• Deadlocking latch

• Latch by lever inside or key outside

• Outside lever rigid at all times

• ANSI F86

Finishes Come In: 26D,03, 04,10, 10B, 26

Levers Come In: L, B & P

Strength, Durability and Security

• Cycle Test: Exceeds 5 times A156.2 Grade 1 requirements
• Abusive Locked Lever Torque- without entry gained: Exceeds 1.5 times A156.2 Grade 1 requirements
• 7 YEAR LIMITED WARRANTY - no service required to maintain warranty

Convenience

• Installs in 1 minute or less
• Quickly adapts to fit multiple through-bolt positions
• User friendly packaging
• User friendly instruction sheets
• Convenient installation diagram on box

Design

• Solid feel and precise lever action
• Slim rose design available
• Decorative Levers — Coastal Series designs – Gulfport and Yarmouth
• Levers are solid one piece cast construction, except “J” lever

Security

• Torx® and spanner screws optional
• Classroom security and multiple locking functions are available
• Vandal resistant, Free Wheeling (FW) trim optional (not available with 70 or 71 functions)
• Security key systems available (Signaturem Keso, BR-XC, XC)

Certification Compliance

• Certified ANSI A156.2 Series 4000-Grade 1
• UL listed to USA and Canadian safety standards. Listed for 3 hour doors (double doors require 41-option)                                                                                     Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
• Positive Pressure: Meets UL 10C and UBC 7-2 (1997)
• All levers conform to ADA requirement for barrier-free accessibility
• Levers (L,J & P) conform to California Administrative Code Title 19 and 24
• All individual components of a total door opening are required to comply with each code (Hurricane code)
• Conforms to national & state fire and handicapped requirements

Flexibility

• Fits a variety of door preparations with adaptable through-bolt positioning
• Accommodates retrofit applications with optional 2-3/8", 3-3/4", and 5" backset latches
• 6 ADA lever styles to complement a wide array of design applications
• Levers (B, L, J & P) are non-handed for efficient warehousing and for ease of installation
• 11 Architectural grade finishes
• 21 Functions
• SARGENT uses engineered solutions and flexible manufacturing processes to accommodate special applications

• Deadlocking latch

• Latch by either lever unless outside lever is locked by push/turn button in inside lever

• Push button released by key outside or lever inside

• Turn button must be released manually

• Key retracts latch when outside lever is locked

• ANSI F109

Finishes Come In: 26D,03, 04,10, 10B, 26

Levers Come In: L, B & P

Strength, Durability and Security

• Cycle Test: Exceeds 5 times A156.2 Grade 1 requirements
• Abusive Locked Lever Torque- without entry gained: Exceeds 1.5 times A156.2 Grade 1 requirements
• 7 YEAR LIMITED WARRANTY - no service required to maintain warranty

Convenience

• Installs in 1 minute or less
• Quickly adapts to fit multiple through-bolt positions
• User friendly packaging
• User friendly instruction sheets
• Convenient installation diagram on box

Design

• Solid feel and precise lever action
• Slim rose design available
• Decorative Levers — Coastal Series designs – Gulfport and Yarmouth
• Levers are solid one piece cast construction, except “J” lever

Security

• Torx® and spanner screws optional
• Classroom security and multiple locking functions are available
• Vandal resistant, Free Wheeling (FW) trim optional (not available with 70 or 71 functions)
• Security key systems available (Signaturem Keso, BR-XC, XC)

Certification Compliance

• Certified ANSI A156.2 Series 4000-Grade 1
• UL listed to USA and Canadian safety standards. Listed for 3 hour doors (double doors require 41-option)                                                                                     Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
• Positive Pressure: Meets UL 10C and UBC 7-2 (1997)
• All levers conform to ADA requirement for barrier-free accessibility
• Levers (L,J & P) conform to California Administrative Code Title 19 and 24
• All individual components of a total door opening are required to comply with each code (Hurricane code)
• Conforms to national & state fire and handicapped requirements

Flexibility

• Fits a variety of door preparations with adaptable through-bolt positioning
• Accommodates retrofit applications with optional 2-3/8", 3-3/4", and 5" backset latches
• 6 ADA lever styles to complement a wide array of design applications
• Levers (B, L, J & P) are non-handed for efficient warehousing and for ease of installation
• 11 Architectural grade finishes
• 21 Functions
• SARGENT uses engineered solutions and flexible manufacturing processes to accommodate special applications

• Deadlocking latch

• Latch by inside lever

• Outside lever rigid at all times.

Finishes Come In: 26D,03, 04,10, 10B, 26

Levers Come In: L, B & P

Strength, Durability and Security

• Cycle Test: Exceeds 5 times A156.2 Grade 1 requirements
• Abusive Locked Lever Torque- without entry gained: Exceeds 1.5 times A156.2 Grade 1 requirements
• 7 YEAR LIMITED WARRANTY - no service required to maintain warranty

Convenience

• Installs in 1 minute or less
• Quickly adapts to fit multiple through-bolt positions
• User friendly packaging
• User friendly instruction sheets
• Convenient installation diagram on box

Design

• Solid feel and precise lever action
• Slim rose design available
• Decorative Levers — Coastal Series designs – Gulfport and Yarmouth
• Levers are solid one piece cast construction, except “J” lever

Security

• Torx® and spanner screws optional
• Classroom security and multiple locking functions are available
• Vandal resistant, Free Wheeling (FW) trim optional (not available with 70 or 71 functions)
• Security key systems available (Signaturem Keso, BR-XC, XC)

Certification Compliance

• Certified ANSI A156.2 Series 4000-Grade 1
• UL listed to USA and Canadian safety standards. Listed for 3 hour doors (double doors require 41-option)                                                                                     Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
• Positive Pressure: Meets UL 10C and UBC 7-2 (1997)
• All levers conform to ADA requirement for barrier-free accessibility
• Levers (L,J & P) conform to California Administrative Code Title 19 and 24
• All individual components of a total door opening are required to comply with each code (Hurricane code)
• Conforms to national & state fire and handicapped requirements

Flexibility

• Fits a variety of door preparations with adaptable through-bolt positioning
• Accommodates retrofit applications with optional 2-3/8", 3-3/4", and 5" backset latches
• 6 ADA lever styles to complement a wide array of design applications
• Levers (B, L, J & P) are non-handed for efficient warehousing and for ease of installation
• 11 Architectural grade finishes
• 21 Functions
• SARGENT uses engineered solutions and flexible manufacturing processes to accommodate special applications

