Falcon D121 Single Cylinder x Rose Grade 1 Deadbolt - Barzel Lock - Barzellock.com

Falcon D121 Single Cylinder x Rose Grade 1 Deadbolt - US Lock Supply

$ 78.00
Falcon D121 Single Cylinder x Rose Grade 1 Deadbolt - Barzel Lock - Barzellock.com

Falcon D121 Single Cylinder x Rose Grade 1 Deadbolt - US Lock Supply

by Falcon
$ 78.00
Falcon D121 Single Cylinder x Rose Deadbolt. The D Series deadbolt from Falcon will fit on virtually any door, thanks to an adjustable backset with an innovative lock-in-place design. The Grade 1 D100 Series deadbolt can be fitted with any cylinder, enhancing lock strength on the jamb side of the door and is easier to install than any deadbolt you've ever worked with.
 Falcon D121 Single Cylinder x Rose Deadbolt:
  • Deadbolt thrown or retracted by key only.
  • Blank plate inside. Bolt automatically deadlocks when fully thrown
Features and Benefits
  • Integrated anti-pry shield behind cylinder assembly for added security and quicker installation
  • Integrated trim design – fewer pieces out of the box and improved installation time
  • Tapered front resists wrenching
  • Accepts small format interchangable style cores (SFIC) and conventional cylinders
  • Adjustable backset with lock-in-place design for greater versatility
  • Latch tube construction
  • Heavy duty saw-resistant bolt with spinning hardened steel pin inside for additional protection
  • ADA compliant thumbturn

Specifications
Door Thickness: 1 3/8” to 1 3/4”. Up to 2 1/4” door thickness also available.
Backsets: 2 3/8” to 2 3/4” adjustable deadbolt.
Attachment: Locks are solidly attached to the door by 1/4” heat-treated steel bolts. These bolts pass through a steel plate (D111, D121 and D141) or the inner cylinder housing (D131) and thread directly into the back of the outer cylinder housing.
A permanent cap is inserted over the inside cylinder (D131) making the bolts nearly impossible to remove.
Handing: Non-handed. May be used on right hand or left hand doors swinging in or out.
Cylinders: Furnished with solid brass plug and housing, drilled with 6-pin chambers, pinned in 5 unless otherwise specified. Also available with 7-pin cylinders. Available with 6 or 7-pin interchangeable cores. Furnished with two (2) nickel silver keys standard.
Keyways: “G” keyway standard on conventional cylinders. “A” keyway standard on I/C core cylinders. Also available with some optional keyways.
Exposed Trim: Wrought brass or bronze reinforced with steel insert.
Deadbolts: Deadbolt locks are furnished with deadbolts which have a full 1” projection. Housed within the deadbolt is a freeturning, 1/4” thick, hardened steel, saw-resistant roller. Furnished standard with 2 3/8” to 2 3/4” adjustable backset and 1 1/8” x 2 1/4” faceplate. Optional 1” x 2 1/4” faceplate. Consult Options and Accessories section for other optional faceplates. D100 bolt is high strength steel.
Strikes: 2 3/4” x 1 1/8” lipless strike standard. ANSI 4 7/8” x 1 1/4” lipless, 2 1/4” full lip strikes, a 2 3/4” x 1 1/8” T-strike or a security strike are available. Consult Options and Accessories section.
Screws: Furnished with wood/machine screws for use on wood or metal doors or frames.
ANSI/BHMA Standard: A156.5, 2001, Grade 1. UL Listed, A label, 3 hour.

Falcon D131 Double Cylinder Grade 1 Deadbolt - Barzel Lock - Barzellock.com

Falcon D131 Double Cylinder Grade 1 Deadbolt - US Lock Supply

$ 99.00
Falcon D131 Double Cylinder Grade 1 Deadbolt - Barzel Lock - Barzellock.com

Falcon D131 Double Cylinder Grade 1 Deadbolt - US Lock Supply

by Falcon
$ 99.00
Falcon D131 Double Cylinder Deadbolt. The D Series deadbolt from Falcon will fit on virtually any door, thanks to an adjustable backset with an innovative lock-in-place design. The Grade 1 D100 Series deadbolt can be fitted with any cylinder, enhancing lock strength on the jamb side of the door and is easier to install than any deadbolt you've ever worked with.
 Falcon D131 Double Cylinder Deadbolt:
  • Deadbolt thrown or retracted by key from either side.
  • Deadbolt thrown or retracted by key from either side. Bolt automatically deadlocks when fully thrown.
Features and Benefits
  • Integrated anti-pry shield behind cylinder assembly for added security and quicker installation
  • Integrated trim design – fewer pieces out of the box and improved installation time
  • Tapered front resists wrenching
  • Accepts small format interchangable style cores (SFIC) and conventional cylinders
  • Adjustable backset with lock-in-place design for greater versatility
  • Latch tube construction
  • Heavy duty saw-resistant bolt with spinning hardened steel pin inside for additional protection
  • ADA compliant thumbturn

Specifications
Door Thickness: 1 3/8” to 1 3/4”. Up to 2 1/4” door thickness also available.
Backsets: 2 3/8” to 2 3/4” adjustable deadbolt.
Attachment: Locks are solidly attached to the door by 1/4” heat-treated steel bolts. These bolts pass through a steel plate (D111, D121 and D141) or the inner cylinder housing (D131) and thread directly into the back of the outer cylinder housing.
A permanent cap is inserted over the inside cylinder (D131) making the bolts nearly impossible to remove.
Handing: Non-handed. May be used on right hand or left hand doors swinging in or out.
Cylinders: Furnished with solid brass plug and housing, drilled with 6-pin chambers, pinned in 5 unless otherwise specified. Also available with 7-pin cylinders. Available with 6 or 7-pin interchangeable cores. Furnished with two (2) nickel silver keys standard.
Keyways: “G” keyway standard on conventional cylinders. “A” keyway standard on I/C core cylinders. Also available with some optional keyways.
Exposed Trim: Wrought brass or bronze reinforced with steel insert.
Deadbolts: Deadbolt locks are furnished with deadbolts which have a full 1” projection. Housed within the deadbolt is a freeturning, 1/4” thick, hardened steel, saw-resistant roller. Furnished standard with 2 3/8” to 2 3/4” adjustable backset and 1 1/8” x 2 1/4” faceplate. Optional 1” x 2 1/4” faceplate. Consult Options and Accessories section for other optional faceplates. D100 bolt is high strength steel.
Strikes: 2 3/4” x 1 1/8” lipless strike standard. ANSI 4 7/8” x 1 1/4” lipless, 2 1/4” full lip strikes, a 2 3/4” x 1 1/8” T-strike or a security strike are available. Consult Options and Accessories section.
Screws: Furnished with wood/machine screws for use on wood or metal doors or frames.
ANSI/BHMA Standard: A156.5, 2001, Grade 1. UL Listed, A label, 3 hour.

Falcon D141 Single Cylinder x Thumbturn Grade 1 Deadbolt - Barzel Lock - Barzellock.com

Falcon D141 Single Cylinder x Thumbturn Grade 1 Deadbolt - US Lock Supply

$ 78.00
Falcon D141 Single Cylinder x Thumbturn Grade 1 Deadbolt - Barzel Lock - Barzellock.com

Falcon D141 Single Cylinder x Thumbturn Grade 1 Deadbolt - US Lock Supply

by Falcon
$ 78.00
Falcon D141 Single Cylinder x Thumbturn Deadbolt. The D Series deadbolt from Falcon will fit on virtually any door, thanks to an adjustable backset with an innovative lock-in-place design. The Grade 1 D100 Series deadbolt can be fitted with any cylinder, enhancing lock strength on the jamb side of the door and is easier to install than any deadbolt you've ever worked with.
 Falcon D141 Single Cylinder x Thumbturn Deadbolt:
  • Deadbolt thrown or retracted by key from outside.
  • Deadbolt thrown or retracted by turn. Bolt automatically deadlocks when fully thrown.
Features and Benefits
  • Integrated anti-pry shield behind cylinder assembly for added security and quicker installation
  • Integrated trim design – fewer pieces out of the box and improved installation time
  • Tapered front resists wrenching
  • Accepts small format interchangable style cores (SFIC) and conventional cylinders
  • Adjustable backset with lock-in-place design for greater versatility
  • Latch tube construction
  • Heavy duty saw-resistant bolt with spinning hardened steel pin inside for additional protection
  • ADA compliant thumbturn

Specifications
Door Thickness: 1 3/8” to 1 3/4”. Up to 2 1/4” door thickness also available.
Backsets: 2 3/8” to 2 3/4” adjustable deadbolt.
Attachment: Locks are solidly attached to the door by 1/4” heat-treated steel bolts. These bolts pass through a steel plate (D111, D121 and D141) or the inner cylinder housing (D131) and thread directly into the back of the outer cylinder housing.
A permanent cap is inserted over the inside cylinder (D131) making the bolts nearly impossible to remove.
Handing: Non-handed. May be used on right hand or left hand doors swinging in or out.
Cylinders: Furnished with solid brass plug and housing, drilled with 6-pin chambers, pinned in 5 unless otherwise specified. Also available with 7-pin cylinders. Available with 6 or 7-pin interchangeable cores. Furnished with two (2) nickel silver keys standard.
Keyways: “G” keyway standard on conventional cylinders. “A” keyway standard on I/C core cylinders. Also available with some optional keyways.
Exposed Trim: Wrought brass or bronze reinforced with steel insert.
Deadbolts: Deadbolt locks are furnished with deadbolts which have a full 1” projection. Housed within the deadbolt is a freeturning, 1/4” thick, hardened steel, saw-resistant roller. Furnished standard with 2 3/8” to 2 3/4” adjustable backset and 1 1/8” x 2 1/4” faceplate. Optional 1” x 2 1/4” faceplate. Consult Options and Accessories section for other optional faceplates. D100 bolt is high strength steel.
Strikes: 2 3/4” x 1 1/8” lipless strike standard. ANSI 4 7/8” x 1 1/4” lipless, 2 1/4” full lip strikes, a 2 3/4” x 1 1/8” T-strike or a security strike are available. Consult Options and Accessories section.
Screws: Furnished with wood/machine screws for use on wood or metal doors or frames.
ANSI/BHMA Standard: A156.5, 2001, Grade 1. UL Listed, A label, 3 hour.

