Von Duprin
At US Lock Supply, our Von Duprin selection covers the full range of the many different exit devices and door openers the Von Duprin company offers. Some of our popular sellers from the Von Duprin exit device line include the Von Duprin 33 series of vertical rod exit devices; the Von Duprin 99 and Von Duprin 98 series of concealed, surface mounted and other vertical rod exit devices; the Von Duprin 22 exit device series; the Von Duprin 55 series of cross bar exit devices; and the Von Duprin 88 exit device series.
We offer Von Duprin products in a wide range of options, such as several different finishes to fit your application and in fire-rated or non-fire-rated versions. Many of these exit devices are fully reversible (non-handed) and field-sizeable to make them easy to install for an exact fit.
For rugged exit devices that stand up to heavy use and keep your building’s exits secure, order Von Duprin exit device products today from US Lock Supply.
Von Duprin 9827EO-F/9927EO-F Surface Mounted Vertical Rod Fire Touch Bar Exit Device
Von Duprin 9827EO-F/9927EO-F Surface Mounted Vertical Rod Fire Touch Bar Exit Device
The 9827-F/9927-F devices are available in the following finishes: US3, US4, US10, US26, US26D, US28 and 313AN. US32D available with 98 Series only.
Specifications
- Device Functions: Device ships EO/DT/NL. Field selectable. For TP,K,or L remove NL drive screw from device
- Device Lengths: 3’: 2’4" to 3’ (711mm to 914 mm) Door Size; 4’: 2’10" to 4’ (864 mm to 1219 mm) Door Size
- Strikes: Top – 299F (499F LBR) – Dull Black, Bottom – 304L - Unfinished; Optional Strikes available
- Dogging Feature: No Mechanical Dogging, EL and QEL option available
-
Electric Options: LX Latchbolt Monitor Switch; RX Pushpad Monitor Switch; RX2 Double Pushpad Monitor Switch; EL Electric Latch Retraction; SS Signal Switch
CX Chexit Delayed Exit; ALK Alarm Exit Kit; E Electric Unlocking and Locking Trim; QEL Quiet Electric Latch Retraction - Mechanical Options: PN Pneumatic Latch Retraction; LBR Less Bottom Rod; GBK Glass Bead Kit ; WS Tornado and Hurricane Tested
- Fasteners & Sex Bolts (SNB): Includes screw pack for 1-3/4" (44mm) – 2-1/4" (57mm) Thick Wood or Metal Doors, and 325 SNB for top & bottom latch. Optional 425 SNB available
- Latch Bolt: Deadlocking Anti-friction Top & Bottom Bolt, 5/8" (16mm) throw
- Device Centerline from Finished Floor: 39-5/8" (1006 mm);
- Door Undercut 1/4" (7mm)
- Center Case Dimensions: 8" x 2-3/4" x 2-3/8" (203mm x 70mm x 60mm)
- Mechanism Case Dimensions: 2-1/4" x 2-1/4" (57mm x 57mm)
- Top & Bottom Latch Case: 4-1/2" x 2-1/8" x 1-1/2" (114mm x 54mm x 38mm)
- Vertical Rods: 1/2" square tubing, standard rods accommodate 7’ (2134mm) door; Top rod length is 34-15/16" (887mm); Bottom rod length is 31-1/2" (794mm); Extension rods available, 1’ (205mm) or 3’ (914mm) for doors over 7’; One piece top rod available for 8’ (2438mm) and 10’ (3048mm) door
- Projection: Pushbar Neutral – 3-13/16" (97 mm); Pushbar Depressed – 3-1/16" (78 mm)
Von Duprin 9827EO/9927EO Surface Mounted Vertical Rod Touch Bar Exit Device
Von Duprin 9827/9927 surface mounted vertical rod device for all types of single or double doors, UL listed for Panic Exit Hardware. Devices are ANSI A156.3 – 2001 Grade 1. Covers stock hollow metal doors with 86 or 161 cutouts. The 9827 device has a smooth mechanism case and the 9927 device has a grooved case. The surface vertical rod device is non-handed except when the following device options are used: SD (Special Dogging), or SS (Signal Switch).
Vertical rod and latch guards are available to protect the bottom rod of the exit device from damage by impacts of carts or gurneys passing through doors.