• Deadlocking latch

• Blank rose outside

• Latch by lever inside

• Minimum clearance of 1-1/8" on single doors and 2-1/4" between double doors

Finishes Come In: 26D,03, 04,10, 10B, 26

Levers Come In: L, B & P

Strength, Durability and Security

• Cycle Test: Exceeds 5 times A156.2 Grade 1 requirements
• Abusive Locked Lever Torque- without entry gained: Exceeds 1.5 times A156.2 Grade 1 requirements
• 7 YEAR LIMITED WARRANTY - no service required to maintain warranty

Convenience

• Installs in 1 minute or less
• Quickly adapts to fit multiple through-bolt positions
• User friendly packaging
• User friendly instruction sheets
• Convenient installation diagram on box

Design

• Solid feel and precise lever action
• Slim rose design available
• Decorative Levers — Coastal Series designs – Gulfport and Yarmouth
• Levers are solid one piece cast construction, except “J” lever

Security

• Torx® and spanner screws optional
• Classroom security and multiple locking functions are available
• Vandal resistant, Free Wheeling (FW) trim optional (not available with 70 or 71 functions)
• Security key systems available (Signaturem Keso, BR-XC, XC)

Certification Compliance

• Certified ANSI A156.2 Series 4000-Grade 1
• UL listed to USA and Canadian safety standards. Listed for 3 hour doors (double doors require 41-option)                                                                                     Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
• Positive Pressure: Meets UL 10C and UBC 7-2 (1997)
• All levers conform to ADA requirement for barrier-free accessibility
• Levers (L,J & P) conform to California Administrative Code Title 19 and 24
• All individual components of a total door opening are required to comply with each code (Hurricane code)
• Conforms to national & state fire and handicapped requirements

Flexibility

• Fits a variety of door preparations with adaptable through-bolt positioning
• Accommodates retrofit applications with optional 2-3/8", 3-3/4", and 5" backset latches
• 6 ADA lever styles to complement a wide array of design applications
• Levers (B, L, J & P) are non-handed for efficient warehousing and for ease of installation
• 11 Architectural grade finishes
• 21 Functions
• SARGENT uses engineered solutions and flexible manufacturing processes to accommodate special applications

• Deadlocking latch

• Latch by either lever unless outside lever is locked by key in inside lever

• Key in outside lever retracts latch when outside lever is locked

• Inside lever always operative

• ANSI F88

Finishes Come In: 26D,03, 04,10, 10B, 26

Levers Come In: L, B & P

Strength, Durability and Security

• Cycle Test: Exceeds 5 times A156.2 Grade 1 requirements
• Abusive Locked Lever Torque- without entry gained: Exceeds 1.5 times A156.2 Grade 1 requirements
• 7 YEAR LIMITED WARRANTY - no service required to maintain warranty

Convenience

• Installs in 1 minute or less
• Quickly adapts to fit multiple through-bolt positions
• User friendly packaging
• User friendly instruction sheets
• Convenient installation diagram on box

Design

• Solid feel and precise lever action
• Slim rose design available
• Decorative Levers — Coastal Series designs – Gulfport and Yarmouth
• Levers are solid one piece cast construction, except “J” lever

Security

• Torx® and spanner screws optional
• Classroom security and multiple locking functions are available
• Vandal resistant, Free Wheeling (FW) trim optional (not available with 70 or 71 functions)
• Security key systems available (Signaturem Keso, BR-XC, XC)

Certification Compliance

• Certified ANSI A156.2 Series 4000-Grade 1
• UL listed to USA and Canadian safety standards. Listed for 3 hour doors (double doors require 41-option)                                                                                     Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
• Positive Pressure: Meets UL 10C and UBC 7-2 (1997)
• All levers conform to ADA requirement for barrier-free accessibility
• Levers (L,J & P) conform to California Administrative Code Title 19 and 24
• All individual components of a total door opening are required to comply with each code (Hurricane code)
• Conforms to national & state fire and handicapped requirements

Flexibility

• Fits a variety of door preparations with adaptable through-bolt positioning
• Accommodates retrofit applications with optional 2-3/8", 3-3/4", and 5" backset latches
• 6 ADA lever styles to complement a wide array of design applications
• Levers (B, L, J & P) are non-handed for efficient warehousing and for ease of installation
• 11 Architectural grade finishes
• 21 Functions
• SARGENT uses engineered solutions and flexible manufacturing processes to accommodate special applications

• Deadlocking latch

• Both levers rigid at all times

• Latch by key either side

• Use only on rooms with more than one exit

• ANSI F87

Finishes Come In: 26D,03, 04,10, 10B, 26

Levers Come In: L, B & P

Strength, Durability and Security

• Cycle Test: Exceeds 5 times A156.2 Grade 1 requirements
• Abusive Locked Lever Torque- without entry gained: Exceeds 1.5 times A156.2 Grade 1 requirements
• 7 YEAR LIMITED WARRANTY - no service required to maintain warranty

Convenience

• Installs in 1 minute or less
• Quickly adapts to fit multiple through-bolt positions
• User friendly packaging
• User friendly instruction sheets
• Convenient installation diagram on box

Design

• Solid feel and precise lever action
• Slim rose design available
• Decorative Levers — Coastal Series designs – Gulfport and Yarmouth
• Levers are solid one piece cast construction, except “J” lever

Security

• Torx® and spanner screws optional
• Classroom security and multiple locking functions are available
• Vandal resistant, Free Wheeling (FW) trim optional (not available with 70 or 71 functions)
• Security key systems available (Signaturem Keso, BR-XC, XC)

Certification Compliance

• Certified ANSI A156.2 Series 4000-Grade 1
• UL listed to USA and Canadian safety standards. Listed for 3 hour doors (double doors require 41-option)                                                                                     Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
• Positive Pressure: Meets UL 10C and UBC 7-2 (1997)
• All levers conform to ADA requirement for barrier-free accessibility
• Levers (L,J & P) conform to California Administrative Code Title 19 and 24
• All individual components of a total door opening are required to comply with each code (Hurricane code)
• Conforms to national & state fire and handicapped requirements