Falcon D211 Classroom Grade 2 Deadbolt - Barzel Lock - Barzellock.com

Falcon D211 Classroom Grade 2 Deadbolt - US Lock Supply

$ 61.00
Falcon D211 Classroom Grade 2 Deadbolt - Barzel Lock - Barzellock.com

Falcon D211 Classroom Grade 2 Deadbolt - US Lock Supply

by Falcon
$ 61.00
Falcon D211 Classroom Deadbolt. The D Series deadbolt from Falcon will fit on virtually any door, thanks to an adjustable backset with an innovative lock-in-place design. The Grade 2 D200 Series deadbolt can be fitted with any cylinder, enhancing lock strength on the jamb side of the door and is easier to install than any deadbolt you've ever worked with.
 Falcon D211 Classroom Deadbolt:
  • Deadbolt thrown or retracted by key from outside.
  • Inside turn will only retract bolt. Bolt automatically deadlocks when fully thrown.
Features and Benefits
  • Integrated anti-pry shield behind cylinder assembly for added security and quicker installation
  • Integrated trim design – fewer pieces out of the box and improved installation time
  • Tapered front resists wrenching
  • Accepts small format interchangable style cores (SFIC) and conventional cylinders
  • Adjustable backset with lock-in-place design for greater versatility
  • Latch tube construction
  • Heavy duty saw-resistant bolt with spinning hardened steel pin inside for additional protection
  • ADA compliant thumbturn

Specifications
Door Thickness: 1 3/8” to 1 7/8”. For thicker doors, available up to 2 1/4”.
Backsets: 2 3/8” to 2 3/4” adjustable deadbolt.
Attachment: Locks are solidly attached to the door by 1/4” heat-treated steel bolts. These bolts pass through a steel plate (D211, D221 and D241) or the inner cylinder housing (D231) and thread directly into the back of the outer cylinder housing.
Handing: Non-handed. May be used in right hand or left hand doors swinging in or out.
Cylinders: Furnished with solid brass plug and housing, drilled with 6-pin chambers, pinned in 5 unless otherwise specified. Available with 6 or 7-pin interchangeable cores. Furnished with two (2) nickel silver keys standard.
Keyways: “G” keyway standard on conventional cylinders. “A” keyway standard on I/C core cylinders. Also available with some optional keyways.
Exposed Trim: Wrought brass or bronze reinforced with steel insert.
Deadbolts: Deadbolt locks are furnished with deadbolts which have a full 1” projection. Housed within the deadbolt is a freeturning, 1/4” thick, hardened steel, saw-resistant roller. Furnished standard with 2 3/8” to 2 3/4” adjustable backset and 1 1/8” x 2 1/4” faceplate. Optional 1” x 2 1/4” faceplate. Consult Options and Accessories section for other optional faceplates. D200 bolt is cast zinc.
Strikes: 2 3/4” x 1 1/8” lipless standard. ANSI 4 7/8” x 1 1/4” lipless, 2 1/4” full lip strikes, a 2 3/4” x 1 1/8” T-strike or a security strike are available. Consult Options and Accessories section.
Screws: Furnished with wood/machine screws for use on wood or metal doors or frames.
ANSI/BHMA Standard: A156.5, 2001, Grade 2. UL Listed, A label, 3 hour.

http://us.allegion.com/IRSTDocs/Catalog/106196.pdf

Falcon D221 Single Cylinder x Rose Grade 2 Deadbolt - Barzel Lock - Barzellock.com

Falcon D221 Single Cylinder x Rose Grade 2 Deadbolt - US Lock Supply

$ 58.00
Falcon D221 Single Cylinder x Rose Grade 2 Deadbolt - Barzel Lock - Barzellock.com

Falcon D221 Single Cylinder x Rose Grade 2 Deadbolt - US Lock Supply

by Falcon
$ 58.00
Falcon D221 Single Cylinder x Rose Deadbolt. The D Series deadbolt from Falcon will fit on virtually any door, thanks to an adjustable backset with an innovative lock-in-place design. The Grade 2 D200 Series deadbolt can be fitted with any cylinder, enhancing lock strength on the jamb side of the door and is easier to install than any deadbolt you've ever worked with.
 Falcon D221 Single Cylinder x Rose Deadbolt:
  • Deadbolt thrown or retracted by key only.
  • Blank rose inside. Bolt automatically deadlocks when fully thrown.
Features and Benefits
  • Integrated anti-pry shield behind cylinder assembly for added security and quicker installation
  • Integrated trim design – fewer pieces out of the box and improved installation time
  • Tapered front resists wrenching
  • Accepts small format interchangable style cores (SFIC) and conventional cylinders
  • Adjustable backset with lock-in-place design for greater versatility
  • Latch tube construction
  • Heavy duty saw-resistant bolt with spinning hardened steel pin inside for additional protection
  • ADA compliant thumbturn

Specifications
Door Thickness: 1 3/8” to 1 7/8”. For thicker doors, available up to 2 1/4”.
Backsets: 2 3/8” to 2 3/4” adjustable deadbolt.
Attachment: Locks are solidly attached to the door by 1/4” heat-treated steel bolts. These bolts pass through a steel plate (D211, D221 and D241) or the inner cylinder housing (D231) and thread directly into the back of the outer cylinder housing.
Handing: Non-handed. May be used in right hand or left hand doors swinging in or out.
Cylinders: Furnished with solid brass plug and housing, drilled with 6-pin chambers, pinned in 5 unless otherwise specified. Available with 6 or 7-pin interchangeable cores. Furnished with two (2) nickel silver keys standard.
Keyways: “G” keyway standard on conventional cylinders. “A” keyway standard on I/C core cylinders. Also available with some optional keyways.
Exposed Trim: Wrought brass or bronze reinforced with steel insert.
Deadbolts: Deadbolt locks are furnished with deadbolts which have a full 1” projection. Housed within the deadbolt is a freeturning, 1/4” thick, hardened steel, saw-resistant roller. Furnished standard with 2 3/8” to 2 3/4” adjustable backset and 1 1/8” x 2 1/4” faceplate. Optional 1” x 2 1/4” faceplate. Consult Options and Accessories section for other optional faceplates. D200 bolt is cast zinc.
Strikes: 2 3/4” x 1 1/8” lipless standard. ANSI 4 7/8” x 1 1/4” lipless, 2 1/4” full lip strikes, a 2 3/4” x 1 1/8” T-strike or a security strike are available. Consult Options and Accessories section.
Screws: Furnished with wood/machine screws for use on wood or metal doors or frames.
ANSI/BHMA Standard: A156.5, 2001, Grade 2. UL Listed, A label, 3 hour.

http://us.allegion.com/IRSTDocs/Catalog/106196.pdf

Falcon D231 Double Cylinder Grade 2 Deadbolt - Barzel Lock - Barzellock.com

Falcon D231 Double Cylinder Grade 2 Deadbolt - US Lock Supply

$ 75.00
Falcon D231 Double Cylinder Grade 2 Deadbolt - Barzel Lock - Barzellock.com

Falcon D231 Double Cylinder Grade 2 Deadbolt - US Lock Supply

by Falcon
$ 75.00
Falcon D231 Double Cylinder Deadbolt. The D Series deadbolt from Falcon will fit on virtually any door, thanks to an adjustable backset with an innovative lock-in-place design. The Grade 2 D200 Series deadbolt can be fitted with any cylinder, enhancing lock strength on the jamb side of the door and is easier to install than any deadbolt you've ever worked with.
 Falcon D231 Double Cylinder Deadbolt:
  • Deadbolt thrown or retracted by key from either side.
  • Deadbolt thrown or retracted by key from either side. Bolt automatically deadlocks when fully thrown.
Features and Benefits
  • Integrated anti-pry shield behind cylinder assembly for added security and quicker installation
  • Integrated trim design – fewer pieces out of the box and improved installation time
  • Tapered front resists wrenching
  • Accepts small format interchangable style cores (SFIC) and conventional cylinders
  • Adjustable backset with lock-in-place design for greater versatility
  • Latch tube construction
  • Heavy duty saw-resistant bolt with spinning hardened steel pin inside for additional protection
  • ADA compliant thumbturn

