Sensors & Switches
BEA 10TD433HH1 433 MHz digital handheld transmitter, 1 button control receiver
BEA 10BOX475SQSM
Mount box, 4.75 In. square, surface mount
BEA 10BOXJAMBSM
Mount box, 1.5 In. by 4.75 In. surface mount, use with transmitter
BEA 10FLYKITB Motion Sensor
Passive infrared sensor, field adjustable detection zone, 0 to 180 degree mounting angle, 12 to 24 V AC/DC
BEA 10R2E-100 Motion Sensor
Infrared motion sensor, 20 to 48 In. detection range, optional alarm, 12 to 24 V AC/DC
BEA 10ACPBSS1 Pushbutton
Access Control Push Button, 2 In. by 4 In. Illuminated green button, "Push to Exit", Momentary switch, No delay, 10 AMP at 125/250 V AC
Touchless Wall Switch – width: 2-3/4″ (single), 4-1/2″ (double)
Exit Motion Sensor, White, use with EEB3N or EEB3
The XMS Passive Infrared Request to Exit Device is a motion detector specifically designed to reliably release magnetic locks. A person approaching the door is "seen" by the motion detector just before reaching the door.
Product Features
- Passive Infrared Request to Exit Device
- Designed to reliably release magnetic locks
- Automatically cuts power to the lock, allowing the individual to exit without even realizing that the door is secured
- Request to Exit (REX) output
- Easily adjustable beam pattern
- Adjustable time relock
- UL Listed
- MagnaCare® lifetime replacement, no fault warranty
Specification Data
- Input Voltage: 12 or 24VDC
- Power Draw: 20-50mA, depending on switching status
- Environment: Indoor use only
- Shipping Weight: 0.5 lbs.
Models
| Part # | Description |
| XMS | Exit Motion Sensor |
Safety Notice: Securitron recommends that an emergency exit button be used in conjunction with the XMS to meet applicable building codes and specific life safety issues.
- UL/cUL ALVY.BP7041
- CSFM 3774-0923:0103
- ANSI/UL 294 Listed
- UL Certificate of Compliance (CoC)
- Underwriter's Laboratories: File BP7041 (UL 294)
No Touch Switch, Dual Color LED
The NTS No Touch Request to Exit Station uses infrared sensors to reliably allow safe egress or to activate a device with the simple hand presentation. Designed to reduce the risk of contamination for sensitive applications including: bathrooms, hospitals, labs, schools and offices.
Features
Standard:
- Stainless steel with vandal resistant face plate
- Sensor detection range up to 4"
- Bi-color Halo LED status indicators
- Plate screened "Wave To Open"
- Time delay settable for 1 to 35 seconds
Options:
- NTS-1 with single gang wall plate
- NTS-2 with double gang wall plate
- NTS-3 with narrow stile wall plate
Specifications
Electrical:
- SPDT relay rated 2A at 30 VDC/VAC
- Operates on 12VDC or 24 VDC
Operating Temperature:
- -13 to + 131 F (-25 to 55 C)
910TC Series 12/24 VDC Touchless Actuators, Waving Hand Icon, Black Finish
- Aesthetically pleasing designs.
- Hands-free – helps reduce the spread of germs and bacteria.
- Adjustable detection zone to reduce unwanted activations.
- When the device is activated, the indicator light (waving hand) will change color.
- Secondary Normally Open (NO) mechanical switch in the event of a power loss.
- Selectable unlock times (1-63 seconds).
- Mounts on single-gang electrical box.
- Available remote control to trigger switch remotely.
- May be purchased as a kit (910TC-WRM-WRB). Includes 910TC Switch, 910TCWRM Remote Receiver Module and 910TC-WRB Remote Transmitter.
- Meets ADA compliance to ANSI/BHMA A156.19
(Always check local building codes for compliance in your area)
| Technical Specs | |
| Operating Voltages | 12/24 VDC |
| Relay Action | Momentary |
| Relay Type | SPDT |
| Sensor Technology | Capacitive |
| Range | 1" to 2" |
| Mounting Plate Size | 1 Gang |
| Environment | Indoor |
| Product Type | Touchless Actuators |
Microwave Touchless Actuator, Detection Range From 4 to 24" (Adjustable), Wave to Open Text & Logo
EAGLE Family Motion Sensor for Automatic Doors, 0 to 90 Degree Mounting Angle, 10 to 16' Mounting Height, 12 to 24 V AC/DC
EAGLE Family Motion Sensor for Automatic Doors, 0 to 90 Degree Mounting Angle, 6 to 13' Mounting Height, 12 to 24 V AC/DC
FALCON Motion Sensor, 11.5' to 23' Mounting Height, 33' of Cable, Multiple Detection Options, 12 to 24 V AC/DC
FALCON Motion Sensor, 6.5' to 11.5' Mounting Height, 33' of Cable, Multiple Detection Options, 12 to 24 V AC/DC
FALCON Motion Sensor, 6.5' to 11.5' Mounting Height, 33' of Cable, Multiple Detection Options, 12 to 24 V AC/DC
This versatile sensor can be surface mounted above any door, as well as the ceiling or wall. The flexibility and low profile design make it an effective sensor for managing building security and traffic flow.
- 12/24 VDC
- Compact, aesthetically pleasing design
- Includes ceiling and surface mount adapters
- Operating temp: -22 degrees F to 140 degrees F
- Passive Infrared Sensor (PIR)