Flexibility

• Fits a variety of door preparations with adaptable through-bolt positioning
• Accommodates retrofit applications with optional 2-3/8", 3-3/4", and 5" backset latches
• 6 ADA lever styles to complement a wide array of design applications
• Levers (B, L, J & P) are non-handed for efficient warehousing and for ease of installation
• 11 Architectural grade finishes
• 21 Functions
• SARGENT uses engineered solutions and flexible manufacturing processes to accommodate special applications

• Deadlocking latch

• Latch by either lever unless outside lever is locked by push button in inside lever

• Push button released by key or turning inside lever

• Closing door does not unlock outside lever or release button

• Key in outside lever retracts latch when outside lever is locked and releases inside push button

• ANSI F82

Finishes Come In: 26D,03, 04,10, 10B, 26

Levers Come In: L, B & P

Strength, Durability and Security

• Cycle Test: Exceeds 5 times A156.2 Grade 1 requirements
• Abusive Locked Lever Torque- without entry gained: Exceeds 1.5 times A156.2 Grade 1 requirements
• 7 YEAR LIMITED WARRANTY - no service required to maintain warranty

Convenience

• Installs in 1 minute or less
• Quickly adapts to fit multiple through-bolt positions
• User friendly packaging
• User friendly instruction sheets
• Convenient installation diagram on box

Design

• Solid feel and precise lever action
• Slim rose design available
• Decorative Levers — Coastal Series designs – Gulfport and Yarmouth
• Levers are solid one piece cast construction, except “J” lever

Security

• Torx® and spanner screws optional
• Classroom security and multiple locking functions are available
• Vandal resistant, Free Wheeling (FW) trim optional (not available with 70 or 71 functions)
• Security key systems available (Signaturem Keso, BR-XC, XC)

Certification Compliance

• Certified ANSI A156.2 Series 4000-Grade 1
• UL listed to USA and Canadian safety standards. Listed for 3 hour doors (double doors require 41-option)                                                                                     Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
• Positive Pressure: Meets UL 10C and UBC 7-2 (1997)
• All levers conform to ADA requirement for barrier-free accessibility
• Levers (L,J & P) conform to California Administrative Code Title 19 and 24
• All individual components of a total door opening are required to comply with each code (Hurricane code)
• Conforms to national & state fire and handicapped requirements

Flexibility

• Fits a variety of door preparations with adaptable through-bolt positioning
• Accommodates retrofit applications with optional 2-3/8", 3-3/4", and 5" backset latches
• 6 ADA lever styles to complement a wide array of design applications
• Levers (B, L, J & P) are non-handed for efficient warehousing and for ease of installation
• 11 Architectural grade finishes
• 21 Functions
• SARGENT uses engineered solutions and flexible manufacturing processes to accommodate special applications

• Deadlocking latch

• Latch by either lever

• Key in either lever locks or unlocks both levers

• ANSI F91

Finishes Come In: 26D,03, 04,10, 10B, 26

Levers Come In: L, B & P

Strength, Durability and Security

• Cycle Test: Exceeds 5 times A156.2 Grade 1 requirements
• Abusive Locked Lever Torque- without entry gained: Exceeds 1.5 times A156.2 Grade 1 requirements
• 7 YEAR LIMITED WARRANTY - no service required to maintain warranty

Convenience

• Installs in 1 minute or less
• Quickly adapts to fit multiple through-bolt positions
• User friendly packaging
• User friendly instruction sheets
• Convenient installation diagram on box

Design

• Solid feel and precise lever action
• Slim rose design available
• Decorative Levers — Coastal Series designs – Gulfport and Yarmouth
• Levers are solid one piece cast construction, except “J” lever

Security

• Torx® and spanner screws optional
• Classroom security and multiple locking functions are available
• Vandal resistant, Free Wheeling (FW) trim optional (not available with 70 or 71 functions)
• Security key systems available (Signaturem Keso, BR-XC, XC)

Certification Compliance

• Certified ANSI A156.2 Series 4000-Grade 1
• UL listed to USA and Canadian safety standards. Listed for 3 hour doors (double doors require 41-option)                                                                                     Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
• Positive Pressure: Meets UL 10C and UBC 7-2 (1997)
• All levers conform to ADA requirement for barrier-free accessibility
• Levers (L,J & P) conform to California Administrative Code Title 19 and 24
• All individual components of a total door opening are required to comply with each code (Hurricane code)
• Conforms to national & state fire and handicapped requirements

Flexibility

• Fits a variety of door preparations with adaptable through-bolt positioning
• Accommodates retrofit applications with optional 2-3/8", 3-3/4", and 5" backset latches
• 6 ADA lever styles to complement a wide array of design applications
• Levers (B, L, J & P) are non-handed for efficient warehousing and for ease of installation
• 11 Architectural grade finishes
• 21 Functions
• SARGENT uses engineered solutions and flexible manufacturing processes to accommodate special applications

• Deadlocking latch

• Latch by either lever

• Key in either lever locks or unlocks its own lever only

• Use only on rooms with more than one exit

• ANSI F80

Finishes Come In: 26D,03, 04,10, 10B, 26

Levers Come In: L, B & P

Strength, Durability and Security

• Cycle Test: Exceeds 5 times A156.2 Grade 1 requirements
• Abusive Locked Lever Torque- without entry gained: Exceeds 1.5 times A156.2 Grade 1 requirements
• 7 YEAR LIMITED WARRANTY - no service required to maintain warranty

Convenience

• Installs in 1 minute or less
• Quickly adapts to fit multiple through-bolt positions
• User friendly packaging
• User friendly instruction sheets
• Convenient installation diagram on box

Design

• Solid feel and precise lever action
• Slim rose design available
• Decorative Levers — Coastal Series designs – Gulfport and Yarmouth
• Levers are solid one piece cast construction, except “J” lever

Security

• Torx® and spanner screws optional
• Classroom security and multiple locking functions are available
• Vandal resistant, Free Wheeling (FW) trim optional (not available with 70 or 71 functions)
• Security key systems available (Signaturem Keso, BR-XC, XC)

Certification Compliance

• Certified ANSI A156.2 Series 4000-Grade 1
• UL listed to USA and Canadian safety standards. Listed for 3 hour doors (double doors require 41-option)                                                                                     Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
• Positive Pressure: Meets UL 10C and UBC 7-2 (1997)
• All levers conform to ADA requirement for barrier-free accessibility
• Levers (L,J & P) conform to California Administrative Code Title 19 and 24
• All individual components of a total door opening are required to comply with each code (Hurricane code)
• Conforms to national & state fire and handicapped requirements