Specifications
Door Thickness: 1 3/8” to 1 7/8”. For thicker doors, available up to 2 1/4”.
Backsets: 2 3/8” to 2 3/4” adjustable deadbolt.
Attachment: Locks are solidly attached to the door by 1/4” heat-treated steel bolts. These bolts pass through a steel plate (D211, D221 and D241) or the inner cylinder housing (D231) and thread directly into the back of the outer cylinder housing.
Handing: Non-handed. May be used in right hand or left hand doors swinging in or out.
Cylinders: Furnished with solid brass plug and housing, drilled with 6-pin chambers, pinned in 5 unless otherwise specified. Available with 6 or 7-pin interchangeable cores. Furnished with two (2) nickel silver keys standard.
Keyways: “G” keyway standard on conventional cylinders. “A” keyway standard on I/C core cylinders. Also available with some optional keyways.
Exposed Trim: Wrought brass or bronze reinforced with steel insert.
Deadbolts: Deadbolt locks are furnished with deadbolts which have a full 1” projection. Housed within the deadbolt is a freeturning, 1/4” thick, hardened steel, saw-resistant roller. Furnished standard with 2 3/8” to 2 3/4” adjustable backset and 1 1/8” x 2 1/4” faceplate. Optional 1” x 2 1/4” faceplate. Consult Options and Accessories section for other optional faceplates. D200 bolt is cast zinc.
Strikes: 2 3/4” x 1 1/8” lipless standard. ANSI 4 7/8” x 1 1/4” lipless, 2 1/4” full lip strikes, a 2 3/4” x 1 1/8” T-strike or a security strike are available. Consult Options and Accessories section.
Screws: Furnished with wood/machine screws for use on wood or metal doors or frames.
ANSI/BHMA Standard: A156.5, 2001, Grade 2. UL Listed, A label, 3 hour.

http://us.allegion.com/IRSTDocs/Catalog/106196.pdf

Falcon D241 Single Cylinder x Thumbturn Grade 2 Deadbolt - Barzel Lock - Barzellock.com

Falcon D241 Single Cylinder x Thumbturn Grade 2 Deadbolt - US Lock Supply

$ 58.00
Falcon D241 Single Cylinder x Thumbturn Grade 2 Deadbolt - Barzel Lock - Barzellock.com

Falcon D241 Single Cylinder x Thumbturn Grade 2 Deadbolt - US Lock Supply

by Falcon
$ 58.00
Falcon D241 Single Cylinder x Thumbturn Deadbolt. The D Series deadbolt from Falcon will fit on virtually any door, thanks to an adjustable backset with an innovative lock-in-place design. The Grade 2 D200 Series deadbolt can be fitted with any cylinder, enhancing lock strength on the jamb side of the door and is easier to install than any deadbolt you've ever worked with.
 Falcon D241 Single Cylinder x Thumbturn Deadbolt:
  • Deadbolt thrown or retracted by key or by turn. Bolt automatically deadlocks when fully thrown.
  • Deadbolt thrown or retracted by turn unit only. Bolt automatically deadlocks when fully thrown.
Features and Benefits
  • Integrated anti-pry shield behind cylinder assembly for added security and quicker installation
  • Integrated trim design – fewer pieces out of the box and improved installation time
  • Tapered front resists wrenching
  • Accepts small format interchangable style cores (SFIC) and conventional cylinders
  • Adjustable backset with lock-in-place design for greater versatility
  • Latch tube construction
  • Heavy duty saw-resistant bolt with spinning hardened steel pin inside for additional protection
  • ADA compliant thumbturn

Specifications
Door Thickness: 1 3/8” to 1 7/8”. For thicker doors, available up to 2 1/4”.
Backsets: 2 3/8” to 2 3/4” adjustable deadbolt.
Attachment: Locks are solidly attached to the door by 1/4” heat-treated steel bolts. These bolts pass through a steel plate (D211, D221 and D241) or the inner cylinder housing (D231) and thread directly into the back of the outer cylinder housing.
Handing: Non-handed. May be used in right hand or left hand doors swinging in or out.
Cylinders: Furnished with solid brass plug and housing, drilled with 6-pin chambers, pinned in 5 unless otherwise specified. Available with 6 or 7-pin interchangeable cores. Furnished with two (2) nickel silver keys standard.
Keyways: “G” keyway standard on conventional cylinders. “A” keyway standard on I/C core cylinders. Also available with some optional keyways.
Exposed Trim: Wrought brass or bronze reinforced with steel insert.
Deadbolts: Deadbolt locks are furnished with deadbolts which have a full 1” projection. Housed within the deadbolt is a freeturning, 1/4” thick, hardened steel, saw-resistant roller. Furnished standard with 2 3/8” to 2 3/4” adjustable backset and 1 1/8” x 2 1/4” faceplate. Optional 1” x 2 1/4” faceplate. Consult Options and Accessories section for other optional faceplates. D200 bolt is cast zinc.
Strikes: 2 3/4” x 1 1/8” lipless standard. ANSI 4 7/8” x 1 1/4” lipless, 2 1/4” full lip strikes, a 2 3/4” x 1 1/8” T-strike or a security strike are available. Consult Options and Accessories section.
Screws: Furnished with wood/machine screws for use on wood or metal doors or frames.
ANSI/BHMA Standard: A156.5, 2001, Grade 2. UL Listed, A label, 3 hour.

http://us.allegion.com/IRSTDocs/Catalog/106196.pdf

Falcon D261 Thumbturn Inside Only Grade 2 Deadbolt - Barzel Lock - Barzellock.com

Falcon D261 Thumbturn Inside Only Grade 2 Deadbolt - US Lock Supply

$ 45.00
Falcon D261 Thumbturn Inside Only Grade 2 Deadbolt - Barzel Lock - Barzellock.com

Falcon D261 Thumbturn Inside Only Grade 2 Deadbolt - US Lock Supply

by Falcon
$ 45.00
Falcon D261 Thumbturn Inside Only Deadbolt. The D Series deadbolt from Falcon will fit on virtually any door, thanks to an adjustable backset with an innovative lock-in-place design. The Grade 2 D200 Series deadbolt can be fitted with any cylinder, enhancing lock strength on the jamb side of the door and is easier to install than any deadbolt you've ever worked with.
 Falcon D261 Thumbturn, Inside Only Deadbolt:
  • No outside trim.
  • Deadbolt thrown or retracted by turn unit only. Bolt automatically deadlocks when fully thrown.
Features and Benefits
  • Integrated anti-pry shield behind cylinder assembly for added security and quicker installation
  • Integrated trim design – fewer pieces out of the box and improved installation time
  • Tapered front resists wrenching
  • Accepts small format interchangable style cores (SFIC) and conventional cylinders
  • Adjustable backset with lock-in-place design for greater versatility
  • Latch tube construction
  • Heavy duty saw-resistant bolt with spinning hardened steel pin inside for additional protection
  • ADA compliant thumbturn

Specifications
Door Thickness: 1 3/8” to 1 7/8”. For thicker doors, available up to 2 1/4”.
Backsets: 2 3/8” to 2 3/4” adjustable deadbolt.
Attachment: Locks are solidly attached to the door by 1/4” heat-treated steel bolts. These bolts pass through a steel plate (D211, D221 and D241) or the inner cylinder housing (D231) and thread directly into the back of the outer cylinder housing.
Handing: Non-handed. May be used in right hand or left hand doors swinging in or out.
Cylinders: Furnished with solid brass plug and housing, drilled with 6-pin chambers, pinned in 5 unless otherwise specified. Available with 6 or 7-pin interchangeable cores. Furnished with two (2) nickel silver keys standard.
Keyways: “G” keyway standard on conventional cylinders. “A” keyway standard on I/C core cylinders. Also available with some optional keyways.
Exposed Trim: Wrought brass or bronze reinforced with steel insert.
Deadbolts: Deadbolt locks are furnished with deadbolts which have a full 1” projection. Housed within the deadbolt is a freeturning, 1/4” thick, hardened steel, saw-resistant roller. Furnished standard with 2 3/8” to 2 3/4” adjustable backset and 1 1/8” x 2 1/4” faceplate. Optional 1” x 2 1/4” faceplate. Consult Options and Accessories section for other optional faceplates. D200 bolt is cast zinc.
Strikes: 2 3/4” x 1 1/8” lipless standard. ANSI 4 7/8” x 1 1/4” lipless, 2 1/4” full lip strikes, a 2 3/4” x 1 1/8” T-strike or a security strike are available. Consult Options and Accessories section.
Screws: Furnished with wood/machine screws for use on wood or metal doors or frames.
ANSI/BHMA Standard: A156.5, 2001, Grade 2. UL Listed, A label, 3 hour.

http://us.allegion.com/IRSTDocs/Catalog/106196.pdf

Falcon D271 Thumbturn x Occupancy Indicator Grade 2 Deadbolt - Barzel Lock - Barzellock.com

Falcon D271 Thumbturn x Occupancy Indicator Grade 2 Deadbolt - US Lock Supply

$ 46.00
Falcon D271 Thumbturn x Occupancy Indicator Grade 2 Deadbolt - Barzel Lock - Barzellock.com