The 9827/9927 devices are available in the following finishes: US3, US4, US1 0, US26, US26D, US28 and 313AN. US32D available with 98 Series only.
Specifications
- Device Functions: Device ships EO/DT/NL. Field selectable. For TP,K,or L remove NL drive screw from device
- Device Lengths: 3’: 2’4" to 3’ (711mm to 914 mm) Door Size; 4’: 2’10" to 4’ (864 mm to 1219 mm) Door Size
- Strikes: Top - 299 – Dull Black, Bottom – 248L4 & 304L - Unfinished; Optional Strikes available
- Dogging Feature: Hex key dogging standard
- Dogging Options: CD Cylinder Dogging; SD Special Center Case Dogging; LD Less Dogging
- Electric Options: LX Latchbolt Monitor Switch; RX Pushpad Monitor Switch; RX2 Double Pushpad Monitor Switch; EL Electric Latch Retraction; SS Signal Switch; CX Chexit Delayed Exit; ALK Alarm Exit Kit; QEL Quiet Electric Latch Retraction; PN Pneumatic Latch Retraction; LBR Less Bottom Rod
- Mechanical Options: GBK Glass Bead Kit; PL Pullman Latch; WS Tornado and Hurricane Tested
- Fasteners & Sex Bolts (SNB): Includes screw pack for 1-3/4" (44mm) – 2-1/4" (57mm) Thick Metal or Wood Doors, and 325 SNB for top & bottom latch. Optional 425 SNB available
- Latch Bolt: Deadlocking Anti-friction Top & Bottom Bolt, 5/8" (16mm) throw
- Device Centerline from Finished Floor: 39-5/8" (1006 mm);
- Door Undercut 1/4" (7mm)
- Center Case Dimensions: 8" x 2-3/4" x 2-3/8" (203mm x 70mm x 60mm)
- Mechanism Case Dimensions: 2-1/4" x 2-1/4" (57mm x 57mm)
- Top & Bottom Latch Case: 4-1/2" x 2-1/8" x 1-1/2" (114mm x 54mm x 38mm)
- Vertical Rods: 1/2" square tubing, standard rods accommodate 7’ (2134mm) door; Top rod length is 34-15/16" (887mm); Bottom rod length is 31-1/2" (794mm); Extension rods available, 1’ (205mm) or 3’ (914mm) for doors over 7’ "F"; One piece top rod available for 8’ (2438mm) and 10’ (3048mm) door
- Projection: Pushbar Neutral – 3-13/16" (97 mm); Pushbar Depressed – 3-1/16" (78 mm)
Von Duprin 9847EO-F/9947EO-F Concealed Vertical Rod Fire Touch Bar Exit Device
The 9847-F/9947-F devices are available in the following finishes: US3, US4, US10, US26, US26D, US28 and 313AN. US32D available with 98 Series only.
- Device Functions: Device ships EO/DT/NL. Field selectable. For TP,K,or L remove NL drive screw from device
- Device Lengths: 3’: 2’4" to 3’ (711mm to 914 mm) Door Size; 4’: 2’10" to 4’ (864 mm to 1219 mm) Door Size
- Strikes: Top - 338 – Unfinished, Bottom – 385A - Unfinished; Optional Strikes available
- Dogging Feature: No Mechanical Dogging, EL and QEL option available
- Electric Options: LX Latchbolt Monitor Switch; RX Pushpad Monitor Switch; RX2 Double Pushpad Monitor Switch; EL Electric Latch Retraction; SS Signal Switch; CX Chexit Delayed Exit; ALK Alarm Exit Kit; E Electric Unlocking and Locking Trim; QEL Quiet Electric Latch Retraction
- Mechanical Options: PN Pneumatic Latch Retraction; LBR Less Bottom Rod; GBK Glass Bead Kit
- Fasteners & Sex Bolts (SNB): Includes screw pack for 1-3/4" (44mm) – 2-1/4" (57mm) Thick Metal and Wood Doors. Optional 425 SNB available
- Latch Bolt: Deadlocking Anti-friction Top & Bottom Bolt, 5/8" (16mm) throw
- Device Centerline from Finished Floor: 39-5/8" (1006 mm) Standard, Adjustable from 35-5/8" (905mm) to 49-5/8" (1260mm)
- Door Undercut: 1/4" (7mm) maximum
- Center Case Dimensions: 8" x 2-3/4" x 2-3/8" (203mm x 70mm x 60mm)
- Mechanism Case Dimensions: 2-1/4" x 2-1/4" (57mm x 57mm)
- Top & Bottom Latch Case: 4-1/2" x 2-1/8" x 1-1/2" (114mm x 54mm x 38mm);
- Vertical Rods: Round 2 piece adjustable rods; Top rod adjustable from 6’8" (2027mm) to 8’4"(2533mm); Bottom rod adjustable 35-5/8" (905 mm) to 49-5/8" (1260 mm); Extension rod kits available for doors over 8’4" (2533mm)
- Projection: Pushbar Neutral – 3-13/16" (97 mm); Pushbar Depressed – 3-1/16" (78 mm)
The 9847/9947 devices are available in the following finishes: US3, US4, US10, US26, US26D, US28 and 313AN. US32D available with 98 Series only.