Flexibility

• Fits a variety of door preparations with adaptable through-bolt positioning
• Accommodates retrofit applications with optional 2-3/8", 3-3/4", and 5" backset latches
• 6 ADA lever styles to complement a wide array of design applications
• Levers (B, L, J & P) are non-handed for efficient warehousing and for ease of installation
• 11 Architectural grade finishes
• 21 Functions
• SARGENT uses engineered solutions and flexible manufacturing processes to accommodate special applications

• Deadlocking latch

• Latch by either lever unless outside lever is locked by key

• Key in outside lever locks or unlocks outside lever and retracts latch

• Inside lever always operative

• ANSI F84

Finishes Come In: 26D,03, 04,10, 10B, 26

Levers Come In: L, B & P

Strength, Durability and Security

• Cycle Test: Exceeds 5 times A156.2 Grade 1 requirements
• Abusive Locked Lever Torque- without entry gained: Exceeds 1.5 times A156.2 Grade 1 requirements
• 7 YEAR LIMITED WARRANTY - no service required to maintain warranty

Convenience

• Installs in 1 minute or less
• Quickly adapts to fit multiple through-bolt positions
• User friendly packaging
• User friendly instruction sheets
• Convenient installation diagram on box

Design

• Solid feel and precise lever action
• Slim rose design available
• Decorative Levers — Coastal Series designs – Gulfport and Yarmouth
• Levers are solid one piece cast construction, except “J” lever

Security

• Torx® and spanner screws optional
• Classroom security and multiple locking functions are available
• Vandal resistant, Free Wheeling (FW) trim optional (not available with 70 or 71 functions)
• Security key systems available (Signaturem Keso, BR-XC, XC)

Certification Compliance

• Certified ANSI A156.2 Series 4000-Grade 1
• UL listed to USA and Canadian safety standards. Listed for 3 hour doors (double doors require 41-option)                                                                                     Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
• Positive Pressure: Meets UL 10C and UBC 7-2 (1997)
• All levers conform to ADA requirement for barrier-free accessibility
• Levers (L,J & P) conform to California Administrative Code Title 19 and 24
• All individual components of a total door opening are required to comply with each code (Hurricane code)
• Conforms to national & state fire and handicapped requirements

Flexibility

• Fits a variety of door preparations with adaptable through-bolt positioning
• Accommodates retrofit applications with optional 2-3/8", 3-3/4", and 5" backset latches
• 6 ADA lever styles to complement a wide array of design applications
• Levers (B, L, J & P) are non-handed for efficient warehousing and for ease of installation
• 11 Architectural grade finishes
• 21 Functions
• SARGENT uses engineered solutions and flexible manufacturing processes to accommodate special applications

• Deadlocking latch

• Latch by either lever unless outside lever is locked by key

• Key in either lever locks or unlocks outside lever

• Inside lever always operable

• Locked indication on inside rose standard with this function

Finishes Come In: 26D,03, 04,10, 10B, 26

Levers Come In: L, B & P

Strength, Durability and Security

• Cycle Test: Exceeds 5 times A156.2 Grade 1 requirements
• Abusive Locked Lever Torque- without entry gained: Exceeds 1.5 times A156.2 Grade 1 requirements
• 7 YEAR LIMITED WARRANTY - no service required to maintain warranty

Convenience

• Installs in 1 minute or less
• Quickly adapts to fit multiple through-bolt positions
• User friendly packaging
• User friendly instruction sheets
• Convenient installation diagram on box

Design

• Solid feel and precise lever action
• Slim rose design available
• Decorative Levers — Coastal Series designs – Gulfport and Yarmouth
• Levers are solid one piece cast construction, except “J” lever

Security

• Torx® and spanner screws optional
• Classroom security and multiple locking functions are available
• Vandal resistant, Free Wheeling (FW) trim optional (not available with 70 or 71 functions)
• Security key systems available (Signaturem Keso, BR-XC, XC)

Certification Compliance

• Certified ANSI A156.2 Series 4000-Grade 1
• UL listed to USA and Canadian safety standards. Listed for 3 hour doors (double doors require 41-option)                                                                                     Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
• Positive Pressure: Meets UL 10C and UBC 7-2 (1997)
• All levers conform to ADA requirement for barrier-free accessibility
• Levers (L,J & P) conform to California Administrative Code Title 19 and 24
• All individual components of a total door opening are required to comply with each code (Hurricane code)
• Conforms to national & state fire and handicapped requirements

Flexibility

• Fits a variety of door preparations with adaptable through-bolt positioning
• Accommodates retrofit applications with optional 2-3/8", 3-3/4", and 5" backset latches
• 6 ADA lever styles to complement a wide array of design applications
• Levers (B, L, J & P) are non-handed for efficient warehousing and for ease of installation
• 11 Architectural grade finishes
• 21 Functions
• SARGENT uses engineered solutions and flexible manufacturing processes to accommodate special applications

• Deadlocking latch

• Latch by either lever unless outside lever is locked by push button in inside lever

• Key retracts latch when outside lever is locked

• Push button released by turning inside lever, closing door, or by key in outside lever unless push button is fixed in locked position by turning coin slot in inside lever

• Slotted inside button must be manually released

• ANSI F92

Finishes Come In: 26D,03, 04,10, 10B, 26

Levers Come In: L, B & P

Strength, Durability and Security

• Cycle Test: Exceeds 5 times A156.2 Grade 1 requirements
• Abusive Locked Lever Torque- without entry gained: Exceeds 1.5 times A156.2 Grade 1 requirements
• 7 YEAR LIMITED WARRANTY - no service required to maintain warranty

Convenience

• Installs in 1 minute or less
• Quickly adapts to fit multiple through-bolt positions
• User friendly packaging
• User friendly instruction sheets
• Convenient installation diagram on box

Design

• Solid feel and precise lever action
• Slim rose design available
• Decorative Levers — Coastal Series designs – Gulfport and Yarmouth
• Levers are solid one piece cast construction, except “J” lever

Security

• Torx® and spanner screws optional
• Classroom security and multiple locking functions are available
• Vandal resistant, Free Wheeling (FW) trim optional (not available with 70 or 71 functions)
• Security key systems available (Signaturem Keso, BR-XC, XC)