Falcon D271 Thumbturn x Occupancy Indicator Grade 2 Deadbolt - US Lock Supply

by Falcon
$ 46.00
Falcon D271 Thumbturn x Occupancy Indicator Deadbolt. The D Series deadbolt from Falcon will fit on virtually any door, thanks to an adjustable backset with an innovative lock-in-place design. The Grade 2 D200 Series deadbolt can be fitted with any cylinder, enhancing lock strength on the jamb side of the door and is easier to install than any deadbolt you've ever worked with.
 Falcon D271 Thumbturn x Occupancy Indicator Deadbolt:
  • Occupancy indicator on outside (reads either in use or vacant with color coding).
  • Deadbolt thrown or retracted by turn unit only. Bolt automatically deadlocks when fully thrown.
Features and Benefits
  • Integrated anti-pry shield behind cylinder assembly for added security and quicker installation
  • Integrated trim design – fewer pieces out of the box and improved installation time
  • Tapered front resists wrenching
  • Accepts small format interchangable style cores (SFIC) and conventional cylinders
  • Adjustable backset with lock-in-place design for greater versatility
  • Latch tube construction
  • Heavy duty saw-resistant bolt with spinning hardened steel pin inside for additional protection
  • ADA compliant thumbturn

Specifications
Door Thickness: 1 3/8” to 1 7/8”. For thicker doors, available up to 2 1/4”.
Backsets: 2 3/8” to 2 3/4” adjustable deadbolt.
Attachment: Locks are solidly attached to the door by 1/4” heat-treated steel bolts. These bolts pass through a steel plate (D211, D221 and D241) or the inner cylinder housing (D231) and thread directly into the back of the outer cylinder housing.
Handing: Non-handed. May be used in right hand or left hand doors swinging in or out.
Cylinders: Furnished with solid brass plug and housing, drilled with 6-pin chambers, pinned in 5 unless otherwise specified. Available with 6 or 7-pin interchangeable cores. Furnished with two (2) nickel silver keys standard.
Keyways: “G” keyway standard on conventional cylinders. “A” keyway standard on I/C core cylinders. Also available with some optional keyways.
Exposed Trim: Wrought brass or bronze reinforced with steel insert.
Deadbolts: Deadbolt locks are furnished with deadbolts which have a full 1” projection. Housed within the deadbolt is a freeturning, 1/4” thick, hardened steel, saw-resistant roller. Furnished standard with 2 3/8” to 2 3/4” adjustable backset and 1 1/8” x 2 1/4” faceplate. Optional 1” x 2 1/4” faceplate. Consult Options and Accessories section for other optional faceplates. D200 bolt is cast zinc.
Strikes: 2 3/4” x 1 1/8” lipless standard. ANSI 4 7/8” x 1 1/4” lipless, 2 1/4” full lip strikes, a 2 3/4” x 1 1/8” T-strike or a security strike are available. Consult Options and Accessories section.
Screws: Furnished with wood/machine screws for use on wood or metal doors or frames.
ANSI/BHMA Standard: A156.5, 2001, Grade 2. UL Listed, A label, 3 hour.

http://us.allegion.com/IRSTDocs/Catalog/106196.pdf

Falcon F-24-R Fire Rated Rim Touch Bar Exit Device - Barzellock.com

Falcon F-24-R Fire Rated Rim Touch Bar Exit Device

from $ 818.00
Falcon F-24-R Fire Rated Rim Touch Bar Exit Device - Barzellock.com

Falcon F-24-R Fire Rated Rim Touch Bar Exit Device

by Falcon
$ 818.00
Falcon F-24-R Fire Rated Rim Touch Bar Exit Device. Offices, banks, assisted living facilities, retail stores and other commercial buildings have constant traffic, so door hardware must be able to take continual use and abuse. The Falcon 24 Series exit devices fit the bill with some of the toughest, most reliable performance in the business. A host of features makes this a smart solution, like a choice of an A or B label fire rating, electrified and panic options, and a full complement of trims. Sleek, streamlined styling and narrow stile device applications means a smart solution for your building design, as well as its use. And since they’re backed by one of the best names in the business, you can be sure you’re getting the utmost value, reliability and durability.
Falcon F-24-R Catalog
Hand: Non-handed UL: “B” label (1 1 ⁄2 hr.); 4'0" x 8'0".
Functions F-24-REO (Exit only) has all functions built in. Order trim with the device, or add it later.
Finishes: US3 (605); US4 (606); US10 (612); US26 (625); US26D (626); US32 (629); US32D (630); US28 (628), 313AN. Contact Us At 212-677-7530 For Finishes That Are not In Our Finish Option.
Strikes: 299F strike standard.
Latchbolt: Stainless steel, 3⁄4" throw.
Deadlocking latchbolt: Standard.
Doors: 1 3⁄4" thick, wood or metal. Specify thickness if other than 1 3⁄4".
Projections: 2 3⁄4" maximum.
Mounting height: 40" from CL to finished floor.
Fasteners: All mounting screws are concealed. Furnished with all machine screws.
Sex bolts: Required when used with wood, composite or non-reinforced hollow metal doors. For EO device, specify 4 - 425 (#10-24) SNB and 2 - 325 (1 ⁄4"-20) SNB. For devices with trim, specify 4 - 425 (#10-24) SNB.
ANSI: Certified ANSI A156.3-2001 grade 1 standards.
Center case & working parts: Investment-cast ferrous alloy with heavy wrought and sintered metal parts

Features and Benefits
  • Streamlined design includes flush-end cap for clean lines and a more attractive installation
  • Stainless steel pushpad cover for a scratch-resistant surface
  • Clean design with no exposed screws or rivets on the back of the device
  • Patent-pending deadlocking technology ensures reliable security
  • One trim input design for maximum versatility
  • Extruded aluminum construction delivers greater strength and impact resistance
Falcon F-24-V Fire Rated Vertical EO Rod Exit Device - Barzellock.com

Falcon F-24-V Fire Rated Vertical EO Rod Exit Device

from $ 1,169.00
Falcon F-24-V Fire Rated Vertical EO Rod Exit Device - Barzellock.com

Falcon F-24-V Fire Rated Vertical EO Rod Exit Device

by Falcon
$ 1,169.00

Falcon F-24-Vertical EO Rod Exit Device. Panic exit hardware High-traffic applications demand the added strength and protection that comes with a vertical rod device. The Falcon 24-V Series delivers with a surface-applied design that includes standard top latch and deadlocking. The narrow stile and sleek touch bar design ensure an attractive installation.

Hand: Field reversible

Finishes: US3 (605); US4 (606); US10 (612); US26 (625); US26D (626); US32 (629); US32D (630); US28 (628), 313AN. Contact Us For Finishes Not In The Finish Options.

UL: “A” Label (3 hr) - double egress - 8' x 10'; 90 min. same egress - 8' x 10'. Wood door: 20 min. 8' x 10'; 90 min. 8' x 9'. Consult door manufacturer for maximum rating.

Strikes: 3788 top strike is surface applied, 2130 bottom strike is mortised into floor.

Angle Bracket: Use 4215 angle bracket in flush transom installations. Allow use of standard 3788 strike.

Latchbolt: Top stainless steel, top latch 3⁄4" throw, bottom bolt 1 ⁄2" throw.

Deadlocking latchbolt: Standard with top latch

Latch retention hold: Standard with top latch. On top latch.

Doors: 1 3⁄4" thick, wood or metal. Specify thickness if other than 1 3⁄4" thick.

Projections: 2 3⁄4" maximum, 2" dogged.

Stile: 1 3⁄4” minimum when used in pairs.

Fasteners: All mounting screws are concealed, sheet metal screws standard, machine screws available, specify AMS.

Sex bolts: Recommended when device is used with hollow core wood, composite or light gauge hollow metal doors. For EO device, specify 8 - 425 (#10-24) SNB and 2 - 325 (1 ⁄4"-20) SNB. For devices with trim, specify 8 - 425 (#10-24) SNB.

ANSI: Certified ANSI A156.3-2001 grade 1 standards

Vertical rods: Furnished to length based on a 40" horizontal CL from finished floor and a 7'0" door standard. Variations from these standards must be specified when ordering.



