The low, versatile profile CS Series of electric strikes are designed for use with cylindrical locksets and select mortise locksets without deadbolt for both metal and wood door frames.

• Simple and easy field selectable fail-safe/fail-secure
• Field selectable 12/24 VDC
• Two face plates and trim piece included for improved appearance
• Voltage spike suppressor included
• US10B faceplates available
• CS450 series accepts latchbolt up to 9/16”
• CS750 series accepts latchbolt up to ¾”
• Latch bolt monitoring available

• UL1034
• UL294
• Static strength of 1500 lbf., UL certified
•  Dynamic strength of 70 ft.lbf., UL certified
• 250,000 cycles, UL certified (non-LBM models)

Product information

• Locknetics Access Control Sell Sheet
• Competitive Cross Reference Guide
• Locknetics Full Line Catalog

Technical resources

• Installation instructions
• Manuals & user guides

The DKP Series keypads are designed for simple access control or code control for up to four individual devices. These keypads are a great choice for controlling electric strikes, electromagnetic locks, security systems or other types of openings requiring on/off or momentary control outputs.

DKP-165 Series

• Fully programmable with up to 480 users with 1 to 6 digit user codes
• Keys are back-lit for visibility in dark areas with audible and visual key press feedback
• 12/24 VDC, switch contacts rated @ 2A/30VAC/VDC
• Multi-colored LEDs indicate the state of the keypad
• Timed anti-pass back
• 302 stainless steel gang plate
• Operating temperature range is -10° F to +130° F
• Available in surface mount (DKP-165-S) or flush mount (DKP-165-FM)
• Tamper resistant screws included for faceplate (DKP-165-S only)
• Designed for indoor use (DKP-165)

• DKP-165
• 4 3⁄4" x 3" x 1 3⁄8"
• (120mm x 76mm x 34.9mm)

• DKP-165-S
• 4 15⁄16" x 4 1⁄8" x 2 3⁄8"
• (125mm x 105mm x 60mm)

• DKP-165-FM
• 4 3⁄4" x 3 15⁄16" x 1 1⁄2"
• (120mm x 100mm x 37.4mm)

• DKP-165 Indoor digital keypad; Up to 480 users with timed anti-pass back

• DKP-165-S Digital keypad; Surface mount with case; Up to 480 users with timed anti-pass back
• DKP-165-FM Digital keypad; Flush mount; Up to 480 users with timed anti-pass back
• DKP-NS1 Outdoor digital keypad; Up to 1,010 users with two zone, re locking time delay

The DKP Series keypads are designed for simple access control or code control for up to four individual devices. These keypads are a great choice for controlling electric strikes, electromagnetic locks, security systems or other types of openings requiring on/off or momentary control outputs.

DKP-165 Series

• Fully programmable with up to 480 users with 1 to 6 digit user codes
• Keys are back-lit for visibility in dark areas with audible and visual key press feedback
• 12/24 VDC, switch contacts rated @ 2A/30VAC/VDC
• Multi-colored LEDs indicate the state of the keypad
• Timed anti-pass back
• 302 stainless steel gang plate
• Operating temperature range is -10° F to +130° F
• Available in surface mount (DKP-165-S) or flush mount (DKP-165-FM)
• Tamper resistant screws included for faceplate (DKP-165-S only)
• Designed for indoor use (DKP-165)

• DKP-165
• 4 3⁄4" x 3" x 1 3⁄8"
• (120mm x 76mm x 34.9mm)

• DKP-165-S
• 4 15⁄16" x 4 1⁄8" x 2 3⁄8"
• (125mm x 105mm x 60mm)

• DKP-165-FM
• 4 3⁄4" x 3 15⁄16" x 1 1⁄2"
• (120mm x 100mm x 37.4mm)

• DKP-NS
• 1 11⁄16" x 5 7⁄8" x 15⁄16"
• (43.2mm x 149.9mm x 24.1mm)

• DKP-165 Indoor digital keypad; Up to 480 users with timed anti-pass back

• DKP-165-S Digital keypad; Surface mount with case; Up to 480 users with timed anti-pass back
• DKP-165-FM Digital keypad; Flush mount; Up to 480 users with timed anti-pass back
• DKP-NS1 Outdoor digital keypad; Up to 1,010 users with two zone, re locking time delay

The resettable EGB Series are call points that can be activated without a power supply during emergencies.

• Resettable, non-glass unit
• Blue backlight with built in buzzer
• Detachable terminal block for easy installation
• 12/24 VDC, DPDT switch contacts rated @ 5A/125VAC
• Available in green or red case

Product information

• Locknetics Access Control Sell Sheet
• Competitive Cross Reference Guide
• Locknetics Full Line Catalog

Technical resources

• Installation instructions
• Manuals & user guides

This versatile sensor can be surface mounted above any door, as well as the ceiling or wall. The flexibility and low profile design make it an effective sensor for managing building security and traffic flow.

• 12/24 VDC
• Compact, aesthetically pleasing design
• Includes ceiling and surface mount adapters
• Operating temp: -22 degrees F to 140 degrees F
• Passive Infrared Sensor (PIR)