Certification Compliance

• Certified ANSI A156.2 Series 4000-Grade 1
• UL listed to USA and Canadian safety standards. Listed for 3 hour doors (double doors require 41-option)                                                                                     Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
• Positive Pressure: Meets UL 10C and UBC 7-2 (1997)
• All levers conform to ADA requirement for barrier-free accessibility
• Levers (L,J & P) conform to California Administrative Code Title 19 and 24
• All individual components of a total door opening are required to comply with each code (Hurricane code)
• Conforms to national & state fire and handicapped requirements

Flexibility

• Fits a variety of door preparations with adaptable through-bolt positioning
• Accommodates retrofit applications with optional 2-3/8", 3-3/4", and 5" backset latches
• 6 ADA lever styles to complement a wide array of design applications
• Levers (B, L, J & P) are non-handed for efficient warehousing and for ease of installation
• 11 Architectural grade finishes
• 21 Functions
• SARGENT uses engineered solutions and flexible manufacturing processes to accommodate special applications

• Deadlocking latch

• Latch by key outside and lever inside • Outside lever always rigid

• Depressing push button when door is closed shuts out all keys except emergency key and projects visual occupancy indicator in cylinder face

• Push button released by turning inside lever automatically reactivating all keys and retracting visual occupancy indicator

• Lock out key fixes push button in locked position, shutting out all keys except emergency

• Push button fixed by lockout key must be released manually

• Lock out key provided

• Emergency key ordered separately. Part # 6267EMK

• ANSI F93

Finishes Come In: 26D,03, 04,10, 10B, 26

Levers Come In: L, B & P

Strength, Durability and Security

• Cycle Test: Exceeds 5 times A156.2 Grade 1 requirements
• Abusive Locked Lever Torque- without entry gained: Exceeds 1.5 times A156.2 Grade 1 requirements
• 7 YEAR LIMITED WARRANTY - no service required to maintain warranty

Convenience

• Installs in 1 minute or less
• Quickly adapts to fit multiple through-bolt positions
• User friendly packaging
• User friendly instruction sheets
• Convenient installation diagram on box

Design

• Solid feel and precise lever action
• Slim rose design available
• Decorative Levers — Coastal Series designs – Gulfport and Yarmouth
• Levers are solid one piece cast construction, except “J” lever

Security

• Torx® and spanner screws optional
• Classroom security and multiple locking functions are available
• Vandal resistant, Free Wheeling (FW) trim optional (not available with 70 or 71 functions)
• Security key systems available (Signaturem Keso, BR-XC, XC)

Certification Compliance

• Certified ANSI A156.2 Series 4000-Grade 1
• UL listed to USA and Canadian safety standards. Listed for 3 hour doors (double doors require 41-option)                                                                                     Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
• Positive Pressure: Meets UL 10C and UBC 7-2 (1997)
• All levers conform to ADA requirement for barrier-free accessibility
• Levers (L,J & P) conform to California Administrative Code Title 19 and 24
• All individual components of a total door opening are required to comply with each code (Hurricane code)
• Conforms to national & state fire and handicapped requirements

Flexibility

• Fits a variety of door preparations with adaptable through-bolt positioning
• Accommodates retrofit applications with optional 2-3/8", 3-3/4", and 5" backset latches
• 6 ADA lever styles to complement a wide array of design applications
• Levers (B, L, J & P) are non-handed for efficient warehousing and for ease of installation
• 11 Architectural grade finishes
• 21 Functions
• SARGENT uses engineered solutions and flexible manufacturing processes to accommodate special applications

• Deadlocking latch

• Latch by either lever unless outside lever is locked by push button inside or key outside

• Rotating inside lever or closing door releases inside button only, but does not unlock the outside lever if locked by key

• Key outside locks or unlocks outside lever and also retracts latchbolt when locked

• ANSI F90

Finishes Come In: 26D,03, 04,10, 10B, 26

Levers Come In: L, B & P

Strength, Durability and Security

• Cycle Test: Exceeds 5 times A156.2 Grade 1 requirements
• Abusive Locked Lever Torque- without entry gained: Exceeds 1.5 times A156.2 Grade 1 requirements
• 7 YEAR LIMITED WARRANTY - no service required to maintain warranty

Convenience

• Installs in 1 minute or less
• Quickly adapts to fit multiple through-bolt positions
• User friendly packaging
• User friendly instruction sheets
• Convenient installation diagram on box

Design

• Solid feel and precise lever action
• Slim rose design available
• Decorative Levers — Coastal Series designs – Gulfport and Yarmouth
• Levers are solid one piece cast construction, except “J” lever

Security

• Torx® and spanner screws optional
• Classroom security and multiple locking functions are available
• Vandal resistant, Free Wheeling (FW) trim optional (not available with 70 or 71 functions)
• Security key systems available (Signaturem Keso, BR-XC, XC)

Certification Compliance

• Certified ANSI A156.2 Series 4000-Grade 1
• UL listed to USA and Canadian safety standards. Listed for 3 hour doors (double doors require 41-option)                                                                                     Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
• Positive Pressure: Meets UL 10C and UBC 7-2 (1997)
• All levers conform to ADA requirement for barrier-free accessibility
• Levers (L,J & P) conform to California Administrative Code Title 19 and 24
• All individual components of a total door opening are required to comply with each code (Hurricane code)
• Conforms to national & state fire and handicapped requirements

Flexibility

• Fits a variety of door preparations with adaptable through-bolt positioning
• Accommodates retrofit applications with optional 2-3/8", 3-3/4", and 5" backset latches
• 6 ADA lever styles to complement a wide array of design applications
• Levers (B, L, J & P) are non-handed for efficient warehousing and for ease of installation
• 11 Architectural grade finishes
• 21 Functions
• SARGENT uses engineered solutions and flexible manufacturing processes to accommodate special applications

• 10G70: Power off, unlocks outside lever

• 10G71: Power off, locks outside lever

• Deadlocking latch

• Key retracts latch

• Inside lever always allows egress

• Voltage requirements: 12VDC or 24VDC Regulated; always specify voltage

• 250mA at 24VDC or 500mA at 12VDC

• Provided with ElectroLynx® 8-Pin Connector

Finishes Come In: 26D,03, 04,10, 10B, 26

Levers Come In: L, B & P

Strength, Durability and Security

• Cycle Test: Exceeds 5 times A156.2 Grade 1 requirements
• Abusive Locked Lever Torque- without entry gained: Exceeds 1.5 times A156.2 Grade 1 requirements
• 7 YEAR LIMITED WARRANTY - no service required to maintain warranty