Falcon SC61 RW, HD, HW Door Closer SC60 Series - Barzellock.com

Falcon SC61 RW, HD, HW Door Closer SC60 Series

from $ 85.00
Falcon SC61 RW, HD, HW Door Closer SC60 Series - Barzellock.com

Falcon SC61 RW, HD, HW Door Closer SC60 Series

by Falcon
$ 85.00
US Lock Supply Stocks The Falcon SC61 Closer In All Finishes & Options Ready To Ship For Free On Orders Over $189.
The Falcon SC60 Series is a dependable closer for light to medium-duty application. Designed for interior use with an aluminum storefront, the SC60 Series offers ANSI Grade 1 durability backed by a ten-year warranty. Most common hole pattern in the industry for versatile use and easy retrofit.
 Surface mounted light duty closer that is easily installed and adjusted for your light to medium duty doors.
Finishes:
689-Aluminum
695-Dark Bronze
Arms:
RW/PA Regular Arm
HW/PA Hold Open With Regular Arm
HD/PA Heavy Duty With Parallel Arm
Specifications
  • Meets ANSI A117.1
  • ANSI/BHMA A156.4, Grade 1
  • UL Listed
  • 1 3/8" diameter piston
  • Closer mounts hinge side, top jamb or parallel arm when either the Rw/PA or Hw/PA arm is specified
  • Adjustable sizes 1-5 (SC61)
  • Single piece cast aluminum body
  • Staked valves
  • Non-handed for left or right swinging doors
  • Separate adjustable general speed, latch speed and backcheck
  • Heat-treated steel piston
  • Heat-treated pinion
  • UL 10C approved fluid
  • Universal screw pack
  • 10-year warranty

Certifications
The Falcon SC60 Series is UL approved and compliant with the UL 10C and UBC 7-2 (1997) fire test. Additionally, the SC61 is designed to meet the American Disabilities Act (ADA) and ANSI A117.1. The SC60 Series is ANSI/BHMA A156.4, Grade 1 certified.

Falcon SC71 Door Closer - Barzellock.com

Falcon SC71 Door Closer

from $ 167.00
Falcon SC71 Door Closer - Barzellock.com

Falcon SC71 Door Closer

by Falcon
$ 167.00
US Lock Supply Stocks The Falcon SC71 Closer In All Finishes & Options Ready To Ship For Free On Orders Over $189.
Falcon SC71 heavy duty closers are built for busy commercial doors that demand a strong reliable closer.
Falcon Door Control Catalog
Falcon SC71 Installation Instructions
Falcon SC71H Hold Open Installation Instructions
Finishes:
689-Aluminum
695-Dark Bronze
Arms:
RW/PA Regular Arm
HW/PA Hold Open With Regular Arm
HD/PA Heavy Duty With Parallel Arm
DS Dead Stop Arm
HW/DS Hold Open With Dead Stop Arm
SS Spring N Stop Arm

Similar Door Closers: Falcon SC61 | Falcon SC81
Specifications
  • Meets ANSI A117.1
  • ANSI/BHMA A 156.4, Grade 1
  • UL Listed
  • 1 1/2" diameter piston
  • Closer mounts hinge side, tob jamp or parallel arm when either the Rw/PA or Hw/PA arm is specified
  • Adjustable sizes 1-6
  • Single piece cast aluminum body
  • Non-handed for left or right swinging doors
  • Fast and easy installation
  • Separate adjustable general speed, latch speed and backcheck
  • Heat-treated forged steel piston
  • Double heat-treated pinion
  • Cover is high-impact UL Listed fire retardant plastic that meets UL 10C and UBC 7-2 (1997) fire test
  • UL 10C approved fluid
  • Universal screw pack
  • 10-year warranty

Certifications
The Falcon SC71 is UL approved and compliant with the UL 10C and UBC 7-2 (1997) fire test. Additionally, the SC71 is rated ANSI/BHMA A156.4, Grade 1 and designed to meet the American Disabilities Act (ADA) and ANSI A117.1.

Falcon SC81 Door Closer - Barzellock.com

Falcon SC81 Door Closer

from $ 107.00
Falcon SC81 Door Closer - Barzellock.com
Falcon SC81 Door Closer

Falcon SC81 Door Closer

by Falcon
$ 107.00
US Lock Supply Stocks The Falcon SC81 Closer In All Finishes & Options Ready To Ship For Free On Orders Over $189.
The Falcon SC81 is a medium duty door closer used on medium traffic doors in facilities like health care offices, schools, offices, hospitals & more.
Finishes:
689-Aluminum
695-Dark Bronze
Arms:
RW/PA Regular Arm
HW/PA Hold Open With Regular Arm
HD/PA Heavy Duty With Parallel Arm
DS Dead Stop Arm
Falcon SC81 Data Sheet
Falcon Door Closer Catalog
Falcon SC81 Installation Instructions
Similar Items: Falcon SC91 | Falcon SC71

Specifications
  • Meets ANSI A117.1
  • UL Listed
  • 1 1/4" diameter piston
  • Closer mounts hinge side, top jamb or parallel arm when either the Rw/PA or Hw/PA arm is specified
  • Adjustable sizes 1-6
  • Single piece cast aluminum body
  • Non-handed for left or right swinging doors
  • Separate adjustable general speed, latch speed and backcheck
  • Heat-treated steel piston
  • Heat-treated pinion
  • Cover is high-impact UL Listed fire retardant plastic that meets UL 10C and UBC 7-2 (1997) fire test
  • UL 228 listed
  • UL 10C approved fluid
  • Universal screw pack
  • 10-year warranty

Certifications
The Falcon SC81 is UL approved and compliant with UL 10C and UBC 7-2 (1997) fire test. Additionally, the SC81 is designed to meet the Americans with Disabilities Act (ADA) and ANSI A117.1.

Falcon SC91 Regular Arm, 689,695 Finish Door Closer SC90 Series - Barzellock.com

Falcon SC91 Regular Arm, 689,695 Finish Door Closer SC90 Series

$ 73.00
Falcon SC91 Regular Arm, 689,695 Finish Door Closer SC90 Series - Barzellock.com

Falcon SC91 Regular Arm, 689,695 Finish Door Closer SC90 Series

by Falcon
$ 73.00
US Lock Supply Stocks The Falcon SC91 Closer In All Finishes & Options Ready To Ship For Free On Orders Over $189.
Designed for light-duty interior applications the Falcon SC90 closer ensures smooth, reliable operation, while meeting ADA accessibility requirements. The SC90 is backed by a ten-year warranty and is preset for easy installation.
Finishes:
689-Aluminum
695-Dark Bronze

Specifications
  • Meets ANSI A117.1
  • ANSI/BHMA A156.4, Grade 3
  • UL Listed
  • Closer mounts hinge side, top jamb or parallel arm when either the Rw/PA or Hw/PA arm is specified.
  • Fixed sizes 1, 3, & 4
  • Single piece cast aluminum body
  • Non-handed for left or right swinging doors
  • Separate adjustable general speed and latch speed
  • Heat-treated  steel piston
  • Heat-treated pinion
  • UL 10C approved fluid
  • Universal screw pack
  • 10-year warranty
Listings and Certifications
The Falcon SC90 Series is UL approved and compliant with the UL 10C and UBC 7-2 (1997) fire test. Additionally, the SC90 Series is designed to meet the American Disabilities Act (ADA) and ANSI A117.1. The SC90 Series is ANSI/BHMA A156.4, Grade 3 certified.
Regular Arm, SC90-3011PA Non-handed arm with adjustable forearm assembly to accommodate a range of doors and frame reveal conditions. Mounts hinge side, top jamb or parallel arm. PA shoe included to allow installation in a parallel arm configuration.
Falcon T101 Passage/Closet Lever Lock - Barzellock.com

Falcon T101 Passage/Closet Lever Lock

$ 187.00
Falcon T101 Passage/Closet Lever Lock - Barzellock.com

Falcon T101 Passage/Closet Lever Lock

by Falcon
$ 187.00
Simply put, the Falcon T-Series lock is the most versatile lockset in the industry. This extra heavy duty lock can accept any manufacturer’s cylinder, and the cylinder can easily be removed for quick, easy re-keying. Redesigned with a compression spring behind the cylinder, the T-Series is now stronger than ever and lever sag has been virtually eliminated. This adaptable lock is well suited to either new construction or retrofit use in buildings as varied as multi-family, retail, institutional and government/military.

Passage/closet latchset—Latch bolt by levers at all times.

Features and Benefits
Key-in-lever cylindrical locksets shall be Falcon Lock T Series or equal and meet the following requirements:
• All locks shall meet the new ANSI/BHMA A156.2, Series 4000,Grade 1 for key-in-lever locksets.
• Locksets shall be UL Listed (3 hour A Label).
• Locksets shall be provided standard with Pressure Release™feature. When outside lever is locked, it is not rigid but will move freely without operating the latch bolt.
• Lever trim shall have individual heavy-duty compression springs behind rose for lever return and to prevent lever sag. Trim shall be through-bolted with two (2) 10-32 screws coated with thread sealant to provide strength and resistance to loosening. Inner Elevation Door Edge Standard Strike
• All lever designs shall be solid and meet the federal ADA and state disability requirements. Inside levers shall be attached by Allen-head set screw to prevent tampering or vandalism.
• Locksets shall adjust to fit door thickness from 1-3/4” to 2- 1/8”.
• All locksets shall be non-handed and not require field disassembly for re-handing.
• Preparation for door must be non-handed.
Acceptable manufacturer: FALCON LOCK

Specifications
Door Thickness: 1-3/4” to 2-1/8” standard. Thin door adapter kit (A30775-000-00) available for doors thinner than 1-3/4”, please specify door thickness.
Backset: 2-3/4” standard.
Mechanism: Parts constructed of brass or cold formed steel, zinc plated and dichromated for rust resistance. Springs are stainless steel.
Attachment: Lock chassis secured to door by threaded mounting nuts. Completely preassembled outer trim and inner spindle assembly are through-bolted over chassis using (2) 10-32 screws. Adding rose and lever to inner spindle assembly completes installation.
Handing: Locks are non-handed.
Latches: 9/16” bolt projection, UL listed with latch faceplates 2-1/4” x 1-1/8” with square corners standard. 3/4” projection, UL listed latch with 2-3/4” backset also available. Adjustable front standard.
Strikes: 4-7/8” x 1-1/4” ANSI strike with curved lip to meet ANSI A115.2 door frame preparation standard.
Screws: Furnished with combination screws for use in wood or metal doors and frames.
Electrified Functions: Available in 24 VDC .185 AMP.

