- Adjustable spring power and speed controls
- Designed for medium to heavy use
- Improves fire safety and energy savings
designations
ANSI:
Meets ANSI A156.4 - Grade 1 Standards
UL Listing:
For "A" Label 3 Hour Fire Doors, UL10C Positive Pressure Rated
Accessibility:
Meets ADA requirements ANSI A117.1
features
Heavy Duty
Cast Aluminum Closer Body
Heat Treated
Heat Treated Heavy Duty Steel Piston, Spindle & Spring
Handing
Non-Handed – Completely reversible
specifications
- Precision Rack & Pinion Construction
- Spindle with Needle Bearings
- Adjustable Size 1 to 6
- Staked Valves
- Independent Latch & Sweep Speed Controls
- Adjustable Back Check Intensity Control Valve
sell sheets
- 116/316 Series Door Closer Accessories
- 116 Series Friction Hold Open Arm
- 316/116 Series Blade Stop Spacer
- 116 Series Adjustable Hold Open Arm
- 116 Series Extended Arm
- 116 Series Closer Cover
- 116 Series HD Hold Open Arm
- 116 Series Heavy Duty Arm
- 116 Series Heavy Duty Door Closer
- 116 Series PA Drop Plate
- 116 Series Regular Drop Plate
installation instructions
- 116 Adjustable Hold Open Arm Installation Instructions
- 116 Friction Type Hold Open Arm Installation Instructions
- 116 Heavy Duty Hold Open Arm Installation Instructions
- 116 Heavy Duty Arm Installation Instructions
- 116 Series Door Closer Reg-TJ-PA Installation Instructions
- 116 Friction Type Hold Open Arm Installation Instructions