Convenience

• Installs in 1 minute or less
• Quickly adapts to fit multiple through-bolt positions
• User friendly packaging
• User friendly instruction sheets
• Convenient installation diagram on box

Design

• Solid feel and precise lever action
• Slim rose design available
• Decorative Levers — Coastal Series designs – Gulfport and Yarmouth
• Levers are solid one piece cast construction, except “J” lever

Security

• Torx® and spanner screws optional
• Classroom security and multiple locking functions are available
• Vandal resistant, Free Wheeling (FW) trim optional (not available with 70 or 71 functions)
• Security key systems available (Signaturem Keso, BR-XC, XC)

Certification Compliance

• Certified ANSI A156.2 Series 4000-Grade 1
• UL listed to USA and Canadian safety standards. Listed for 3 hour doors (double doors require 41-option)                                                                                     Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
• Positive Pressure: Meets UL 10C and UBC 7-2 (1997)
• All levers conform to ADA requirement for barrier-free accessibility
• Levers (L,J & P) conform to California Administrative Code Title 19 and 24
• All individual components of a total door opening are required to comply with each code (Hurricane code)
• Conforms to national & state fire and handicapped requirements

Flexibility

• Fits a variety of door preparations with adaptable through-bolt positioning
• Accommodates retrofit applications with optional 2-3/8", 3-3/4", and 5" backset latches
• 6 ADA lever styles to complement a wide array of design applications
• Levers (B, L, J & P) are non-handed for efficient warehousing and for ease of installation
• 11 Architectural grade finishes
• 21 Functions
• SARGENT uses engineered solutions and flexible manufacturing processes to accommodate special applications

• 10G70: Power off, unlocks outside lever

• 10G71: Power off, locks outside lever

• Deadlocking latch

• Key retracts latch

• Inside lever always allows egress

• Voltage requirements: 12VDC or 24VDC Regulated; always specify voltage

• 250mA at 24VDC or 500mA at 12VDC

• Provided with ElectroLynx® 8-Pin Connector

Finishes Come In: 26D,03, 04,10, 10B, 26

Levers Come In: L, B & P

Strength, Durability and Security

• Cycle Test: Exceeds 5 times A156.2 Grade 1 requirements
• Abusive Locked Lever Torque- without entry gained: Exceeds 1.5 times A156.2 Grade 1 requirements
• 7 YEAR LIMITED WARRANTY - no service required to maintain warranty

Convenience

• Installs in 1 minute or less
• Quickly adapts to fit multiple through-bolt positions
• User friendly packaging
• User friendly instruction sheets
• Convenient installation diagram on box

Design

• Solid feel and precise lever action
• Slim rose design available
• Decorative Levers — Coastal Series designs – Gulfport and Yarmouth
• Levers are solid one piece cast construction, except “J” lever

Security

• Torx® and spanner screws optional
• Classroom security and multiple locking functions are available
• Vandal resistant, Free Wheeling (FW) trim optional (not available with 70 or 71 functions)
• Security key systems available (Signaturem Keso, BR-XC, XC)

Certification Compliance

• Certified ANSI A156.2 Series 4000-Grade 1
• UL listed to USA and Canadian safety standards. Listed for 3 hour doors (double doors require 41-option)                                                                                     Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
• Positive Pressure: Meets UL 10C and UBC 7-2 (1997)
• All levers conform to ADA requirement for barrier-free accessibility
• Levers (L,J & P) conform to California Administrative Code Title 19 and 24
• All individual components of a total door opening are required to comply with each code (Hurricane code)
• Conforms to national & state fire and handicapped requirements

Flexibility

• Fits a variety of door preparations with adaptable through-bolt positioning
• Accommodates retrofit applications with optional 2-3/8", 3-3/4", and 5" backset latches
• 6 ADA lever styles to complement a wide array of design applications
• Levers (B, L, J & P) are non-handed for efficient warehousing and for ease of installation
• 11 Architectural grade finishes
• 21 Functions
• SARGENT uses engineered solutions and flexible manufacturing processes to accommodate special applications

• Latch by either lever

Finishes Come In: 26D,03, 04,10, 10B, 26

Levers Come In: L, B & P

Strength, Durability and Security

• Cycle Test: Exceeds 5 times A156.2 Grade 1 requirements
• Abusive Locked Lever Torque- without entry gained: Exceeds 1.5 times A156.2 Grade 1 requirements
• 7 YEAR LIMITED WARRANTY - no service required to maintain warranty

Convenience

• Installs in 1 minute or less
• Quickly adapts to fit multiple through-bolt positions
• User friendly packaging
• User friendly instruction sheets
• Convenient installation diagram on box

Design

• Solid feel and precise lever action
• Slim rose design available
• Decorative Levers — Coastal Series designs – Gulfport and Yarmouth
• Levers are solid one piece cast construction, except “J” lever

Security

• Torx® and spanner screws optional
• Classroom security and multiple locking functions are available
• Vandal resistant, Free Wheeling (FW) trim optional (not available with 70 or 71 functions)
• Security key systems available (Signaturem Keso, BR-XC, XC)

Certification Compliance

• Certified ANSI A156.2 Series 4000-Grade 1
• UL listed to USA and Canadian safety standards. Listed for 3 hour doors (double doors require 41-option)                                                                                     Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
• Positive Pressure: Meets UL 10C and UBC 7-2 (1997)
• All levers conform to ADA requirement for barrier-free accessibility
• Levers (L,J & P) conform to California Administrative Code Title 19 and 24
• All individual components of a total door opening are required to comply with each code (Hurricane code)
• Conforms to national & state fire and handicapped requirements

Flexibility

• Fits a variety of door preparations with adaptable through-bolt positioning
• Accommodates retrofit applications with optional 2-3/8", 3-3/4", and 5" backset latches
• 6 ADA lever styles to complement a wide array of design applications
• Levers (B, L, J & P) are non-handed for efficient warehousing and for ease of installation
• 11 Architectural grade finishes
• 21 Functions
• SARGENT uses engineered solutions and flexible manufacturing processes to accommodate special applications

