 Listed locking cylinder optional: specify Primus 20-500 Series cylinder.
ADA Compliant: Schlage Lock Company offers a wide selection of locks designed to meet the Americans With Disabilities Act.
Schlage D82PD Institution Knob Lock D Series - Barzellock.com
Schlage D82PD Institution Knob Lock. Heavy duty performance for high traffic applications.
At Schlage we know that every product you specify has to stand up to constant use and abuse without compromising security. The D-Series gets the job done with tough, dependable ANSI Grade 1 locks designed for use in military barracks, back-of-house hospitality and retrofit applications. Built for heavy traffic applications, D-Series locks are easy to service and maintain, and come in a range of styles and finishes to fit your building.
SCHLAGE
ANSI
Description
D82PD F87 Institution Lock
Schlage D82PD Institution Lock:
• Both knobs fixed.
• Entrance by key in either knob
Caution: Double cylinder locks are a life safety hazard in times of emergency and their use is not recommended. Installation should be in accordance with existing codes only.
Knob Styles:
Orbit
Plymouth
Tulip

Schlage D-Series
Schlage D-Series knobs are built to tough manufacturing standards that ensure a long life with smooth performance. With finishes to fit your building design, and a choice of styles, the D-Series is one of the toughest knobs we make.

We don’t compromise on security.

The safety and security of your clients’ buildings is something we take very seriously. That’s why every Schlage lock and deadbolt undergoes intensive testing to determine its ANSI grade level:
• Cycle tests
• Resistance tests
• Door impact tests
• Warped door tests
• Bolt strength tests

We pay attention to these details so you can focus on creating a functional and aesthetically pleasing environment for your clients. In fact, every one of our D-Series locks meets ANSI Grade 1 standards for safety.

Features and Benefits
• Exceeds 800,000-cycle ANSI Grade 1 requirements
• Exceeds ANSI A156.2, Series 4000 Grade 1 lock knob torque requirements
• Heavy-gauge, cold-rolled steel mechanisms are corrosion treated for normal atmosphere conditions

Door Handing
All Schlage locks are reversible. Hand information is necessary to ensure proper cylinder orientation in keyed functions, and finish of latchbolt and strike for locks that are to be installed on reverse bevel doors. Consult your catalog for door handing information.

Specifications
Handing: Keyed functions of knob designs are field reversible.
Door Thickness: 1 3/8” to 2” (35mm–51mm) standard.
2” to 2 1/2” (51mm–64mm) optional.
Backset: 2 3/4” (70 mm) standard. 2 3/8”, 3 3/4” and 5”
(60 mm, 95 mm, 127 mm) optional.
Faceplate: Brass, bronze or stainless steel. 11/8” x 21/4”
(29 mm x 57mm) square corner, beveled.
Lock Chassis: Steel, zinc dichromate plated for corrosion resistance.
Latch Bolt: Brass, 1/2” (12mm) throw, deadlocking on keyed and exterior functions. 3/4” (19 mm) throw anti-friction latch available for pairs of fire doors.
Exposed Trim: Wrought brass, bronze or stainless steel.
Strike: ANSI curved lip strike 11/4” x 4 7/8” x 13/16”lip to center standard. Optional strikes, lip lengths and ANSI strike box available. See page 20.
Cylinder & Keys: 6-pin Everest 29 S123 keyway standard with two patented nickel silver keys per lock.
Keying Options: Full size interchangeable core and Primus® high security cylinders. Master keying, grand master keying and construction keying.
Warranty: Three-year limited warranty.

