Product Overview
Features
Functions available for any industrial or commercial application
Field adjustable handing
Available in a variety of attractive trims and finishes
Status indicator options available to provide peace of mind on the locked/unlocked status of a door
Lever attached directly to escutcheon trim for added security (Specific to 8800 SL version)
Thrubolted security head screws offer added protection (Specific to 8800 SL version)
UL/cUL listed for 3-hour fire rated doors
Heavy-duty escutcheon trim for resistance against damage and vandalism
Benefits
10-year mechanical warranty
Certified ANSI/BHMA A156.13, Series 1000, Operational Grade 1 (8800FL with CN escutcheon & SL8800 meet Security Grade 1).
Specifications
Filter
ANSI/BHMA Code: A156.13
ANSI/BHMA Series: Series 1000
Backset Depth (Standard): 2 3/4"
Cylinder Format: Conventional, Large Format, Small Format
Door Thickness (Standard): 1 3/4"
Handing: Field Reversible
Latchbolt Throw: 3/4"
Maximum Backset: 2 3/4"
Minimum Backset: 2 3/4"
Maximum Door Thickness: 3 1/4"
Minimum Door Thickness: 1 3/4"
Number of Keys: 2
Strike Type: Curved Lip
UL Listed: Yes
ULC Listed: Yes
Warranty: 10-year (Mechanical) / 2-year (Electrified) limited warranty
Certifications
Environmental Product Declaration (EPD)
CAL FIRE, 3775-0257:0113
Buy American Act*
*Domestic Sourcing regulations vary greatly within Federal, state and local government agencies and therefore certain restrictions may apply. Please contact BAACompliance.Americas@assaabloy.com for additional information.
UL-cUL Fire-Rated Up to 3 Hours
ANSI/BHMA A117.1
ANSI/BHMA A156.13, Series 1000, Operational and Security Grade 1
|
8801 |
Passage or closet latch |
F01 |
|