• Latch by either lever unless outside lever is locked by push button in inside lever

• Turning inside lever or closing door releases button

• Emergency button in outside lever unlocks, with use of a blade screwdriver in outside lever and releases inside button

• ANSI F76

Finishes Come In: 26D,03, 04,10, 10B, 26

Levers Come In: L, B & P

Strength, Durability and Security

• Cycle Test: Exceeds 5 times A156.2 Grade 1 requirements
• Abusive Locked Lever Torque- without entry gained: Exceeds 1.5 times A156.2 Grade 1 requirements
• 7 YEAR LIMITED WARRANTY - no service required to maintain warranty

Convenience

• Installs in 1 minute or less
• Quickly adapts to fit multiple through-bolt positions
• User friendly packaging
• User friendly instruction sheets
• Convenient installation diagram on box

Design

• Solid feel and precise lever action
• Slim rose design available
• Decorative Levers — Coastal Series designs – Gulfport and Yarmouth
• Levers are solid one piece cast construction, except “J” lever

Security

• Torx® and spanner screws optional
• Classroom security and multiple locking functions are available
• Vandal resistant, Free Wheeling (FW) trim optional (not available with 70 or 71 functions)
• Security key systems available (Signaturem Keso, BR-XC, XC)

Certification Compliance

• Certified ANSI A156.2 Series 4000-Grade 1
• UL listed to USA and Canadian safety standards. Listed for 3 hour doors (double doors require 41-option)                                                                                     Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
• Positive Pressure: Meets UL 10C and UBC 7-2 (1997)
• All levers conform to ADA requirement for barrier-free accessibility
• Levers (L,J & P) conform to California Administrative Code Title 19 and 24
• All individual components of a total door opening are required to comply with each code (Hurricane code)
• Conforms to national & state fire and handicapped requirements

Flexibility

• Fits a variety of door preparations with adaptable through-bolt positioning
• Accommodates retrofit applications with optional 2-3/8", 3-3/4", and 5" backset latches
• 6 ADA lever styles to complement a wide array of design applications
• Levers (B, L, J & P) are non-handed for efficient warehousing and for ease of installation
• 11 Architectural grade finishes
• 21 Functions
• SARGENT uses engineered solutions and flexible manufacturing processes to accommodate special applications

Latch by either lever unless outside lever is locked by push button in inside lever

• Turning inside lever or closing door releases button

• Rotating thumbturn in outside lever unlocks the outside lever and releases the inside button

Finishes Come In: 26D,03, 04,10, 10B, 26

Levers Come In: L, B & P

Strength, Durability and Security

• Cycle Test: Exceeds 5 times A156.2 Grade 1 requirements
• Abusive Locked Lever Torque- without entry gained: Exceeds 1.5 times A156.2 Grade 1 requirements
• 7 YEAR LIMITED WARRANTY - no service required to maintain warranty

Convenience

• Installs in 1 minute or less
• Quickly adapts to fit multiple through-bolt positions
• User friendly packaging
• User friendly instruction sheets
• Convenient installation diagram on box

Design

• Solid feel and precise lever action
• Slim rose design available
• Decorative Levers — Coastal Series designs – Gulfport and Yarmouth
• Levers are solid one piece cast construction, except “J” lever

Security

• Torx® and spanner screws optional
• Classroom security and multiple locking functions are available
• Vandal resistant, Free Wheeling (FW) trim optional (not available with 70 or 71 functions)
• Security key systems available (Signaturem Keso, BR-XC, XC)

Certification Compliance

• Certified ANSI A156.2 Series 4000-Grade 1
• UL listed to USA and Canadian safety standards. Listed for 3 hour doors (double doors require 41-option)                                                                                     Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
• Positive Pressure: Meets UL 10C and UBC 7-2 (1997)
• All levers conform to ADA requirement for barrier-free accessibility
• Levers (L,J & P) conform to California Administrative Code Title 19 and 24
• All individual components of a total door opening are required to comply with each code (Hurricane code)
• Conforms to national & state fire and handicapped requirements

Flexibility

• Fits a variety of door preparations with adaptable through-bolt positioning
• Accommodates retrofit applications with optional 2-3/8", 3-3/4", and 5" backset latches
• 6 ADA lever styles to complement a wide array of design applications
• Levers (B, L, J & P) are non-handed for efficient warehousing and for ease of installation
• 11 Architectural grade finishes
• 21 Functions
• SARGENT uses engineered solutions and flexible manufacturing processes to accommodate special applications

• For wood or custom hollow metal doors

• Lever and rose both sides joined by two through-bolts

• Requires special door preparation — see template

Finishes Come In: 26D,03, 04,10, 10B, 26

Levers Come In: L, B & P

Strength, Durability and Security

• Cycle Test: Exceeds 5 times A156.2 Grade 1 requirements
• Abusive Locked Lever Torque- without entry gained: Exceeds 1.5 times A156.2 Grade 1 requirements
• 7 YEAR LIMITED WARRANTY - no service required to maintain warranty

Convenience

• Installs in 1 minute or less
• Quickly adapts to fit multiple through-bolt positions
• User friendly packaging
• User friendly instruction sheets
• Convenient installation diagram on box

Design

• Solid feel and precise lever action
• Slim rose design available
• Decorative Levers — Coastal Series designs – Gulfport and Yarmouth
• Levers are solid one piece cast construction, except “J” lever

Security

• Torx® and spanner screws optional
• Classroom security and multiple locking functions are available
• Vandal resistant, Free Wheeling (FW) trim optional (not available with 70 or 71 functions)
• Security key systems available (Signaturem Keso, BR-XC, XC)

Certification Compliance

• Certified ANSI A156.2 Series 4000-Grade 1
• UL listed to USA and Canadian safety standards. Listed for 3 hour doors (double doors require 41-option)                                                                                     Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
• Positive Pressure: Meets UL 10C and UBC 7-2 (1997)
• All levers conform to ADA requirement for barrier-free accessibility
• Levers (L,J & P) conform to California Administrative Code Title 19 and 24
• All individual components of a total door opening are required to comply with each code (Hurricane code)
• Conforms to national & state fire and handicapped requirements