Specifications
- Device Functions: Device ships EO/DT/NL. Field selectable. For TP,K,or L remove NL drive screw from device
- Device Lengths: 3’: 2’4" to 3’ (711mm to 914 mm) Door Size; 4’: 2’10" to 4’ (864 mm to 1219 mm) Door Size
- Strikes: Top - 338 – Unfinished, Bottom – 385A - Unfinished; Optional Strikes available
- Dogging Feature: Hex key dogging standard
- Dogging Options: CD Cylinder Dogging; SD Special Center Case Dogging; LD Less Dogging
- Electric Options: LX Latchbolt Monitor Switch; RX Pushpad Monitor Switch; RX2 Double Pushpad Monitor Switch; EL Electric Latch Retraction; SS Signal Switch; CX Chexit Delayed Exit; ALK Alarm Exit Kit; E Electric Unlocking and Locking Trim; QEL Quiet Electric Latch Retraction
- Mechanical Options: PN Pneumatic Latch Retraction; LBR Less Bottom Rod; GBK Glass Bead Kit; PL Pullman Latch
- Fasteners & Sex Bolts (SNB): Includes screw pack for 1-3/4" (44mm) – 2-1/4" (57mm) Thick Metal and Wood Doors. Optional 425 SNB available
- Latch Bolt: Deadlocking Top & Bottom Bolt, 5/8" (16mm) throw
- Device Centerline from Finished Floor: 39-5/8" (1006 mm) Standard, Adjustable from 35-5/8" (905mm) to 49-5/8" (1260mm)
- Door Undercut: 1/4" (7mm) maximum
- Center Case Dimensions: 8" x 2-3/4" x 2 3/8" (203mm x 70mm x 60mm)
- Mechanism Case Dimensions: 2-1/4" x 2-1/4" (57mm x 57mm)
- Top & Bottom Latch Case: 4-1/2" x 2-1/8" x 1-1/2" (114mm x 54mm x 38mm);
- Vertical Rods: Round 2 piece adjustable rods; Top rod adjustable from 6’8" (2027mm) to 8’4"(2533mm); Bottom rod adjustable 35-5/8" (905 mm) to 49-5/8" (1260 mm); Extension rod kits available for doors over 8’4" (2533mm)
- Projection: Pushbar Neutral – 3-13/16" (97 mm); Pushbar Depressed – 3-1/16" (78 mm)
Von Duprin 9847WDCEO-F/9947WDCEO-F Wood Door Concealed Vertical Rod Fire Touch Bar Exit Device
Von Duprin 9847WDCEO-F/9947WDCEO-F Wood Door Concealed Vertical Rod Fire Touch Bar Exit Device
Specifications
- Device Functions: Device ships EO/DT/NL. Field selectable. For TP,K,or L remove NL drive screw from device
- Device Lengths: 3’: 2’4" to 3’ (711mm to 914 mm) Door Size; 4’: 2’10" to 4’ (864 mm to 1219 mm) Door Size
- Strikes: Top - 338 – Unfinished, Bottom – 385A - Unfinished; Optional Strikes available
- Dogging Feature: Hex key dogging standard
- Dogging Options: CD Cylinder Dogging; SD Special Center Case Dogging; LD Less Dogging
-
Electric Options: LX Latchbolt Monitor Switch; RX Pushpad Monitor Switch; RX2 Double Pushpad Monitor Switch; EL Electric Latch Retraction; SS Signal Switch
CX Chexit Delayed Exit; ALK Alarm Exit Kit; E Electric Unlocking and Locking Trim; QEL Quiet Electric Latch Retraction - Mechanical Options: PN Pneumatic Latch Retraction; GBK Glass Bead Kit; PL Pullman Latch
- Fasteners & Sex Bolts (SNB): Includes screw pack for 1-3/4" (44mm) – 2-1/4" (57mm) Thick Wood Doors. 425 SNB required on wood doors without SLM Blocking