Certifications
ANSI/BHMA: Meets ANSI/BHMA A156.2, Series 4000, Grade 1.
UL: 3 hour A label. and outer trim shall “bottom out” to prevent door collapse. Roses shall be minimum of 3-1/2” diameter.
Falcon T12 Dummy Lever Lock-D,Q,& A Levers - Barzellock.com

Falcon T12 Dummy Lever Lock-D,Q,& A Levers

from $ 81.00
Falcon T12 Dummy Lever Lock-D,Q,& A Levers - Barzellock.com

Falcon T12 Dummy Lever Lock-D,Q,& A Levers

by Falcon
$ 81.00
Simply put, the Falcon T-Series lock is the most versatile lockset in the industry. This extra heavy duty lock can accept any manufacturer’s cylinder, and the cylinder can easily be removed for quick, easy re-keying. Redesigned with a compression spring behind the cylinder, the T-Series is now stronger than ever and lever sag has been virtually eliminated. This adaptable lock is well suited to either new construction or retrofit use in buildings as varied as multi-family, retail, institutional and government/military.
Dummy trim—Single trim-surface mounted rigid lever.
Features and Benefits
Key-in-lever cylindrical locksets shall be Falcon Lock T Series or equal and meet the following requirements:
• All locks shall meet the new ANSI/BHMA A156.2, Series 4000,Grade 1 for key-in-lever locksets.
• Locksets shall be UL Listed (3 hour A Label).
• Locksets shall be provided standard with Pressure Release™feature. When outside lever is locked, it is not rigid but will move freely without operating the latch bolt.
• Lever trim shall have individual heavy-duty compression springs behind rose for lever return and to prevent lever sag. Trim shall be through-bolted with two (2) 10-32 screws coated with thread sealant to provide strength and resistance to loosening. Inner Elevation Door Edge Standard Strike
• All lever designs shall be solid and meet the federal ADA and state disability requirements. Inside levers shall be attached by Allen-head set screw to prevent tampering or vandalism.
• Locksets shall adjust to fit door thickness from 1-3/4” to 2- 1/8”.
• All locksets shall be non-handed and not require field disassembly for re-handing.
• Preparation for door must be non-handed.
Acceptable manufacturer: FALCON LOCK

Specifications
Door Thickness: 1-3/4” to 2-1/8” standard. Thin door adapter kit (A30775-000-00) available for doors thinner than 1-3/4”, please specify door thickness.
Backset: 2-3/4” standard.
Mechanism: Parts constructed of brass or cold formed steel, zinc plated and dichromated for rust resistance. Springs are stainless steel.
Attachment: Lock chassis secured to door by threaded mounting nuts. Completely preassembled outer trim and inner spindle assembly are through-bolted over chassis using (2) 10-32 screws. Adding rose and lever to inner spindle assembly completes installation.
Handing: Locks are non-handed.
Latches: 9/16” bolt projection, UL listed with latch faceplates 2-1/4” x 1-1/8” with square corners standard. 3/4” projection, UL listed latch with 2-3/4” backset also available. Adjustable front standard.
Strikes: 4-7/8” x 1-1/4” ANSI strike with curved lip to meet ANSI A115.2 door frame preparation standard.
Screws: Furnished with combination screws for use in wood or metal doors and frames.
Electrified Functions: Available in 24 VDC .185 AMP.

Certifications
ANSI/BHMA: Meets ANSI/BHMA A156.2, Series 4000, Grade 1.
UL: 3 hour A label. and outer trim shall “bottom out” to prevent door collapse. Roses shall be minimum of 3-1/2” diameter.
Falcon T301 Privacy Lever Lock-D,Q,& A Levers - Barzellock.com

Falcon T301 Privacy Lever Lock-D,Q,& A Levers

$ 235.00
Falcon T301 Privacy Lever Lock-D,Q,& A Levers - Barzellock.com

Falcon T301 Privacy Lever Lock-D,Q,& A Levers

by Falcon
$ 235.00
Simply put, the Falcon T-Series lock is the most versatile lockset in the industry. This extra heavy duty lock can accept any manufacturer’s cylinder, and the cylinder can easily be removed for quick, easy re-keying. Redesigned with a compression spring behind the cylinder, the T-Series is now stronger than ever and lever sag has been virtually eliminated. This adaptable lock is well suited to either new construction or retrofit use in buildings as varied as multi-family, retail, institutional and government/military.

Privacy lock—Latch bolt by levers. Outside lever locked by push button in inside lever. Rotating inside lever or closing door releases push button. Emergency release in outside lever unlocks door.

Features and Benefits
Key-in-lever cylindrical locksets shall be Falcon Lock T Series or equal and meet the following requirements:
• All locks shall meet the new ANSI/BHMA A156.2, Series 4000,Grade 1 for key-in-lever locksets.
• Locksets shall be UL Listed (3 hour A Label).
• Locksets shall be provided standard with Pressure Release™feature. When outside lever is locked, it is not rigid but will move freely without operating the latch bolt.
• Lever trim shall have individual heavy-duty compression springs behind rose for lever return and to prevent lever sag. Trim shall be through-bolted with two (2) 10-32 screws coated with thread sealant to provide strength and resistance to loosening. Inner Elevation Door Edge Standard Strike
• All lever designs shall be solid and meet the federal ADA and state disability requirements. Inside levers shall be attached by Allen-head set screw to prevent tampering or vandalism.
• Locksets shall adjust to fit door thickness from 1-3/4” to 2- 1/8”.
• All locksets shall be non-handed and not require field disassembly for re-handing.
• Preparation for door must be non-handed.
Acceptable manufacturer: FALCON LOCK

Specifications
Door Thickness: 1-3/4” to 2-1/8” standard. Thin door adapter kit (A30775-000-00) available for doors thinner than 1-3/4”, please specify door thickness.
Backset: 2-3/4” standard.
Mechanism: Parts constructed of brass or cold formed steel, zinc plated and dichromated for rust resistance. Springs are stainless steel.
Attachment: Lock chassis secured to door by threaded mounting nuts. Completely preassembled outer trim and inner spindle assembly are through-bolted over chassis using (2) 10-32 screws. Adding rose and lever to inner spindle assembly completes installation.
Handing: Locks are non-handed.
Latches: 9/16” bolt projection, UL listed with latch faceplates 2-1/4” x 1-1/8” with square corners standard. 3/4” projection, UL listed latch with 2-3/4” backset also available. Adjustable front standard.
Strikes: 4-7/8” x 1-1/4” ANSI strike with curved lip to meet ANSI A115.2 door frame preparation standard.
Screws: Furnished with combination screws for use in wood or metal doors and frames.
Electrified Functions: Available in 24 VDC .185 AMP.

Certifications
ANSI/BHMA: Meets ANSI/BHMA A156.2, Series 4000, Grade 1.
UL: 3 hour A label. and outer trim shall “bottom out” to prevent door collapse. Roses shall be minimum of 3-1/2” diameter.
Falcon T381 Classroom Lever Lock-D,Q,& A Levers - Barzellock.com

Falcon T381 Classroom Lever Lock-D,Q,& A Levers

$ 304.00
Falcon T381 Classroom Lever Lock-D,Q,& A Levers - Barzellock.com

Falcon T381 Classroom Lever Lock-D,Q,& A Levers

by Falcon
$ 304.00
Simply put, the Falcon T-Series lock is the most versatile lockset in the industry. This extra heavy duty lock can accept any manufacturer’s cylinder, and the cylinder can easily be removed for quick, easy re-keying. Redesigned with a compression spring behind the cylinder, the T-Series is now stronger than ever and lever sag has been virtually eliminated. This adaptable lock is well suited to either new construction or retrofit use in buildings as varied as multi-family, retail, institutional and government/military.
Classroom security lock—Deadlocking latch bolt by levers from either side except when outside lever is locked by key from inside. Outside key only retracts latch. Outside lever is locked and unlocked only by inside key
Features and Benefits
Key-in-lever cylindrical locksets shall be Falcon Lock T Series or equal and meet the following requirements:
• All locks shall meet the new ANSI/BHMA A156.2, Series 4000,Grade 1 for key-in-lever locksets.
• Locksets shall be UL Listed (3 hour A Label).
• Locksets shall be provided standard with Pressure Release™feature. When outside lever is locked, it is not rigid but will move freely without operating the latch bolt.
• Lever trim shall have individual heavy-duty compression springs behind rose for lever return and to prevent lever sag. Trim shall be through-bolted with two (2) 10-32 screws coated with thread sealant to provide strength and resistance to loosening. Inner Elevation Door Edge Standard Strike
• All lever designs shall be solid and meet the federal ADA and state disability requirements. Inside levers shall be attached by Allen-head set screw to prevent tampering or vandalism.
• Locksets shall adjust to fit door thickness from 1-3/4” to 2- 1/8”.
• All locksets shall be non-handed and not require field disassembly for re-handing.
• Preparation for door must be non-handed.
Acceptable manufacturer: FALCON LOCK

Specifications
Door Thickness: 1-3/4” to 2-1/8” standard. Thin door adapter kit (A30775-000-00) available for doors thinner than 1-3/4”, please specify door thickness.
Backset: 2-3/4” standard.
Mechanism: Parts constructed of brass or cold formed steel, zinc plated and dichromated for rust resistance. Springs are stainless steel.
Attachment: Lock chassis secured to door by threaded mounting nuts. Completely preassembled outer trim and inner spindle assembly are through-bolted over chassis using (2) 10-32 screws. Adding rose and lever to inner spindle assembly completes installation.
Handing: Locks are non-handed.
Latches: 9/16” bolt projection, UL listed with latch faceplates 2-1/4” x 1-1/8” with square corners standard. 3/4” projection, UL listed latch with 2-3/4” backset also available. Adjustable front standard.
Strikes: 4-7/8” x 1-1/4” ANSI strike with curved lip to meet ANSI A115.2 door frame preparation standard.
Screws: Furnished with combination screws for use in wood or metal doors and frames.
Electrified Functions: Available in 24 VDC .185 AMP.

