MDS Series
The MDS100 Series electric strike is designed for use with heavy duty mortise locksets and cylindrical locksets. Five different faceplates included for optional flexibility of installation in wood or metal frames.
Overview
The MDS100 Series electric strike is designed for use with heavy duty mortise locksets and cylindrical locksets. Five different faceplates included for optional flexibility of installation in wood or metal frames.
- Simple and easy field selectable fail-safe/fail-secure, non-fire rated models
- Field selectable 12/24 VDC
- Five faceplates and trim piece included for improved appearance
- US10B faceplates available
- MDS series accepts up to 1” latchbolt
- Latch bolt monitoring available
- Fire rated version available
- UL1034
- UL294
- UL10C on select models
- Static strength of 1500 lbf., UL certified
- Dynamic strength of 70 ft.lbf., UL certified
- 250,000 cycles, UL certified