- Latch Bolt: Deadlocking Top & Bottom Bolt, 5/8" (16mm) throw
- Device Centerline from Finished Floor: 39 5/8" (1006 mm) Standard, Adjustable from 35 5/8" (905mm) to 49 5/8" (1260mm)
- Door Undercut: 1/4" (7mm) maximum
- Center Case Dimensions: 8" x 2-3/4" x 2-3/8" (203mm x 70mm x 60mm)
- Mechanism Case Dimensions: 2-1/4" x 2-1/4" (57mm x 57mm)
- Top & Bottom Latch Case: 4-1/2" x 2 1/8" x 1-1/2" (114mm x 54mm x 38mm)
- Vertical Rods: Round 2 piece adjustable rods; Top rod adjustable from 6’8" (2027mm) to 8’4"(2533mm); Bottom rod adjustable 35-5/8" (905 mm) to 49-5/8" (1260 mm); Extension rod kits available for doors over 8’4" (2533mm)
- Projection: Pushbar Neutral – 3-13/16" (97 mm); Pushbar Depressed – 3-1/16" (78 mm)
Von Duprin 9847WDCEO/9947WDCEO Wood Door Concealed Vertical Rod Touch Bar Exit Device
Von Duprin 9847WDCEO/9947WDCEO Wood Door Concealed Vertical Rod Touch Bar Exit Device
Specifications
- Device Functions: Device ships EO/DT/NL. Field selectable. For TP,K,or L remove NL drive screw from device
- Device Lengths: 3’: 2’4" to 3’ (711mm to 914 mm) Door Size; 4’: 2’10" to 4’ (864 mm to 1219 mm) Door Size
- Strikes: Top - 338 – Unfinished, Bottom – 385A - Unfinished; Optional Strikes available
- Dogging Feature: Hex key dogging standard
- Dogging Options: CD Cylinder Dogging; SD Special Center Case Dogging; LD Less Dogging
-
Electric Options: LX Latchbolt Monitor Switch; RX Pushpad Monitor Switch; RX2 Double Pushpad Monitor Switch; EL Electric Latch Retraction; SS Signal Switch
CX Chexit Delayed Exit; ALK Alarm Exit Kit; E Electric Unlocking and Locking Trim; QEL Quiet Electric Latch Retraction - Mechanical Options: PN Pneumatic Latch Retraction; GBK Glass Bead Kit; PL Pullman Latch
- Fasteners & Sex Bolts (SNB): Includes screw pack for 1-3/4" (44mm) – 2-1/4" (57mm) Thick Wood Doors. 425 SNB required on wood doors without SLM Blocking
- Latch Bolt: Deadlocking Top & Bottom Bolt, 5/8" (16mm) throw
- Device Centerline from Finished Floor: 39 5/8" (1006 mm) Standard, Adjustable from 35 5/8" (905mm) to 49 5/8" (1260mm)
- Door Undercut: 1/4" (7mm) maximum
- Center Case Dimensions: 8" x 2-3/4" x 2-3/8" (203mm x 70mm x 60mm)
- Mechanism Case Dimensions: 2-1/4" x 2-1/4" (57mm x 57mm)
- Top & Bottom Latch Case: 4-1/2" x 2 1/8" x 1-1/2" (114mm x 54mm x 38mm)
- Vertical Rods: Round 2 piece adjustable rods; Top rod adjustable from 6’8" (2027mm) to 8’4"(2533mm); Bottom rod adjustable 35-5/8" (905 mm) to 49-5/8" (1260 mm); Extension rod kits available for doors over 8’4" (2533mm)
- Projection: Pushbar Neutral – 3-13/16" (97 mm); Pushbar Depressed – 3-1/16" (78 mm)
Von Duprin 9848EO-F/9948EO-F Concealed Vertical Rod Fire Touch Bar Exit Device
The 9848-F/9948-F devices are available in the following finishes: US3, US4, US10, US26, US26D, US28 and 313AN. US32D available with 98 Series only.