Certifications
ANSI: Meets or exceeds A156.2 Series 4000, Grade 1 strength and operational requirements.
Federal: Meets FF-H-106C Series 161.
UL / cUL: All locks listed for A label single doors, 4’ x 8’. Letter F and UL symbol on latch front indicate listing. Electrified functions are UL19X Listed for single point locking applications. UL437 Listed locking cylinder optional: specify Primus 20-500 Series cylinder.
ADA Compliant: Schlage Lock Company offers a wide selection of locks designed to meet the Americans With Disabilities Act.
Schlage D85PD Hotel or Restroom Knob Lock D Series - Barzellock.com
Schlage D85PD Hotel or Restroom Knob Lock. Heavy duty performance for high traffic applications.
At Schlage we know that every product you specify has to stand up to constant use and abuse without compromising security. The D-Series gets the job done with tough, dependable ANSI Grade 1 locks designed for use in military barracks, back-of-house hospitality and retrofit applications. Built for heavy traffic applications, D-Series locks are easy to service and maintain, and come in a range of styles and finishes to fit your building.
SCHLAGE
ANSI
Description
D85PD F93 Hotel or Restroom Lock
Schlage D80PD Hotel or Restroom Lock:
• Outside knob is fixed.
• Entrance by key only.
• Push-button on inside knob activates “shut-out” mode with visual occupancy indicator, allowing only master key to operate.
• Rotate inside knob to release shut-out mode, except when inside spinner-button has been rotated to keep lock in shut-out mode.
• Inside knob is always free for immediate egress
Knob Designs
Orbit
Plymouth
Tulip

Schlage D-Series
Schlage D-Series knobs are built to tough manufacturing standards that ensure a long life with smooth performance. With finishes to fit your building design, and a choice of styles, the D-Series is one of the toughest knobs we make.

We don’t compromise on security.

The safety and security of your clients’ buildings is something we take very seriously. That’s why every Schlage lock and deadbolt undergoes intensive testing to determine its ANSI grade level:
• Cycle tests
• Resistance tests
• Door impact tests
• Warped door tests
• Bolt strength tests

We pay attention to these details so you can focus on creating a functional and aesthetically pleasing environment for your clients. In fact, every one of our D-Series locks meets ANSI Grade 1 standards for safety.

Features and Benefits
• Exceeds 800,000-cycle ANSI Grade 1 requirements
• Exceeds ANSI A156.2, Series 4000 Grade 1 lock knob torque requirements
• Heavy-gauge, cold-rolled steel mechanisms are corrosion treated for normal atmosphere conditions

Door Handing
All Schlage locks are reversible. Hand information is necessary to ensure proper cylinder orientation in keyed functions, and finish of latchbolt and strike for locks that are to be installed on reverse bevel doors. Consult your catalog for door handing information.

Specifications
Handing: Keyed functions of knob designs are field reversible.
Door Thickness: 1 3/8” to 2” (35mm–51mm) standard.
2” to 2 1/2” (51mm–64mm) optional.
Backset: 2 3/4” (70 mm) standard. 2 3/8”, 3 3/4” and 5”
(60 mm, 95 mm, 127 mm) optional.
Faceplate: Brass, bronze or stainless steel. 11/8” x 21/4”
(29 mm x 57mm) square corner, beveled.
Lock Chassis: Steel, zinc dichromate plated for corrosion resistance.
Latch Bolt: Brass, 1/2” (12mm) throw, deadlocking on keyed and exterior functions. 3/4” (19 mm) throw anti-friction latch available for pairs of fire doors.
Exposed Trim: Wrought brass, bronze or stainless steel.
Strike: ANSI curved lip strike 11/4” x 4 7/8” x 13/16”lip to center standard. Optional strikes, lip lengths and ANSI strike box available. See page 20.
Cylinder & Keys: 6-pin Everest 29 S123 keyway standard with two patented nickel silver keys per lock.
Keying Options: Full size interchangeable core and Primus® high security cylinders. Master keying, grand master keying and construction keying.
Warranty: Three-year limited warranty.