Certifications
ANSI/BHMA: Meets ANSI/BHMA A156.2, Series 4000, Grade 1.
UL: 3 hour A label. and outer trim shall “bottom out” to prevent door collapse. Roses shall be minimum of 3-1/2” diameter.
Falcon T411 Asylum Lever Lock-D,Q,& A Levers - Barzellock.com

Falcon T411 Asylum Lever Lock-D,Q,& A Levers

$ 304.00
Falcon T411 Asylum Lever Lock-D,Q,& A Levers - Barzellock.com

Falcon T411 Asylum Lever Lock-D,Q,& A Levers

by Falcon
$ 304.00
Simply put, the Falcon T-Series lock is the most versatile lockset in the industry. This extra heavy duty lock can accept any manufacturer’s cylinder, and the cylinder can easily be removed for quick, easy re-keying. Redesigned with a compression spring behind the cylinder, the T-Series is now stronger than ever and lever sag has been virtually eliminated. This adaptable lock is well suited to either new construction or retrofit use in buildings as varied as multi-family, retail, institutional and government/military.
Asylum lock—Deadlocking latch bolt operated by key in lever from either side. Both levers always inoperable.
Features and Benefits
Key-in-lever cylindrical locksets shall be Falcon Lock T Series or equal and meet the following requirements:
• All locks shall meet the new ANSI/BHMA A156.2, Series 4000,Grade 1 for key-in-lever locksets.
• Locksets shall be UL Listed (3 hour A Label).
• Locksets shall be provided standard with Pressure Release™feature. When outside lever is locked, it is not rigid but will move freely without operating the latch bolt.
• Lever trim shall have individual heavy-duty compression springs behind rose for lever return and to prevent lever sag. Trim shall be through-bolted with two (2) 10-32 screws coated with thread sealant to provide strength and resistance to loosening. Inner Elevation Door Edge Standard Strike
• All lever designs shall be solid and meet the federal ADA and state disability requirements. Inside levers shall be attached by Allen-head set screw to prevent tampering or vandalism.
• Locksets shall adjust to fit door thickness from 1-3/4” to 2- 1/8”.
• All locksets shall be non-handed and not require field disassembly for re-handing.
• Preparation for door must be non-handed.
Acceptable manufacturer: FALCON LOCK

Specifications
Door Thickness: 1-3/4” to 2-1/8” standard. Thin door adapter kit (A30775-000-00) available for doors thinner than 1-3/4”, please specify door thickness.
Backset: 2-3/4” standard.
Mechanism: Parts constructed of brass or cold formed steel, zinc plated and dichromated for rust resistance. Springs are stainless steel.
Attachment: Lock chassis secured to door by threaded mounting nuts. Completely preassembled outer trim and inner spindle assembly are through-bolted over chassis using (2) 10-32 screws. Adding rose and lever to inner spindle assembly completes installation.
Handing: Locks are non-handed.
Latches: 9/16” bolt projection, UL listed with latch faceplates 2-1/4” x 1-1/8” with square corners standard. 3/4” projection, UL listed latch with 2-3/4” backset also available. Adjustable front standard.
Strikes: 4-7/8” x 1-1/4” ANSI strike with curved lip to meet ANSI A115.2 door frame preparation standard.
Screws: Furnished with combination screws for use in wood or metal doors and frames.
Electrified Functions: Available in 24 VDC .185 AMP.

Certifications
ANSI/BHMA: Meets ANSI/BHMA A156.2, Series 4000, Grade 1.
UL: 3 hour A label. and outer trim shall “bottom out” to prevent door collapse. Roses shall be minimum of 3-1/2” diameter.
Falcon T501 Entry Lever Lock-D,Q,& A Levers - Barzellock.com

Falcon T501 Entry Lever Lock-D,Q,& A Levers

$ 262.00
Falcon T501 Entry Lever Lock-D,Q,& A Levers - Barzellock.com

Falcon T501 Entry Lever Lock-D,Q,& A Levers

by Falcon
$ 262.00
Simply put, the Falcon T-Series lock is the most versatile lockset in the industry. This extra heavy duty lock can accept any manufacturer’s cylinder, and the cylinder can easily be removed for quick, easy re-keying. Redesigned with a compression spring behind the cylinder, the T-Series is now stronger than ever and lever sag has been virtually eliminated. This adaptable lock is well suited to either new construction or retrofit use in buildings as varied as multi-family, retail, institutional and government/military.
Entry lock—Push button locking. Button on inside locks outside lever until unlocked by key or by rotating inside lever. Inside lever always free. Deadlocking latch bolt.
Features and Benefits
Key-in-lever cylindrical locksets shall be Falcon Lock T Series or equal and meet the following requirements:
• All locks shall meet the new ANSI/BHMA A156.2, Series 4000,Grade 1 for key-in-lever locksets.
• Locksets shall be UL Listed (3 hour A Label).
• Locksets shall be provided standard with Pressure Release™feature. When outside lever is locked, it is not rigid but will move freely without operating the latch bolt.
• Lever trim shall have individual heavy-duty compression springs behind rose for lever return and to prevent lever sag. Trim shall be through-bolted with two (2) 10-32 screws coated with thread sealant to provide strength and resistance to loosening. Inner Elevation Door Edge Standard Strike
• All lever designs shall be solid and meet the federal ADA and state disability requirements. Inside levers shall be attached by Allen-head set screw to prevent tampering or vandalism.
• Locksets shall adjust to fit door thickness from 1-3/4” to 2- 1/8”.
• All locksets shall be non-handed and not require field disassembly for re-handing.
• Preparation for door must be non-handed.
Acceptable manufacturer: FALCON LOCK

Specifications
Door Thickness: 1-3/4” to 2-1/8” standard. Thin door adapter kit (A30775-000-00) available for doors thinner than 1-3/4”, please specify door thickness.
Backset: 2-3/4” standard.
Mechanism: Parts constructed of brass or cold formed steel, zinc plated and dichromated for rust resistance. Springs are stainless steel.
Attachment: Lock chassis secured to door by threaded mounting nuts. Completely preassembled outer trim and inner spindle assembly are through-bolted over chassis using (2) 10-32 screws. Adding rose and lever to inner spindle assembly completes installation.
Handing: Locks are non-handed.
Latches: 9/16” bolt projection, UL listed with latch faceplates 2-1/4” x 1-1/8” with square corners standard. 3/4” projection, UL listed latch with 2-3/4” backset also available. Adjustable front standard.
Strikes: 4-7/8” x 1-1/4” ANSI strike with curved lip to meet ANSI A115.2 door frame preparation standard.
Screws: Furnished with combination screws for use in wood or metal doors and frames.
Electrified Functions: Available in 24 VDC .185 AMP.