Specifications
- Device Functions: Device ships EO/DT/NL. Field selectable. For TP,K,or L remove NL drive screw from device
- Device Lengths: 3’: 2’4" to 3’ (711mm to 914 mm) Door Size; 4’: 2’10" to 4’ (864 mm to 1219 mm) Door Size
- Strikes: Top - 338 – Unfinished, Bottom – 385A - Unfinished; Optional Strikes available
- Dogging Feature: No Mechanical Dogging, EL and QEL option available
- Electric Options: LX Latchbolt Monitor Switch; RX Pushpad Monitor Switch; RX2 Double Pushpad Monitor Switch; EL Electric Latch Retraction; SS Signal Switch; CX Chexit Delayed Exit; ALK Alarm Exit Kit; E Electric Unlocking and Locking Trim; QEL Quiet Electric Latch Retraction
- Mechanical Options: PN Pneumatic Latch Retraction; GBK Glass Bead Kit
- Fasteners & Sex Bolts (SNB): Includes screw pack for 1-3/4" (44mm) – 2-1/4" (57mm) Thick Metal Doors. Optional 425 SNB available
-
Latch Bolt: Deadlocking Top Bolt, 3/4" (19mm) throw
Deadlocking Bottom Bolt, 1-1/2" (38mm) throw - Device Centerline from Finished Floor: 39 5/8" (1006 mm) Standard, Adjustable from 35 5/8" (905mm) to 49 5/8" (1260mm)
- Door Undercut: 1/4" (7mm) up to 3/4" (19mm)maximum
- Center Case Dimensions: 8" x 2-3/4" x 2-3/8" (203mm x 70mm x 60mm)
- Mechanism Case Dimensions: 2-1/4" x 2-1/4" (57mm x 57mm)
- Top & Bottom Latch Case: 4-1/2" x 2 1/8" x 1-1/2" (114mm x 54mm x 38mm);
- Vertical Rods: Round 2-piece adjustable rods; Top rod adjustable from 6’8" (2027mm) to 8’4"(2533mm); Bottom rod adjustable 35-5/8" (905 mm) to 49-5/8" (1260 mm); Extension rod kits available for doors over 8’4" (2533mm)
- Projection: Pushbar Neutral – 3-13/16" (97 mm); Pushbar Depressed – 3-1/16" (78 mm)
The 9848/9948 devices are available in the following finishes: US3, US4, US10, US26, US26D, US28 and 313AN. US32D available with 98 Series only.
- Device Functions: Device ships EO/DT/NL. Field selectable. For TP,K,or L remove NL drive screw from device
- Device Lengths: 3’: 2’4" to 3’ (711mm to 914 mm) Door Size; 4’: 2’10" to 4’ (864 mm to 1219 mm) Door Size
- Strikes: Top - 338 – Unfinished, Bottom – 385A - Unfinished; Optional Strikes available
- Dogging Feature: Hex key dogging standard
- Dogging Options: CD Cylinder Dogging; SD Special Center Case Dogging; LD Less Dogging
- Electric Options: LX Latchbolt Monitor Switch; RX Pushpad Monitor Switch; RX2 Double Pushpad Monitor Switch; EL Electric Latch Retraction; SS Signal Switch; CX Chexit Delayed Exit; ALK Alarm Exit Kit; EL Electric Latch Retractor
- Mechanical Options: PN Pneumatic Latch Retraction; GBK Glass Bead Kit
- Fasteners & Sex Bolts (SNB): Includes screw pack for 1-3/4" (44mm) – 2-1/4" (57mm) Thick Metal Doors. Optional 425 SNB available
-
Latch Bolt: Deadlocking Top Bolt, 3/4" (19mm) throw
Deadlocking Bottom Bolt, 1-1/2" (38mm) throw - Device Centerline from Finished Floor: 39 5/8" (1006 mm) Standard, Adjustable from 35 5/8" (905mm) to 49 5/8" (1260mm)
- Door Undercut: 1/4" (7mm) maximum up to 3/4" (19mm)
- Center Case Dimensions: 8" x 2-3/4" x 2-3/8" (203mm x 70mm x 60mm)