Certifications
ANSI: Meets or exceeds A156.2 Series 4000, Grade 1 strength and operational requirements.
Federal: Meets FF-H-106C Series 161.
UL / cUL: All locks listed for A label single doors, 4’ x 8’. Letter F and UL symbol on latch front indicate listing. Electrified functions are UL19X Listed for single point locking applications. UL437 Listed locking cylinder optional: specify Primus 20-500 Series cylinder.
ADA Compliant: Schlage Lock Company offers a wide selection of locks designed to meet the Americans With Disabilities Act.
Schlage Electronics CO100-CY-70-KP

CO-100 models are designed for use as easy to manage, low maintenance locks that use 3-6 digit PIN codes as credentials. Administrator level users can program it right at the door to add or delete user PIN codes or change preferences or functions at any time.



CO-100 Standalone Electronic Lock, Cylindrical, Classroom Function, Keypad Reader



How to order chart

They are ideal for:

  • Visitor pass through/common areas
  • Vestibules or reception area doors controlled by remote release
  • Pool gates, breezeways and other outdoor applications
  • Maintenance areas
  • Supply closets/equipment rooms
  • Workout rooms
  • Restrooms/bathrooms
  • Dressing/fitting rooms
  • Maternity/nursing rooms
  • Other private rooms needing occupancy indication

Security

  • Helps to minimize key distribution to ensure the integrity of the key system over time
  • Classroom/storeroom function can be used to secure doors and gates indoors and out
  • Office and privacy function options for application on interior or perimeter doors
  • Available with Schlage’s full complement of key cylinder options including levers designed for compatibility with many other OEM cylinders
  • Compatible with most major brands of exit devices

Efficiency

  • Manages up to 500 unique 3-6 digit PIN codes with user rights stored on the lock
  • Utilize existing master key system
  • Low lifetime cost of ownership

Convenience

  • PIN codes can be issued and revoked quickly, right at the keypad
  • Normal, toggle, pass through, and freeze programming options
  • Occupancy indication programmable option available on privacy function locks
  • Up to 2 years battery life with status indicator for easy maintenance

Certifications

  • ANSI/BHMA A156.25 full outdoor (70 function)
  • ANSI/BHMA, Grade 1
  • UL 294
  • UL 10C
  • UL Canada
  • FCC Part 15
  • ADA

Meets or exceeds

  • Cylindrical - ANSI/BHMA A156.2, Series 4000, Grade 1
  • Mortise - ANSI/BHMA A156.13, Series 1000, Grade 1
  • Exit trim - ANSI/BHMA A156.3

For full electronic specifications please reference the CO-100 data sheet.

Reader options

  • Keypad only

User verification

  • Capable of credential verification <1 second
  • Up to 500 users
  • Remote release available on Office function locks

Programming options

Basic users can:

  • Enter assigned PIN code to unlock door momentarily from normally locked state

Managers can:

  • Be assigned toggle code priveges to change the lock to an unlocked state and back when desired
  • Assign or delete basic user PIN codes

Administrators can:

  • Assign or delete basic user PIN codes
  • Change programming codes
  • Adjust desired relock delay from 1-120 seconds
  • Put lock into freeze state that cannot be toggled
  • Use a pass-through code to momentarily unlock regardless of current state
  • Disable or enable remote features like release or occupancy indication where available

Additional

  • Programmable privacy function option provides lighted occupancy indication when in use
  • Battery life - up to 2 years with 4 AA batteries
  • Exterior Temp: -31° to 151°F (-35° to 66°C)
  • Interior Temp: 32° to 120°F (0° to 49°C) (battery)
  • Humidity: 0 - 100% non-condensing



For full mechanical specifications please reference the CO-100 data sheet.

Chassis

  • Cylindrical
  • Mortise
  • Exit trim
  • Each offered with LED status indicator

Cylinder and keys

  • Standard keyway: Schlage 6-pin Everest 29 S123 with two patented keys
  • Classic and restricted keyways, master keying and grand master keying options
  • Key-in-lever, FSIC, and SFIC cylinder options
  • Less cylinder options to fit common Sargent®, Corbin Russwin®, Medeco®, Yale® and Falcon® cylinders

Functions

  • 70 Classroom/Storeroom



Category information

Product information
