HES 9200 Series Electric Strike

SKU: 9200N-605
$ 961.95

Retro-mounted electric strike with integrated adjustability and field installable options for maximized versatility on single glass doors.

Product Features

  • Retro-mount using existing header prep
  • No cutting required
  • Integrated adjustability
  • Adaptable voltage sensing technology (12-24 VDC)
  • Factory configured or field installable monitoring
  • Static strength 1,500 lbs
  • Dynamic strength to 70 ft-lbs
  • Endurance 1,000,000 cycles
  • Field selectable fail secure/fail safe
  • Quiet operation
  • Stainless steel construction
  • SecuriCare five-year, no-fault, no questions asked warranty
Application
  • Adjustability : Fully Adjustable
  • Surface Mounting : Yes
  • Frame Material : Aluminum|Hollow Metal|Wood
  • Shim Type : Field Adjustable
  • Latchbolt Accommodation : 5/8" - 3/4"
Electrical
  • Voltage : 12/24
  • Monitoring Installation : Factory Configured|Field Installable
  • Monitoring Options : Latchbolt Monitoring|Latchbolt Strike Monitor
Strength & Durability
  • Endurance : 1000000
  • Dynamic Strength (lbs) : 70
  • Tamper Resistant : Yes
  • Fail Safe | Fail Secure : Field selectable fail safe/fail secure
General Specifications
  • Warranty : SecuriCare five-year, no fault, no questions asked warranty
  • Lock Type : Exit Device
Weights & Dimensions
  • Strike Body Depth (in) : 0-5/8"
  • Strike Body Height (in) : 13"
  • Strike Body Width (in) : 1-7/8"
Certifications
  • ANSI/BHMA A156.31, Grade 1
  • RoHS Compliant
  • UL 1034 burglary-resistant listed and suitable for outdoor use
  • UL 294 - Standard for Access Control System Units
  • UL 305 - Standard for Panic Hardware