- Mechanism Case Dimensions: 2-1/4" x 2-1/4" (57mm x 57mm)
- Top & Bottom Latch Case: 4-1/2" x 2 1/8" x 1-1/2" (114mm x 54mm x 38mm);
- Vertical Rods: Round 2-piece adjustable rods; Top rod adjustable from 6’8" (2027mm) to 8’4"(2533mm); Bottom rod adjustable 35-5/8" (905 mm) to 49-5/8" (1260 mm); Extension rod kits available for doors over 8’4" (2533mm)
- Projection: Pushbar Neutral – 3-13/16" (97 mm); Pushbar Depressed – 3-1/16" (78 mm)
Von Duprin 9857EO-F/9957EO-F Three-Point Latching Fire Touch Bar Exit Device
The 9857-F/9957-F devices are available in the following finishes: US3, US4, US10, US26, US26D, US28 and 313AN. US32D available with 98 Series only.
Specifications
- Device Functions: Device ships EO/DT/NL. Field selectable. For TP,K,or L remove NL drive screw from device
- Device Lengths: 3’: 2’4" to 3’ (711mm to 914 mm) Door Size; 4’: 2’10" to 4’ (864 mm to 1219 mm) Door Size
- Strikes: Top & Middle-299–Dull Black, Bottom–248L4 & 304L-Unfinished; Optional Strikes available
- Dogging Feature: No Mechanical Dogging, EL and QEL options available
- Electric Options: LX Latchbolt Monitor Switch; RX Pushpad Monitor Switch; RX2 Double Pushpad Monitor Switch; EL Electric Latch Retraction; SS Signal Switch; CX Chexit Delayed Exit; ALK Alarm Exit Kit; E Electric Unlocking and Locking Trim
- Mechanical Options: PN Pneumatic Latch Retraction; LBR Less Bottom Rod; GBK Glass Bead Kit
- Fasteners & Sex Bolts (SNB): Includes screw pack for 1-3/4 (44mm) – 2-1/4" (57mm) Thick Metal and Wood Doors, and 325 SNB for top & bottom latch. Optional 425 SNB available for metal doors. 425 SNB required on wood doors without SLM Blocking.
- Latch Bolt: Deadlocking Anti-friction Top & Bottom Bolt, 5/8" (16mm) throw; Deadlocking Rim Bolt, 3/4" (19mm) throw
- Device Centerline from Finished Floor: 39-13/16" (1011 mm)
- Door Undercut: 1/4" (7mm)
- Center Case Dimensions: 8" x 2-3/4" x 2-3/8" (203mm x 70mm x 60mm)
- Mechanism Case Dimensions: 2-1/4" x 2-1/4" (57mm x 57mm)
- Top & Bottom Latch Case: 4-1/2" x 2-1/8" x 1-1/2" (114mm x 54mm x 38mm);
- Vertical Rods: 1/2" square tubing, standard rods accommodate 7’ (2134mm) door; Top rod length is 34-15/16" (887mm); Bottom rod length is 31-1/2" (794mm); Extension rods available, 1’ (205mm) or 3’ (914mm) for doors over 7’ "F"; One piece top rod available for 8’ (2438mm) – 10’ (3048mm) door
- Projection: Pushbar Neutral – 3-13/16" (97 mm); Pushbar Depressed – 3-1/16" (78 mm)
Von Duprin 9857EO/9957EO three-point latching device for all types of single or double doors, UL listed for Panic Exit Hardware. Devices are ANSI A156.3 – 2001 Grade 1. Covers stock hollow metal doors with 86 or 161 cutouts. The 9857 device has a smooth mechanism case and the 9957 device has a grooved case. The three-point latching device is non-handed except when the following device options are used: SD (Special Dogging), or SS (Signal Switch).
Vertical rod and latch guards are available to protect the bottom rod of the exit device from damage by impacts of carts or gurneys passing through doors.
