MODEL 51 | 3/4" OFFSET HUNG FLOOR CLOSERS
The Norton Rixson 51 Series is a 3/4" offset shallow-depth floor closer designed for standard door frame installation for interior doors weighing up to 250lbs.
PRODUCT FEATURES
- 51 floor closer, automatic hold open with/ backcheck
- Single acting, handed
- M19 intermediate pivots required (order separately)
- Allows doors to swing 180°, trim permitting
- Available non-hold open (NBC) or automatic hold open (ABC); specify 90°, 105°, or 180°
- Doors will swing 5° beyond the hold-open point
- Separate independent valves for closing speed, latch speed, and backcheck
- Vertical door adjustment
- Interchangeable spindle adapters
- Extended spindles available in 1/2" up to 2"
BENEFITS
- Aesthetically appealing way to support and control the door
- Constructed with robust materials and internal components
- Concealment in-floor provides vandal resistance
- Multiple valves provide enhanced control
- Ideal for upper levels of multi-story buildings due to shallow depth design
- The weight of the door is supported by the floor closer
SPECIFICATIONS
- Closer Type: Floor
- Maximum Door Weight: 250 lbs
- Traffic Rating: Moderate Traffic
- Warranty: 2-year limited warranty
CERTIFICATIONS
- Certain models are UL Listed (F prefix)
- Fire rated for 20-minute labeled doors (suffix -20)
RESOURCES & DOWNLOADS
Norton Rixson 5103ABC 3/4" Offset Automatic Hold Open With Backcheck Shallow Depth Floor Closer Catalog
Norton Rixson 5103ABC 3/4" Offset Automatic Hold Open With Backcheck Shallow Depth Floor Closer Installation
Norton Rixson Warranty
