Securitron GL1-FL Gate Maglock

SKU: GL1-FL
$ 243.00

The heavy duty GL1 Electromechanical Gate Lock provides weather-resistant access control for a wide range of gate applications.

Heavy Duty Gate Lock with One Ton of Holding Power

The heavy duty GL1 Electromechanical Gate Lock provides weather-resistant access control for a wide range of gate applications. The GL1 provides 2000 lbs of holding force for electrical and manually operated indoor or outdoor gates where preload is a concern. Ideal for swinging or sliding Product features vehicle, pedestrian, or stock gate access control.

Securitron GL1 Gate Lock Feature Image 1
Securitron DM62 Electromagnetic Lock Feature Image 1

Product Features

  • 2,000 lbs holding force
  • Operates under preload up to 100 lbs
  • Automatic dual voltage - no field adjustment required
  • Accepts a standard mortise cylinder with Adams Rite MS cam for manual key override (not included, see spacer guide below)
  • Self-aligning receiver (+/- 1/2" horizontally) helps compensate for gate misalignment and sag
  • Tamper resistant cast housing
  • Optional latch status monitor
  • Surface mount
Strength & Durability
  • Holding Force (lbs): 2000
Weights & Dimensions
  • Height (in): 2.75
  • Width (in): 7.25
  • Depth (in): 3.25
  • Shipping Weight (lbs): 6
Environmental
  • Maximum Operating Temperature (F): 167
  • Minimum Operating Temperature (F): -58
  • Weather Resistance: Indoor/Outdoor
Electrical
  • Voltage: 12/24 VDC
  • Current 12v DC (mA): 870
  • Current 24v DC (mA): 720
Documents

Securitron GL1 Gate Locks Operating Manual

Securitron GL1 Gate Locks Quick Start Installation Instructions

Securitron GL1 Gate Lock Sell Sheet

Securitron GL1 Gate Locks Catalog Page

Securitron GL1 Gate Locks Gate & Fence Brochure
Certifications

Securitron GL1 Gate Lock Certificate of Compliance