The 9857/9957 devices are available in the following finishes: US3, US4, US10, US26, US26D, US28 and 313AN. US32D available with 98 Series only.
Specifications
-
Device Functions: Device ships EO/DT/NL. Field selectable. For TP,K,or L remove NL drive screw from device
-
Device Lengths: 3’ 2’4" to 3’ (711mm to 914 mm) Door Size; 4’ 2’10" to 4’ (864 mm to 1219 mm) Door Size
-
Strikes: Top & Middle-299–Dull Black, Bottom–248L4 & 304L-Unfinished; Optional Strikes available
-
Dogging Feature: Hex key dogging standard
-
Dogging Options: CD Cylinder Dogging; SD Special Center Case Dogging; LD Less Dogging
-
Electric Options: LX Latchbolt Monitor Switch; RX Pushpad Monitor Switch; RX2 Double Pushpad Monitor Switch; EL Electric Latch Retraction; SS Signal Switch; CX Chexit Delayed Exit; ALK Alarm Exit Kit; E Electric Unlocking and Locking Trim
-
Mechanical Options: PN Pneumatic Latch Retraction; LBR Less Bottom Rod; GBK Glass Bead Kit; PL Pullman Latch
-
Fasteners & Sex Bolts (SNB): Includes screw pack for 1-3/4" (44mm) – 2-1/4" (57mm) Thick Metal and Wood Doors, and 325 SNB for top & bottom latch. Optional 425SNB available
-
Latch Bolt: Deadlocking Anti-friction Top & Bottom Bolt, 5/8" (16mm) throw; Deadlocking Rim Bolt, 3/4" (19mm) throw
-
Device Centerline from Finished Floor: 39-13/16" (1011 mm)
-
Door Undercut: 1/4" (7mm)
-
Center Case Dimensions: 8" x 2-3/4" x 2-3/8" (203mm x 70mm x 60mm)
-
Mechanism Case Dimensions: 2-1/4" x 2-1/4" (57mm x 57mm)
-
Top & Bottom Latch Case: 4-1/2" x 2-1/8" x 1-1/2" (114mm x 54mm x 38mm)
-
Vertical Rods: 1/2" square tubing, standard rods accommodate 7’ (2134mm) door; Top rod length is 34-15/16" (887mm); Bottom rod length is 31-1/2" (794mm); Extension rods available, 1’ (205mm) or 3’ (914mm) for doors over 7’ "F"; One piece top rod available for 8’ (2438mm) and 10’ (3048mm) door
-
Projection: Pushbar Neutral – 3-13/16" (97 mm); Pushbar Depressed – 3-1/16" (78 mm)
The 9875-F/9975-F devices are available in the following finishes: US3, US4, US10, US26, US26D, US28 and 313, 315. US32D, US15 available with 98 Series only.
Specifications
- Device Functions: Device ships EO/DT/NL. Field selectable. Device Lengths: 3’ 2’4" to 3’ (711mm to 914 mm) Door Size; 4’ 2’10" to 4’ (864 mm to 1219 mm) Door Size
- Strikes: 575 – Dull Black; Optional Strikes available
- Dogging Option: No Mechanical Dogging, EL and QEL option available
- Electric Options: RX Pushpad Monitor Switch; RX2 Double Pushpad Monitor Switch; E Electric Locking & Unlocking; EL Electric Latch Retraction; SS Signal Switch; CX Chexit Delayed Exit; ALK Alarm Exit Kit; QEL Quiet Electric Latch Retraction
- Mechanical Options: PN Pneumatic Latch Retraction; -2 Double Cylinder; GBK Glass Bead Kit
- Fasteners & Sex Bolts (SNB): Includes screw3 pack for 1-3/4" (19mm) – 2-1/4" (57mm) Thick Metal or Wood Doors; Optional 425 SNB available for metal doors. 425 SNB required on wood doors without SLM blocking.
