The Alarm Controls RP-04 Remote Wall Plate is a single gang remote key switch plate designed for access control, remote door release, and security applications. Featuring a durable stainless steel finish, a 3/4" “D” hole for an Ace lock, and dual red and green LED status indicators, the RP-04 provides a clean, professional solution for controlled entry installations.
Its standard single gang design allows for easy installation, while the integrated LED indicators provide clear visual status feedback. Multiple plate finishes and a larger LED option are available to meet specific project requirements.
Features
- Single gang remote wall plate
- Stainless steel finish
- 3/4" “D” hole for Ace lock
- Dual 1/4" red and green LED status indicators
- N/C tamper switch
- LEDs with flying leads
- Compact, professional design
- Ideal for access control and remote door release applications
Options & Accessories
- RP-04L – Includes 1/2" LED indicators
- KA-105 / KA-108 – Key switches for use with RP-04
- Multiple plate finishes available
Specifications
| Specification | Details |
|---|---|
| Model | RP-04 |
| Dimensions | 2-3/4"W x 4-1/2"H |
| Plate Type | Single gang |
| Standard Finish | Stainless steel |
| Lock Hole | 3/4" “D” hole for Ace lock |
| Standard LEDs | 1/4" red and green |
| Tamper Switch | N/C |
| Standard LED Current Draw | 8 mA @ 12 VDC; 12 mA @ 24 VDC |
| RP-04L LED Current Draw | 9 mA @ 12 VDC; 19 mA @ 24 VDC |
| LED Wiring | Flying leads |