Certifications
ANSI/BHMA: Meets ANSI/BHMA A156.2, Series 4000, Grade 1.
UL: 3 hour A label. and outer trim shall “bottom out” to prevent door collapse. Roses shall be minimum of 3-1/2” diameter.
Falcon T511 Entry/Office Lever Lock-D,Q,& A Levers - Barzellock.com

Falcon T511 Entry/Office Lever Lock-D,Q,& A Levers

$ 262.00
Falcon T511 Entry/Office Lever Lock-D,Q,& A Levers - Barzellock.com

Falcon T511 Entry/Office Lever Lock-D,Q,& A Levers

by Falcon
$ 262.00
Simply put, the Falcon T-Series lock is the most versatile lockset in the industry. This extra heavy duty lock can accept any manufacturer’s cylinder, and the cylinder can easily be removed for quick, easy re-keying. Redesigned with a compression spring behind the cylinder, the T-Series is now stronger than ever and lever sag has been virtually eliminated. This adaptable lock is well suited to either new construction or retrofit use in buildings as varied as multi-family, retail, institutional and government/military.
Entry/office lock—Turn/push button locking. Pushing and turning button locks outside lever requiring use of key until button is manually unlocked. Push button locking. Pushing button locks outside lever until unlocked by key or by rotating inside lever. Inside lever always free. Deadlocking latch bolt
Features and Benefits
Key-in-lever cylindrical locksets shall be Falcon Lock T Series or equal and meet the following requirements:
• All locks shall meet the new ANSI/BHMA A156.2, Series 4000,Grade 1 for key-in-lever locksets.
• Locksets shall be UL Listed (3 hour A Label).
• Locksets shall be provided standard with Pressure Release™feature. When outside lever is locked, it is not rigid but will move freely without operating the latch bolt.
• Lever trim shall have individual heavy-duty compression springs behind rose for lever return and to prevent lever sag. Trim shall be through-bolted with two (2) 10-32 screws coated with thread sealant to provide strength and resistance to loosening. Inner Elevation Door Edge Standard Strike
• All lever designs shall be solid and meet the federal ADA and state disability requirements. Inside levers shall be attached by Allen-head set screw to prevent tampering or vandalism.
• Locksets shall adjust to fit door thickness from 1-3/4” to 2- 1/8”.
• All locksets shall be non-handed and not require field disassembly for re-handing.
• Preparation for door must be non-handed.
Acceptable manufacturer: FALCON LOCK

Specifications
Door Thickness: 1-3/4” to 2-1/8” standard. Thin door adapter kit (A30775-000-00) available for doors thinner than 1-3/4”, please specify door thickness.
Backset: 2-3/4” standard.
Mechanism: Parts constructed of brass or cold formed steel, zinc plated and dichromated for rust resistance. Springs are stainless steel.
Attachment: Lock chassis secured to door by threaded mounting nuts. Completely preassembled outer trim and inner spindle assembly are through-bolted over chassis using (2) 10-32 screws. Adding rose and lever to inner spindle assembly completes installation.
Handing: Locks are non-handed.
Latches: 9/16” bolt projection, UL listed with latch faceplates 2-1/4” x 1-1/8” with square corners standard. 3/4” projection, UL listed latch with 2-3/4” backset also available. Adjustable front standard.
Strikes: 4-7/8” x 1-1/4” ANSI strike with curved lip to meet ANSI A115.2 door frame preparation standard.
Screws: Furnished with combination screws for use in wood or metal doors and frames.
Electrified Functions: Available in 24 VDC .185 AMP.

Certifications
ANSI/BHMA: Meets ANSI/BHMA A156.2, Series 4000, Grade 1.
UL: 3 hour A label. and outer trim shall “bottom out” to prevent door collapse. Roses shall be minimum of 3-1/2” diameter.
Falcon T521 Office Lever Lock-D,Q,& A Levers - Barzellock.com

Falcon T521 Office Lever Lock-D,Q,& A Levers

$ 262.00
Falcon T521 Office Lever Lock-D,Q,& A Levers - Barzellock.com

Falcon T521 Office Lever Lock-D,Q,& A Levers

by Falcon
$ 262.00
Simply put, the Falcon T-Series lock is the most versatile lockset in the industry. This extra heavy duty lock can accept any manufacturer’s cylinder, and the cylinder can easily be removed for quick, easy re-keying. Redesigned with a compression spring behind the cylinder, the T-Series is now stronger than ever and lever sag has been virtually eliminated. This adaptable lock is well suited to either new construction or retrofit use in buildings as varied as multi-family, retail, institutional and government/military.
Office lock—Turn button locking. Turning button locks outside lever requiring use of key until button is manually unlocked. Inside lever always free. Deadlocking latch bolt.
Features and Benefits
Key-in-lever cylindrical locksets shall be Falcon Lock T Series or equal and meet the following requirements:
• All locks shall meet the new ANSI/BHMA A156.2, Series 4000,Grade 1 for key-in-lever locksets.
• Locksets shall be UL Listed (3 hour A Label).
• Locksets shall be provided standard with Pressure Release™feature. When outside lever is locked, it is not rigid but will move freely without operating the latch bolt.
• Lever trim shall have individual heavy-duty compression springs behind rose for lever return and to prevent lever sag. Trim shall be through-bolted with two (2) 10-32 screws coated with thread sealant to provide strength and resistance to loosening. Inner Elevation Door Edge Standard Strike
• All lever designs shall be solid and meet the federal ADA and state disability requirements. Inside levers shall be attached by Allen-head set screw to prevent tampering or vandalism.
• Locksets shall adjust to fit door thickness from 1-3/4” to 2- 1/8”.
• All locksets shall be non-handed and not require field disassembly for re-handing.
• Preparation for door must be non-handed.
Acceptable manufacturer: FALCON LOCK

Specifications
Door Thickness: 1-3/4” to 2-1/8” standard. Thin door adapter kit (A30775-000-00) available for doors thinner than 1-3/4”, please specify door thickness.
Backset: 2-3/4” standard.
Mechanism: Parts constructed of brass or cold formed steel, zinc plated and dichromated for rust resistance. Springs are stainless steel.
Attachment: Lock chassis secured to door by threaded mounting nuts. Completely preassembled outer trim and inner spindle assembly are through-bolted over chassis using (2) 10-32 screws. Adding rose and lever to inner spindle assembly completes installation.
Handing: Locks are non-handed.
Latches: 9/16” bolt projection, UL listed with latch faceplates 2-1/4” x 1-1/8” with square corners standard. 3/4” projection, UL listed latch with 2-3/4” backset also available. Adjustable front standard.
Strikes: 4-7/8” x 1-1/4” ANSI strike with curved lip to meet ANSI A115.2 door frame preparation standard.
Screws: Furnished with combination screws for use in wood or metal doors and frames.
Electrified Functions: Available in 24 VDC .185 AMP.

Certifications
ANSI/BHMA: Meets ANSI/BHMA A156.2, Series 4000, Grade 1.
UL: 3 hour A label. and outer trim shall “bottom out” to prevent door collapse. Roses shall be minimum of 3-1/2” diameter.
Falcon T561 Office Classroom Lever Lock-D,Q,& A Levers - Barzellock.com

Falcon T561 Office Classroom Lever Lock-D,Q,& A Levers

$ 262.00
Falcon T561 Office Classroom Lever Lock-D,Q,& A Levers - Barzellock.com

Falcon T561 Office Classroom Lever Lock-D,Q,& A Levers

by Falcon
$ 262.00
Simply put, the Falcon T-Series lock is the most versatile lockset in the industry. This extra heavy duty lock can accept any manufacturer’s cylinder, and the cylinder can easily be removed for quick, easy re-keying. Redesigned with a compression spring behind the cylinder, the T-Series is now stronger than ever and lever sag has been virtually eliminated. This adaptable lock is well suited to either new construction or retrofit use in buildings as varied as multi-family, retail, institutional and government/military.
Classroom lock—Deadlocking latch bolt by levers. Outside lever is locked by key in outside lever.Inside lever is always free.
Features and Benefits
Key-in-lever cylindrical locksets shall be Falcon Lock T Series or equal and meet the following requirements:
• All locks shall meet the new ANSI/BHMA A156.2, Series 4000,Grade 1 for key-in-lever locksets.
• Locksets shall be UL Listed (3 hour A Label).
• Locksets shall be provided standard with Pressure Release™feature. When outside lever is locked, it is not rigid but will move freely without operating the latch bolt.
• Lever trim shall have individual heavy-duty compression springs behind rose for lever return and to prevent lever sag. Trim shall be through-bolted with two (2) 10-32 screws coated with thread sealant to provide strength and resistance to loosening. Inner Elevation Door Edge Standard Strike
• All lever designs shall be solid and meet the federal ADA and state disability requirements. Inside levers shall be attached by Allen-head set screw to prevent tampering or vandalism.
• Locksets shall adjust to fit door thickness from 1-3/4” to 2- 1/8”.
• All locksets shall be non-handed and not require field disassembly for re-handing.
• Preparation for door must be non-handed.
Acceptable manufacturer: FALCON LOCK

Specifications
Door Thickness: 1-3/4” to 2-1/8” standard. Thin door adapter kit (A30775-000-00) available for doors thinner than 1-3/4”, please specify door thickness.
Backset: 2-3/4” standard.
Mechanism: Parts constructed of brass or cold formed steel, zinc plated and dichromated for rust resistance. Springs are stainless steel.
Attachment: Lock chassis secured to door by threaded mounting nuts. Completely preassembled outer trim and inner spindle assembly are through-bolted over chassis using (2) 10-32 screws. Adding rose and lever to inner spindle assembly completes installation.
Handing: Locks are non-handed.
Latches: 9/16” bolt projection, UL listed with latch faceplates 2-1/4” x 1-1/8” with square corners standard. 3/4” projection, UL listed latch with 2-3/4” backset also available. Adjustable front standard.
Strikes: 4-7/8” x 1-1/4” ANSI strike with curved lip to meet ANSI A115.2 door frame preparation standard.
Screws: Furnished with combination screws for use in wood or metal doors and frames.
Electrified Functions: Available in 24 VDC .185 AMP.

Certifications
ANSI/BHMA: Meets ANSI/BHMA A156.2, Series 4000, Grade 1.
UL: 3 hour A label. and outer trim shall “bottom out” to prevent door collapse. Roses shall be minimum of 3-1/2” diameter.