- Device Centerline from Finished Floor: 39-5/8" (1006 mm);
- Center Case Dimensions 8" x 2-3/4" x 2-3/8" (203mm x 70mm x 60mm)
- Mechanism Case Dimensions: 2-1/4" x 2-1/4" (57mm x 57mm)
- Projection: Pushbar Neutral – 3-13/16" (97 mm); Pushbar Depressed – 3-1/16" (78 mm)
- Device Functions: Device ships EO/DT/NL. Field selectable. For TP,K,or L adjust NL drive screw in mortise lock
- Device Lengths: 3’ 2’4" to 3’ (711mm to 914 mm) Door Size; 4’ 2’10" to 4’ (864 mm to 1219 mm) Door Size
- Strikes: 575 – Dull Black; Optional Strikes available
- Dogging Feature: Hex key dogging standard
- Dogging Options: CD Cylinder Dogging; LD Less Dogging;
- Mechanical Options: PN Pneumatic Latch Retraction; -2 Double Cylinder; GBK Glass Bead Kit
- Fasteners & Sex Bolts (SNB): Includes screw pack for 1-3/4" (19mm) – 2-1/4" (57mm) Thick Metal or Wood Doors; Optional 425 SNB available for device
- Device Centerline from Finished Floor: 39-5/8" (1006 mm)
- Center Case Dimensions: 8" x 2-3/4" x 2-3/8" (203mm x 70mm x 60mm)
- Mechanism Case Dimensions: 2-1/4" x 2-1/4" (57mm x 57mm)
-
Projection: Pushbar Neutral – 3-13/16" (97 mm)
Pushbar Depressed – 3-1/16" (78 mm)
The 98-F/99-F devices are available in the following finishes: US3, US4, US10, US26, US26D, US28 and 313AN. US32D available with 98 Series only.
Specifications
-
Device Functions: Device ships EO/DT/NL. Field selectable. For TP,K,or L remove NL drive screw from device
-
Device Lengths: 3’ 2’4" to 3’ (711mm to 914 mm) Door Size; 4’ 2’10" to 4’ (864 mm to 1219 mm) Door Size
-
Strikes: 299F – Dull Black, 499F with Mullions. Optional Strikes also available
-
Dogging Feature: No Mechanical Dogging, EL and QEL option available
-
Electric Options: LX Latchbolt Monitor Switch; RX Pushpad Monitor Switch; RX2 Double Pushpad Monitor Switch; E Electric Locking & Unlocking; EL Electric Latch Retraction; SS Signal Switch; CX Chexit Delayed Exit; ALK Alarm Exit Kit; QEL Quiet Electric Latch Retraction
-
Mechanical Options: PN Pneumatic Latch Retraction; -2 Double Cylinder; GBK Glass Bead Kit; XP Extra Protection
-
Fasteners & Sex Bolts (SNB): Includes screw pack for 1-3/4" (19mm) – 2-1/4" (57mm) Wood & Metal Doors Optional 425 SNB available for metal doors. 425 and 825 SNB required on wood doors without SLM blocking.
-
Latch Bolt: Deadlocking, 3/4" (19mm) throw
-
Device Centerline from Finished Floor: 39-13/16" (1011 mm); 39-11/16" (1008 mm) with Mullion
-
Center Case Dimensions: 8" x 2-3/4" x 2-3/8" (203mm x 70mm x 60mm)
-
Mechanism Case Dimensions: 2-1/4" x 2-1/4" (57mm x 57mm)
-
Projection: Pushbar Neutral – 3-13/16" (97 mm); Pushbar Depressed – 3-1/16" (78 mm)
99/98 Specification
Deadlocking latchbolt provides security and improved performance at standard device cost.
The Quiet One®
A fluid dampener decelerates the pushpad on its return stroke and eliminates most noise associated with exit device operations. Furnished on all 98/99™ series exit devices.
Electric power transfer (EPT) provides a means of transferring electrical power from a door frame to the edge of a swinging door.
2 models available: EPT-2 and EPT-10
EPT-2 has two 18-gauge wires
EPT-10 has 10 24-gauge wires
Ball and socket joint construction provides cut and pinch protection for wiring
Available in finishes 689 and 695
Electronic power transfers (EPT) provide a wiring path from the door to the frame, allowing products on or around the door to receive power as well as monitoring door status.
The unit is completely concealed when the door is in the closed position and ideally suited for installations with heavy traffic.
Allegion offers two models to meet the needs of any opening, with either two-wire or ten-wire harnesses, and both can be ordered with quick connect fittings.
