Overview
Features
- A A156.2 Grade 2 certification
- Multiple functions and finishes available
- Field Reversible
- Optional backset lengths available
- UL Listed
- Precision manufactured mechanisms
- Stainless steel latchbolt for long life
Benefits
- Adjustable latchbolts accommmodate flat and beveled doors
- Outstanding combination of value and performance
- Internal parts are zinc dichromate plated for corrosion resistance
Specifications
- ANSI/BHMA Code: A156.2
- ANSI/BHMA Series: Series 4000
- Backset Depth (Standard): 2 3/4"
- Cylinder Format: Conventional
- Cylinder Pins: 6 pin
- Door Thickness (Standard): 1 3/4"
- Handing: Field Reversible
- Latchbolt Throw: 1/2"
- Maximum Backset: 2 3/4"
- Maximum Door Thickness: 1 3/4"
- Minimum Backset: 2 3/8"
- Minimum Door Thickness: 1 3/8"
- Number of Keys: 2
- Strike Type (Standard): ANSI Curved Lip
- UL Listed: Yes
- ULC Listed: Yes
- Warranty: 1-year limited warranty
Certifications
- UL listed and UL10c compliant
- UL-cUL Listed for use on fire doors having a rating up to and including 3-hours
- ANSI/BHMA A156.2, Series 4000, Grade 2
Mechanical Option
| Option Type | Code | Description |
|---|---|---|
|
Backset |
B234 |
2-3/4" (70mm) |
|
Backset |
B238 |
2-3/8" (60mm) |
|
Fronts |
M17 |
ANSI Wrought Strike Box |
|
Strikes |
SA100 |
1" (25mm) Curved Lip ANSI Strike |
|
Strikes |
SA112 |
1-1/2" (38mm) Curved Lip ANSI Strike |
|
Strikes |
SA114 |
1-1/4" (32mm) Curved Lip ANSI Strike |
|
Strikes |
SA118 |
1-1/8" (29mm) Curved Lip ANSI Strike |
|
Strikes |
SA134 |
1-3/4" (44mm) Curved Lip ANSI Strike |
|
Strikes |
SA138 |
1-3/8" (35mm) Curved Lip ANSI Strike |
|
Strikes |
SA200 |
2" (51mm) Curved Lip ANSI Strike |
|
Strikes |
SA212 |
2-1/2" (64mm) Curved Lip ANSI Strike |
|
Strikes |
SA214 |
2-1/4" (57mm) Curved Lip ANSI Strike |
|
Strikes |
SA234 |
2-3/4" (70mm) Curved Lip ANSI Strike |
|
Strikes |
SA300 |
3" (76mm) Curved Lip ANSI Strike |
|
Strikes |
SC100 |
1" (25mm) Curved Lip T-Strike with Strike Box |
|
Strikes |
SC112 |
1-1/2" (38mm) Curved Lip T-Strike with Strike Box |
|
Strikes |
SC114 |
1-1/4" (32mm) Curved Lip T-Strike with Strike Box |
|
Strikes |
SC118 |
1-1/8" (29mm) Curved Lip T-Strike with Strike Box |
|
Strikes |
SC134 |
1-3/4" (44mm) Curved Lip T-Strike with Strike Box |
|
Strikes |
SC138 |
1-3/8" (35mm) Curved Lip T-Strike with Strike Box |
|
Strikes |
SC200 |
2" (51mm) Curved Lip T-Strike with Strike Box |
|
Strikes |
SC212 |
2-1/2" (64mm) Curved Lip T-Strike with Strike Box |
|
Strikes |
SC214 |
2-1/4" (57mm) Curved Lip T-Strike with Strike Box |
|
Strikes |
SC234 |
2-3/4" (70mm) Curved Lip T-Strike with Strike Box |
|
Strikes |
SC300 |
3" (76mm) Curved Lip T-Strike with Strike Box |
|
Strikes |
SF114 |
1-1/4" (32mm) Full Lip Strike with Strike Box |
Cylinder Option
| Option Type | Code | Description |
|---|---|---|
|
Access 3 |
AHS |
Access 3® High Security Fixed Core |
|
Access 3 |
AP |
Access 3® Patented Fixed Core |
|
Access 3 |
AS |
Access 3® Security Fixed Core |
|
Cylinder/Key Stamping |
CKC2 |
Concealed Key Control Cylinders with VKC Keys. (Not for AS, AHS, ACS, ACHS, PHS, PCHS, HS or CHS) |
|
Cylinder/Key Stamping |
CKC3 |
Concealed Key Control Cylinders with VKC Keys. (Not for AS, AHS, ACS, ACHS, PHS, PCHS, HS or CHS) |
|
Cylinder/Key Stamping |
KY# |
More Than 2 Keys Per Lock (Ex: KY6) |
|
Cylinder/Key Stamping |
VKC0 |
No Bitting or Keyset Stamping on Keys |
|
Cylinder/Key Stamping |
VKC1 |
Visual Key Control Keys Only |
|
Cylinder/Key Stamping |
VKC2 |
Visual Key Control Cylinders and Keys (Not for AS, AHS, ACS, ACHS, PHS, PCHS, HS or CHS) |
|
Cylinder/Key Stamping |
VKC3 |
Visual Key Control Cylinders Only (Not for AS, AHS, ACS, ACHS, PHS, PCHS, HS or CHS) |
|
Miscellaneous |
6P |
Conventional 6-Pin |
|
Miscellaneous |
LC |
Less Cylinder |
|
Pyramid |
PHS |
Pyramid High Security Fixed Core |
|
Pyramid |
PS |
Pyramid Security Fixed Core |
|
Security |
HS |
Security |