Flexibility

• Fits a variety of door preparations with adaptable through-bolt positioning
• Accommodates retrofit applications with optional 2-3/8", 3-3/4", and 5" backset latches
• 6 ADA lever styles to complement a wide array of design applications
• Levers (B, L, J & P) are non-handed for efficient warehousing and for ease of installation
• 11 Architectural grade finishes
• 21 Functions
• SARGENT uses engineered solutions and flexible manufacturing processes to accommodate special applications

• For wood or custom hollow metal doors

• Lever and rose both sides joined by two through-bolts

• Requires special door preparation — see template

Finishes Come In: 26D,03, 04,10, 10B, 26

Levers Come In: L, B & P

Strength, Durability and Security

• Cycle Test: Exceeds 5 times A156.2 Grade 1 requirements
• Abusive Locked Lever Torque- without entry gained: Exceeds 1.5 times A156.2 Grade 1 requirements
• 7 YEAR LIMITED WARRANTY - no service required to maintain warranty

Convenience

• Installs in 1 minute or less
• Quickly adapts to fit multiple through-bolt positions
• User friendly packaging
• User friendly instruction sheets
• Convenient installation diagram on box

Design

• Solid feel and precise lever action
• Slim rose design available
• Decorative Levers — Coastal Series designs – Gulfport and Yarmouth
• Levers are solid one piece cast construction, except “J” lever

Security

• Torx® and spanner screws optional
• Classroom security and multiple locking functions are available
• Vandal resistant, Free Wheeling (FW) trim optional (not available with 70 or 71 functions)
• Security key systems available (Signaturem Keso, BR-XC, XC)

Certification Compliance

• Certified ANSI A156.2 Series 4000-Grade 1
• UL listed to USA and Canadian safety standards. Listed for 3 hour doors (double doors require 41-option)                                                                                     Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
• Positive Pressure: Meets UL 10C and UBC 7-2 (1997)
• All levers conform to ADA requirement for barrier-free accessibility
• Levers (L,J & P) conform to California Administrative Code Title 19 and 24
• All individual components of a total door opening are required to comply with each code (Hurricane code)
• Conforms to national & state fire and handicapped requirements

Flexibility

• Fits a variety of door preparations with adaptable through-bolt positioning
• Accommodates retrofit applications with optional 2-3/8", 3-3/4", and 5" backset latches
• 6 ADA lever styles to complement a wide array of design applications
• Levers (B, L, J & P) are non-handed for efficient warehousing and for ease of installation
• 11 Architectural grade finishes
• 21 Functions
• SARGENT uses engineered solutions and flexible manufacturing processes to accommodate special applications

• For wood or custom hollow metal doors

• Lever and rose both sides joined by two through-bolts

• Dummy latch plate

• Uses standard door prep template

Finishes Come In: 26D,03, 04,10, 10B, 26

Levers Come In: L, B & P

Strength, Durability and Security

• Cycle Test: Exceeds 5 times A156.2 Grade 1 requirements
• Abusive Locked Lever Torque- without entry gained: Exceeds 1.5 times A156.2 Grade 1 requirements
• 7 YEAR LIMITED WARRANTY - no service required to maintain warranty

Convenience

• Installs in 1 minute or less
• Quickly adapts to fit multiple through-bolt positions
• User friendly packaging
• User friendly instruction sheets
• Convenient installation diagram on box

Design

• Solid feel and precise lever action
• Slim rose design available
• Decorative Levers — Coastal Series designs – Gulfport and Yarmouth
• Levers are solid one piece cast construction, except “J” lever

Security

• Torx® and spanner screws optional
• Classroom security and multiple locking functions are available
• Vandal resistant, Free Wheeling (FW) trim optional (not available with 70 or 71 functions)
• Security key systems available (Signaturem Keso, BR-XC, XC)

Certification Compliance

• Certified ANSI A156.2 Series 4000-Grade 1
• UL listed to USA and Canadian safety standards. Listed for 3 hour doors (double doors require 41-option)                                                                                     Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
• Positive Pressure: Meets UL 10C and UBC 7-2 (1997)
• All levers conform to ADA requirement for barrier-free accessibility
• Levers (L,J & P) conform to California Administrative Code Title 19 and 24
• All individual components of a total door opening are required to comply with each code (Hurricane code)
• Conforms to national & state fire and handicapped requirements

Flexibility

• Fits a variety of door preparations with adaptable through-bolt positioning
• Accommodates retrofit applications with optional 2-3/8", 3-3/4", and 5" backset latches
• 6 ADA lever styles to complement a wide array of design applications
• Levers (B, L, J & P) are non-handed for efficient warehousing and for ease of installation
• 11 Architectural grade finishes
• 21 Functions
• SARGENT uses engineered solutions and flexible manufacturing processes to accommodate special applications

Features

• Meets and exceeds ANSI/BHMA 156.4 Grade 1 Requirements
• UL and UL 10C Listed                                                                                                   Note: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Sargent Manufacturing Company makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
• Complies with ADA requirements and ANSI 111.7 and exterior doors
• Adjustable closing force from size 1-6
• High impact full plastic cover secured by machine screws
• One-piece high strength aluminum alloy body
• 1-1/4” diameter piston for enhanced control
• 7/16” Square arm engagement for enhanced torque transmission
• Heat treated rack and pinion assembly
• Speed control valves- Separate latching, closing and sweep speed, captivated valves are easily adjusted using a standard 1/8" Allen Wrench
• Arms and accessories are powder coated
• 10 year limited warranty, body is date coded

Flexibility

• Retrofits a Dor-O-Matic SC 80 and Dorma 8600
• Both machine and self-tapping screws provided
• Universal body is interchangeable for all applications (standard, top jamb & parallel)
• Designed for aluminum store front doors and frames
• Similar design style to complement the Heavy Duty Powerglide Series
• Allows door to open a full 180° (trim permitting)

Innovation

• SARGENT's revolutionaryMicroShield®available. This antimicrobial silver-based finish coating permanently suppresses the growth of bacteria, algae, fungus, mold, and mildew. EPA and NSF approved and FDA listed

Convenience

• Non-handed closer
• All weather hydraulic fluid
• Easily installed in minutes!
• Easy-to-use instructions
• Full size paper templates
• Mortise nuts available when door condition requires through boltingTri Pack or "Universal Packed" - JUO or JUH (Hold Open). Packages include one extra bracket that gives the installer a choice for installation from Standard, Parallel or Top Jamb applications.
• When Tri-Pack is not required, specific application can be ordered.
