The aluminum 190-RKW Straight Door Pull features a durable and weather-resistant Santoprene grip.
Product Overview
Features
- Santoprene™ durable weather resistant grip
- 3 1/2" Barrier Free Projection is standard
- Black, red or brown Santoprene available
- Custom Santoprene colors available upon request
- Soft, comfortable gripping surface
- Santoprene made in-house by Lorient US
Specifications
- Grip Shape: Round
- Grip Type: Santoprene
- Post Shape: Round
- Base Material: Aluminum
- Fastener: 1/4 - 20 x 2-1/4" Thru Bolt & Finish Washer (standard 1-3/4" door)
- Projection: 3 1/2"
- Pull Type: Straight
- Options: Back to back mounting in pairs — use BTB suffix and mounting type number Concealed mounting single pulls — use C suffix and mounting type number (190RKWC6) Advise if door thickness is other than 1-3⁄4"
| Part Number | Material Size | Center-To-Center | Base Size | Clearance | Weight |
|---|---|---|---|---|---|
|
190-RKW |
1" dia |
12" |
1" dia |
2" |
3.2 lbs |
Options
- Soft, comfortable gripping surface
- Black, red or brown Santoprene available
- Custom Santoprene colors available upon request
- 3 1/2" Barrier Free Projection is standard
- Santoprene™ durable weather resistant grip
- Santoprene made in-house by Lorient US
Mounting Types
Our mounting systems firmly attach the pull to the door and are guaranteed for the life of the door. Choose from thrubolt, back to back or concealed mountings for wood, metal and glass doors.
Note: Y base plates are recommended on wood or glass doors to make a stable and durable mounting.
Note: Heavy Duty (HD) mounting features hex drive for positive tightening and large overall size for superior strength. Recommended for high frequency and rough service openings.
Download Mounting Chart File: Mounting Chart.pdf
| Type | Description | |
|---|---|---|
|
Type 1 |
Thru Bolt Wood or Metal Door |
|
|
Type 5 |
Back-to-Back Wood or Metal Door |
|
|
Type 6 |
Surface Concealed Metal Door |
|
|
Type 8 |
Surface Concealed Wood Door |
|
|
Type 13 |
Back-to-Back Glass Door |
|
|
Type 15 |
Decorative Thru Bolt Glass Door |
